VDO ELECTRONIC SPEEDOMETER 1323 User manual

By its modular design and custom-tailored front
panel, the electronic speedometer 1323 can be inte-
grated harmoniously into present and future cockpit
systems.
The electronic speedometer 1323 provides the
required display of the speed either Stand alone or in
combination with the radio-format tachograph MTCO
or DTCO.
Used stand alone the electronic speedometer 1323
is directly connected to the speed sensor. In combi-
nation with the tachograph the K-Line or the CAN-
interface are used.
The microprocessor and modern stepper motor
technology form the basis for the precise speed indi-
cation and odometer. The accurate data recording
and indication meet the stringent requirements of
national and EU-wide regulations.
Features
• Indication of total distance travelled in the 7-digit
LC display with 100 meter digit
• Speed pointer set to the legally required tolerance
• Optional display of daily kilometres and time with
setting knob
• Custom-tailored design for pointers, dial and front
frame as an option
• Outputs for v-signal, 4 imp/m, driving and stop
signal for stand alone version
• Communication with tachograph via K-Line or CAN
Application
• Vehicles subject to tachograph regulations with
seperate indication and recording
• Vehicles not subject to tachograph regulation
• Replace KTCO in combination with MTCO or DTCO
www.vdo.com
Electronic Speedometer
1323

Technical Information
Measuring range 125 km/h (standard)
Operating temperature - 25 ... + 70° C
Operating voltage 12 or 24 V
Power consumption typ. 6 mA at 24 V 8 mA CAN version
(Standby)
Pulse range 2 400 - 25 000 Imp/km
no pulse range CAN version
Inputs Hall sensor, inductive sensor, instrument
interface K-Line or CAN
Outputs 2 x v-pulse, 4 Imp/m, driving/stop signal
(stand alone version)
Accuracy Speed pointer set to the legally required tolerance
EMV/EMC RL 95/94/EG ISO 7637
Casing Acrylonitrile-butatiene-Styrene (ABS)
Weight approx. 470 g
Standard mounting position according to DIN 16257 between + 20 ° and + 80 °
Mounting Dimensions
(in mm):
Available options
Trip indicator, time, custom-
tailored front frame design,
function control LED and
T symbol in connection with
tachograph measuring range:
• to customer requirements,
from 80 km/h - 180 km/h
• 125 km/h + 80 mph;
160 km/h + 100 mph
• 100, 140, 180 km/h
(in connections with MTCO
and DTCO)
