Turnstiles mWing User manual

Operating Instructions
Pedestrian gate with swing wings
mWing
Doc.ID: 5817,0034EN
Version 01USA
mWing
mWing mWing
www.TURNSTILES.us | [email protected] | 303-670-1099

2
mWing
www.TURNSTILES.us | [email protected] | 303-670-1099

3
mWing
Contents
Contents
1 Notices on the document 7
1.1 Purpose and contents of this operating instructions 7
1.2 Reading and storing the operating instructions 7
1.3 Non-observance of the operating instructions 8
1.4 Symbols and illustrations used in the operating instructions 8
1.4.1 Warning notes and notices 8
2 Safety 10
2.1 Intended use 10
2.2 Changes and modifications 10
2.3 Target groups 11
2.3.1 Operator and its responsibility 11
2.3.2 Personnel - activities and qualifications 12
2.4 Personal protective equipment 13
2.5 Symbols on the device 14
2.6 For your safety 14
2.7 To protect the environment 15
2.8 Emergency opening of the pedestrian gate 15
3 Technical data 16
3.1 Dimensions and design 16
3.1.1 mWing 16
3.2 Clearances and line configuration to be maintained 18
3.3 Electrical connection 19
3.4 Operating conditions 19
3.5 Emissions 19
3.6 Control unit MGCplus 20
4 Design and function 21
4.1 Design 21
4.2 Definitions 23
4.2.1 A-module 24
4.2.2 B-module 25
4.2.3 C-module 26
4.3 Function 27
www.TURNSTILES.us | [email protected] | 303-670-1099

4
mWing
Contents
5 Receipt of goods, transport and storage 28
5.1 Receipt of goods 28
5.2 Safety during transport 28
5.3 Transport 29
5.4 Storage 30
6 Unpacking, scope of delivery and identification 31
6.1 Unpacking 31
6.2 Scope of delivery 32
6.3 Identification 33
6.3.1 Type plate 33
7 Installation and mounting 34
7.1 Safety during installation and mounting 34
7.2 Mounting variants 35
7.3 Steps to be taken 37
7.4 Building foundation and laying empty conduits 37
7.4.1 Requirements foundation 37
7.4.2 Requirements empty conduits 38
7.4.3 Building foundation and laying empty conduits 38
7.4.4 Foundation plan and reinforcement 39
7.4.5 Distances depending on panel heights and passage
widths 41
7.4.6 Empty conduit plan 43
7.5 Base frame FURA100 44
7.6 Base plate FlowMotion 44
7.7 Base frame FURA102 45
7.8 Aligning the pedestrian gate 46
7.9 Preparing mTripod for mounting and electrical connection 46
7.10 Mounting mWing 49
7.10.1 Mounting variant 1 (direct mounting) 49
7.10.2 Mounting variant 2 52
7.10.3 Mounting variant 3 57
7.10.4 Mounting variant 4 61
7.11 Assembling the mWing 64
7.12 Mounting swing wing 66
7.13 Dismantling and mounting the cover 68
7.14 Checking the mounting 69
www.TURNSTILES.us | [email protected] | 303-670-1099

5
mWing
Contents
8 Electrical connection 70
8.1 Safety during electrical connection 70
8.2 Installing electrical protective devices 71
8.3 Connecting the mains cable and the mains connection cable 72
8.3.1 Wire and cable cross-sections, stripping lines
and cores 73
8.3.2 Overview of connection of mains cables and mains
connection cables 74
8.3.3 Connecting module with master connection side 76
8.3.4 Connecting module with slave connection side 76
8.4 Connect customer's control lines 77
8.4.1 Connecting emergency opening contacts 77
8.5 Installing and connecting customer access-control devices 77
8.6 Checking the electrical connections 78
9 Commissioning 79
9.1 Safety during commissioning 79
9.2 Putting the pedestrian gate into operation 79
9.3 Switching the pedestrian gate on and off 80
9.4 Parameterising the pedestrian gate 81
10 Log book 81
11 Operation 82
12 Cleaning and maintenance 83
12.1 Cleaning the pedestrian gate 83
12.2 Maintenance schedule 83
13 Corrective action 84
14 Spare parts and repair 84
15 Customer service 84
16 Decommissioning 85
16.1 Safety during decommissioning 85
16.2 Taking the pedestrian gate out of service 85
17 Dismounting and disposal 86
17.1 Safety during dismounting and disposal 86
17.2 Dismounting and disposal of pedestrian gate 86
www.TURNSTILES.us | [email protected] | 303-670-1099

6
mWing
18 EU-Declaration of Conformity 87
Index 89
www.TURNSTILES.us | [email protected] | 303-670-1099

7
mWing
Notices on the document
1 Notices on the document
1.1 Purpose and contents of this operating instructions
These operating instructions provide all the information required for the
product in the various phases of its life cycle.
This operating instructions contains the following information: Design and
function, transport and storage, unpacking and delivery, installation and
mounting, electrical connection, commissioning, operation, cleaning and
maintenance, decommissioning, dismounting and disposal.
IMPORTANT!
For parameterisation see separate document "Description of
control unit MGC for mWing (Doc.ID: 5817,0033)".
IMPORTANT!
The swing wings are available in different heights. In the figures,
the swing wings are mainly shown in the standard height.
1.2 Reading and storing the operating instructions
Prerequisite for secure work is compliance with all indicated safety notes,
warning notes and instructions. In addition, the local accident prevention
regulations, general safety regulations and local environmental regulations
applicable to the area of application of the product must be observed.
Carefully read these operating instructions before starting any work! The
operating instructions are a product component and must be kept in direct
proximity of the product, well accessible to the personnel at all times.
When passing the product on to third parties, these operating instructions
must also be handed over.
www.TURNSTILES.us | [email protected] | 303-670-1099

8
mWing
Notices on the document
1.3 Non-observance of the operating instructions
Magnetic declines all liability for personal injury and material damage caused
by not observing the operating instructions.
This applies in particular to damage caused by:
› Improper use
› Use of non-qualified personnel
› Use of non-approved components
› Arbitrary modifications
› Inappropriate mounting and installation
› Incorrect operation
› Defective or unperformed maintenance and repairs
› Use of non-approved spare parts
› Operating a defective product
1.4 Symbols and illustrations used in the operating instructions
1.4.1 Warning notes and notices
Warning notes are characterised by pictograms in these instructions. A warning
note starts with a signal word that expresses the extent of the hazard.
It is absolutely essential to observe the warning notes and to proceed with
caution in order to prevent accidents as well as bodily injuries and property
damage.
Warning Notes
DANGER
The signal word DANGER points to an immediately dangerous
situation, which leads to death or severe injuries if it is not
avoided.
WARNING
The signal word WARNING points to a potentially dangerous
situation, which can lead to death or severe injuries if it is not
avoided.
www.TURNSTILES.us | [email protected] | 303-670-1099

9
mWing
Notices on the document
CAUTION
The signal word CAUTION points to a potentially dangerous
situation, which can lead to minor injuries if it is not avoided.
NOTICE
The signal word NOTICE points to a potentially harmful situation,
which leads to property damage if it is not avoided.
Notes and recommendations
IMPORTANT!
The signal word IMPORTANT highlights useful notes and
recommendations as well as information for an efficient and
trouble-free operation.
www.TURNSTILES.us | [email protected] | 303-670-1099

10
mWing
Safety
2
2.1
Safety
Intended use
The Magnetic pedestrian gate mWing is designed for the control of persons
entering or leaving an area with restricted access.
The pedestrian gate is intended for passage of persons who can pass the
pedestrian gate safely, speedily and without any help. Separate means of
access must be provided for persons who cannot pass through the pedestrian
gate safely, quickly or without assistance, such as small children, elderly people
or people with disabilities. Children under 8 years of age may only pass
through the pedestrian gate under the supervision of an adult.
The pedestrian gate may only be mounted on non-flammable floors.
The pedestrian gate may only be operated within the temperature range
indicated on the type plate.
Misuse
Any use differing from or beyond this is improper use. Manufacturer is not
liable for any resulting personal injury or damage to property.
For example, the following applications are regarded as improper use:
› Use of the pedestrian gate by unaccompanied children under 8 years of age.
› Use of the pedestrian gate by persons who cannot pass the pedestrian gate
safely, quickly or without assistance.
› Use of the pedestrian gate without released passage. This means that the
swing wings are forced to rotate.
2.2
› Mounting of the pedestrian gate on flammable ground.
Changes and modifications
Modifications and conversions to the product, to an attachment or to one of
the components can lead to unforeseen dangers. Written approval must be
obtained before any technical modifications or alterations are made to the
product or any of its components.
www.TURNSTILES.us | [email protected] | 303-670-1099

11
mWing
Safety
2.3 Target groups
2.3.1 Operator and its responsibility
The operator must comply with the statutory obligations regarding work safety.
In addition to the safety instructions and warning notes in this operating
instructions, the valid safety, accident prevention and environmental
protection regulations must be observed.
In particular, the operator must:
› determine additional danger in a danger analysis
› implement the necessary behavioural requirements in work instructions for
operation with the product at the operating location
› regularly verify throughout the product time of use that the work
instructions drawn up by him comply with the current state of the
regulations
› adapt the working instructions to any new provisions, standards and usage
conditions - where required.
› clearly regulate the responsibilities for all work on the product and with the
product such as mounting, commissioning, operation, cleaning,
maintenance, etc.
› ensure that personal protective equipment is worn
› ensures that all employees who work with the product or on the product
have read and understood the operating instructions.
Furthermore, the operator must train personnel regarding the use of the
product at regular intervals and provide information on possible dangers.
Furthermore, the operator is responsible for:
› the product is always in perfect technical condition.
› the product is maintained at specified maintenance intervals
› the product is only operated within the permitted temperature range.
The operator is also responsible for ensuring that the danger area of the
product cannot be accessed by any unauthorised persons under any
circumstances.
www.TURNSTILES.us | [email protected] | 303-670-1099

12
mWing
Safety
2.3.2 Personnel - activities and qualifications
Only authorised, trained and sufficiently qualified personnel may work on and
with the product. The personnel must know and have understood the
operating instructions and the required operating procedures.
Designation Qualification
Transport equipment operator › Has professional experience as a transport equipment
operator or warehouse and transport worker.
› Has a valid driving licence for the required industrial
truck, e.g. forklift.
› Knows the necessary regulations.
› Can evaluate the work assigned to him, recognise
possible dangers and take appropriate safety measures.
Technician › Has completed training as a systems mechanic,
machinery technician, installation mechanic, installation
technician or has comparable technical training.
› Has completed training as an electrical safety expert.
› Has additional knowledge and experience.
› Knows the relevant technical terms and regulations.
› Can evaluate the work assigned to him, recognise
possible dangers and take appropriate safety measures.
Manufacturer service expert › Meets all the requirements of the technician.
› Trained and authorised by Manufacturer.
Operator › Trained by the operator.
Table 1: Qualifications of personnel
www.TURNSTILES.us | [email protected] | 303-670-1099

13
mWing
Safety
Task Transport
equipment
operator
Technician Magnetic
service expert
Operator
Transporting X X – –
Unpacking X X X –
Laying the foundation – X – –
Mounting – X X –
Electrical connection – X X –
Parameterisation – – X –
Commissioning 1) – – X –
Operating – X X X
Cleaning – X X X
Servicing – X X –
Troubleshooting – X X –
Repairing – X X –
Decommissioning – X X –
Dismounting – X X –
Disposing – X – –
2.4
1) According to the supplied log book
Table 2: Activities and qualifications
Personal protective equipment
It is necessary to wear personal protective equipment when dealing with
the product so as to minimize health hazards.
Before carrying out any work, properly dress in the necessary protective
equipment such as work clothes, protective gloves, safety shoes and wear
during work.
www.TURNSTILES.us | [email protected] | 303-670-1099

14
mWing
Safety
2.5 Symbols on the device
Warning of electric voltage!
The warning sign indicates dangerous areas with dangerous
electric voltage. Non-observance of the warning signs causes
severe injuries or death. The work to be carried out may only be
carried out by a qualified electrician or an electrical safety
expert.
This warning sign is fixed at the following point:
› At the terminals, under the cover.
2.6 For your safety
Mortal danger by electric voltage!
Touching live parts can be lethal. Damage to the insulation or to
individual components can be lethal.
› If the insulation or any parts are damaged, switch off the
power supply at once and initiate repair.
› Only qualified electricians or electrical safety experts may
carry out work on the electrical system.
› Before commencing any work, switch off power supply and
secure against restarting. Test for absence of voltage.
› Perform the electrical installation in accordance with the
applicable regulations.
› Protective devices that are required according to national and
local regulations, e.g. residual current devices, must be
provided. These protective devices must be provided by the
customer.
› Observe the information on the type plate.
› Close all covers after all work is completed.
› Keep moisture and dust away from live parts. Intruding
moisture and dust may cause a short circuit.
› If the electrical connection is made during precipitation, e.g.
rain or snow, prevent the intrusion of moisture by means of
suitable protective covers.
› During or after a lightning strike into the system, there is
danger to life if the components are touched or during a stay
in the immediate vicinity of the system. When mounting
outside, do not install and mount the pedestrian gate during
thunderstorms.
www.TURNSTILES.us | [email protected] | 303-670-1099

15
mWing
Safety
2.7 To protect the environment
Improper disposal!
Improper disposal can result in damage to the environment.
› Dispose of the product in accordance with local and national
laws and regulations.
› Sort resources and supply them to recycling.
2.8 Emergency opening of the pedestrian gate
äPage 77, chapter 8.4.1.
www.TURNSTILES.us | [email protected] | 303-670-1099

16
mWing
Technical data
3 Technical data
3.1 Dimensions and design
3.1.1 mWing
Fig. 1: Dimensions mWing with swing wing at standard height (dimensions in
inches), X corresponds to ordered passage width
A Installation space for reader without the option of the passage direction display,
installation depth 1.6"
www.TURNSTILES.us | [email protected] | 303-670-1099

17
mWing
Technical data
Mag01122
A
3.9
1.7
2.4
3.1
51.2
48.7
X + 6.1
X
2.0
7.1
9.4
70.8
41.3
3.1
7.1
3.1
3.7
A
A
Fig. 2: Dimensions mWing with swing wing in high version (dimensions in inches
X corresponds to the ordered passage width.
A Installation space for reader without the option of the passage
direction display, installation depth = 1.6".
www.TURNSTILES.us | [email protected] | 303-670-1099

18
mWing
Technical data
Designation Value
Dimensions
(length x width x height)
› mWing with swing wing at standard height
51.2" x 7.1" x 41.3"
äPage 16, Fig. 1.
› mWing with swing wing in high version
51.2" x 13.2" x 41.3"
äPage 17, Fig. 2.
Passage width ›Standard versions: 23.5" or 36.2" (600 mm or 920 mm)
›Special versions: 37.8" extra-wide passage (960 mm)
›Other dimensions on request
Weight ›Pedestrian gate: Approx. 181 lbs.
›Base frame FURA100 1): 24.3 lbs.
›Base frame FURA102 1): 38.5 lbs.
Material › Housing: mDure
› Base frame 1): Stainless steel
› Base plate 1): Stainless steel
1) Optional
Table 3: Dimensions and design – mWing
3.2 Clearances and line configuration to be maintained
mWingmWingmWing
Mag01001a
2.0" 2.0"
Fig. 3: Clearances and line configuration to be maintained. Recommended minimum
distance 2.0"
Distances between modules äPage 16, Fig. 1 and äPage 17, Fig. 2
www.TURNSTILES.us | [email protected] | 303-670-1099

19
mWing
Technical data
3.3 Electrical connection
Designation Value
Power supply 100 to 240 V AC ± 10 %, 50 to 60 Hz
Current consumption at 240 V AC 1.0 A
Current consumption at 100 V AC 2.1 A
Max. performance 174 W
Duty cycle 100 %
Table 4: Electrical connection
3.4 Operating conditions
Designation Value
Operating temperature range -22 to +131 °F
Storage temperature range -22 to +131 °F
Relative humidity Maximum 95 %, non-condensing
IP rating IP 54
Table 5: Operating conditions
3.5 Emissions
Designation Value
Airborne sound pressure level (LpA) ≤ 70 dB (A)
Table 6: Emissions
www.TURNSTILES.us | [email protected] | 303-670-1099

20
mWing
Technical data
3.6 Control unit MGCplus
Designation Value
Power supply 24 V DC
Control unit max. 1 A: max. 300 mA + current
consumption of the individual plug-
in modules
Power consumption max. 24 W: Max. 7.2 W +
power consumption of the
individual plug-in modules
Control unit safety device 1 A T
Output terminal 2 Output voltage 24 V DC
Max. output current 300 mA
Digital inputs Number 8
Input voltage 24 ± 10 % V DC
Input current < 10 mA per input
Max. cable length 1) 30 m
Digital outputs Number 4 (open collector)
Input voltage 24 ± 10 % V DC
Input current 100 mA
Max. cable length 1) 30 m
Relay outputs Number 3 closers + 3 changeovers ,
isolated
Max. switched voltage 30 V AC / DC
Switching current 10 mA to 1 A
Max. cable length 1) 30 m
Display Graphics display, 128 x 65 pixel
Number of slots for plug-in modules 5
1) Specified without optional over voltage module. For cable lengths above 95 feet, over-voltage
modules must be installed upstream of the connection terminals.
Table 7: Control unit MGCplus
www.TURNSTILES.us | [email protected] | 303-670-1099
