Vari Beam User manual

Beam
Patent and trademark informaon: vari.com/patents | ©2021 Varidesk, LLC All rights reserved.

2.
Beam Assembly
NOTE: READ ALL INSTRUCTIONS AND PLAN LAYOUT BEFORE ASSEMBLING.
x2POSTBEAM x1
2 People Required
x1BASE PLATE
ALLEN KEY x1

3.
Place the post on the base plate as illustrated above. Then, using an Allen key, ghten both
sides of the post. Repeat to assemble the second post.
1
2
With help from a second person, li the beam, keeping the ends level with each other.
Insert the brackets on the beam end into the corresponding holes on the post.

4.
Insert the brackets on the second end of the beam into the second post.
3
4
Pull down the side cover on the beam to access the draw latches, located in the upper
corners. Swing the rubber gasket into the slot and push up, then pull the latch so that it is
ush with the top of the beam. This will lock the rubber gasket in place.

5.
If leveling is needed, spin the base plates clockwise (to raise) or counterclockwise (to lower)
the posts.
Repeat the previous steps to connect addional beams, creang your desired conguraon.
5
6
Once the beam is installed, press down rmly on the top of the beam to ensure the
connecons are secure.

6.
Electrical Component Assembly
NOTE: READ ALL INSTRUCTIONS AND PLAN LAYOUT BEFORE ASSEMBLING.
x2RECEPTACLEDISTRIBUTION HARNESS x1
2 People Required
x1
JUMPER CABLE
Comes in 4 Sizes:
14.75", 20.375", 34.375", 44.375"
x1
WHIP

7.
1
2
Open the side covers on both sides of the beam. Remove all outlet covers by pushing them
through the outlet opening.
Secure both distribuon harnesses to the stretcher. There are 4 pre-drilled holes located on
the underside of the top extrusion on each side of the beam. There are a total of 8 screws
per beam. Orient the distribuon harnesses so that the arrow on the scker is pointed
towards the end of the beam; this is where the receptacles will aach. Make sure the N
symbol is always poinng upward.

8.
3
Aach each receptacle to the distribuon harness by placing it in the opening, then slide it
toward the nearest post unl the clip is engaged. Make sure the N symbol on the receptacle
is poinng upward.
Repeat steps 1-3 for all remaining distribuon harnesses in the run of beams.

9.
4
Connect the distribuon harnesses to each other using the appropriate jumper cable,
running the cable through the central support bars. Jumper cable lengths will vary for each
beam size, as listed below. Make sure the N symbol on the jumper cable is poinng upward.
• Beam 48: 20.375" jumper cable
• Beam 60: 34.375" jumper cable
• Beam 72: 44.375" jumper cable
BEAM 60
BEAM 72
BEAM 48

10.
Connect the electrical components from one beam to a second beam using the 14.75"
jumper cable, running it through the shared post. Make sure the N symbol on the jumper
cable is poinng upward.
5

6
Aer all of the jumpers have been installed, connect the whip to the distribuon harness at
the end of the run closest to the electrical box. Make sure the N sumbol is poinng upward.
WARNING: To complete installaon, beams must be hardwired by a qualied electrician.
Do NOT aempt to connect the whip to the main power on your own.

ATTENTION: Power sources must be hardwired by a qualied electrician. For proper installaon,
reference NEC and local applicable building codes.
WARNING: To avoid electric shock, disconnect power at source prior to installaon.
WARNING: Do not open any components; there is danger of electric shock.
CAUTION: Keep plug away from heated surfaces.
CAUTION: Beverages such as water or coee could cause product failure if spilled.
WARNING: Never operate this product if it has a damaged cord or plug, if it is not working properly,
if it has been dropped or damaged, or if it has had contact with water or other liquids. Contact our
customer service department during business hours to report any issues.
WARNING: To reduce risk of re, electric shock, or personal injury, use only indoors and do not install
in a wet or damp locaon.
CLEANING: Dust can be removed with a dry cloth. Do not use water or any other liquid on any surface
where it may come into contact with electrical components.
