The TYCO Model ESFR-25 Pendent
Sprinklers are “Early Suppression,
Fast Response Sprinklers” having
a nominal K-Factor of 25.2. (Refer to
Figure 1.) They are suppression-mode
sprinklers that are especially advanta-
geous as a means of eliminating the
use of in-rack sprinklers when pro-
tecting high-piled storage.
The Model ESFR-25 Sprinklers are
primarily used for ceiling-only sprin-
kler protection of (but not limited to)
the following storage applications:
• Most encapsulated or non-encap-
sulated common materials including
cartoned, unexpanded plastics.
• Uncartoned (exposed) expanded
plastics in accordance with NFPA
13 and FM Global standards.
• Some storage arrangements of
rubber tires, roll paper, ammable
liquids, aerosols, and automotive
components.
For more specic criteria, refer to
Table 1 in this data sheet as well as
the applicable design standard.
The Model ESFR-25 Sprinklers
provide the system designer with
hydraulic and sprinkler placement
options not presently available
to the traditional ESFR sprinklers
having nominal K-Factors of 14.0
and 16.8. In particular, the Model
ESFR-25 Sprinkler has been designed
to operate at substantially lower-end
head pressures, as compared to ESFR
Sprinklers having nominal K-Factors
of 14.0 and 16.8. This feature offers
exibility when sizing system piping,
as well as possibly reducing or
eliminating the need for a system re
pump.
Also, Model ESFR-25 Sprinklers per-
mit use of a maximum deector-to-
ceiling distance of 18 inches (460 mm)
versus 14 inches (360 mm). Addi-
tionally, a storage arrangement of 40
ft. (12,2 m) with a ceiling height of 45
ft. (13,7 m) does not require in-rack
sprinklers as do other ESFR Sprinklers
having nominal K-Factors of 14.0. and
16.8.
Applications for the TYCO ESFR
Sprinklers are expanding beyond cur-
rently recognized installation stan-
dards. For information on research
re tests (with ammable liquids and
aerosols, for example) that may be
acceptable to an Authority Having Ju-
risdiction, contact the Technical Ser-
vices department.
NOTICE
The Model ESFR-25 Sprinklers described
herein must be installed and maintained
in compliance with this document, as well
as with the applicable standards of the
National Fire Protection Association, in
addition to the standards of any authorities
having jurisdiction (for example, FM
Global). Failure to do so may impair the
performance of these devices.
Owners are responsible for maintaining
their fire protection system and devices in
proper operating condition. The installing
contractor or sprinkler manufacturer
should be contacted with any questions.
In all cases, the appropriate NFPA or FM
installation standard, or other applicable
standard, must be referenced to ensure
applicability and to obtain complete
installation guidelines. The general
guidelines in this data sheet are not
intended to provide complete installation
criteria.
Model/Sprinkler
Identification
Number (SIN)
TY9226 - Pendent K=25.2
TY9226 is a re-designation for C9226,
G8441, and S8010.
Technical
Data
Approvals
UL and C-UL Listed
FM and VdS Approved
LPCB Approved (094b/01 and 07l/01)
NYC under MEA 356-01-E
Maximum Working Pressure
175 psi (12,1 bar)
Pipe Thread Connections
1 inch NPT
ISO 7-R1
Discharge Coefficient
K = 25.2 GPM/psi1/2
(362,9 LPM/bar1/2)
Model ESFR-25
Early Suppression, Fast Response Pendent Sprinklers
25.2 K-Factor
Page 1 of 4 FEBRUARY 2011 TFP312
Technical Services: Tel: [phone] / Fax: [phone]
Email: [e-mail]
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cau-
tions with respect to handling
and installation of sprinkler sys-
tems and components. Improp-
er handling and installation can
permanently damage a sprin-
kler system or its components
and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.

TFP312
Page 2 of 4
Temperature Ratings
165°F (74°C)
214°F (101°C)
Finish
Natural Brass
Physical Characteristics
Frame........................ Brass
Deector..................... Bronze
Compression Screw. . . . . . Stainless Steel
Hook.........................Monel
Strut .........................Monel
Link Assembly . . . . . . . . . . . Solder, Nickel
Button........................ Brass
Sealing Assembly. . . . . . . Beryllium Nickel
with Teon*
Ejection Spring. . . . . . . . . . . . . . . . Inconel
Patents
U.S.A. Patent Numbers:
5,829,532
6,059,044
6,336,509
6,502,643
6,868,917
7,165,624
Additional Patents pending
Design
Criteria
The following general guidelines pro-
vided for the TYCO Model ESFR-25
Sprinklers can be used for a quick
reference.
* Registered trademark of Dupont
NOTICE
The National Fire Protection Association
(NFPA) and FM Global (FM) provide
installation standards that must be used
to properly design an automatic sprinkler
system utilizing Early Suppression,
Fast Response (ESFR) Sprinklers. The
guidelines provided by NFPA and FM
may differ. Consequently, the appropriate
standard must be used for a given
installation.
In all cases, the appropriate NFPA or FM
installation standard must be referenced
to ensure applicability and to obtain
complete installation guidelines. The
following general guidelines are not
intended to provide complete installation
criteria.
In addition to this data sheet, the fol-
lowing data sheets describe other
TYCO ESFR Sprinklers:
• TFP315 — Model ESFR-17
(TY7226), K=16.8 Pendent Sprinkler
• TFP316 — Model ESFR-17
(TY7126), K=16.8 Upright Sprinkler
• TFP318 — Model ESFR-1
(TY6226), K=14.0 Pendent Sprinkler
System Type
Wet pipe system
Roof Construction
Unobstructed or obstructed construc-
tion; for example, smooth ceiling, bar
joists, beam and girder, and so forth.
Where the depths of the solid struc-
tural members (beams and stem, for
example) exceed 12 inches (302 mm),
install ESFR Sprinklers in each chan-
nel formed by the structural members.
Ceiling Slope
Maximum 2-inch rise for 12-inch run
(16.7%)
Maximum Coverage Area
100 ft2 (9,3 m2)
In some cases, the installation stan-
dards permit a greater coverage area.
Minimum Coverage Area
64 ft2 (5,8 m2) per NFPA 13/FM 2-0
Maximum Spacing
12 feet (3,7 m) for building heights up
to 30 feet (9,1 m)
10 feet (3,1 m) for building heights
greater than 30 feet (9,1 m)
Minimum Spacing
8 feet (2,4 m)
Minimum Clearance to Commodity
36 inches (914 mm)
NFPA 13 Deector-to-Ceiling
Distance
6 to 18 inches (152 to 457 mm)
FM 2-0
Consult FM and/or FM Guidelines for
allowable deector-to-ceiling distanc-
es as well as thermal sensing element-
to-ceiling criteria.
FIGURE 1
MODEL ESFR-25, EARLY SUPPRESSION, FAST RESPONSE
PENDENT SPRINKLER 25.2 K-FACTOR
2
3
6
4
5
9
8
7
1
1" NPT
FLATS
WRENCH
(96,8 mm)
3-13/16"
9/16"
(14,3 mm)
2" (50,8 mm)
(46,0 mm)
1-13/16"
SENSING
THERMAL
ELEMENT
NOMINAL
MAKE-IN
TEMPERATURE
RATING
-Hook4
-
9
-
7
8-
5
6
-
-Link Assembly
Ejection Spring
Sealing
Button
Assembly
Strut
-
2
3-
1-
Compression
Deflector
Frame
Screw
Components:

Storage Type NFPA FM
Open Frame (that is, no solid shelves)
Single, Double, Multiple-Row, or Portable Rack Storage
of Class I-IV and Group A or B Plastics
Refer to NFPA 13, Chapters 16 and 17. Refer to FM 2-0 and 8-9.
Solid Pile or Palletized Storage of Class I-IV
and Group A or B Plastics Refer to NFPA 13, Chapters 14 and 15. Refer to FM 2-0 and 8-9.
Idle Pallet Storage Refer to NFPA 13, Chapter 12. Refer to FM 2-0, 8-9, and 8-24.
Rubber Tire Storage Refer to NFPA 13, Chapter 18. Refer to FM 2-0 and 8-9.
Rolled Paper Storage (Refer to the standard.) Refer to NFPA 13, Chapter 19. Refer to FM 8-21.
Flammable Liquid Storage (Refer to the standard.) Refer to NFPA 30. N/A
Aerosol Storage (Refer to the standard.) Refer to NFPA 30B. Refer to FM 7-31.
Automotive Components in Portable Racks
(Control mode only; refer to the standard.) Refer to NFPA 13, Chapter 20. N/A
N/A = Non-Applicable
TABLE 1
COMMODITY SELECTION AND DESIGN CRITERIA OVERVIEW FOR
MODEL ESFR-25 PENDENT SPRINKLERS
Operation
The fusible link assembly is comprised
of two link halves that are joined to-
gether by a thin layer of solder. When
the rated temperature is reached, the
solder melts and the two link halves
separate, activating the sprinkler and
owing water.
Installation
The TYCO Model ESFR-25 Pendent
Sprinklers must be installed in accor-
dance with the following instructions.
NOTICE
Damage to the fusible Link Assembly
during installation can be avoided by
handling the sprinkler by the frame
arms only (that is, do not apply pres-
sure to the fusible Link Assembly),
and by using the appropriate sprinkler
wrench. Failure to do so can lead to an
unstable link assembly and premature
activation of the sprinkler. Damaged
sprinklers must be replaced.
Obtain a leak-tight 1-inch NPT sprin-
kler joint by applying a minimum-to-
maximum torque of 20 to 30 ft.lbs.
(26,8 to 40,2 Nm). Higher levels of
torque can distort the sprinkler inlet
with consequent leakage or impair-
ment of the sprinkler.
1. Install the Model ESFR-25 Pendent
Sprinkler in the pendent position
(Figure 2).
2. With pipe-thread sealant applied,
hand-tighten the sprinkler into the
sprinkler tting. Do not apply pres-
sure to the Link Assembly, and
handle the Model ESFR-25 Sprin-
kler only by the Frame arms.
3. Wrench-tighten the Model ESFR-
25 Sprinkler using only the W-
Type 1 Sprinkler Wrench (Figure 2)
and by fully engaging (seating) the
wrench on the sprinkler wrench
ats (Figure 1).
4. After installation, inspect the Link
Assembly of each Model ESFR-
25 Sprinkler for damage. In partic-
ular, verify that the Link Assembly
and Hook are positioned as illus-
trated in Figure 1, and that the Link
Assembly is not bent, creased, or
forced out of normal position in any
way. Replace damaged sprinklers.
"FITTING SIDE"
FITTING
TOWARDS SPRINKLER
RECESS
WRENCH
FIGURE 2
W-TYPE 1
SPRINKLER WRENCH
TFP312
Page 3 of 4

Care and
Maintenance
The TYCO Model ESFR-25 Sprinklers
must be maintained and serviced
in accordance with the following
instructions.
NOTICE
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
it controls, obtain permission to shut
down the affected fire protection systems
from the proper authorities and notify all
personnel who may be affected by this
action.
Exercise care to avoid damage before,
during, and after installation. Never
paint, plate, coat, or otherwise alter
automatic sprinklers after they leave
the factory.
Replace sprinklers that:
• were modied or over-heated.
• were damaged by dropping, strik-
ing, wrench twisting, wrench slip-
page, or the like.
• are leaking or exhibiting visible
signs of corrosion.
Responsibility lies with the owner for
the inspection, testing, and mainte-
nance of their re protection system
and devices in compliance with this
document, as well as with the appli-
cable standards of the National Fire
Protection Association (for example,
NFPA 25), in addition to the standards
of any authorities having jurisdiction.
Contact the installing contractor or
sprinkler manufacturer regarding any
questions.
Automatic sprinkler systems are
recommended to be inspected,
tested, and maintained by a qualied
Inspection Service in accordance with
local requirements and/or national
codes.
Limited
Warranty
Products manufactured by Tyco
Fire Suppression & Building Prod-
ucts (TFSBP) are war ranted solely to
the original Buyer for ten (10) years
against defects in mate rial and work-
manship when paid for and properly
installed and maintained under nor-
mal use and service. This warranty
will expire ten (10) years from date of
shipment by TFSBP. No warranty is
given for products or com ponents
manufactured by companies not afli-
ated by ownership with TFSBP or for
products and components which have
been subject to misuse, improper in-
stallation, corrosion, or which have
not been installed, maintained, modi-
ed or repaired in accordance with
ap plicable Standards of the National
Fire Protection Association, and/or
the standards of any other Authorities
Having Jurisdiction. Materials found
by TFSBP to be defective shall be ei-
ther repaired or replaced, at TFSBP’s
sole option. TFSBP neither assumes,
nor authorizes any person to assume
for it, any other obligation in connec-
tion with the sale of products or parts
of prod ucts. TFSBP shall not be re-
sponsible for sprinkler system design
errors or inac curate or incomplete in-
formation sup plied by Buyer or Buy-
er’s repre sentatives.
In no event shall TFSBP be liable, in
contract, tort, strict liability or under
any other legal theory, for inciden-
tal, indirect, special or consequential
dam ages, including but not limited to
labor charges, regardless of whether
TFSBP was informed about the pos-
sibility of such damages, and in no
event shall TFSBP’s liability exceed an
amount equal to the sales price.
The foregoing warranty is made in
lieu of any and all other warranties,
express or implied, including warran-
ties of merchantability and tness for
a particular purpose.
This limited warranty sets forth the ex-
clusive remedy for claims based on
failure of or defect in products, materi-
als or components, whether the claim
is made in contract, tort, strict liability
or any other legal theory.
This warranty will apply to the full ex-
tent permitted by law. The invalidity,
in whole or part, of any portion of this
warranty will not affect the remainder.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indi-
cate the full product name. Refer to
the Price List for complete listing of
Part Numbers (P/Ns).
Sprinkler Assemblies
Specify: (temperature rating), natural
brass, TY9226 Pendent Sprinkler, P/N
(below).
165°F (74°C) . . . . . . . . . . . . . . .P/N 58-441-1-165
214°F (101°C) . . . . . . . . . . . . . .P/N 58-441-1-214
Special-Order Sprinkler
Assemblies with ISO 7/1 Thread
Connections
Specify: (temperature rating), natural
brass, TY9226 Pendent Sprinkler with
thread connection per ISO 7/1, P/N
(below).
165°F (74°C) . . . . . . . . . . . . . . P/N 58-442-1-165
214°F (101°C) . . . . . . . . . . . . . P/N 58-442-1-214
Sprinkler Wrench
Specify: W-Type 1 Sprinkler Wrench,
P/N 56-872-1-025.
Copyright © 2007-2011 Tyco Fire Suppression & Building Products. All rights reserved.
TFP312
Page 4 of 4
