Uplift Desk FRM066 User manual

Step 1 - Attach Keypad to Desktop
There are keypad attachment holes pre-drilled into UPLIFT desktops. The pre-drilled
holes are located on both the left and right sides so you can choose which side of the
desktop you’d like to attach the keypad. Note: Typically the desk is upside down when
assembling and attaching the keypad, so if this is the case the keypad will be on the
opposite side once the desk is ipped upright.
If your desktop doesn’t have pre-drilled keypad holes, refer to the Optional Desktop
Drilling Instructions at the bottom of the page.
A. Align the keypad mounting holes with the pre-drilled holes in the desktop.
B. Being careful not to overtighten the screws to avoid stripping (especially if using a
drill to insert the screws), attach the keypad to the desktop with two #10x5/8” wood
screws provided with your desk and labeled H14.
Advanced Comfort
Angled Keypad
SKU: FRM066
Package Contents
Keypad (2) #10x5/8’’ Wood Screws (provided with desk and labeled H14)
Desk shown upside down
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7
C3 C4 C5
C9
H4a
H7
C6
H1 H2 H3 H5
H4b
H6
C7

AI-FRM066-1.0
Step 2 - Perform Desk Reset Procedure
IMPORTANT: Before using your desk, perform the following Desk Reset to ensure the desk legs are calibrated properly
after assembly.
A. Hold the DOWN button until the desk reaches its lowest height and then release the button.
B. Press and hold the DOWN button again for up to 15 seconds until the keypad display shows , then release the
button.
C. Press and hold the DOWN button again until the desk lowers slightly then rises slightly. Release the button. If the desk
didn’t move, try the reset procedure again.
D. Your desk is now ready for use!
Optional Desktop Drilling Instructions: If you are using your own desktop
or you would like to attach the keypad in a different location than the pre-
drilled holes, position the keypad on the desktop and make a pencil mark at
the center of each keypad mounting hole. Drill no deeper than 1/2” into the
desktop to prevent damaging the desktop surface (we recommend wrapping
a piece of tape around your drill bit 1/2” from the tip and stopping just before
the tape touches the desktop). Drill pilot holes using a 1/8” drill bit.
X
0.5”
Tape
Step 3 - Keypad Settings &
Programming
Scan the QR code or visit https://www.
upliftdesk.com/desk-assembly-and-
programming/ to see Settings and
Programming instructions.
Email [email protected] with questions | ©2022 UPLIFT Desk®. All Rights Reserved
Safety and Warnings
See the Safety and Warnings listed
on the assembly instructions
included with your desk frame
