UFREE SCOOTER FS-E12 User manual

UFREE SCOOTER www.scooter-manufacturer.com
INSTRUCTION MANUAL
ELECTRIC SCOOTER FS-E12

UFREE SCOOTER www.scooter-manufacturer.com
INTRODUCTION
CONGRATULATIONS!
The electrical scooter is a kind of new fashion motorized
vehicle. It can be replaced as walking. It is energy saving,
entertain able, and is environment protection sport vehicle. Our
electric scooter is small, long riding time, easy for carry, and
easy for repair. Please let our product. Tiger sting Ray Electric
Scooter stay with you throughout your day. Before using the
scooter, please read all the instructions consist inside the manual.
In order for us to better serve you, let us know how our product
works.
THANK YOU FOR SELECTING OUR ELECTRIC
SCOOOTER, WE HOPE YOUR WILL ENJOY THE
EXCITING RIDING.

UFREESCOOTER www.scooter-manufacturer.com
1
KNOWING YOUR SCOOTER
The scooter will be as the following:
Fig1. Scooter with full assembly showing name for each part
Also, you should have the following with your scooter
Fig2. The changer and how it connects.
Also, for your convenience, the following access or are provided.
Speed throttle control
Brake handle
Seat saddle
Battery indicator
Front light
Seat collar clamp
Folding accessories Brake ligh
t
Front wheel
Back wheel
Rear brake
Fuse socket
Charger socket
Plastic cover Stand

UFREE SCOOTER www.scooter-manufacturer.com
2
Fig 3 tools set
Here is the specification for your scooter:
Weight (including Battery): 30kgs
Load Capacity: 85kg
Brake system: hand front, rear brake
Full Charge Mileage: 20km
Max Speed: 20km/hr
System Voltage: 24V
Motor Power: 300W
Charge Voltage: 100-230V
Battery: 12V 12AH*2pcs
Charge time: 4-6 hours
Tyres: Rubber pneumatic tyres

UFREE SCOOTER www.scooter-manufacturer.com
3
ASSEMBLY INSTRUCTION
1. Pick out all the things from the carton box; you will have all the following things
Scooter and its accessories ×1set
Basket ×1set
toolsset ×1set
charger ×1set
instructionmanual ×1piece

UFREESCOOTER www.scooter-manufacturer.com
4
3. To finish the assembly, you need to put the fuse into
the fuse socket. Remove the cover of the fuse socket
and put the fuse on the cover, then re-close the cover.
WARNING: when putting on the fuse, please make
sure the power key switch turns to OFF.
how to install the fuse
4. Check all the locks and bolts, make sure all the
locks and bolts tighten, you have finished assembly
the scooter.
•

UFREE SCOOTER www.scooter-manufacturer.com
5
RECHARGING INSTRUCTION & BATTERY CARING
Each scooter has one "T" mark adaptor. To recharge of the battery,
please read the following instruction:
1. Connect the charger as the picture show.
2. Use the recharging adaptor provided, plug against the electric
wall slot while the
other cord connect to the scooter (charging socket located at the
side of the
deck.)
3. Complete recharging time takes 12 hours.
4.If the scooter is shelved for a long time, the battery must
recharge once per
month.
5. Unplug the charger and put the charger in
safety places.
CAUTION: the PES mark charge have the function of auto stop
charging process, in order to proceed the charging, you must
connect the plug to the scooter first and then connect with AC
supply.
The charger must keep in good condition which should not be
contact with heat or fire. Those broken charger cannot be used
anymore. Please contact with your dealers if happened.
Warning: Use only the charger as per attached for this scooter, other
chargers may cause accident when charging.
How to keep the battery in long life:
The completely charging time for a battery is around 12 hours. For
first time charging, it is recommended to charge at least 16 hours.
Charge the battery every time after using. Recharging process must
be complete once the process is started. This helps to extend the
battery life.
Does not use the scooter while the battery showing low energy. If it
is over used, the battery will reduce its life.

UFREE SCOOTER www.scooter-manufacturer.com
7
SAFETY INSTRUCTIONS
Before riding the electric scooter, please read the following instruction carefully.
DO:
1. This Electric Scooter should be used by people aged over 14 or under the
supervision of an adult.
2. For people weight more than 200 lbs should not use this Electric Scooter.
3. Do read the whole manual and follow all the safety and maintenance
recommendations made there.
4. Do check the electric scooter thoroughly before used. Make sure all the part and
install correctly and tightly.
5. Do switch off the key to turn off the power after used every time.
6. Do keep the body part away from the moving part of the scooter.
7. Do avoid use the scooter on gravel, sand, grass, mud, water and rough surface
area.
8. Do wear a safety helmet when riding.
9. Do getting alert to any contingent accident.
DON'T
1. Don't use this electric scooter in the rain to prevent short circuit.
2. Don't place the battery near the fire or heat to prevent exploded.
3. Don't explode the charger to moisture or water.
4. Don't allow the child under 14 years of age to handle the scooter without the
supervision of an adult
5. Don't ride the scooter with more than a person at the same time.
6. Don't riding the scooter after drinking alcohol.

UFREE SCOOTER www.scooter-manufacturer.com
8
OPERATING THE SCOOTER
After assembly and charging your scooter, your scooter is ready to ride. Put
the key into the power key switch; turn to "ON" status. Test all the electric
functions before riding on the road, including direction light, front light,
horn and brake light. It is suggested user should have a short test for the
scooter before riding on the road.
To start the running, turn the accelerator anti clockwise to start movement
and increase the speed. You can adjust the speed by turning the accelerator.
The speed for the scooter can rise up to 25 km/hr. The actual speed is
depended on the user weight, the road, tyre pressure and other factors.
To stop the scooter, you can release the accelerator by turning clockwise.
Doing this, your scooter will slow down and stop. Moreover, a rear brake
system has been installed to your scooter. When your pull the brake, it will
automatically cut off the power supply to the motor and slow down. Then
the rear brake on the back tyre will stop the scooter.
CAUSION: For safety reason, your brake system won't stop the scooter once
it is applied immediately. Do be aware whenever you are driving the
scooter.
After riding the scooter, you must turn the key power to "OFF" status, to
avoid unexpected accident and save energy. Also, do charge the battery after
each usage.

UFREESCOOTER www.scooter-manufacturer.com
8
TROUBLESHOOTING GUID
Problem Possible causes Action
Power does not on 1. The fuse does not install / 1. Replace the fuse
not function 2. Turn on the Power key and
2. Power key switch do not try again
turns to "ON" status 3. Connect the battery by
3. Battery is not connected open the cover
4. Battery is drained 4. Charge the battery
5. Electric fault 5. Check all the connections
Motor does not 1. The accelerator handle bar is 1. Check the connection of
work even the broken. the accelerator, or change
power is on 2. Brake is too tight one.
3. Motor problems occurs 2.Adjust the brake system.
4. The connection of electric 3. Contact to the technician
for the accelerator is broken. 4. Check the connection
5. Circuit breaker tripped 5. Turn off the powerand
6. The brake pulled firmly wait for 5 second
6. Restore the brake
Rear tyre not works I. The brake is too tight 1.Adjust the brake system
normally 2. The chains is too loose 2. Adjust the chain system
(note 1)
Insufficient Range 1. Battery is not power enough 1. Charge the battery
2. Low tyre pressure 2. Pump the tyre. If you
3. Popping sound found can't pump the air
in, please check the tyre.
3. The chains are too loose
(note 1)
Charging not 1. Not power supply to the 1. Please make sure all the
proceed charger connection is correct
2.Auto disconnect function of 2. Please remove the charger
the charger occurs totally. Connect the
3. The charger broken charger with the scooter
first, and then connect to
theAC power supply.
3. Please contact with dealer
for a new charger.

UFREE SCOOTER www.scooter-manufacturer.com
9
Note 1: drive chain adjustment
Periodic adjustment of the drive chain will be necessary to maintain
proper tension. If the chain is too loose, it will make a "popping" noise
while accelerating, indicating the need for immediate adjustments.
Before Adjusting the chain, please make sure to disconnect the battery
power to prevent accident starts or shocks. Lose the rear axle nuts until
the tyre can be moved easily. Adjust the rear tyre position to change the
tension by adjusting the back tyre adjusting screw. Check the tension by
rotating the tyre by hand. Be sure that the tension of the chain should be
proper only. To tight may cause easy broken and the axis of the tyre to be
parallel to the motor. Tighten the axle nuts and recheck the tension.
After Sales Service and repair of electrical scooter
1. If there are any problems with our products while being use, feel free
to contact your retailer as soon as possible, The retailers will help you
diagnose your product and have some kind of repair methods for you to
repair your scooter.
2. If the battery, engine, charger, chain, and activator are damaged within
the 3 month warranty . the retailer will be informing to replace or
repair(if available).The valid date of warranty starts on the date of the
invoice that you had purchased the scooter.
3. For the first 30 days everything on the scooter is cover by the warranty.
After that, only major electrical components listed in number two
statement are cover. Everything else is considering accessor.

UFREE SCOOTER www.scooter-manufacturer.com
10
IMPORTANT INFORMATION
BEFORE EACH USE PLEASE CHECK THE FOLLOWING:
1. All users read safety/operation information
2. Tyre condition and pressure
3. Brake condition and operation
4. Drive belt/chain condition and adjustment
5. Wires and cables. Condition/secure
6. Oil/grease bearings (DO NOT OIL OR GREASE DRIVE BELT)
7. Battery fully charged
8. All securing nuts, bolts and screws are tightened
9. When charging, always connect charger to scooter before
turning power on
10.Over loading this unit may cause premature motor failure
11.Continuous use on steep gradients may cause motor to overheat.
Please allow to cool periodically
GUARANTEE
This product is guaranteed for 90 days from the date of purchase
against manufacturer defects. If a fault should occur within this time, we
undertake to repair or replace the defective part/s free of charge. The
faulty unit should be returned to the place of purchase or the address
specified by your supplier for inspection, repair or replacement.

UFREE SCOOTER www.scooter-manufacturer.com
11
PLEASE NOTE:
Tyres, tubes, drive belts; faults due to accidental damage, misuse, wear
and tear or modification of the standard product are not covered under
this warranty. You must report any faults as soon as it is noticed.
Unauthorized tampering with this product may invalidate the warranty.
Invalid claims will be returned in the condition received (upon receipt of
postage/ packaging charges).
To validate warranty please complete and return form below within 14
days of purchase to unlimited Tech, 3677 san Gabriel River Parkway Pico
Rivera CA 90660.
Tel: 562-695-4229
Name: Supplier Name & Address/Stamp
Address:
Post Code:
Tel. No.:
Date of Purchase
Product code/
Description:
Serial Number:

UFREE SCOOTER www.scooter-manufacturer.com
12
CERTIFICATE OF WARRANTY
(only valid in conjunction with sales receipt)
Name: Supplier Name & Address/Stamp
Address: Please include proof of purchase
Post Code:
Tel. No.:
Date of Purchase
Product
code/
Description:
Serial Number:
Detailed Description of Defect:

UFREE SCOOTER www.scooter-manufacturer.com
13
In the event of a claim the unit should be returned, together with
warranty certificate and sales receipt, to the place of purchase or the
address specified by your supplier for inspection, repair or
replacement. Postage &packaging cost arc the responsibility of the
purchaser and excluded from warranty.
P1EASE NOTE:
Tyres, tubes, drive belts; faults due to accidental damage, misuse, wear
and tear or modification of the standard product are not covered under
this warranty. You must report any faults as soon as it is noticed.
Unauthorised tampering with this product may invalidate the warranty.
Invalid claims will be returned in the condition received (upon receipt of
postage/ packaging charges).
Print:
Sign: Date:
Table of contents
Other UFREE SCOOTER Scooter manuals
