Uplift Desk CHR466 User manual

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Allen wrenches
(sizes: 4 mm, 5 mm, 6mm)
Base
Casters (qty 5)
Cover plate
(optional)
Arms (qty 2)Back
M6x25 screws (qty 8)
M8x30 screws (qty 3)
M6x20 screws (qty 2)
M6 washers (qty 8)
M8 washers (qty 3)Cylinder
Headrest
Step 1
With the Base turned upside down, insert the Caster stems into the
holes on the Base, and press them rmly to secure them in place.
Flip the Base, so the Casters are on the oor, and insert the Cylinder
into the Base in the orientation shown with the smaller diameter
end up. Be cautious around the small end of the Cylinder to avoid
getting grease on you or your clothes.
Step 2
Place the Seat upside down on the edge of a stable surface, such
as a table.
Insert the tab of the Back into the slot on the Seat and line up the
holes on each. Have a friend help keep the Seat steady while you
attach the Back to it. Using the 6 mm Allen wrench, attach the
Back to the Seat with three M8x30 screws and three M8 wash-
ers. Start all screws loosely, then tighten them all using the 6 mm
Allen wrench.
Step 3
Note: The screws and washers may arrive inserted into the
Seat. Simply remove, and then use to attach the Arms to the
Seat. Line each Arm with the holes on either side of the seat.
They should angle towards the front of the chair when installed.
Attach them using the M6x25 screws and M6 washers you
removed earlier. Start screws loosely, then tighten using the 5
mm Allen wrench.
Step 4
Flip the chair assembly from Steps 2 and 3 right-side up, and
lower it onto the Cylinder.
Press down on the seat (or sit on it) to secure it in place on the
Cylinder.
Step 5
If you don’t want to install the Headrest, snap the Cover plate in
place where shown. This will cover the area where the Headrest
would have attached.
If you would like to install the Headrest, line it up with the screw
holes at the top of the Back and attach with the
two M6x20
screws.
Start both screws loosely, then tighten them using the 4
mm Allen wrench.
Seat
Package Contents
Facet Ergonomic Chair
SKU: CHR466

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
Adjustment Guide
Seat Height
When seated, nd the lever on your right-hand side and lift it up to
raise or lower the seat.
Your feet should rest at on the ground. To nd your optimal
settings, refer to our Ergonomic Calculator:
www.upliftdesk.com/ergonomic-calculator/
Back Tilt
Tilt Tension- Twist the knob on the right-hand side to adjust the Tilt
tension. Twist it clockwise for stronger tension and counterclock-
wise to reduce tension.
Tilt Lock-
Recline to your desired position. Turn the knob on the left-
hand side clockwise to lock the back at that position. Turn it coun-
terclockwise to unlock, and then lean back slightly to disengage.
There are six recline positions for the backrest.
Armrest Adjustments
Height- Press the button on the arm to raise or lower the armrest.
Depth- Grasp armpads and push forwards or backwards to desired
placement.
Angle- Grasp armpads and rotate them inwards or outwards to ad-
just angle.
Seat Depth
To change your Seat Depth, unlock the seat position by pulling out
the lever located under your seat on the right-hand side. Slide the
seat forward or backward as you desire. Release the lever to lock.
To return the seat to the back position, pull the lever out and lift
yourself off of the seat. The seat will slide back on its own.
Lumbar Depth
Twist both knobs on the back frame to adjust the depth of the Lum-
bar support cushion.
Back & Headrest Height
There are seven height settings for the Back. To raise the Back,
grasp it on both sides and pull up, one click at a time, until you reach
your desired height. To lower the Back, raise it to the maximum
height, then allow it it to lower itself down.
Note: If the Back will not lock when returned to the lowest position,
pull the seat forward to allow the back to reach its lowest position.
To raise or lower the Headrest, hold both sides and slide up or down
to your desired height. This is most easily done while standing be-
hind the chair.

© UPLIFT Desk • 800-349-3839 • [email protected] • upliftdesk.com
CAUTION: Read all instructions before assembly. Failure to assemble properly may result in
damage or personal injury.
WARNING: This product’s maximum weight capacity is 250 lb (113.4 kg). DO NOT exceed the
maximum weight capacity.
CAUTIONS & WARNINGS
!
!
!
Normal- Vacuum your fabric seat as needed. Vacuuming picks up dust and reduces the need for professional cleaning.
Ink Stains- Apply a small amount of isopropyl alcohol to a clean and damp absorbent cloth. Start at the outside of the ink
stain and work towards the center. Apply pressure, but do not rub too vigorously. As you work and your cloth soaks up
the ink from the fabric stain, it’s important to use a clean section of the cloth or the stain will spread. Apply more isopropyl
alcohol to the cloth as needed. If the ink stain persists, try using acetone. Note: This procedure is not intended for day-to-
day cleaning.
Spot Cleaning- Immediately soak up the stain with a soft, absorbent cloth. Do not dry the stain completely, as this may
set it in the fabric permanently. The longer a stain is allowed to remain on the fabric, the more difcult it is to remove.
Oil-based Stains- Use a dry cleaning solution applied with a damp clean cloth or sponge. Test the cleaning solution on a
small, concealed spot on the fabric rst before attempting on a larger area. If there is no spotting, ringing, or damage to
the fabric or its dyes, apply the cleaning solution to the soiled area with light, quick strokes. Begin at the outside of the
stain and work towards the middle, making sure you use a clean part of the cloth as you work.
Water-based Stains- Use a water-based fabric cleaner (specically made for cleaning fabric) or a solution of mild, alkaline,
warm soapy water. Make sure that the soap and water mixture is not overly soapy. Test on a small, concealed section
of the fabric rst before applying to the main area. Work the cleaner or soap/water mixture into the stain on the fabric,
starting from the outside of the fabric and working your way to the middle.
*A note about fabric care

512-614-3152
800-349-3839
[email protected]
upliftdesk.com
Work Better. Live Healthier
Copyright Notice: This guide is a component of the UPLIFT Facet Chair. This guide is a part of the scope of delivery, even if the item is resold. This
guide is also available on the UPLIFT Desk website: upliftdesk.com. Excerpts or copies may not be forwarded to third parties or used in any other
published form without the prior written consent of UPLIFT Desk. These instructions are subject to United States copyright law.
©
®
AI-CHR466-1.0.1
