Turnigy SU-26 EP Operation instructions

CAUTION : this plane is not a toy!
Before use , please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
●Assemble this kit only in places out of children’s reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model’s assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:1200g;
Wing Span:48.3in/1228mm;
Wing Area:30sq.dm;
Outer Runner Brushless Motors;
Length:45.7in/1160mm;
Radio:6channels 4servos;
performance to full extent .
P.1

Glue the aileron.
Cut the servo holes on the
bottom of the main wings.
Put the servo into the cutout,
and pull the servo extention
out from the hole.
MAIN WING
P.2

Screw the hors onto the
ailerons. Link the servos
with L locks as shown.
Install the elevator servo to
the fuselage.
Cut off the film for the
elevator assmble to the
fuselage.
Line the position, remove the
cover, and glow the stabilizer
to the fuselage.
ELEVATOR
P.3

Glue the elevator to the
stabilizer by AB Glue.
Assemble the elevator servo
in the fuselage as shown.
Screw the horns onto the
elevator. Link the servos with
L locks as shown.
AB
Glue
Carbon
Tailwheel
P.4

Line the position, remove the
cover, and glow the rudder to
the fuselage.
Screw the horns onto the
stabilizer,link the steeling
wire to the servo in fuselage.
The other side as shown.
RUDDER
P.5

The finished photo as shown.
Install the motor to the
firewall as shown.
TAILWHEEL
MOTOR
P.6

Tie the motor with nylon belt
provided.
Install the ESC and tie it
with nylon belt provided.
Install the switch as shown.
P.7

Join the main wings with
carbon joiner.
Pull the servo extention
through the fuselage.
Screw the main wings by nylon
screws provided.
Assemble the canopy and
screw it .
FUSELAGE
CANOPY
P.8

Install the wheels and wheel
covers to the landing gear.
Fixup the mian landing gear
to the fuselage by screws.
Assemble the cowling
as shown.
COWLING
MAIN LANDING GEAR
Carbon landing
gear
P.9

Assemble the propller
as shown.
Assemble the spinner
as shown.
ADJUSTMENT
P.10

CG & SERFACE MOVEMENT
P.11

FINISHED PHOTO
P.12
