Viavi OneAdvisor 800 Series User manual

Page 1 of 43
Method of Procedure - CellSite Installation
Fiber Inspection, Fiber Continuity, Optical Insertion Loss, OTDR and Cable & Antenna
Testing
OneAdvisor 800

Page 2 of 43
Table of Contents
1. Scope .......................................................................................................................................................... 3
2. Typical Carrier Test Standards .................................................................................................................... 4
3. Test Applications Overview ........................................................................................................................ 5
4. Required Products ...................................................................................................................................... 6
5. CellSite Installation Test Overview ............................................................................................................. 9
5.1 Fiber Inspection and Test – Simplex/Duplex ...................................................................................... 9
5.1.1 Overview .................................................................................................................................... 9
5.1.2 Fiber Inspection Workflow ....................................................................................................... 10
5.1.3 Tools: Fiber Inspection Microscopes ....................................................................................... 10
5.1.4 Tools: Fiber Inspection Tips and Cleaners ............................................................................... 11
5.1.5 Fiber Inspection Testing – p5000i ............................................................................................ 12
5.2 Fiber Inspection and Test - MPO ...................................................................................................... 14
5.3 Continuity Test with a Visual Fault Locator ...................................................................................... 16
5.4 Optical Insertion Loss ....................................................................................................................... 17
5.4.1 Tools: ONA-800 OTDR with Optical Source (CW) and USB Optical Power Meter (MP-60/80) 17
5.4.2 Insertion Loss – Performing the Test ....................................................................................... 19
5.5 OTDR Testing .................................................................................................................................... 22
5.5.1 OTDR Test Overview ................................................................................................................. 22
5.5.2 Test Setup ................................................................................................................................. 22
5.5.3 Instrument Setup and Test - OTDR........................................................................................... 23
5.6 Cable and Antenna Testing .............................................................................................................. 29
5.6.1 Return Loss, VSWR and Distance to Fault Overview ................................................................ 29
5.6.2 Initial Setup .............................................................................................................................. 31
5.6.3 RF Reflection Test ..................................................................................................................... 33
5.6.4 RF Distance to Fault (DTF) ........................................................................................................ 36
5.6.5 RF Cable Loss ............................................................................................................................ 38
5.6.6 Save Measurement Results ...................................................................................................... 40
6. Remote Control ........................................................................................................................................ 41
7. Technical Support ..................................................................................................................................... 43

Page 3 of 43
1. Scope
This document describes how to configure the OneAdvisor-800 (and Fiber Accessories) for
- Fiber Inspection, including:
o Fiber Endface and Bulkhead Analysis
o Simplex, Duplex and MPO Endfaces
- Fiber Continuity Testing
- Optical Insertion Loss
- Optical Time Domain Reflectometry, including:
o Optical Insertion Loss
o Event Characterization
o Event Loss and Length
- Cable and Antenna Testing, including:
o Reflection tests: Return loss and VSWR
o Distance to Fault
o Cable Loss

Page 4 of 43
2. Typical Carrier Test Standards
The following parameters are typical test requirements set by various Wireless Network Operators. These
are mentioned here and then again with each applicable test application in this document. The numbers in
bubbles are a reference to the test applications discussed later that provide the required measurement.
Measurement
Passing Criteria
Fiber Inspection
Passing Auto
-
Test according to
IEC
-
61300
-
3
-
xx
Fiber
Reflectance per Connector
More negative than
-
45 dB
Fiber
Loss through a Connector
Less than .5 dB
Fiber
Path loss
-
end to end
Less than 3 dB of loss (
≥
-
3 dB)
COAX
/System
-
Return Loss
-
12dB to
-
16dB typical
VSWR
/System
1:67
to 1:37

Page 5 of 43
3. Test Applications Overview
Figure - Test Access Points at the Tower

Page 6 of 43
4. Required Products
The required products and parts to complete this procedure are as follows:
Test
Point
Test
When
Why
Where
With
1 Fiber
Inspection:
Inspect Before
You Connect
(IBYC) –
Simplex/Duplex
Fibers
Anytime a
fiber
connection is
about to be
made. It is
also useful to
pre-inspect
fibers in a
hybrid cable
before
installation.
Dirt and debris
in connections
will cause
system failure.
Dirty fibers can
be cleaned.
Damaged ones
should be
replaced.
Every
Connection.
Often
forgotten are:
 SFP ports
 OTDR port
This is all the
Tower Top
Technician
needs
USB Fiber Inspection Probe –
p5000i
Wireless Fiber Inspection
Probe – Fiberchek
Fiber Inspection Tips
1 Fiber
Inspection:
Inspect Before
You Connect
(IBYC) – MPO
Fibers
Any Fiber
using an
MPO
Connector
such as
Corning
Optitip,
Jonhon,
CommScope
HMFOC and
ODC MPO
connectors
Dirt and debris
in connections
will cause
system failure.
Dirty fibers can
be cleaned.
Damaged ones
should be
replaced.
At the Top of
the Tower, at
the junction
box.
At the Bottom
of the Tower,
at the handoff
from Fronthaul
to Tower.
May be done
at the Top and
Bottom of
Tower
depending on
network
architecture
MPO Inspection Probe –
Sidewinder
MPO Fiber Cleaner
2 Continuity Test:
Visual Fault
Locator (VFL)
Use to prove
basic
continuity
and make
sure the
ground tech
and the
climber are
working on
the same
fiber pair
Reduces
confusion and
speeds up
work- flow.
Reveals
mislabeling.
Reveals
damaged fiber
jumpers
On the Hybrid
and on any
fiber jumpers
to be used.
Done from the
bottom of the
tower.
VFL – FFL-050

Page 7 of 43
Test
Point
Test
When
Why
Where
With
3 Optical
Insertion Loss:
Optical Light
Source and
Optical Power
Meter
During
Construction,
as it requires
an optical
light source
at one end
and an
optical
power meter
at the other.
Such access
requires a
tower climb.
If you have
an OTDR,
skip this test
as an OTDR
result
includes this
measure.
Reveals overall
loss through
the fiber
system. Should
be less than
3dB. If it
passes, move
on. If it fails,
isolate problem
with VFL/OTDR.
If you have an
OTDR, skip this
test as an OTDR
result includes
this measure.
Through one
fiber in a pair
within the
hybrid, thru
the RU jumper
with a
loopback on
RU end of the
jumper, back
down to the
source. If you
have an OTDR,
skip this test as
an OTDR result
includes this
measure.
From the
Bottom
ONA-800 with OTDR CW Light
Source
ONA-800 with USB Optical Power
Meter – MP-60/80
4 Optical Time
Domain
Reflectometry
(OTDR)
During
Construction.
Test both TX
and RX on a
duplex fiber
(up and
back) via a
loopback
fiber placed
at the RU
end. This is
done for
efficiency
(half the
tests)
An OTDR
provides a
much more
detailed
characterization
of the fiber
system.
Problems are
immediately
identified based
on their
distance from
the source
Through one
fiber in a pair
within the
hybrid, thru
the RU jumper
with a
loopback on
RU end of the
jumper, back
down to the
source. From
the Bottom
OTDR - ONA-800 Front
OTDR – ONA-800 Side
ONA-800 Modules

Page 8 of 43
Test
Point
Test
When
Why
Where
With
5 Cable and
Antenna
Testing
Accessories – Cable and Antenna Module
Open Short Load (OSL) Calibration Kit either Electronic (Manual or
EZcal)
- Manual OSL calibration kit Type-N(m)
- EZcal, electronic OSL calibration kit Type-N(m)
Manual EZCal
JD78050509 JD70050509
RF Cables
- RF Cable DC to 8 GHz Type-N M to Type-N (F) 1.5 m
G700050531
Accessories – Fiber Tools
OTDR Jumper Cable
>=20 meters
Fiber Cleaner(s)
IBC Cleaner for Bulkheads,
Jumpers and SFPs
Cletop for Fiber Jumpers Only

Page 9 of 43
5. CellSite Installation Test Overview
The OneAdvisor is a portable instrument for Cell Site installation and maintenance, the main test functions
of OneAdvisor for cell site installation include:
- Fiber Inspection
- Continuity Testing
- Optical Insertion Loss
- Fiber Characterization - OTDR
- COAX Sweep Testing - Cable and Antenna
5.1 Fiber Inspection and Test – Simplex/Duplex
5.1.1 Overview
Every fiber connection is a potential point of failure should the end face of the mated fibers be dirty or
damaged. Proper handling as well as inspection and cleaning techniques are imperative. The best practice
is to Inspect Before You Connect (IBYC). Trace the steps on the flow chart below. Always inspect before
that first cleaning attempt. If the end face is already pristine, the redundant cleaning effort could introduce
a problem.
Most Operators require fiber inspection of every end face in the path to the IEC-61300-3-35 Standard.
The VIAVI P5000i and FiberChek Pro both provide automated pass/fail analysis to this standard.
Measurement
Passing Criteria
Fiber Inspection
Passing Au
to
-
Test according to IEC
-
61300
-
3
-
35
Fibercheck - Fiber Inspection Quick card

Page 10 of 43
5.1.2 Fiber Inspection Workflow
5.1.3 Tools: Fiber Inspection Microscopes
FiberChek Probe shown below. Full Pass/Fail Analysis and results saving can be done on the FiberChek
Probe/Sidewinder. Or it can be connected via USB or WIFI to a PC/Android/IOS/ONA.
The P5000i Microscope shown below operates with a PC/Android/TBERD or purpose built VIAVI displays.
The FiberChek Probe and P5000i use the same adapters for the various interfaces you will encounter.
Study the following table for proper adapter tips and cleaning options.
Inspect Before You Connect
When you are building or
troubleshooting a site, it is all about
eliminating possible sources of
problems. Making sure fibers AND ports
(Bulkheads and SFPs) are clean and
undamaged is a quick and simple step
that should be undertaken as soon as
the decision is made to make/break any
fiber connections.

Page 11 of 43
5.1.4 Tools: Fiber Inspection Tips and Cleaners
Fiber Type /
Connector
Tip(s) to use on
FiberChek/P5000i
Cleaning options
LC Fiber
Used at DU to
Hybrid
connection
and at the RU
side of tower
jumper.
Possibly on
CSR
FBPT-U12M
LC type IBC Cleaner (above) Cletop (below)
SFP/SFP+
In DU and RU.
Possibly on
CSR
FBPT-LC
Clean the TX side only if it has the same appearance as a
fiber (picture on far left). The RX side of SFP should not be
cleaned, just inspected to make certain there are no large
obstructions. Remove the entire aqua blue cap from the pen
to clean the SFP or a bulkhead (see below)
LC Bulkhead
or Patch Panel
FBPT-LC
ODC
–
O
ut
-
Door
Connector
Located at top
of the hybrid
to the RU
jumper cable
on Ericsson
To inspect ODC fibers, the BAP-3
Barrel assembly should replace
the BAP-1 barrel on the probe
and then the Male/Female
guides are used to align the
H125 type IBC Cleaner

Page 12 of 43
Fiber Type /
Connector
Tip(s) to use on
FiberChek/P5000i
Cleaning options
BAP
-
3 over the fibers. See
right >>
SC
-
APC
FBPT-SC-APC OTDR Test Port
SC
-
APC
Connector on
OTDR Launch
Fiber
FBPT-U25MA
Note that the TBERD 5800 OTDR Port and the 10M launch
fiber may have the SC-APC style green connection. A is for
Angled. The 8-degree angle on the end face creates a
superior connection in terms of reflectance and durability.
The OTDR port can be cleaned with a SC style IBC stick
cleaner (shown above). The fiber itself can be cleaned with
that as well or with wipes, CLETOP, etc. The tips for the
inspection scope have a built-in angle as well. Be sure and
inspect and then protect the cleanliness of your OTDR port
and launch fiber.
5.1.5 Fiber Inspection Testing – p5000i
Step
Action
Description
/Diagram
1
Press
and hold
the ON/OFF
button to turn on the ONA-800.
Press the Home Key
Select the Microscope Tab

Page 13 of 43
Step
Action
Description
/Diagram
2
Fiber end
-
face will appear on
screen
Confirm “Focus Bar” is suitable
Using Drop-Down, select type
of connector profile
Select Test
3
Analyze Pass / Fail
If Test fails, please clean the
fiber end face and retest with
scope procedure.
If Test passes, move-on to VFL
Testing.
3
Analyze Pass / Fail
If Test fails, please clean the
fiber end face and retest with
scope procedure.
If Test passes, move-on to VFL
Testing.

Page 14 of 43
5.2 Fiber Inspection and Test - MPO
As with simplex fiber, MPO connections are a potential point of failure should the end face of the mated
fibers be dirty or damaged. However, whereas simplex fibers are a single connection, an MPO has 8-24 fiber
connections. Proper handling as well as inspection and cleaning techniques are imperative. The best
practice is to Inspect Before You Connect (IBYC). Trace the steps on the flow chart below. Always inspect
before that first cleaning attempt. If the end face is already pristine, the redundant cleaning effort could
introduce a problem.
Examples of MPO connectors on the Tower are Corning Optitip, Jonhon, CommScope HMFOC and ODC
MPO connectors.
Most Operators require fiber inspection of every end face in the path to the IEC-61300-3-35 Standard.
The MPO Sidewinder provides automated pass/fail analysis to this standard.
Measurement
Passing Criteria
Fiber Inspection
Passing Auto
-
Test according to IEC
-
61300
-
3
-
35
Tools: MPO Fiber Inspection Microscope and cleaning tools/supplies
The MPO Sidewinder is shown above. Full Pass/Fail Analysis and results saving can be done on the MPT
Sidewinder alone. Or it can be connected via USB or WIFI to a PC/Android/IOS/ONA.

Page 15 of 43
Fiber Type /
Connector
Tip(s) to use on
MPO
Sidewinder
Inspection and
Cleaning opti
ons
MPO Fiber
OptiTip
ODC
Used at the
Hybrid
connection
and at the DU
side of tower
jumper.
FCPT-MTPA FCPT-MTP
FCPT-COD-MTA-P FCPT-COD-MTA-R
FCPT-ODC12A-P FCPT-ODC12A-S
Sidewinder
connection to
MPO jumpers
and
connectors
FCPT-MTPA FCPT-MTP
OptiTip
Connectors
Located at top
of the hybrid
to the RU
jumper cable
ODC – Out-
Door
Connector
FCPT-COD-MTA-P FCPT-COD-MTA-R
FCPT-ODC12A-P FCPT-ODC12A-S

Page 16 of 43
Test Examples from the MPO result
MPO Fiber Inspection Quick card
5.3 Continuity Test with a Visual Fault Locator
A VFL is handy device that should be in the tool kit for anyone who deals with fiber optics. Use it to inject
visible red light through a fiber under test up to 5 km on single-mode fiber. Seeing the red light at the far
end of the fiber proves to the observer that there is continuity. It also resolves the “Are we on the same
fiber?” question. If it is a short fiber or fiber jumper, you can also look along the length of it for any red
light escaping from a bend, break, or cut.
When installing a fiber system for a macro cell site, the VFL is a time saver. When testing each TX/RX fiber
pair, a loopback device or cable can be placed at the far (usually the RU end) of the fiber pair. The VFL’s red
light is shined up one fiber and returns on the other. If it does not, the person at the far end might notice
the red light coming from a fiber other than where they connected the loopback and make the adjustment.
An FFL-050 VFL is shown below left. Below right shows a simplex coupler for connecting the VFL through a
short jumper. The duplex fiber in the right portion of the picture is eventually looped back and the red light
comes out of the other fiber in the pair. The back of business card is held there just to show this for a
photograph.
FFL
-
050 Visual Fault Locator

Page 17 of 43
The picture below shows as example of the LC Duplex connector at the RU end of the tower top jumper. A
duplex coupler can be used to then connect a simplex fiber as a loopback.
Once Continuity is proven with a VFL you can move on to an Optical Insertion Loss Measurement or an
OTDR Measurement.
5.4 Optical Insertion Loss
This is a measurement of the total optical power loss from the beginning to the end of the fiber system. In
a tower or rooftop site during construction, this would typically be from the bottom, to the top, through a
loopback cable or device, and back to the bottom. This speeds up and simplifies the test by keeping the
Source and Meter at ground level. On a 12-pair hybrid, this also cuts the test count from 24 to 12. This
step comes immediately after IBYC and creating the loopback and proving continuity with the VFL (see
above). However, if an OTDR is available, skip the Optical Insertion Loss test because a system loss
expressed in dB is one of the results that an OTDR provides. Doing both tests would be redundant. Use the
Insertion Loss Test as part of a spot check at the warehouse or on the ground before hoisting. The use of an
OTDR test is recommended for final close-out. The OTDR provides the system loss information as well as
the per event reflectance and per event loss information required.
Most Operators expect a round trip Insertion Loss (IL) value to be less than 3 dB (half power loss)
Measurement
Passing Criteria
Path loss end to end
Less than 3 dB of loss (
<
-
3 dB)
5.4.1 Tools: ONA-800 OTDR with Optical Source (CW) and USB Optical Power Meter (MP-
60/80)
This test has 2 steps.
1) (Left picture below) As always, IBYC. Then the Light Source and the MP-60/80 Power Meter needs
to be connected to each other using the clean test leads that will be used in the actual test. Use
1310 nm for Single Mode Fiber. Regardless of the absolute power from the source (in dBm) the
Power Meter is referenced to 0 dB. This also negates any losses from the test leads themselves.
2) (Right picture below) Now the Light Source and Power Meter are connected to the system under
test using the same test fibers that have been referenced out. The loopback established in the
Continuity Test earlier is still in place. Read the value on the power meter. It will be expressed in

Page 18 of 43
dB to indicate loss as compared to the reference test. We expect a negative value close to 0.
Anything better than 3 dB of loss is passing.
1 – Referencing of the Test/Jumper Cables 2 – Connecting to System under test
There are many Power Meters that could be used for this test. The one shown above is the MP-60A Power
Meter plugged into the ONA-800. It is screen-less device with a USB connection to be plugged into a ONA-
800 (display shown on left) in these illustrations. Both examples are passing because the result is that the
loss is less than 3dB. Read that as NOT more negative than 3dB.
1
2

Page 19 of 43
5.4.2 Referencing Fiber Jumpers / Performing the Test
1
Connect
two
test jumper
s
from
the ONA-800 OTDR Port to the
MP-60 installed into the USB
port of the ONA thru a coupler
as shown
2
Press the Home Key
Select the Fiber 1 Module
Select the Source key
3
Confirm module is in “CW’
mode and confirm wavelength
(1310nm)
Using drop down menus.
Select “Laser Start”

Page 20 of 43
4
Confirm power and wavelength
measurement with MP-60.
Select
Tap
Select 1310nm
Tap
Select ‘dB’
Verify Results / Power Level
5
Once in the dB mode
, t
ouch the
ABS>REF button to “reference
out” the test cables
The fiber jumpers have now
been referenced into the results
