Vega VEGABAR 86 User manual

Operating Instructions
Submersible pressure transmitter with
ceramic measuring cell
VEGABAR 86
HART and accumulator pack
Document ID: 45040

2
Contents
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
Contents
1 Zu diesem Dokument............................................................................................................... 4
1.1 Funktion ........................................................................................................................... 4
1.2 Zielgruppe........................................................................................................................ 4
1.3 Verwendete Symbolik....................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 EU conformity................................................................................................................... 6
2.6 NAMUR recommendations .............................................................................................. 6
2.7 Installation and operation in the USA and Canada ........................................................... 6
2.8 Environmental instructions ............................................................................................... 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 8
3.3 Packaging, transport and storage................................................................................... 10
3.4 Accessories.................................................................................................................... 11
4 Mounting................................................................................................................................. 12
4.1 General instructions ....................................................................................................... 12
4.2 Ventilation and pressure compensation.......................................................................... 14
4.3 Level measurement........................................................................................................ 15
5 Connecting to power supply................................................................................................. 16
5.1 Connection of the battery charger .................................................................................. 16
5.2 Wiring plan ..................................................................................................................... 16
5.3 Switch-on phase............................................................................................................. 17
6 Set up with the display and adjustment module ................................................................ 19
6.1 Insert display and adjustment module............................................................................ 19
6.2 Adjustment system......................................................................................................... 20
6.3 Measured value indication.............................................................................................. 21
6.4 Parameter adjustment - Quick setup .............................................................................. 22
6.5 Parameter adjustment - Extended adjustment................................................................ 22
6.6 Menu overview ............................................................................................................... 33
6.7 Saving the parameterisation data................................................................................... 35
7 Setup with PACTware............................................................................................................. 36
7.1 Connect the PC.............................................................................................................. 36
7.2 Parameter adjustment with PACTware............................................................................ 36
7.3 Saving the parameterisation data................................................................................... 37
8 Diagnosis, asset management and service ........................................................................ 38
8.1 Maintenance .................................................................................................................. 38
8.2 Diagnosis memory ......................................................................................................... 38
8.3 Asset Management function........................................................................................... 39
8.4 Rectify faults................................................................................................................... 42
8.5 Exchanging the electronics module................................................................................ 43
8.6 Software update ............................................................................................................. 43

3
Contents
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
8.7 How to proceed if a repair is necessary.......................................................................... 43
9 Dismount................................................................................................................................. 44
9.1 Dismounting steps.......................................................................................................... 44
9.2 Disposal ......................................................................................................................... 44
10 Supplement ............................................................................................................................ 45
10.1 Technical data ................................................................................................................ 45
10.2 Dimensions .................................................................................................................... 54
10.3 Gewerbliche Schutzrechte ............................................................................................. 62
10.4 Trademark ...................................................................................................................... 62
Safety instructions for Ex areas
TakenoteoftheExspecicsafetyinstructionsforExapplications.
These instructions are attached as documents to each instrument
with Ex approval and are part of the operating instructions.
Editing status: 2021-03-31

4
1 Zu diesem Dokument
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
1 Zu diesem Dokument
1.1 Funktion
Die vorliegende Anleitung liefert Ihnen die erforderlichen Informa-
tionen für Montage, Anschluss und Inbetriebnahme sowie wichtige
Hinweise für Wartung, Störungsbeseitigung, den Austausch von
Teilen und die Sicherheit des Anwenders. Lesen Sie diese deshalb
vor der Inbetriebnahme und bewahren Sie sie als Produktbestandteil
in unmittelbarer Nähe des Gerätes jederzeit zugänglich auf.
1.2 Zielgruppe
Diese Betriebsanleitung richtet sich an ausgebildetes Fachpersonal.
Der Inhalt dieser Anleitung muss dem Fachpersonal zugänglich
gemacht und umgesetzt werden.
1.3 Verwendete Symbolik
Document ID
Dieses Symbol auf der Titelseite dieser Anleitung weist auf die Docu-
ment ID hin. Durch Eingabe der Document ID auf www.vega.com
kommen Sie zum Dokumenten-Download.
Information, Hinweis, Tipp: Dieses Symbol kennzeichnet hilfreiche
Zusatzinformationen und Tipps für erfolgreiches Arbeiten.
Hinweis: Dieses Symbol kennzeichnet Hinweise zur Vermeidung von
Störungen, Fehlfunktionen, Geräte- oder Anlagenschäden.
Vorsicht: Nichtbeachten der mit diesem Symbol gekennzeichneten
Informationen kann einen Personenschaden zur Folge haben.
Warnung: Nichtbeachten der mit diesem Symbol gekennzeichneten
Informationen kann einen ernsthaften oder tödlichen Personen-
schaden zur Folge haben.
Gefahr: Nichtbeachten der mit diesem Symbol gekennzeichneten In-
formationen wird einen ernsthaften oder tödlichen Personenschaden
zur Folge haben.
Ex-Anwendungen
Dieses Symbol kennzeichnet besondere Hinweise für Ex-Anwendun-
gen.
• Liste
Der vorangestellte Punkt kennzeichnet eine Liste ohne zwingende
Reihenfolge.
1 Handlungsfolge
Vorangestellte Zahlen kennzeichnen aufeinander folgende Hand-
lungsschritte.
Batterieentsorgung
Dieses Symbol kennzeichnet besondere Hinweise zur Entsorgung
von Batterien und Akkus.

5
2 For your safety
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The VEGABAR 86 is a pressure transmitter for level and gauge
measurement. Due to the integrated accumulator the instrument is
particularly suitable as a portable measuring system or test sensor for
special applications.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives. The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument. When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.

6
2 For your safety
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
2.5 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
The EU conformity declaration can be found on our homepage.
2.6 NAMUR recommendations
NAMUR is the automation technology user association in the process
industry in Germany. The published NAMUR recommendations are
acceptedasthestandardineldinstrumentation.
ThedevicefullstherequirementsofthefollowingNAMURrecom-
mendations:
• NE 21 – Electromagnetic compatibility of equipment
• NE 43 – Signal level for fault information from measuring transduc-
ers
• NE53–Compatibilityofelddevicesanddisplay/adjustment
components
• NE107–Self-monitoringanddiagnosisofelddevices
For further information see www.namur.de.
2.7 Installation and operation in the USA and
Canada
This information is only valid for USA and Canada. Hence the follow-
ing text is only available in the English language.
Installations in the US shall comply with the relevant requirements of
theNationalElectricalCode(ANSI/NFPA70).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code.
2.8 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter "Packaging, transport and storage"
• Chapter "Disposal"

7
3 Product description
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Sensor with integrated accumulator
• Battery charger
The further scope of delivery encompasses:
• Documentation
– Quick setup guide VEGABAR 86
– Testcerticateforpressuretransmitters
– Instructions for optional instrument features
– Ex-specic"Safety instructions"(withExversions)
– Ifnecessary,furthercerticates
Information:
Optional instrument features are also described in this operating
instructions manual. The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
• Hardware from 1.0.0
• Software from 1.3.5
Note:
Youcanndthehardwareandsoftwareversionoftheinstrumentas
follows:
• On the type plate of the electronics module
• In the adjustment menu under "Info"
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
7
6
4
5
2
3
1
Fig. 1: Layout of the type label (example)
1 Product code
2 Field for approvals
3 Technical data
4 Serial number of the instrument
5 QR code
6 Symbol of the device protection class
7 ID numbers, instrument documentation
Scope of delivery
Scope of this operating
instructions
Type label

8
3 Product description
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
The type label contains the serial number of the instrument. With it
youcanndthefollowinginstrumentdataonourhomepage:
• Productcode(HTML)
• Deliverydate(HTML)
• Order-specicinstrumentfeatures(HTML)
• Operating instructions and quick setup guide at the time of ship-
ment(PDF)
• Order-specicsensordataforanelectronicsexchange(XML)
• Testcerticate(PDF)-optional
Move to "www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Alternatively, you can access the data via your smartphone:
• Download the VEGA Tools app from the "Apple App Store" or the
"Google Play Store"
• Scan the DataMatrix code on the type label of the instrument or
• Enter the serial number manually in the app
3.2 Principle of operation
The VEGABAR 86 is a submersible pressure transmitter for level
measurementinwells,basinsandopenvessels.Itsgreatexibility
throughdierentcableandtubeversionsallowstheinstrumenttobe
usedinmanydierentapplications.
Measured products are liquids.
Depending on the instrument version and measurement setup, meas-
ured products can also be viscous or contain abrasive substances.
The VEGABAR 86 is suitable for the measurement of the following
process variables:
• Level
Serial number - Instru-
ment search
Application area
Measured products
Measured variables

9
3 Product description
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
Fig. 2: Level measurement with VEGABAR 86
The sensor element is the CERTEC®measuring cell with robust
ceramicdiaphragm.Theprocesspressuredeectstheceramic
diaphragm and causes a capacitance change in the measuring cell.
This capacitance change is converted into an electrical signal and
outputted as measured value via the output signal.
The measuring cell is available in two sizes:
• CERTEC®(ø28mm)withsensor32mm
• Mini-CERTEC®(ø17.5mm)withsensor22mm
A temperature sensor in the ceramic diaphragm of the CERTEC®or
on the ceramic base of the Mini-CERTEC®measuring cell detects the
actual process temperature. The temperature value is output via:
• The display and adjustment module
• The current output or the additional current output
• The digital signal output
Even extreme jumps in process temperature are immediately de-
tected by the CERTEC®measuring cell. The values in the ceramic
diaphragm are compared with those on the ceramic base body. Within
a few measuring cycles, the intelligent sensor electronics compen-
sates for otherwise unavoidable measurement deviations caused by
temperature shocks in the range. Depending on the adjusted damp-
ing, these cause only slight and brief changes in the output signal. 1)
The measuring cell design depends on the selected pressure type.
Relative pressure: the measuring cell is open to the atmosphere.
The ambient pressure is detected in the measuring cell and compen-
sated.Itthushasnoinuenceonthemeasuredvalue.
Measuring system pres-
sure
Measuring system tem-
perature
Pressure types
1) At temperatures above 100 °C the function is automatically deactivated, at
temperatures below 95 °C it is automatically reactivated.

10
3 Product description
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
Absolute pressure: the measuring cell contains vacuum and is
encapsulated. The ambient pressure is not compensated and does
henceinuencethemeasuredvalue.
Relative pressure, climate-compensated: the measuring cell is
evacuated and encapsulated. The ambient pressure is detected
through a reference sensor in the electronics and compensated. It
thushasnoinuenceonthemeasuredvalue.
The following illustration shows the installation of the ceramic measur-
ing cell in the sensor as well as the sealing concept.
1
2
3
4
5
Fig. 3: Front-ush installation of the ceramic measuring cell with double seal
1 Housing, sensor
2 Measuring cell
3 Lateral seal for measuring cell
4 Additional, front seal for measuring cell
5 Diaphragm
3.3 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
Seal concept
Packaging
Transport
Transport inspection
Storage

11
3 Product description
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
Withinstrumentweightsofmorethan18kg(39.68lbs)suitableand
approved equipment must be used for lifting and carrying.
3.4 Accessories
The instructions for the listed accessories can be found in the down-
load area on our homepage.
The display and adjustment module is used for measured value indi-
cation, adjustment and diagnosis.
TheintegratedBluetoothmodule(optional)enableswirelessadjust-
ment via standard adjustment devices.
The interface adapter VEGACONNECT enables the connection of
communication-capable instruments to the USB interface of a PC.
The protective cover protects the sensor housing against soiling and
intense heat from solar radiation.
Screwedangesareavailableindierentversionsaccordingtothe
following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5,
JIS B 2210-1984, GOST 12821-80.
Welded sockets are used to connect the devices to the process,
threaded and hygienic adapters for easy adaptation of devices with
standardthreadedttings,e.g.tohygienicconnectionsonthepro-
cess side.
Storage and transport
temperature
Lifting and carrying
PLICSCOM
VEGACONNECT
Protective cover
Flanges
Welded socket, threaded
and hygienic adapter

12
4 Mounting
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
4 Mounting
4.1 General instructions
Note:
For safety reasons, the instrument must only be operated within the
permissibleprocessconditions.Youcannddetailedinformationon
the process conditions in chapter "Technical data" of the operating
instructions or on the type label.
Hence make sure before mounting that all parts of the instrument ex-
posed to the process are suitable for the existing process conditions.
These are mainly:
• Active measuring component
• Processtting
• Process seal
Process conditions in particular are:
• Process pressure
• Process temperature
• Chemical properties of the medium
• Abrasionandmechanicalinuences
Protect your instrument against moisture ingress through the following
measures:
• Use a suitable connection cable (see chapter "Connecting to
power supply")
• Tighten the cable gland or plug connector
• Lead the connection cable downward in front of the cable entry or
plug connector
This applies mainly to outdoor installations, in areas where high
humidityisexpected(e.g.throughcleaningprocesses)andoncooled
or heated vessels.
Note:
Make sure that during installation or maintenance no moisture or dirt
can get inside the instrument.
To maintain the housing protection, make sure that the housing lid is
closed during operation and locked, if necessary.
Deviceswiththreadedttingarescrewedintotheprocessttingwith
a suitable wrench via the hexagon.
See chapter "Dimensions" for wrench size.
Warning:
The housing or the electrical connection may not be used for screw-
ing in! Depending on the device version, tightening can cause dam-
age, e. g. to the rotation mechanism of the housing.
Avoid damages on the device by lateral forces, for example by vibra-
tions.Itisthusrecommendedtoxthedeviceswithprocesstting
Process conditions
Protection against mois-
ture
Screwing in
Vibrations

13
4 Mounting
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
thread G½ of plastic at the installation site via a suitable measuring
instrument holder.
If there is strong vibration at the mounting location, the instrument
version with external housing should be used. See chapter "External
housing".
Thepermissibleprocesspressurerangeisspeciedonthetypelabel
with"MWP"(MaximumWorkingPressure),seechapter"Congura-
tion". This applies even if a measuring cell with a measuring range
(order-related)higherthanthepermissiblepressurerangeofthe
processttingisinstalled.
Inaddition,atemperaturederatingoftheprocesstting,e.g.with
anges,canlimitthepermissibleprocesspressurerangeaccording
to the respective standard.
The permissible process pressure range is stated on the type label.
The instrument should only be operated with these pressures if the
mountingaccessoryusedalsofullsthesevalues.Thisshouldbeen-
suredbysuitableanges,weldedsockets,tensionringswithClamp
connections, sealings, etc.
Higher process temperatures often mean also higher ambient
temperatures. Make sure that the upper temperature limits stated in
chapter "Technical data" for the environment of the electronics hous-
ing and connection cable are not exceeded.
2
1
Fig. 4: Temperature ranges
1 Process temperature
2 Ambient temperature
Depending on the transmitter, the VEGABAR 86 is supplied with a
protective cap or a transport and mounting protection.
Permissible process
pressure (MWP) - Device
Permissible process
pressure (MWP) - Mount-
ing accessory
Temperature limits
Transport and mounting
protection

14
4 Mounting
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
1
2
Fig. 5: VEGABAR 86, transport and mounting protection
1 Transmitter
2 Transport and mounting protection
Remove this protection after mounting and before setting up the
instrument.
In case of slightly contaminated measured media, the transport and
mounting protection can remain on the instrument as an impact pro-
tection during operation.
4.2 Ventilation and pressure compensation
Thelterelementintheelectronicshousinghasthefollowingfunc-
tions:
• Ventilation of the electronics housing
• Atmospheric pressure compensation (with relative pressure meas-
uringranges)
Caution:
Thelterelementcausesatime-delayedpressurecompensation.
Whenquicklyopening/closingthehousingcover,themeasuredvalue
can change for approx. 5 s by up to 15 mbar.
Foraneectiveventilation,thelterelementmustbealwaysfreefrom
buildup. In case of horizontal mounting, turn the housing so that the
lterelementpointsdownwardaftertheinstrumentisinstalled.This
provides better protection against buildup.
Caution:
Donotuseahigh-pressurecleaner.Thelterelementcouldbedam-
aged, which would allow moisture into the housing.
Thefollowingparagraphsdescribehowthelterelementisarranged
inthedierentinstrumentversions.
Filter element - Function

15
4 Mounting
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
1 2 3
6
6
6 6
6
5
4
Fig. 6: Position of the lter element
1 Plastic, stainless steel single chamber (precision casting)
2 Aluminium - single chamber
3 Stainless steel single chamber (electropolished)
4 Plastic double chamber
5 Aluminium, stainless steel double chamber housing (precision casting)
6 Filter element
With the following instruments a blind plug is installed instead of the
lterelement:
• InstrumentsinprotectionIP66/IP68(1bar)-ventilationviacapillar-
ies in non-detachable cable
• Instruments with absolute pressure
4.3 Level measurement
Keep the following in mind when setting up the measuring system:
• Donotmounttheinstrumentclosetothellingstreamoremptying
area
• Mount the instrument so that it is protected against pressure
shocks from the stirrer
Filter element - Position
Measurement setup

16
5 Connecting to power supply
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
5 Connecting to power supply
5.1 Connection of the battery charger
We recommended charging the integrated accumulator completely
beforesettinguptheinstrument.Youcanndthechargingtimein
chapter "Technical data".
The battery charger is plugged into a socket in the supply room, see
chapter "Wiring plan".
The LEDs in the supply room show the charging process and condi-
tion of the accumulator, see chapter "Wiring plan".
5.2 Wiring plan
2
1
Fig. 7: Position of the power supply and electronics compartment
1 Supply room (accumulator)
2 Electronics compartment
5678
4...20mA
2
12
+
( ) (-)
1
Fig. 8: Electronics compartment - double chamber housing
1 Internal connection to the connection compartment
2 Contact pins for the display and adjustment module
Overview
Electronics compartment

17
5 Connecting to power supply
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
2
4
3
5
0
5
1
6
2
7
3
8
4
9
modes
4 ON/OFF
3 ON/OFF 1h
1,2 OFF
Charge Accu
5..9 auto cycle
12
+
( ) (-)
1
Fig. 9: Supply room
1 Internal connection of the socket for the battery charger
2 Mode switch
3 LED green, charging process
4 LED yellow, charging status
5 Socket for the battery charger
The mode switch enables the selection of the following modes:
• 0=sensoro,LEDsshowtheaccumulatorstatus
• 1,2=sensoro,LEDso
• 3=sensoronfor1hourafterpressingakey(deliverystatus)
• 4=sensorpermanentlyon,switchingon/oviabutton
• 5 = sensor is switched on every 30 minutes for 3 minutes
• 6 = sensor is switched on every hour for 3 min.
• 7 = sensor is switched on every 6 hours for 3 minutes
• 8 = sensor is switched on every 12 hours for 3 minutes
• 9 = sensor is switched on every 24 hours for 3 minutes
The green LED characterizes the charging process:
• LEDashes=Accumulatorischarging
• LED lights = accumulator is full, battery charger should be
unplugged(accumulatorlifetime)
After pressing the key or changing the mode the yellow LED shows
the accumulator status for approximately 10 s as follows:
• LED lights = accumulator is full
• LEDashes=accumulatorshouldbecharged
• LEDo=accumulatorisempty
5.3 Switch-on phase
Theinstrumentisswitchedonandobymeansofabuttonoutside
on the housing.
Supply room

18
5 Connecting to power supply
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
1
Fig. 10: Switch on/o button outside on the housing
1 On/O button
After switching on, the instrument carries out a self-check for approxi-
mately 30 s:
• Internal check of the electronics
• Indication of a status message, e.g. "F 105 Determine measured
value" on the display
Then the actual measured value is output to the signal cable. The
value takes into account settings that have already been carried out,
e.g. default setting.

19
6 Set up with the display and adjustment module
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
6 Set up with the display and adjustment
module
6.1 Insert display and adjustment module
The display and adjustment module can be inserted into the sensor
andremovedagainatanytime.Youcanchooseanyoneoffourdier-
ent positions - each displaced by 90°. It is not necessary to interrupt
the power supply.
Proceed as follows:
1. Unscrew the housing lid
2. Place the display and adjustment module on the electronics in the
desired position and turn it to the right until it snaps in.
3. Screw housing lid with inspection window tightly back on
Disassembly is carried out in reverse order.
The display and adjustment module is powered by the sensor, an ad-
ditional connection is not necessary.
Fig. 11: Insertion of the display and adjustment module
Note:
Ifyouintendtoretrottheinstrumentwithadisplayandadjustment
module for continuous measured value indication, a higher lid with an
inspection glass is required.

20
6 Set up with the display and adjustment module
VEGABAR 86 • HART and accumulator pack
45040-EN-210430
6.2 Adjustment system
1
2
Fig. 12: Display and adjustment elements
1 LC display
2 Adjustment keys
• [OK] key:
– Move to the menu overview
– Conrmselectedmenu
– Edit parameter
– Save value
• [->] key:
– Change measured value presentation
– Select list entry
– Select menu items
– Select editing position
• [+] key:
– Change value of the parameter
• [ESC] key:
– Interrupt input
– Jump to next higher menu
The instrument is operated via the four keys of the display and
adjustment module.The individual menu items are shown on the LC
display.Youcanndthefunctionoftheindividualkeysintheprevious
illustration.
With the Bluetooth version of the display and adjustment module you
can also adjust the instrument with the magnetic pen. The pen oper-
ates the four keys of the display and adjustment module right through
theclosedlid(withinspectionwindow)ofthesensorhousing.
Key functions
Operating system - Keys
direct
Adjustment system - keys
via magnetic pen
