VEVOR LCWB90 User manual

LCWB90
USER MANUAL
Poable Workbench

Have product questions? Need technical suppo? Please feel free to contact us:
CustomerSe[email protected]
NEED HELP? CONTACTUS!
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR resees clear interpretation of our user manual. The appear-
ance of the product shall be subject to the product you received. Please forgive us
that we won't inform you again if there is any technology or software updates on
our product.
Poable Workbench
01

02
GENERAL SAFETY RULES
WORKPLACE
PORTABLE WORKBENCH USE AND PRECAUTIONS.
IMPORTANT: carefully read the instructions in this manual as well as the general
safety instructions before using this tool.
WARNING ! Read the instructions and use or operate without following the instruc-
tions listed below will result in deformation, inexible movement, loss of bearing
weight or serious inju.
Before using the tool, read the instruction book carefully.
1) Keep the workplace clean and bright. A messy and dark place can cause
accidents.
2) Do not expose the workbench to rain or wet environment.
3) Pay attention to whether the ground is smooth when working outdoors to prevent
tilt and collapse.
1) Check whether the screws and nuts are tightened to prevent collapse during use.
2) When preparing for work, check whether the universal wheel is locked to prevent
sliding during use.
3) Use safety devices. Always wear gloves.
4) Maintain the poable workbench, check the installation deviation of the moving
pas, whether it is stuck, screw damage and other conditions aecting the opera-
tion of the poable workbench, such as damage, poable workbench must be
repaired before use, many accidents caused by poor maintenance.

03
MAINTENANCE
PRODUCT PARAMETER
1) Send your poable workbench to professional maintenance personnel, must use
the same spare pas for replacement, this will ensure the safety of use after mainte-
nance.
Model
Length
Width
Maximum Adjustable Height
Medium Adjustable Height
Minimum Adjustable Height
Load Limit
G.W
N.W
LCWB90
700 mm
600 mm
900 mm
850 mm
800 mm
100 lbs
25.4 kg
21.9 kg

04
STRUCTURE AND PART NAME

05
Name of Pas:
1: Platform
2: Panel
3: WB90 Column
4: WB90 Column
5: Bulkhead
6: Bower Bulkhead
7: Universal Wheel
8: Directional Wheel
9: M6 Flange Nut
10: M6 Carriage Screws
11: M8 Hex Socket Screws
12: M8 Flange Nuts
13: Inner Hexagonal Wrench
14: 13-10 Open End Wrench

06
ASSEMBLE STEPS
STEP. 1
Put 11 (M8 hex screw) into 7 (universal wheel) and 8 (universal wheel) screw holes
and then screw 12 (M8 ange nut) into them with 13 (hex wrench 6) and 14 (13-10
open end wrench) to tighten and x them.
STEP. 2
Put 10 (M6 carriage screw) into the screw hole of 4 (WB90 column 2) and screw 9
(M6 ange nut) into it with 14 (13-10 open wrench) to tighten and x it.
STEP. 3
Put 5 (divider) into 4 (WB90 column 2), put 10 (M6 carriage screw) into its screw
hole, and screw 9 (M6 ange nut) into it with 14 (13-10 open end wrench) to tighten
and x it.
STEP. 4
Fix 3 (WB90 column 1) After the remaining two holes in its 4 (WB90 column 2), put
10 (M6 carriage screw) into it, and then screw in 9 (M6 ange nut) with 14 (13-10
open wrench) to tighten and x it.
STEP. 5
Fix 2 (panel) into 3 (WB90 column 1) to its screw holes, and then put 10 (M6 carriage
screw) into the top two holes, and then 9 (M6 ange nut) into the 14 (13-10 open
end wrench) to tighten and x it.
STEP. 6
Put 1 (bench) on the 2 (panel) after the screw hole, then put 11 (M8 hex screw) into
the four holes, and then screw 12 (M8 ange nut), use 13 (hex wrench 6) and 14
(13-10 open wrench) to tighten and x it.

07
ADJUST THE HEIGHT
1) The maximum height is 900mm as shown in the gure below. 1.2.3 in 3 (WB90
column 1) and 4 (WB90 column). The holes are aligned, and 10 (M6 carriage screws)
and 9 (M6 ange nuts) are put in and tightened with 14 (13-10 open spanner).
2) Medium height 850mm as shown below: 2.3.4 in 3 (WB90 column 1) and 4 (WB90
column 2) as shown below. The holes are aligned, and 10 (M6 carriage screws) and 9
(M6 ange nuts) are put in and tightened with 14 (13-10 open spanner).

08
3) The minimum height of 800 is shown as follows: 3.4.5 in 3 (WB90 column 1) and 4
(WB90 column 2) as shown below. The holes are aligned, and 10 (M6 carriage
screws) and 9 (M6 ange nuts) are put in and tightened with 14 (13-10 open span-
ner).

09
Impoer: WAITCHX
Address: 250 bis boulevard Saint-Germain 75007 Paris
Impoer: FREE MOOD LTD
Address: 2 Holywell Lane, London, England, EC2A 3ET
MADE IN CHINA
Manufacturer：ZHEJIANG LANGCHENG INDUSTRY&TRADE CO., LTD
Address：No.18 Weisan East Road, Hardware Machine Industrial Zone,
Tongqin Town,Wuyi County, Jinhua City 321201 Zhejiang, P.R.China

E-mail: CustomerSe[e-mail]
