Turnigy EDGE-540 Operation instructions

CAUTION : this plane is not a toy!
Before use , please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
●Assemble this kit only in places out of children’s reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model’s assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
performance to full extent .
Radio:6channels 5-6servos;
Flying Weight:3800g;Wing Span:70.8in/1800mm;
Wing Area:62sq.dm;
Engine:26-30CC GAS;Length:66.1in/1680mm;
P1

Connect the aileron and main
wing with horns.
KIT CONTENTS
MAIN WINGS
AB
Glue
P2

Cut away covering film for
the servo.
Measure the length of the
extention .
Pull out the extention from
the rib of the main wing.
P3

Install the tri-horn and serv
o
arm with pushrod as shown.
Find out the holes in
each sides of fuselage,
then cut the film.
Pull out the servo extention
as shown.
Nylon
Screw
P4

Install the wheel with
screw and collars as shown.
Fixup the wheel to the
landing gear by screw.
Use two TP screws to fix
the wheel cover to the
landing gear.
MAIN LANDING GEAR
P5

Install the main landing
gear on the bottom of the
fuselage.
Fixup 3 screws as shown.
Connect the elevator and
stabilizer with horns and
U steel wire.
Connect the rudder and the
vertifin with horns.
ELEVATOR AND RUDDER
P6

Find and cut the hole for
elevator and also the
servo holes.
Cut away the film along
the edges, and glow the
stabilizer to the fuselage.
Cut the rudder film along
the edges, and glue the
rudder to the fuselage.
P7

Securely glue up and
soaked up the hinge with
AB glue.
Glue the rudder to the
fuselage.
Install the elevator servo
as shown.
P8

Tighten the second loop
through the brass swage
tube.
Crimp the brass tube with
a crimping tool or pliers.
Connect the parts as shown.
P9

Connect the control horn
to the linkage of the
servo.
Bend the tail landing
gear to fit for the rudder
and insert it into the
rudder.
TAIL WHEEL
Rudder
servo arm
Push
rods
P10

Glow the tail landing gear
to the rudder securely.
Install the tail wheel,
and fasten the presser
of the tail wheel to the
stabilizer by screws.
Place the hatch.
Use two screws to secure
it firmly.
P11

Install the ball linkege
connector.Calculate the
length proportion between
the servo arm and the
horn.Rotate the ball
linkage connector to an
appropriate position.
Gather the engine and spare
parts as shown.
ENGINE
Another method for the rudder
servo installation
P12

The finished picture as shown.
Install the DLE 30CC as shown.
Pay attention to:you have DLE and MLD for choice.
P13

P14

CG POSITION & CONTROL THROWS
P15

FINISHED PICTURE
P16
