Turnigy Turbo Raven Operation instructions

1
Wing Span: 62.2in/1580mm;
Engine:2cycle 60,4cycle91;
Wing area:41sq.dm;
Radio:4channels 5sevors;
Length:56.7in/1440mm;
Flying Weight:3000g;
Glow & electric RC model;
CAUTION:This plane is not a toy.
Before use,please carefully read this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
Performance to full extent.
●Assemble this kit only in places out of children’s reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model’s assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.

2
Cut away covering film for
the servo on the botom of the main
wing ..
Connect the aileron and
the main wing by hinges.
Be sure to apply instant
type glue to both sides
of each hinges.
Insert the servo and pull out the servo extention line
from prepared holes .
Conect the tri-horns and servo with pushrod as shown.
Find out the holes on each
sides of the fuselage as
shown.

3
Attach the main wing to the fuselage
by bolt.
Connect the main wings and
the fuselage with joiner.
Use two 5mm screws of each
sides to ensure the wings
fixed upto the fuselage.
Find out the holes on each sides of
the tail fuselage.
Insert the stabilizer into the prepared hole.
Measure the right position
and remove the film from
the stabilizer.

4
Glue the stablilizer to
the fuselage.
Connect the aileron and the
stabilizer by hings, and
glue them.
Bent the piano wire as shown.
Insert the tail wheel
landing gear into the
rudder.Then glue it.

5
Apply instant type glue
to both sides of each
hinges of the rudder.
Screw four TP screws to
fix up the tail wheel on
the tail of the fuselage.
Link the elevator servo to
the elevator with pushrod.
Repeat above steps for other side
elevator assembly.

6
Loop the cable back through the brass
swage tube as shown.
Crimp the brass tube with a crimping
tool or pliers.
Rudder servo assmble on rudder view.
Fixup the tri-horns on both sides of the
rudder,then link the collet .
Rudder servo assemble in fuselage view.
Fixup the two collets with servo horn
as shown.

7
Screw the wheel to the
landing gear.
Be assured that the screw
is fixed up.
Install the wheel cover,
and fix it up to landing
gear with TP screw.
Drill three holes on the landing
gear as shown.
Fixup the landing gear
strut to fuselage with 3
bolts.

8
Install the throttle servo and the
throttle rod as shown.
FULE TANK INSTALLATION.
Install the fuel tank into
the fuselage, and fixup it
with belt.
Install the engine mount
on both sides with four
3mm screws.

9
Use the ruler to measure
the length from firewall
to airscrew, which should
be 118 MM.
Fixup the canopy with TP
screw on each side of the
canopy.
Install the cowling with
four TP screws.
Install the motor with the separate part provided.
