V2 AYROS series User guide

ZIS332
IL 373-1
EDIZ. 22/08/2018
I
ATTUATORE ELETTROMECCANICO
230V/120V IRREVERSIBILE PER
CANCELLI SCORREVOLI FINO A
1200 KG DI PESO
GB
230V/120V ELECTRO-MECHANICAL
IRREVERSIBLE RACK ACTUATOR
FOR SLIDING GATES UP TO 1200 KG
F
OPERATEUR ELECTROMECANIQUE
230V/120V IRREVERSIBLE A
CREMAILLERE POUR PORTAILS
COULISSANTS JUSQU’A 1200 KG DE
POIDS
E
MOTOR ELECTROMECANICO
230V/120V IRREVERSIBLES A
CREMALLERA PARA PUERTAS
CORREDERAS HASTA 1200 KG DE
PESO
AYROS

200 mm
343 mm
178 mm
226 mm
334 mm
3 mm 328 mm
200 mm
343 mm
160 mm
74 mm
50 mm
100 mm
128 mm
206 mm
283 mm

ITALIANO
- 26 -

ENGLISH
- 27 -
INDEX
1 - GENERAL SAFETY INFORMATION ........................................................................................................................
1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED..........................................................
1.2 - TECHNICAL ASSISTANCE SERVICE...................................................................................................................
1.3 - EU DECLARATION OF CONFORMITY ...............................................................................................................
2 - TECHNICAL DATA ..................................................................................................................................................
3 - INSTALLATION OF THE MOTOR............................................................................................................................
3.1 - INSTALLATION OF THE MOTOR .......................................................................................................................
3.2 - MOUNTING THE RACK ...................................................................................................................................
3.3 - FIXING OF THE MOTOR...................................................................................................................................
3.4 - INSTALLING THE MAGNETIC LIMIT SWITCHES .................................................................................................
3.5 - MOTOR OVERRIDING SYSTEM ........................................................................................................................
3.6 - INSTALLATION LAYOUT ...................................................................................................................................
4 - CONTROL UNIT......................................................................................................................................................
4.1 - POWER SUPPLY...............................................................................................................................................
4.2 - FLASHING LIGHT.............................................................................................................................................
4.3 - COURTESY LIGHTS..........................................................................................................................................
4.4 - ACTIVATION INPUTS........................................................................................................................................
4.5 - STOP...............................................................................................................................................................
4.6 - PHOTOCELLS ..................................................................................................................................................
4.7 - SAFETY RIBBONS ............................................................................................................................................
4.8 - EXTERNAL AERIAL...........................................................................................................................................
4.9 - ELECTRICAL CONNECTION..............................................................................................................................
4.10 - PLUG IN RECEIVER ........................................................................................................................................
4.11 - ADI INTERFACE .............................................................................................................................................
5 - CONTROL PANEL ...................................................................................................................................................
5.1 - DISPLAY ..........................................................................................................................................................
5.2 - USE OF THE KEYS FOR PROGRAMMING..........................................................................................................
6 - ACCESSING THE CONTROL UNIT SETTINGS.........................................................................................................
7 - QUICK CONFIGURATION.......................................................................................................................................
8 - LOADING THE DEFAULT PARAMETERS ................................................................................................................
9 - INSTALLATION MENU............................................................................................................................................
9.1 - AUTOMATIC LEARNING OF THE RUN LIMITS ...................................................................................................
9.2 - MANUAL HANDLING ......................................................................................................................................
10 - EMERGENCY DEAD MAN OPERATION...............................................................................................................
11 - READING OF CYCLE COUNTER ...........................................................................................................................
11.1 - SIGNAL OF SERVICE REQUIRED .....................................................................................................................
12 - PROGRAMMING THE CONTROL UNIT................................................................................................................
13 - OPERATION DEFECTS ..........................................................................................................................................
14 - TESTING AND START-UP......................................................................................................................................
15 - MAINTENANCE....................................................................................................................................................
16 - DISPOSAL OF THE PRODUCT..............................................................................................................................
28
29
30
30
31
32
32
33
33
34
35
35
36
36
36
36
36
36
37
37
37
38
39
39
40
40
40
41
41
41
42
42
42
42
43
43
44
49
50
50
50

ENGLISH
- 28 -
AUTOMATION DEVICE
INSTALLERS MANUAL
1 - GENERAL SAFETY INFORMATION
mPrior to proceeding with installation, it is essential the
instructions be read in full, since they contain important
information regarding safety, installation, use and
maintenance.
AUTOMATION MUST BE IMPLEMENTED IN COMPLIANCE WITH
THE EUROPEAN REGULATIONS IN FORCE:
EN 60204-1, EN 12445, EN 12453, EN 13241-1, EN 12635
• The installer must provide for a device (es. magnetotermical
switch) ensuring the omnipolar sectioning of the equipment
from the power supply. The standards require a separation of
the contacts of at least 3 mm in each pole (EN 60335-1).
• The plastic case has an IP44 insulation; to connect flexible or
rigid pipes, use pipefittings having the same insulation level.
• Installation requires mechanical and electrical skills, therefore it
shall be carried out by qualified personnel only, who can issue
the Compliance Certificate concerning the whole installation
(Machine Directive 2006/42/CEE, Annex IIA).
• Also the automation upstream electric system shall comply with
the laws and rules in force and be carried out workmanlike.
• We recommend to make use of an emergency button, to be
installed by the automation (connected to the control unit
STOP input) so that the gate may be immediately stopped in
case of danger.
• For correct installation of the system, we recommend following
the instructions issued by UNAC very carefully
• This instruction manual is only for qualified technicians, who
specialize in installations and automations.
• The contents of this instruction manual do not concern the end
user.
• Every programming and/or every maintenance service should
be done only by qualified technicians.
• Anything not expressly described in these instructions is
prohibited; unforeseen uses may be a source of danger to
people and property.
• Do not install the product in explosive environments and
atmospheres: the presence of inflammable gases or fumes is a
serious safety hazard.
• Do not make any modifications to any part of the automation
device, or the accessories connected to it, unless described in
this manual.
• Any other modifications will void the warranty on the product.
• The installation steps should be conducted so as to avoid rainy
weather, which can expose electronic circuits to dangerous
water seepage.
• All operations requiring the casing of the device to opened
should be performed with the control unit disconnected from
the electricity supply and with a warning notice displayed, for
example: ”CAUTION, MAINTENANCE IN PROGRESS”.
• Avoid exposing the device close to sources of heat and flame.
• In the event of interventions on automatic or differential
breakers or fuses, it is essential that faults be identified and
resolved prior to resetting. In the case of faults that cannot
be resolved using the information to be found in this manual,
consult the V2 customer assistance service.
• V2 declines all responsibility for failure to comply with good
construction practice standards in addition to structural
deformation of the gate that might occur during use.
• V2 reserves the right to make modifications to the product
without prior warning.
• Installation/maintenance personnel should wear individual
protection devices (IPDs), such as overalls, safety helmets, boots
and gloves.
• The ambient operating temperature should be that indicated in
the technical characteristics table.
• The automation device should be shut down immediately in
the event of any anomalous or hazardous situation; the fault
or malfunction should be immediately reported to the person
responsible.
• All safety and hazard warnings on the machinery and
equipment should be complied with.
• Electromechanical actuators for gates are not intended to be
used by people (including children) with diminished physical,
sensory or mental capacity, or lacking in experience or
knowledge, unless they are under supervision or have been
instructed in use of the actuator by a person responsible for
safety.
V2 has the right to modify the product without previous
notice; it also declines any responsibility to damage or
injury to people or things caused by improper use or wrong
installation.

ENGLISH
- 29 -
1.1 - PRELIMINARY CHECKS AND IDENTIFICATION OF THE TYPE TO BE USED
The automation device should not be used until installation, as specified in “Testing and start-up”, has been performed.
It should be remembered that the device does not compensate for defects caused by improper installation, or poor maintenance, thus, prior
to proceeding with installation, ensure that the structure is suitable and meets current standards and, if necessary, perform any structural
modifications aimed at the implementation of safety gaps and the protection or segregation of all crushing, shearing and transit zones, and
verify that:
• The gate has no friction points, either during closing or opening.
• The gate must be equipped with mechanical stoppers.
• The gate is well balanced, i.e. there is no tendency to move spontaneously when stopped in any position.
• The position identified for fixing the motor reducer allows easy and safe manual manoeuvring, compatible with the size of the motor
reducer itself.
• The support on which the automation device will be fixed is solid and durable.
• The mains power supply to which the automation device is connected has a dedicated safety earthing system and differential breaker
with tripping current less than or equal to 30 mA (the breaker gap distance should be greater than or equal to 3 mm).
Warning: The minimum safety level depends on the type of use; please refer to the following outline:
CLOSURE USE TYPE
TYPE OF ACTIVATION
COMMANDS
GROUP 1
Informed people
(use in private area)
GROUP 2
Informed people
(use in public area)
GROUP 3
Informed people
(unlimited use)
Man-present command A B Not possible
Remote control and closure in
view (e.g. infrared)
C or E C or E C and D or E
Remote control and closure not
in view (e.g. radio)
C or E C and D or E C and D or E
Automatic control
(e.g. timed closure control)
C and D or E C and D or E C and D or E
GROUP 1 -Only a limited number of people are authorised for use, and closure is not in a public area. Examples of this type are gates inside
business premises, where the sole users are employees, or a part of them who have been suitably informed.
GROUP 2 - Only a limited number of people are authorised for use, but in this case, closure is in a public area. An example of this may be a
company gate that accesses onto a public street, and which is only used by employees.
GROUP 3 - Anyone can use the automated closure, which is thus located on public land. For example the access gate to a supermarket or
an office, or a hospital.
PROTECTION A - Closure is activated by means of a control button with the person present, i.e. with maintained action.
PROTECTION B - With the person present, closure is activated by a command controlled by means of a key-switch or the like, in order to
prevent use by unauthorised persons.
PROTECTION C - Restricts the force of the leaf of the door or gate. I.e., in the case of the gate striking an obstacle, the impact force must
fall within a curve established by the regulations.
PROTECTION D - Devices, such as photocells, capable of detecting the presence of people or obstacles. They may be active on just one side
or on both sides of the door or gate.
PROTECTION E - Sensitive devices, such as footboards or immaterial barriers, capable of detecting the presence of a person, and installed in
such a way that the latter cannot be struck in any way by a moving leaf or panel. These devices should be active within the entire “danger
zone” of the gate. The Machinery Directive defines “Danger Zone” as any zone surrounding and/or near machinery where the presence of
an exposed person constitutes a risk to the health and safety of that person.
The risk analysis should take into consideration all danger zones for the automation device, which should be appropriately
protected and marked.
In a clearly visible area, apply a sign with information identifying the motorised door or gate.
The installer should provide the user with all the information relating to automatic operation, emergency opening and
maintenance of the motorised door or gate.

ENGLISH
- 30 -
1.2 - TECHNICAL ASSISTANCE SERVICE
For any installation problem please contact our Customer Service
at the number +39-0172.812411 operating Monday to Friday
from 8:30 to 12:30 and from 14:00 to 18:00.
1.3 - EU DECLARATION OF CONFORMITY
AND DECLARATION OF INCORPORATION OF
PARTLY COMPLETED MACHINE
Declaration in accordance with Directives: 2014/35/UE (LVD);
2014/30/UE (EMC); 2006/42/CE (MD) ANNEX II, PART B
The manufacturer V2 S.p.A., headquarters in Corso Principi di
Piemonte 65, 12035, Racconigi (CN), Italy
Under its sole responsibility hereby declares that:
the partly completed machinery model(s):
AYROS400D-230V
AYROS800D-230V
AYROS1200D-230V
AYROS1200D-120V
Description: electromechanical actuator for sliding gates
• is intended to be installed on sliding gates, to create a machine
according to the provisions of the Directive 2006/42/EC.
The machinery must not be put into service until the final
machinery into which it has to be incorporated has been
declared in conformity with the provisions of the Directive
2006/42/EC (annex II-A).
• is compliant with the applicable essential safety requirements
of the following Directives:
Machinery Directive 2006/42/EC (annex I, chapter 1)
Low Voltage Directive 2014/35/EU
Electromagnetic Compatibility Directive 2014/30/EU
Directive ROHS2 2011/65/CE
The relevant technical documentation is available at the national
authorities’ request after justifiable request to:
V2 S.p.A.
Corso Principi di Piemonte 65, 12035, Racconigi (CN), Italy
The person empowered to draw up the declaration and to provide
the technical documentation:
Antonio Livio Costamagna
Legal representative of V2 S.p.A.
Racconigi, il 01/06/2015

ENGLISH
- 31 -
2 - TECHNICAL DATA
AYROS
400D-230V
AYROS
800-230V
AYROS
1200-230V
AYROS
1200-120V
Gate maximum weight 400 kg 800 kg 1200 kg 1200 kg
Power supply 230Vac / 50Hz 230Vac / 50Hz 230Vac / 50Hz 120Vac / 60Hz
Maximum power 350 W 500 W 600 W 600 W
Full load current 1,7 A 2 A 2,6 A 4,3 A
Running capacitor 8 μF 10 μF 12 μF 36 μF
Start off capacitor 18 μF 18 μF 25 μF 75 μF
Gate maximum speed 0,16 m/s 0,16 m/s 0,16 m/s 0,18 m/s
Maximum thrust 400 N 670 N 950 N 950 N
Duty cicle 30 % 30 % 30 % 30 %
Pinion M4 - Z18 M4 - Z18 M4 - Z18 M4 - Z18
Operation temperature -20 ÷ +55 °C -20 ÷ +55 °C -20 ÷ +55 °C -20 ÷ +55 °C
Weight 14 kg 15 kg 16 kg 16 kg
Protection IP44 IP44 IP44 IP44
Maximum load on 24 Vac attachments 10 W 10 W 10 W 10 W
Protection fuses 10 A 10 A 10 A 15 A

ENGLISH
- 32 -
3 - INSTALLATION OF THE MOTOR
3.1 - POSITIONING OF THE MOTOR
To fix AYROS, follow the instructions below:
1. use the measurements indicated in the drawing for the
foundations
2. Arrange for one or two pipes for the passage of electric cables
3. Assemble the 4 clamps on the anchoring plate and fix them
with the 4 bolts issued with the motor
4. Pour the concrete and position the anchoring plate
mWARNING: check that the plate be on a perfectly
levelled surface and parallel to the gate
5. Wait for the complete setting of the concrete
6. Unscrew the bolts fixing the base to the clamps and put the
motor on the plate
7. Adjust the 4 grains to make the motor be perfectly levelled
8. Control that the motor is perfectly parallel to the gate, then
insert the 4 washers Rand lightly screw the 4 bolts D
m WARNING: put the washer G into the hole for the
passing of the cables as shown in the picture. Pierce the
washer to let the cable to be connected to the control
unit pass, paying attention to the dimensions in order to
avoid the entrance of insects and other small animals.
50 mm200 mm
20 mm343 mm
60mm
10cm
30cm
10cm




ENGLISH
- 33 -
3.2 - MOUNTING THE RACK
1. Release the motor and turn the gate completely open.
2. Fix all the rack elements to the gate, making sure that
they stand at the same height than the motor pinion.
The rack MUST BE positioned 1 or 2 mm over the
pinion of the motor all the gate length.
3.3 - FIXING OF THE MOTOR
Check the following points:
1. the motor must be on a levelled surface and perfectly
parallel to the gate
2. the distance between pinion and rack must be
1 or 2 mm. If needed, adjust the 4 grains
3. the rack must be trued up with the pinion of the motor
4. the minimum distance between the maximum overall of
the gate and the case of the pinion of the motor must
be of at least 5 mm
5. Check the above indicated conditions and proceed
fixing the 4 bolts Danchoring the motor to the plate.
97 mm
2 mm
>5 mm
D

ENGLISH
- 34 -
3.4 - INSTALLING THE MAGNETIC LIMIT
SWITCHES
mWARNING: For your safety, it is necessary that the gate
is equipped with mechanical stoppers.
If the gate is not equipped with these stoppers, an erratic
movement past the range limit may cause the gate to fall.
Install the supplied magnet holder on the rack in a way that, in
the opening and closing limit positions, the magnet be positioned
next to the magnetic sensor behind the hood (as near as possible
to the hood).
The supplied magnets have been colored differently in order to be
distinguished from each other:
BLUE MAGNET = RIGHT LIMIT SWITCH (DX)
RED MAGNET = LEFT LIMIT SWITCH (SX)
The type of limit switch (RIGHT/LEFT) depends on the position
of the limit switch towards the motor, independently from the
opening sense.
mWARNING: Once checked the proper working of the
system, we suggest to weld the end-of-stroke brackets on
the rack.
DXSX
DXSX
Max 38 mm
102 mm

ENGLISH
- 35 -
3.5 - MOTOR OVERRIDING SYSTEM
In case of absence of current, the gate can be released by
operating on the motor:
1. Open the hatch of the lock Jin front of the motor
2. Insert the key Kin the lock and turn clockwise to open
the hatch of the release on the side
3. Insert the key Linto the hole and turn clockwise until
reached the limit switch
4. At this point you can manually move the gate
To restore the automation, proceed as follows:
1. Bring the gate to the fully closed position
2. turn the key Lanticlockwise until reached the limit
switch, then draw it out
3. turn the key Kanticlockwise closing the hatch of the
lock, then draw it out
4. Close the lock with the hatch J
3.6 - INSTALLATION LAYOUT
1 3 E
5
4
A
B
F
D
2
C
LENGTH OF THE CABLE < 10 metres from 10 to 20 metres from 20 to 30 metres
Power supply 230V 3G x 1,5 mm23G x 1,5 mm23G x 2,5 mm2
Photocells (TX) 2 x 0,5 mm22 x 0,5 mm22 x 0,5 mm2
Key switch 4 x 0,5 mm24 x 0,5 mm24 x 0,5 mm2
Photocells (RX) 2 x 0,5 mm22 x 0,5 mm22 x 0,5 mm2
Flashing light 2 x 1,5 mm22 x 1,5 mm22 x 1,5 mm2
Antenna (integrated into the flashing light) RG174 RG174 RG174
A
B
C
D
E
F
1
2
3
4
5
Key switch
Pillar photocells
Pillar-mounted digital radio switch
Safety edges
WES-ADI module (via radio management of edges)
WES sensors
Motor
Transmitter
Receiving module
Photocells
Flashing light
COMPONENTS ADDITIONAL ACCESSORIES
L K J

ENGLISH
- 36 -
4 - CONTROL UNIT
PD19 is provided with a display that, not only makes
programming simple, but also allows a continuous monitoring of
the input statuses; in addition, thanks to a menu structure, the
working schedule and the operation logic can be set easily.
In compliance with the European standards concerning electrical
safety and electromagnetic compatibility (EN 60335-1,
EN 50081-1 and EN 50082-1) it has been equipped with the low
voltage circuit total electric insulation (motors included) from the
network voltage.
Other characteristics:
• Obstacle detection function
• Automatic learning of the limit switch position
• Tests for safety devices (photocells, safety ribbons and triac)
before each opening
• Deactivation of safety inputs through the configuration menu:
no jumper is required for terminals concerning safety devices
that have not been installed, yet. You will only need to disable
this function from its relevant menu
• Synchronized operation of two motors using the SYNCRO
optional module
mInstallation of control unit and safety devices must
be carried out with power disconnected.
4.1 - POWER SUPPLY
The control unit must be fed by a 230V - 50Hz electric line,
protected by a differential magnetothermal switch complying with
the law provisions in force.
Connect power supply cables to terminals Land Nof PD19
control unit.
4.2 - FLASHING LIGHT
PD19 control unit provides for a 230V - 40W Flashing light
equipped with intermittence inside.
Connect Flashing light cables to terminals B1 and B2 of the
control unit.
4.3 - COURTESY LIGHTS
Thanks to the output COURTESY LIGHT the control unit allows
the connection of an electric appliance (e.g. courtesy light or
garden lights), controlled automatically or by means of the special
transmitter key.
The output COURTESY LIGHT is a simple N.O. contact with no
power supply.
Connect the cables to terminals B3 and B4.
4.4 - ACTIVATION INPUTS
PD19 control unit is equipped with two activation inputs (START
and START P.), whose operation depends on the programmed
operation modes (see Strt item of programming menu):
mWARNING: If you use maintained command devices
(magnetic loop detectors, timers, presence detectors, etc.)
clock mode must be used (parameter Strt = oroL).
Standard mode
START = START (a command will cause the complete
opening of the gate)
START P. = PEDESTRIAN START (a command will cause the
partial opening of the gate)
Open/Close command
START = OPENING (always controls the gate opening)
START P. = CLOSING (always controls the gate closing)
This is an impulse command, that is to say that an impulse will
cause the complete gate opening or closing.
Manned operation
START = OPENING (always controls the gate opening)
START P. = CLOSING (always controls the gate closing)
This is a monostable command, that is to say, the gate will be
opened or closed as long as the contact is closed and it will
immediately stop as the contact is open
Timer mode
This feature allows you to program time slots during the day
for the gate to be open by using an external timer or other
maintained command devices (e.g. magnetic loop detectors or
presence detectors).
START = START (a command will cause the complete opening of
the gate)
START P. = PEDESTRIAN START (a command will cause the partial
opening of the gate)
The gate stays open (completely or partially) while the contact is
closed on input; as soon as the contact is open the pause time
count down will start, after which the gate will be closed again.
ATTENTION: Automatic closing must be enabled
NOTE: If the parameter P.APP = 0the timer connected to START
P. does not cause the opening, but can inhibit the automatic
closing at preset times.
In all modes, inputs must be connected to devices having
normally open contacts.
Connect cables of device controlling the START input between
terminals M1 (START) and M4 (COM) of the control unit.
Connect cables of device controlling the START P. input between
terminals M2 (START P.) and M4 (COM) of the control unit.
The START input function can also be activated by pressing hkey
(outside the programming menu) or by means of a remote
control stored on channel 1 of MR receiver.
The START P. input function can also be activated by pressing i
key (outside the programming menu) or by means of a remote
control stored on channel 2 of MR receiver.

ENGLISH
- 37 -
4.5 - STOP
For a better safety, you can fit a stop switch that will cause the
immediate gate stop when activated. This switch must have a
normally close contact that will get open in case of operation.
In case the stop switch is operated while the gate is open, the
automatic closing function will always be disabled. To close the
gate again, you will need a start command.
Connect the stop switch cables between terminal M3 and M4 of
the control unit.
The STOP switch function can be activated by means of a remote
control stored on channel 3 of MR receiver
4.6 - PHOTOCELLS
The control unit considers two kinds of photocells, depending on
the terminal to which they are connected:
Photocell 1
Photocells installed on the gate inner side, which are active both
during the opening and the closing phase. When photocells 1
operate, the control unit stops the gate; as soon as the photocell
beam is free, the control unit will open the gate completely.
mWARNING: Type 1 photocells must be installed so that
they completely cover the opening area of the gate.
Photocell 2
Photocells installed on the external gate side and which are active
during the closing phase only. When photocells 2 operate, the
control unit opens the gate immediately, without waiting for
release.
PD19 control unit supplies a 24Vac power supply to photocells
and it can perform a photocell operation test before starting the
gate opening phase. Photocell power terminals are protected by
an electronic fuse that stops current in case of overload.
• Connect power supply cables of photocells transmitter
between terminals M11 and M12 of the control unit.
• Connect power supply cables of photocells receiver between
terminals M10 and M11 of the control unit.
• Connect receiver output of photocells 1 between terminals M5
and M9 of the control unit and receiver output of photocells 2
between terminals M6 and M9 of the control unit.
Use outputs having normally closed contact.
mATTENZIONE:
• If several couples of same kind photocells are mounted, their
outputs must be connected in series.
• In case of reflection photocells, power supply must be
connected to terminals M11 and M12 of the control unit to
carry out the operation test.
4.7 - SAFETY RIBBONS
The control unit considers two kinds of safety ribbons, depending
on the terminal to which they are connected:
Type 1
When type 1 safety ribbons operate during the gate opening
phase, the control unit will close the doors for 3 seconds, then it
stands still; when type 1 safety ribbons operate during the gate
closing phase, the control unit will stand still immediately.
The direction of the gate at next command of START or
PEDESTRIAN START depends upon the parameter STOP (it inverts
or continues the motion).
If the input STOP is disabled, the command makes the motion
continue in the same direction.
Type 2
when type 2 safety ribbons operate during the gate opening
phase, the control unit will stand still immediately; when type 2
safety ribbons operate during the gate closing, the control unit
will open the doors for 3 seconds, then it will stand still. The
direction of the gate at next command of START or PEDESTRIAN
START depends upon the parameter STOP (it inverts or continues
the motion). If the input STOP is disabled, the command makes
the motion continue in the same direction.
Both the input can manage the classic safety edge with n.c.
contact and the conductive rubber safety edge with 8,2 kohm
nominal resistance.
Connect type 1 safety ribbons cables between terminals M7 and
M9 of the control unit.
Connect type 2 safety ribbons cables between terminals M8 and
M9 of the control unit.
In order to meet the requirements of the EN12978 rules, it is
necessary to install safety edges controlled by a control unit
continuously checking the proper working. If using control units
suited to the test by power outage, connect the power supply
cables of the control unit between terminals M11 and M12 of the
control unit.
Otherwise, connect them between terminals M10 and M11.
mWARNING:
• Make use of safety ribbons having outputs with normally close
contact.
• Outputs of same kind safety ribbons must be connected in
series.
4.8 - EXTERNAL AERIAL
We suggest to use the external aerial (model: ANS433) in order to
guarantee the maximal range.
Connect the antenna hot pole to terminal A2 of the control unit
and the braiding to terminal A1.

ENGLISH
- 38 -
4.9 - ELECTRICAL CONNECTION
B3 B4B1 B2
50-60 Hz
230Vac
M1 M2 M3 M4 M5 M6 M7 M8 M9 M10 M11 M12
RECEIVER
FUSE
MAINS
OVERLOAD
L (LINE)
N (NEUTRAL)
LAMP
230V-MAX.40W
COURTESY LIGHT
CONTACT
START
START P.
STOP
COM
PHOTO 1 PHOTO 2
EDGE 1 EDGE 2
COM
24V~ 10W
24V~
(Photo / Edge Test)
GND
ANT
A1 A2
mConnect the motor to ground
through the clamp marked by the
symbol W.
Use the eyelet provided.

ENGLISH
- 39 -
LPower phase 230 Vac
NNeutral 230 Vac
B1 - B2 Flashing light 230Vac - 40W
B3 - B3 Courtesy light
M1 START - Open command for connecting
traditional devices with N.O. contact
mWARNING: If you use maintained
command devices (magnetic loop detectors,
timers, presence detectors, etc.) clock mode
must be used (parameter Strt = oroL).
M2 START P. - Pedestrian open command for
connecting traditional devices with N.O. contact
mWARNING: If you use maintained
command devices (magnetic loop detectors,
timers, presence detectors, etc.) clock mode
must be used (parameter Strt = oroL).
M3 STOP command. N.C. contact
M4 Common (-)
M5 Photocell 1. N.C. contact
M6 Photocell 2. N.C. contact
M7 Type 1 edges. N.C. contact
M8 Type 2 edges. N.C. contact
M9 Accessories common (-)
M10 24Vac supply for photocells and other
accessories
M11 Accessory power common (-)
M12 24Vac supply - photocell/optical edge TX for
functional Test.
Connect power supply cables of photocells
transmitter between terminals M11 and M12
A1 Antenna shield
A2 Antenna
ADI ADI module interface
RECEIVER Plug-in receiver
FUSE 10A
MAINS It shows that the control unit is power supplied
OVERLOAD It shows that there is an overload on accessories
power supply
4.10 - PLUG IN RECEIVER
PD19 control unit is suitable for plugging in a MR receiver having
a high-sensitivity super-heterodyne architecture.
mWARNING: Pay attention to the way you connect the
removable modules.
MR module receiver is provided with 4 channels and each of
them is suitable for a command of PD19 control unit:
• CHANNEL 1 gSTART
• CHANNEL 2 gPEDESTRIAN START
• CHANNEL 3 gSTOP
• CHANNEL 4 gCOURTESY LIGHT
NOTE: Before programming 4 channels and function logics
read carefully the instructions of MR.
4.11 - ADI INTERFACE
The ADI (Additional Devices Interface) interface of the control unit
PD19 allows the connection to V2 optional modules.
Refer to V2 catalogue or to the technical sheets to see which
optional modules with ADI interface are available for this control
unit.
mWARNING: Please read the instructions of each single
module to install the optional modules.
For some devices, it is possible to configure the mode for
interfacing with the control unit; in addition, it is necessary to
enable the interface so that the control unit can process the
signals arriving from the ADI device.
Please refer to the i.Adi programming menu to enable the ADI
interface and access the device configuration menu.
ADI devices use the display of the control unit to issue alarms or
display the configuration of the control unit.
The device connected to the Adi interface is able to signal to the
control unit three alarm signals, which are displayed on the
control unit display as follows:
• PHOTOCELL ALARMS - the upper segment comes on: the gate
stops moving, when the alarm stops opening restarts.
• EDGE ALARM - the lower segment comes on: inverts motion of
the gate for 3 seconds.
• STOP ALARM - both segments start flashing: the gate stops
and cannot restart until the alarm stops.
• SLAVE - segment steadily lit: it is used by the optional module
SYNCRO to indicate that the control unit is configured as
SLAVE.
PHOTOCELL ALARM
STOP ALARM
EDGE ALARM
SLAVE

ENGLISH
- 40 -
5 - CONTROL PANEL
5.1 - DISPLAY
When power is on, the control unit checks that display correctly
operates by switching on all segments for 1.5 sec. 8.8.8.8.
Firmware version, e.g. Pr I.0, will be viewed in the following
1.5 sec.
Panel will be viewed upon completion of this test.
The control panel represents the physical status of the terminal
board contacts and of the program mode keys: if the upper
vertical segment is on, the contact is closed; if the lower vertical
segment is on, the contact is open (the above picture shows an
instance where the inputs PHOTO1, PHOTO2, EDGE1, EDGE2 and
STOP have all been correctly connected).
NOTE: if you are using an ADI module, other segments may
appear on the display, see the paragraph dedicated to the
“ADI INTERFACE”
Points being among display digits show the status of
programming push-buttons: as soon as a push-button is pressed,
its relevant point turns on.
The arrows on the left of the display show the state of the start
inputs. The arrows light when the related input is closed.
The arrows on the display right side show the gate status:
• The highest arrow turns on when the gate is into its opening
phase. If it blinks, it means that the opening has been caused
by a safety device (border or obstacle detector).
• The central arrow shows that the gate is on pause. If it blinks, it
means that the time countdown for the automatic closing has
been activated.
• The lowest arrow blinks when the gate is into its closing phase.
If it blinks, it means that the closing has been caused by a
safety device (border or obstacle detector).
5.2 - USE OF THE KEYS FOR PROGRAMMING
The control unit functions and times are programmed by means
of a special configuration menu, which can be accessed and
explored by using the 3 keys, h, iand OK, located on the side of
the control unit display.
PLEASE NOTE: Outside the configuration menu, pressing
the hkey activates the START command, pressing the ikey
activates the PEDESTRIAN START command.
There are the following three kinds of menu items:
• Function menu
• Time menu
• Value menu
Function menu setup
Function menus allow selecting a function from among a group
of available options. When you enter into a function menu, the
current active option will be viewed; you can scroll all available
options through iand hkeys. By pressing the OK key, you
will activate the option viewed and you will return to the
configuration menu.
Time menu setup
Time menus allow setting a function duration. When you enter
into a time menu, the current setup value will be viewed; the
display mode depends on the current value:
• Each time you press hkey, current time value increases and
each time you press the ikey, current time value decreases.
• By holding down the hkey, you can quickly increase the time
value, up to reach the max. value allowed for this item.
• Vice versa, by holding down the i key, you can quickly decrease
the time value down to reach 0.0”
• In some circumstances, setting the value to 0means that
the relevant function is disabled, in this case, no will appear
instead of 0.0”
• By pressing on OK you will confirm the displayed value and you
will return to the configuration menu.
Value menu setup
Value menus are similar to time menus; however, the setup value
can be any number.
By holding down hor ikeys, the value will increase or decrease
slowly.
By pressing on OK you will confirm the displayed value and you
will return to the configuration menu.
The main programming menus of the control unit are shown in
the next pages.
To go through the menus use the three keys h, iand OK
according to the following chart:
OPENING IN PROGRESS
OPENED CONTACTCLOSED CONTACT
START
PEDESTRIAN
START
PAUSE (GATE OPENED)
CLOSING IN PROGRESS
LIMIT SWITCH (SX)
LIMIT SWITCH (DX)

SAFETY RIBBON 2
OK
STOP
PHOTOCELL 1

PHOTOCELL 2
SAFETY RIBBON 1
Press and release the push-button OK
Keep pressed the push-button OK for 2 seconds
Release the push-button OK
Press and release the push-button h
Press and release the push-button i

ENGLISH
- 41 -
6 - ACCESSING THE CONTROL UNIT SETTINGS
1. Press and hold the OK key until the display shows the menu
desired
2. Release the OK key: the display will show the first item in the
sub-menu
-PrG Programming the control unit (chapter 12)
-Cnt Cycle counter (chapter 11)
-SEt Installation menù (chapter 9)
-dEF Loading the default parameters (chapter 9)
mWARNING: in case no operation is carried out for
more than one minute, the control unit exits from the
programming mode without saving any of your setups and
changes, which will get lost.
7 - QUICK CONFIGURATION
This paragraph concerns a quick procedure to set the control unit
and set it at work immediately.
We recommend following these instructions, in order to
check quickly the correct operation of control unit, motor
and accessories, and then changing the configuration in
case of any non-satisfactory parameter.
1. Call up the default configuration: see chapter 8
2. Set items
dir - StoP - Fot1 - Fot2 - CoS1 - CoS2
according to the safety devices installed on the gate.
For the position of the item menus inside the main menu and
for the options related to each item menu, refer to the
chapter 12.
3. Start the self-learning cycle: see chapter 9-9.1 (AUTOMATIC
LEARNING OF THE RUN LIMITS)
4. Check that the automation work properly and if necessary
modify the configuration of the desired parameters.
8 - LOADING THE DEFAULT PARAMETERS
If necessary, it is possible to restore all parameters to their
standard or default values (see the final summary table).
mPLEASE NOTE: This procedure results in the loss of all
customised parameters.
1. Press and hold the OK key until the display shows -dEF
2. Release the OK key: the display shows ESC (only press the OK
key if it is desired to exit this menu)
3. Press the ikey: the display shows dEF
4. Press the OK key: the display shows no
5. Press the ikey: the display shows Si
6. Press the OK key: all parameters are overwritten with their
default values (see Chapter 12), the control units exits
programming mode and the display shows the control panel.
-PrG d i r
-Cnt tot
-SEt ESC
----
2’’
4’’
6’’
-dEF ESC
8’’
10’’
dEF.
ESC
-dEF
Si
no

ENGLISH
- 42 -
9 - INSTALLATION MENÙ (SEt)
This menu allows you to perform the movements of the gate
needed during installation.
The automatic learning procedure enables to save run limits based
on data collected by the encoder.
The manual handling procedure allows to control the gate in hold
to run mode in special cases such as during installation /
maintenance or a malfunction of the photocells or edges.
mATTENTION: before proceeding, make sure to position
the mechanical stops and the limit sensors correctly.
1. Press and hold the OK key until the display shows -SEt
2. Release the OK key: the display shows ESC (only press the OK
key if it is desired to exit this menu)
3. Use the keys hand ito select the menu Mov to activate
manual handling or APPr to start the automatic learning
procedure of the run limits
4. Press OK to start the selected procedure
9.1 - AUTOMATIC LEARNING OF THE RUN
LIMITS
mCAUTION: to perform the self-learning procedure it
is necessary to disable the ADI interface by means of the
menu i.Adi . If some safeties are controlled by means of the
ADI module, they will not be active during the self-learning
NOTE: during the self-learning the slowdown in the limit
switch area is not active.
To store the precise position of the range limit it is
recommended to activate the slow speed near to the limit.
The position at which the slow speed is activated is stored
as the starting point for slowing down.
5. The display shows the control panel and the automatic learning
procedure of the run limits starts.
5.1 If the gate is not at the closed limit, the motor will
activate to close at the slow speed until it reaches the
range limit.
5.2 Gate opening is activated until the opening limit switch is
reached.
NOTE: To slow down the motor press the control unit
button ior activate the START P. command (wired or
wireless) when the gate comes close to the range limit.
5.3 Gate closing is activated until the closing limit switch is
reached.
NOTE: To slow down the motor press the control unit
button ior activate the START P. command (wired or
wireless) when the gate comes close to the range limit.
6. At the end of the automatic learning procedure, the control
unit automatically exits this menu and returns to normal
operation.
9.2 - MANUAL HANDLING
mWARNING: when this procedure is activated the
safeties are not active.
5. The display shows MAn
6. Press and hold the hkey to open the gate or the ibutton to
close the gate
7. Release the button to stop the gate
8. To exit this menu, press OK
NOTE: If the motor is inactive for more than one minute
the procedure terminates automatically.
APPr
ESC
Mov
MAn
-SEt

ENGLISH
- 43 -
10 - EMERGENCY DEAD MAN OPERATION
This operational mode can be used to move the gate in DEAD
MAN mode in particular cases, such as installation/maintenance or
in the case of malfunctioning of photocell, edge, limit switches or
encoder.
To activate the function the START command must be pressed
3 times (presses must last at least 1 second; the pause between
commands must last at least 1 second).
1” 1” 1” T
>1” >1” >1”
The fourth START command activates the gate in MAN PRESENT
mode. To move the gate keep the START command pressed for
the duration of the operation (time T).
The function will automatically turn off after 10 seconds of
inactivity of the gate.
NOTE: if the Strt parameter is set as StAn, the Start
command (from the terminal block or remote control) moves the
gate in the open and closed directions alternatively (unlike the
normal DEAD MAN mode).
11 - READING OF CYCLE COUNTER
PD19 control unit counts the completed opening cycles of the
gate and, if requested, it shows that service is required after a
fixed number of cycles.
There are two counters available:
• A totalizing counter for completed opening cycles thatcannot
be zeroed (option tot of item Cont )
• A downward counter for the number of cycles before the next
request for service (option SErv of item Cont ).
This counter can be programmed according to the desired value.
The scheme hereafter shows how to read the totalizing counter,
how to read the number of cycles before the next service is
required as well as how to program the number of cycles before
the next request for service (as for the example shown, the control
unit completed no. 12451 cycles and there are no. 1300 cycles
before the next service request.
Area 1 is the reading of the total number of completed cycles;
through hand ikeys, you can alternate the display of thousands
or units.
Area 2 is the reading of the number of cycles before the next
request for service: its value is rounded down to the hundreds.
Area 3 is the setup of this latter counter; on first pressing the
hor ikey the current value of the counter is rounded to the
thousand, each press after this increases the setting by 1000 units
or decreases by 100. The previous displayed count will get lost.
11.1 - SIGNAL OF SERVICE REQUIRED
As soon as the counter of cycles before the next request for
service is zero, the control unit shows the request for service
through an additional 5-second pre-blinking.
This signal will be repeated at each opening cycle, until the
installer enters into the counter reading and setup menu, and
possibly programs the number of cycles after which the next
service will be requested.
In case no new value is setup (that is to say that the counter value
is left at zero), the signalling function for the service request will
be disabled and no signal will be repeated anymore.
mWARNING: service operations shall be carried out by
qualified staff only.
3
2
-Cnt
tot
SEru
ESC
-01.3 -02.0
-01.0
-03.0
1
0 12.
.45 1
