Unicum NERO TOUCH User manual

DRINKS VENDING MACHINE
models NERO TOUCH, NERO TOUCH INSTANT
USER MANUAL
Version 1.1 / December 2017
ТМ

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 2
Version 1.1 / December 2017
ТМ
Document change log
Version Date Brief description Pages
1.0 06.2017 Document creation All
1.1 12.2017 Section 4.3.2 - added (Air fine tuning valve adjustment) 19

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 3
Version 1.1 / December 2017
ТМ
Vending machine manufacturer LLC “KRAFT”
Russian Federation
199155 Saint Petersburg
 13UralskayaStr.,lit.А
Tel: [phone]
Fax: [phone]
www.unicum.ru
Original language - Russian
COMPLIANCE DATA
The drinks vending machines models NERO TOUCH, NERO TOUCH INSTANT are compliant with the
requirements of the European Directives and Standards, listed in the following table:
Directive / Standard Description
2004/108/ЕС Electromagnetic compatibility
2006/95/ЕС Low-voltage equipment
1935/2004/EC Food Contact Materials
2011/65/EU Restriction of Hazardous Substances
The drinks vending machines models NERO TOUCH, NERO TOUCH INSTANT, are compliant with
following requirements of the Technical Regulations of the Customs Union, listed in the table:
Code Description
ТRCU004/2011 Technical Regulation of the Customs Union 004/2011 “About the safety of
low-voltage equipment
ТRCU010/2011 Technical Regulation of the Customs Union 010/2011 “About the safety of
machines and equipment”
ТRCU020/2011 Technical Regulations of the Customs Union 020/2011 “Electromagnetic com-
patibility of machines”

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 4
Version 1.1 / December 2017
ТМ
CONTENTS
1.0 GENERAL INFORMATION...............................................................................................................7
1.1 Introduction .................................................................................................................................7
1.2 Terms of use ...............................................................................................................................8
 1.3Congurationoptions ..................................................................................................................8
1.4 Manufacturer’s warranty .............................................................................................................8
1.5 Vending machine functionality ....................................................................................................9
2.0 TECHNICAL FEATURES.................................................................................................................10
3.0 SAFETY ...........................................................................................................................................11
3.1 Main provision............................................................................................................................ 11
3.2 Service key ................................................................................................................................12
3.3 Temperature...............................................................................................................................12
4.0 TRANSPORTATION, INSTALLATION, COMMISSIONING.............................................................13
4.1 Transportation ............................................................................................................................13
4.2 Installation..................................................................................................................................14
4.3 Commissioning ..........................................................................................................................15
 4.3.1Installationnenessofgrinding ........................................................................................17
 4.3.2Airnetuningvalveadjustment........................................................................................19
4.3.3 Connecting the vending machine to water supply mains .................................................24
5.0 THE VENDING MACHINE’S COMPONENTS.................................................................................26
5.1 Appearance................................................................................................................................26
5.2 Internal view (with option FRESH MILK)....................................................................................27
5.3 Internal view (without door cover) ..............................................................................................28
5.4 Back view...................................................................................................................................29
5.5 Containers for instants ingredients and coffee beans................................................................30
5.6 Waste container .........................................................................................................................32
5.7 Autonomous operations kit.........................................................................................................32
5.8 Flot chamber, boiler pump, boiler and steam boiler ...................................................................33
5.9 Espresso group..........................................................................................................................35
5.10 Mixers for instant ingredients ...................................................................................................38
6.0 VENDING MACHINE CONTROL AND MONITORING DEVICES...................................................39
6.1 Main Board (controller) ..............................................................................................................40
6.2 Quick access keypad .................................................................................................................41
6.3 Touch screen..............................................................................................................................41
7.0 VENDING MACHINE’S WORKING PRINCIPLE.............................................................................42
7.1 Placement of the cup .................................................................................................................42
7.2 Preparation of drinks..................................................................................................................43
7.3 Dispensing the drink ..................................................................................................................43

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 5
Version 1.1 / December 2017
ТМ
CONTENTS
8.0 DESCRIPTION USER MENU ..........................................................................................................44
8.1 Home screen..............................................................................................................................44
8.1.1 Drink choice......................................................................................................................45
8.1.2 The process of making the drink ......................................................................................46
8.1.3 Coffee error ......................................................................................................................46
9.0 DESCRIPTION SERVICE MENU - MENU TECHNICIAN................................................................47
9.1 Menu technician.........................................................................................................................47
9.1.1 System..............................................................................................................................48
9.1.1.1 General.................................................................................................................48
9.1.1.2 Security.................................................................................................................49
9.1.1.3 Franchising...........................................................................................................50
9.1.1.4 Resets ..................................................................................................................51
9.1.1.5 Power ...................................................................................................................52
9.1.1.6 EVA-DTS ..............................................................................................................53
9.1.1.7 Modem..................................................................................................................54
9.1.1.8 Ethernet................................................................................................................56
9.1.1.9 UI..........................................................................................................................57
9.1.1.9.1 Loading video to vending machine........................................................58
9.1.1.10 About ..................................................................................................................60
9.1.2 Errors................................................................................................................................61
9.1.2.1 Setup Errors .........................................................................................................62
9.1.3 Planogram ........................................................................................................................63
9.1.3.1 Planogram settings...............................................................................................64
9.1.3.2 Setting buttons......................................................................................................66
9.1.3.3 Loading image to vending machine......................................................................68
9.1.4 Recipes.............................................................................................................................70
9.1.5 Brewer ..............................................................................................................................72
9.1.6 Sped-up............................................................................................................................74
9.1.7 Boilers...............................................................................................................................76
9.1.8 Cleaning ...........................................................................................................................78
9.1.9 Sensors test......................................................................................................................79
9.1.10 Functional Tests..............................................................................................................80
9.1.11 Cycle Test .......................................................................................................................82
9.1.12 Payment Systems...........................................................................................................83
9.1.13 Others.............................................................................................................................84

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 6
Version 1.1 / December 2017
ТМ
CONTENTS
9.1.14 Statistics .........................................................................................................................85
9.1.14.1 Vending machine (VM) .......................................................................................86
9.1.14.2 Current data........................................................................................................87
9.1.14.3 Common audit ....................................................................................................89
9.1.14.4 Coins ..................................................................................................................90
9.1.14.5 Bills.....................................................................................................................90
9.1.14.6 Errors..................................................................................................................90
9.1.14.7 Power boards .....................................................................................................91
9.1.14.8 Summary ............................................................................................................92
10.0 DESCRIPTION SERVICE MENU - OPERATOR MENU................................................................93
10.1 Operator menu.........................................................................................................................93
11.0 GENERAL TECHNICAL SERVICING............................................................................................94
11.1 General requirements ..............................................................................................................94
11.2 Cleaning list..............................................................................................................................90
11.2.1 Daily operations ..............................................................................................................96
11.2.1.1 Espresso group.................................................................................................96
11.2.1.2 Milk system (FRESH MILK option) ...................................................................96
11.2.1.3 Waste containers ..............................................................................................99
11.2.1.4 Drop tray and tray grill ......................................................................................99
11.2.1.5 Cup tray ............................................................................................................99
11.2.1.6 Milk container (for FRESH MILK only)..............................................................99
11.2.2 Daily operations .............................................................................................................100
 11.2.2.1Milkowmeter(FRESHMILKoption) .............................................................100
11.2.2.2 Check valve (FRESH MILK option) .................................................................102
11.2.2.3 Containers for soluble ingredients ...................................................................102
11.2.2.4 Coffee container ..............................................................................................103
11.2.2.5 Mixer ................................................................................................................103
11.2.1.6 Cappuccinatore (FRESH MILK option)............................................................104
11.3 Ingredients weighing ...............................................................................................................105
12.0 VENDING MACHINE WASHING ..................................................................................................106
13.0 WORKING WITH USB FLASH DRIVE.........................................................................................108
APPENDIX A - HYDRAULIC CIRCUIT FUNCTIONAL CHECK METHOD ..........................................110
APPENDIX B.1 - HYDRAULIC CIRCUIT FOR NERO TOUCH............................................................ 112
APPENDIX B.2 - HYDRAULIC CIRCUIT FOR NERO TOUCH (OPTION FRESH MILK)....................113
APPENDIX B.3
- HYDRAULIC CIRCUIT NERO TOUCH (OPTIONS FRESH MILK, MILK FLOW METER) ... 114
APPENDIX B.4 - HYDRAULIC CIRCUIT FOR NERO TOUCH INSTANT ...........................................115

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 7
Version 1.1 / December 2017
ТМ
1.0 GENERAL INFORMATION
1.1 Introduction
This user manual (hereinafter called the “Manual”) covers drinks vending machines models: NERO
TOUCH, NERO TOUCH INSTANT (hereinafter called the ‘‘Machine’’).
The manual contains basic information about the Machine and its software. It includes the informa-
tion,necessary for preparation for use, use and technical servicing of the Machine, as well as basic infor-
mation about the Machine’s software.
This manual is meant for engineering-technical personnel, who perform technical servicing of vending
machinesandarequaliedtoworkwithsimilarelectronicandelectricalequipment.
This Manual is for the technical and engineering personnel, who provide technical servicing for the Ma-
chine and are permitted to handle electrical units of similar category.
Breach of the requirements of the current Manual can lead to trauma, device damage and renders the
warranty ineffective. You must read and understand the requirements indicated in the current Manual, be-
fore installing and using the Machine, because it contains important information regarding unit safety, and
servicing and usage instructions.
The knowledge of safety requirements is necessary to instruct the users to properly use the Machine.
The Machine buyer is responsible to make sure that the serving personnel had undergone needed train-
ing and was informed properly and that the instructions of the technical documents were fully observed.
The Machine manufacturer carries no responsibility for damage or loss incurred under the following
circumstances:
•Incaseofunsanctionedmodernization;
•Incaseofimproperinstallation;
•Incaseofimproperconnectiontothepowerand/orwatersupply;
•Incaseofcleaningandservicingcontrarytotherequirements;
•IncaseofimproperoperationsoruseofMachine’sequipment;
•Incaseofuseofnon-genuinespareparts;
•rejectionoftheuseoffoodproducts,designedspecicallyforvendingmachines.
The manufacturer of the Machine is in no case liable for any possible losses, which might result from
interruption of business due to Machine breakdown.
These vending machine should only be used for making and selling drinks!
This manual is used for NERO vending machines with a touch screen using coffee beans and instant
coffee.
In this regard for the models using instant coffee, the word “INSTANT” is added to the vending machine
name (e.g. NERO INSTANT).
The INSTANT models have no equipment for making coffee from coffee beans (such as container for
coffee beans, espresso group, coffee grinder and dosing unit, etc.)
Thenumberingofguresinthismanualisgiveninsections.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 8
Version 1.1 / December 2017
ТМ
1.2 Terms of use
This Manual is for a certain version of vending machine software, which is current at the time of printing
of this Manual.
Allpossiblemodications,modernizationsand/oradaptations,whichareeffectedorwillbeexecutedin
future for following sales, do not mandate the manufacturer to conduct similar modernization of software
for the earlier sold Machines, as well as it does not mandate the manufacturer to amend the user docu-
mentation, which is a part of the Machine’s package.
The developer of the Machine and regulatory software have the right to make necessary changes to the
Machine’sstructure,software’sowandinthedocumentationforitsusewithoutnoticetotheuser.
NEROТОUCH NERO TOUCH INSTANT
 1.3Congurationoptions
1.4 Manufacturer’s warranty
The manufacturer’s warranty during the warranty period covers all vending machine units and as-
semblies, except for malfunctions, arising from non-observance of current maintenance documentation
requirements by the customer or due to any mechanical failures.
The following components are excluded from the manufacturer’s warranty:
• gaskets;
• fuses;
• controlboardsbatteries;
• mixerimpellers;
• hydraulic system tubes.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 9
Version 1.1 / December 2017
ТМ
1.5 Vending machine functionality
The vending machine is making various coffee-based drinks (from beans - not INSTANT, and INSTANT),
with the addition of soluble ingredients, and the coffee beans and foamed milk-based drinks (where the
FRESH MILK option is available).
The coffee beans based drinks are made using the espresso process.
The vending machines can be completed with optional equipment (FRESH MILK option, see below).
With the aid of this equipment, the milk is made foam by using steam and air in the milk mixing device
(cappuccinatore).
FRESH MILK option
NERO TOUCH vending machines can be additionally (optionally) completed with the equipment, per-
mitting the making of coffee beans based drinks with the addition of fresh milk made foam by using steam
and air in the mixing device (cappuccinatore) in accordance with the vending machine settings.
In this case, the vending machine has the FRESH MILK inscription in its name.
E.g.:
NERO TOUCH + FRESH MILK option = NERO FRESH MILK TOUCH
This option is agreed with the customer separately when ordering.
This option is not provided for vending machines as standard.
The option includes the installation of the following optional equipment in the standard model of the
vending machine:
steam boiler, circuit board 063V3, a nozzle for foaming milk (cappuccinatore), wire harnesses, hydraulic
tubes, water T-connector, etc.
The vending machines with the FRESH MILK option can be additionally (optionally) completed with the
freshmilkowmeter,whichcontrolsthemilkconsumption.
For vending machines with the FRESH MILK option, it’s recommended to order the milk cooling module
(cooler) from the vending machine manufacturer, which is usually installed on the left side of the vending
machine.
The vending machine may have other optional equipment (payment module, cup heater, etc.), which is
not standard supplied and should be mentioned individually for each order.
When installing the vending machine special pedestals are recommended for use (NERO, NERO TO
GO). NERO TO GO pedestals can also be used for connecting the vending machine to payment modules.
The drink can be selected from the touch screen with the context-sensitive display. To select a drink just
touchthedrinkiconwithyournger.Afterthedrinkselection,thevendingmachinewilloperateautomati-
cally.
All vending machine functions are controlled by the controller (main board).
The touch screen with the interface is controlled by the internal PC.
The vending machine may use a modem for online data transfer.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 10
Version 1.1 / December 2017
ТМ
2.0 TECHNICAL FEATURES
Table 1
Parameters NERO TOUCH NERO TOUCH INSTANT
Dimensions(HхWхD),max. 840х385х495mm
Weight1),max. 55 kg
Number of drinks 10 elections
Drink volume adjusted, max. 300 ml per portion
Electrical supply ~230 V ± 10%, 50 Hz
Powerconsumption(мах.) 1800 W (3200 W - option FRESH MILK)
Water supply
Water pressure
Connection to water supply line
Hardness
Calcium
0,5-8,5bar(0,05-0,85МPa)
G 3/4’’
0,9 - 1,0 mgeq/l
18 - 20 mg/l
Container products2)
Coffee beans 1,0 kg -
Instant coffee - 0,7 kg
Powdered milk / Granulated milk 1,5 / 0,75 kg 2,2 / 1,1 kg
Chocolate 1,5 kg 2,4 kg
Vanilla 1,0 kg 2,4 kg
Ambient temperature 10 - 40 0С,Relativehumidity80%(withoutcondensation)
1) The weight is indicated for standard equipment, excluding optional equipment.
2)Thequantityofingredientscanbedifferentfromtheoneshowndependingonthespecicweightoftheingredient.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 11
Version 1.1 / December 2017
ТМ
3.0 SAFETY
For safe operation of the vending machine comply with the requirements given in this manual.
3.1 Main provision
• Before putting the vending machine in service always make sure that the operating instructions given
in this manual were read and understood.
• Comply with the instructions given in this manual for vending machine transportation, installation,
maintenance, and service.
• The vending machine is not intended for operation by persons (including children) with physical, sen-
sory or intellectual limitations or without the proper experience and/or knowledge, if only they are not
under the supervision of the person, responsible for their safety, or if only they were trained for the
vending machine operation.
• Damaged power cords should be replaced by the manufacturer only.
• Make sure that the vending machine is installed on a stable horizontal surface.
• Make sure that there’s no less than 80 mm of free space behind the vending machine for air circulation.
• Thevendingmachineisintendedforuseindrypremiseswithambientairtemperaturenolessthan10°С.
• The vending machine uses hot water. Don’t get too close to the vending machine when making a drink.
• Use only cooled fresh long-storage milk (pasteurized, UHT) with 2.5 - 3.6% fat. The milk should be
storedatatemperaturefrom3.5to7°С.ForvendingmachineswithFRESHMILKoptiononly.
• For cleaning of the vending machines use only cleaning agents approved for foodstuff.
• Make sure that the vending machine is cleaned daily to avoid hazards for the consumer.
• The vending machine should be serviced by skilled service technicians only.
• The use of the service key is reserved for skilled service technicians only. When the service key is
inserted in the vending machine, the safety device is switched off. Caution - the danger of injury!
• The power supply plug should be easily accessible.
• Never insert the plug into an outlet if it’s wet or by wet hands.
• Use genuine spare parts only.
• Making changes in the vending machine is prohibited. In such cases, the manufacturer bears no re-
sponsibility for any damages!

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 12
Version 1.1 / December 2017
ТМ
3.2 Service key
When opening the vending machine door the special breaker automatically de-energizes the vending
machine hardware and units. Any operations, carried out with the door open, should be performed by
skilled technicians.
The technicians are responsible for the service key safety. Never leave the service key in the vending
machine. The service key is intended for use by skilled technicians only.
To apply voltage to the vending machine hardware with the door open insert the service key.
Service key installation
1.Inserttheservicekeyintothedoortrip(seeg.3a)andturnitthrough90deg.clockwise(seeg.
3b)untilxation.
2. Service key extraction is carried out in the reverse order.
Fig.3а Fig.3b Fig.3c
3.3 Temperature
 Thevendingmachineusesaboilerthatislledwithhotwater.Thewatertemperatureexceeds90°С.
The temperature of water in the boiler gradually decreases after the vending machine is turned off.
DANGER OF BURNS!
Avoid contact with hot water.
The danger is especially high at the drink discharge hole.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 13
Version 1.1 / December 2017
ТМ
4.0 TRANSPORTATION, INSTALLATION, COMMISSIONING
4.1 Transportation
Since there’s always water in the vending machine water route, drain the water before the transporta-
tion, long storage or replacing of the hydraulic system individual units. Failure to follow these measures
can lead to vending machine damages! Use an original package for the vending machine transporta-
tion.
Always drain water before the vending machine transportation or storage at ambient
airtemperaturebelow1°С!Failuretofollowthisrequirementcanleadtovendingma-
chine breakdown!
Flushing the vending machine’s water tract
Stop the water supply to the vending machine. Use the suitable container for draining water. To drain
water do the following:
1. Cool down the boiler. For the purpose enter the service menu (menu technician) and select setting
[Functional Tests]. Then press the touch button [Cool Boiler]. Start the cooling process by press-
ingtheOKbutton.Afteryoustarttheprocessthemachinewillpumpsufcientamountofwater
through the boiler to cool it down to 45 degrees. This process can be executed for machines with
external water supply as well as for machines with internal water cans.
2. After the boiler has been cooled the machine’s display shows the OK sign, after which you
should-disconnect the machine from water supply or you should remove the water supply pipes
fromthecans/bottles.Itisalsonecessarytoushwaterfromthepipe,whichsupplieswaterfrom
externalwatersupplyvalveorautonomouswatersupplypump,totheoatchamber.Forthepur-
poseremovethepipefromthevalveorpumpanddirectittotheushbucket.Makesurethatall
the water from the pipe is discharged.
3. Aftercooling,ushtheboiler.Forthepurposeentertheservicemenu(menutechnician)andselect
setting [Functional Tests]. Then press the touch button [Empty Boiler].starttheushingprocess
bypressingtheOKbutton.Themachinewillstartpumpingoutwaterfromtheoatchamberand
the rest of the water tract, which supplies water to the boiler.
4. When the given process will be completed, you will see the OK sign on the touch screen. This is
when you should turn the machine OFF.
5. Place a container under the boiler and remove the pipe from the bottom of the boiler by loosening
thexatorscrew.ThenturnthemachineONandwaituntilallthewaterwouldbeushedfromthe
boiler (until the water stops dripping).
6. Turn OFF the vending machine.
7. Reconnect the pipe to the boiler with the help of the tightening screw.
NOTE:whenusinginternalwatersupplyfromcans/bottlesitisalsonecessarytoushtheau-
tonomous function pump. For the purpose, following the cooling process and removal of supply
pipefromthepump,itisnecessarytomanuallypulldowntheoatfromtheoatchamberuntilthe
pumpstartsandholdtheoatfor5-10seconds.Afterthisyoumustreinstallthepipe(tothevalve
or the pump).

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 14
Version 1.1 / December 2017
ТМ
4.2 Installation
ATTENTION! A short circuit caused by water! Mortal danger! Vending machine damage.
Never clean the vending machine by watering it from the hose.
Note:
• Make sure that power supply parameters coincide with characteristics, shown on the vending ma-
chine nameplate, located on the rear side of the casing.
• The vending machine should be connected to the earthed mains.
• Don’t use extension cords for connecting the vending machine to the mains.
Generalrequirementsforinstallation
• Install and operate the vending machine in dry and well-ventilated premises only.
• The vending machine is not intended for use outdoors.
• Before commissioning the vending machine, make sure that the ambient air temperature in the
premises, where the vending machine will be operated, is no lower than 10 0C.
• When choosing the location for the installation make sure the vending machine will be accessible
for servicing.
• Makesurethattheinstallationsurfaceisatandstable,withoutvibrations.
• Adjust the vending machine level by using the four support feet.
• The vending machine should be installed on the non slip surface.
• The outlet for the vending machine mains connection should be easily accessible so that the vend-
ing machine power plug could be rapidly disconnected.
• The ambient air temperature for the vending machine normal operation should be from 10 to 35 0С.
• Make sure that the vending machine rear wall is no less than 80 mm away from the wall.
• •Openthevendingmachinedoorandvisuallycheckthehydrauliccircuittubesandthreadedcon-
nections (see Appendix A). In the case of the hydraulic circuit tube defect or loose connection is
detected the further vending machine use is possible only after the malfunction repair.
Note:
Make sure there’s enough free space in front of the vending machine for fully opening its door.
Installation conditions: Intervals (recommended)
• The side distance from the objects on the left and right of the vending machine should be no less
than 50 mm (with the exception of the milk cooling module).
• The distance from the vending machine rear wall should be no less than 80 mm.
• Thedistancefromtheoortothevendingmachineshouldbenolessthan800mm.
Installation conditions: Water
• Make sure that the vending machine is connected to the cold potable water line (in the case of ex-
ternal water supply)!
• The water line pressure should be from 0.5 to 8.5 bar (0.05 - 0.85 MPa). Pressure exceeding or
lowering is not permitted. If the line pressure is too low or too high, the vending machine will not
operate properly.
• Water temperature at the vending machine inlet should be from 5 to 35 0С.
• The water should satisfy all potable water norms.
• Don’t bend over the water connecting line.

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 15
Version 1.1 / December 2017
ТМ
Installation conditions: Mains voltage
• Admissible mains voltage: ~220 V ± 10% 50 Hz
Fig.4.1
Vending machine unpacking
Get the vending machine from the package, and remove all pack-
aging. Because the vending machine should be transported only in the
original package, it’s recommended to save the packaging. The packag-
ing should be recycled in accordance with current environmental legisla-
tion.
Fig.4.2
4.3 Commissioning
Note:
Only skilled technicians can install and put the vending machine in service. Before installing and putting
the vending machine in service read and understand the instructions given in this manual.
After removing the vending machine from the packaging:
1. open the vending machine door by using the key (the key is secured by a tie to the cup shelf or the
cuparrester,seeg.5.1).
2. remove the vending machine components, included in the scope of supply, from the waste contain-
ers,locatedinthelowerpartofthevendingmachine,(seeg.4.2).
1
2
3
4
5
6
7
8
1-Bafeplate(not-INSTANT);
2-Powercable;
3-Passportvendingmachine;
4-Coffeebeancontainer(not-NSTANT);
5-Siliconetubewithterminal(nozzle);
6-Servicekey;
7-Setofextra(spare)fuses;
8 - Hoffmann clamp (option FRESH MILK).

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 16
Version 1.1 / December 2017
ТМ
3. Before putting to use please remove the transportation bracket,
whichholdsthecoffeegrinderunit,bylooseningthenot(seeg.4.3)
Fig.4.3
1
 4.Toinstallthebafeplate,hangitonthebolt(seeg.4.4pos.1),
which is situated on the left inside wall of the vending machine’s body
under the espresso group.
Fig.4.4
If the transportation bracket would not be removed before the start of operations, this
can cause excessive vibration in machine parts, which can cause premature break-
downs and failures!
5. Connect the vending machine to the external or internal water supply in accordance with the manual.
Close the vending machine door.
6. Connect the vending machine to the grounded mains. The mains technical characteristics are shown
on the vending machine nameplate.
7. Switch on the vending machine by turning the switch on the switching unit (see section 4.1) to the (I)
position.
The components and parts, included in the machine’s package are packed in the waste containers,
insidethemachine(seeg.4.2).

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 17
Version 1.1 / December 2017
ТМ
 4.3.1Installationnenessofgrinding
The coffee beans are crushed using the coffee grinder, which is located underneath the coffee bean
container. When you select a drink, which uses coffee beans, the beans fall into the coffee grinder, where
they are ground using the built-in choppers, going further into the dosing apparatus, which is located in
front of the coffee grinder. From here the coffee is fed into the espresso group.
The quality of grinding of coffee depends on the rotation of the screw, located on the coffee grinder (see
g.4.5and4.6position1).Turn the screw clockwise grind more (smaller particles) or counter clock-
wisetogrindless(largerparticles)–(seeg.4.5).
Set up the grinding of the coffee grinder.
After setting the grinding quality, check the quality of coffee. If needed please set again to achieve the
required level of grinding.
Note:Thesmallertheparticlesizethelongerwillbetheextractandthedrinkwillbemoresatu-
rated.
Settingthegrindingparametersforthersttime:
Turn the regulatory screw clockwise and bring the blades as close as possible (turn all the way). Then
turning the screw counter clockwise loosen the upper disk by 540-630 degrees (one and a half turn or one
and a half + quarter turn).
For more detailed settings of coffee grinder you can carry out the following actions I the given sequence:
change the position of the regulatory screw (to change the position of the upper disk of the coffee grinder
to a certain angle) and then make a drink and taste it.
Fig.4.5
1
2
Fig.4.6
If the level of grinding will be too low (very small particles),
thecoffeegrinderwillnotbeabletogroundsufcientamountof
coffee, which would lead to “Grinder” error and will block the dis-
pensing of coffee. In such case you should increase the level of
grinding. For the purpose you must loosen the upper disk by turn-
ing it counter clockwise.
If the particle size is large the coffee will be less concentrat-
ed (less saturated). The time of working of coffee grinder will be
around 3-4 seconds. The thickness of output jet will be 3-4mm.
in this case you can also cause the leaking of the coffee group,
because very large particles of coffee damage the gasket of the
piston. In such cases you should decrease the particle size – turn
the upper disk clockwise.
The optimum time of grinder functioning is: 5-6 seconds
if coffee dosage is set to position 3 and 6-7 seconds if the
coffeedosageissettoposition4(seethenextsection).

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 18
Version 1.1 / December 2017
ТМ
The ground coffee is fed into the dosing apparatus, which ac-
cumulates ground coffee up to a certain level. When the level is
reached the electromagnetic valve opens and the accumulated
dose of coffee is sent to the espresso group.
The dosing apparatus helps you set the required amount of cof-
fee for the espresso group according to the desired drink. The vol-
ume of coffee is regulated with the help of the dosing apparatus’s
cam(seeg.4.6pos.2andg.4.7).Thepositionscanbefrom1
to 6 (MAXIMUM). At the same time it is prohibited to set the cam
to positions 5 or 6 without increasing the volume of the boiling
chamber (see further)! THIS CAN DAMAGE THE ESPRESSO
GROUP!
Fig.4.7
PLEASE NOTE THAT CHANGES IN LEVEL OF GRINDING AND TASTE ARE NOT NOTICED RIGHT
AWAY. ONLY AFTER 3 CYCLES YOU CAN FEEL THE DIFFERENCE (after changing the grinding
parameters, discard two drinks and taste the third one to feel the differer.
It is highly recommended to change grinding parameters discreetly, turning the coffee grinder’s disk by
10-20 degrees each time.
It is STRICTLY PROHIBITED to set the cam to positions 7 or higher!
The recommended settings for the cam are positions 3 or 4. This means a dose of 6.5-7.5 grams
per portion (per drink).
The weight of the ground coffee inside the dosing apparatus depends on the quality of grinding and type
of coffee.
After each re-setting of dosing apparatus, please weigh the amount of ground coffee according to the
current manual.
Depending on the weight of the coffee, you might need to regulate (adjust) the volume of espresso
group’s chamber

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 19
Version 1.1 / December 2017
ТМ
 4.3.2Airnetuningvalveadjustment
Milkfoamadjustment
To adjust the milk foam on the vending machine do the following:
- Make sure that the milk container is installed in the refrigerator near the vending machine.
- Make sure that the milk is fresh and unspoiled.
- Make sure that the silicone milk supply tube at the vending machine inlet is not pinched.
- Make sure that the vending machine milk system was washed beforehand, and all its parts includ-
ing the cappuccinatore are clean. Inspect the tubes for any sour or coagulated milk.
Make sure that all the above items are observed and proceed to the milk foam adjustment by sequen-
tially executing the following operations:
 - Openthevendingmachinedoor;
 - Inserttheservicekeyintothedoortrip;
- Switch the vending machine on (see the manual) and wait for the boiler to heat up to the temper-
aturespeciedinsettings.To achieve the optimum foam performance the steam boiler temperature
should be set to 130°С;
 - Adjustthefoamcontrolknobtothemiddleposition(g.4.8).Fordoingthisturnthecontrolknob
all the way to the left and then all the way to the right. Set the control knob approximately to the middle
position;
Fig.4.8 - Milk foam adjustment

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 20
Version 1.1 / December 2017
ТМ
 - Selectadrinkwiththeadditionoffreshmilk.Asthedrinkismade,observethemilkowfromthe
cappuccinatoreadapter.Theowshouldbeuniform,withoutany"pulsations"or"jerks"(thefoamshould
bepouredintoacupintheformofasmoothstreamwithoutanysplashesorinatingbubbles).
- Observe the cappuccinatore adapter - it's manufactured of transparent plastic to facilitate its con-
tamination level inspection and adjustment process.
Fig.4.9
 - Atthecappuccinatoreandtheadapterjointthere'sagap(seeg.4.9).Thefoamshouldn'trunout
of the adapter during the operation.
- If there's no foam coming out, but a slightly foamed milk, turn the foam control knob counter-clock-
wise. By doing this you are slightly opening the air delivery tap, and the milk foam should start coming out.
- If the foam is squirting out from the above-mentioned gap, this means that there's too much air
supplied. Turn the control knob clockwise.
The optimal foam adjustment:
The foam is streamed out uniformly and without any pulsations. The foam doesn’t overow out-
side the cappuccinatore adapter and should have a ne-porous structure.
When lowering a stirrer to a cup it stands in the foam without declining (the height of the foam
should be higher than the middle of the stirrer).
If having trouble adjusting the foam in accordance with the above instruction, proceed to the following
section:“Offsettingtherangeofadjustmentsontheairnetuningvalve”(seebelow).
