COMPRO TN65 User manual

Network Camera
Model No.
V1-130430
TN65
TN65W

Copyright
© 2013 Compro Technology, Inc. All rights reserved.
Trademark
Compro and Compro logo are trademarks of Compro Technology, Inc. C4Home and C4Home logo
are registered trademarks of AVSecur Technology, Inc. SD, SDHC and microSDHC Logos are trademarks
of SD-3C, LLC. Apple, Apple Logo, MAC, MAC OS, iPhone, iPad are trademarks of Apple Inc., registered in
the U.S. and other countries. Other names and marks may be trademarks of their respective owners.
Restriction
No part of this document may be copied or reproduced in any form or by any means without the prior
written consent of Compro Technology, Inc.
Disclaimer
Compro Technology makes no warranties with respect to this documentation and disclaims any implied
warranties of merchantability, quality, or fitness for any particular purpose. The information in this
document is subject to change without notice. COMPRO reserves the right to make revisions to this
publication without obligation to notify any person or entity of any such changes.
Revision History
2013/04/30 Original Version
Compro Technology, Inc.
www.comprosecurity.com
Tel. [phone], Fax [phone]
4F, No.12, Alley 6, Lane 45, Pao Shin Road,
Hsintien District, New Taipei City 231, Taiwan
Support e-mail: suppor[email protected]

01
<頁頁頁頁頁頁>
Contents
Contents
Chapter 1: Important Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Regulatory Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
FCC Interference Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Operation Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Conventions in this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Chapter 2: Product Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
TN65/TN65W Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Camera Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
LED Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Digital I/O Connector Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Chapter 3: Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Connect the Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Setup Network Camera from iPhone/Android phone or tablet . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Setup TN65W Network Camera from WPS Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Setup Network Camera from PC and Installation CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Wireless Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Compro iDDNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Disassembling and Assembling the Camera Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-11
Mounting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
Dismounting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13
Chapter 4: Accessing the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Ways of Viewing Live Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Instant Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
From C4Home iPhone/Android App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2
From Android Phone/Tablet App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
From C4Home Website . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Accessing via PC Web Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Accessing via M-JPEG Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Accessing via 3GPP Mobile Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Chapter 5: Live View (With WebVUer on PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Page Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Icons on Live View Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Left Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Enable Digital Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Voice Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3
Chapter 6: Conguration (From WebVUer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Main Setup Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Video Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Video Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Stream Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Video Buer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Video Preference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Camera Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3
Video Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-3

02
<頁頁頁頁頁頁>
Compro TN65/TN65W Network Camera
Backlight Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Flickerless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Exposure Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Low Light Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
LED Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Embed Text and Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Flip Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
User Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-5
Network Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
Network Diagnostic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-6
Network Bandwidth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
DDNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
RTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Event Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Event Server Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-8
Trigger Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Motion Detection Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
I/O Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Audio Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Recording Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Recording History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Date Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Multi-Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Chapter 7: Event Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Chapter 8: Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Reboot Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Prole Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Reset All Settings to Default. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Firmware Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
Chapter 9: Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Reset to Factory Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Trouble with the ActiveX Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-2
No user interface in the browser: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-2
Trouble with Remote Viewing on Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
DDNS Conguration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
Symptoms, Causes and Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-7
Contacting Compro Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13
Chapter 10: Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
TN65/TN65W Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1
Chapter 11: Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
Examples of Port Forwarding Setup on Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
Abocom WAA813rn Port Forwarding Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
ASUS RT-N12 Virtual Server Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1
D-Link DIR-655 Virtual Serve Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
TP-LINK wr1043n Virtual Server Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-3

1-1Regulatory Notice
<頁頁頁頁頁頁>
Chapter 1: Important Notices
Chapter 1: Important Notices
Regulatory Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
Operation Safety
Before starting using the camera, please read and follow the steps below to protect your IP camera.
• PleaseplacetheIPcameraonalevelsurfaceandoutofdirectsunshine.
• PleasekeeptheIPcameraindoorsandawayfromwater,dust,humidityormagneticproducts.
• PleasedonotdroptheIPCamerabodytotheoor;itmaycausethedamagetomainparts.
• Pleasedonotdisassembleorremodeltheproduct;itmaycausedamageorre.
• Donotshake,moveordisturbtheIPcamerawhenitisinoperation,assuchactionsmayresultinthe
malfunction of the device.
• PowerotheIPCameraassoonasitisfoundsmokingorsmeltunusual.
• PleasedonotplacetheIPCameraaroundtheheatsources,suchastelevisionormicrowaveoven.

1-2
<頁頁頁頁頁頁>
About this Manual
Compro TN65/TN65W Network Camera
About this Manual
This manual is only intended for the users of Compro TN65/TN65W network camera.
Conventions in this Manual
While you are using this manual, pay attention to some symbols and notations that are used to draw
attention to special situations such as:
Caution!
Information provided here is critical to prevent damage to the product or
injury to the user.
!
Important:
Here it provides instructions that a user must follow in order to complete
a task.
Note:
Additional information or tips to help the user operate the product.

2-1Package Contents
<頁頁頁頁頁頁>
Chapter 2: Product Overview
Chapter 2: Product Overview
Package Contents
Please check the package contents on your hand. If anything is missing, please don’t hesitate to contact your
local distributor.
Figure 1-1. Parts list
Network Camera
RJ-45 LAN Cable
Power Adaptor
Quick Start Guide
Installation CD
Mounting Screw x 3 /Screw Mount x 3

2-2
Camera Layout
Features
Compro TN65/TN65W Network Camera
Features
The camera is an easy-to-install product with support for the H.264/MPEG-4/MJPEG video compression
format that help achieve superior performance and high video quality at reduced bandwidth utilization,
which also means a much lower cost for data storage. Utilizing smart motion detection and built-in 2-way
audio for fast and easy communication, the camera ensures instant responses when security is compromised.
The camera also comes with a built-in microSD slot for local image storage.
TN65/TN65W Features
• 1/3"CMOSMegapixelsensor
• Supportsreal-timeH.264,MPEG-4andMJPEGcompression(TripleCodec)
• Supportsdualstreamssimultaneously
• Support10xdigitalzoom
• Videoresolutionupto1280x1024pixels
• Imageframerateupto30framesat640x480or15framesat1280x1024
• Smartmotiondetection
• Two-wayaudiowithbuilt-inMICandspeaker
• SupportsUPnP(universalplugandplay)
• Supports10/100802.3/Ethernet
• Upgradablefor802.11b/g/nwirelessLAN(TN65Wmodelincludesthewirelessadaptor)
• DigitalI/OforExternalSensorandAlarm(2In/1Out)
• Supportslocalstorage(microSD),Snapshot
• ExclusiveC4HomeTM smartphone and tablet app
• RemoteMonitoringon3GPPmobilephonesorphoneswithwebbrowser(e.g.iPhone/BlackBerry)

2-3Camera Layout
Features
Chapter 2: Product Overview
Camera Layout
Figure 1-2. Front and rear view of TN65
Lens
Microphone
Speaker
LED status indicator
USB Wireless adapter connector
Audio output
Reset button
microSD card slot (on the side)
Microphone input
Power adapter port
Ethernet port
I/O port (2 in / 1 out)

2-4
Digital I/O Connector Block
LED Status Indicator
Compro TN65/TN65W Network Camera
LED Status Indicator
The instant you power on the camera, it automatically starts the booting procedure. There are one blue LED
and one red LED inside the camera casing. Depending on the booting status, the LED indicator will be lit in
the following way:
1. About 25 seconds after powering on the IP camera, both the blue LED and red LED indicator will become
lit (appears purple).
2. About 35 seconds after powering on the IP camera, the red LED will be turned o.
3. Cameratryingtoconnecttonetwork:bothblue&redLEDashingatanintervalof0.5second.
4. Camera established connection: blue LED constantly on (Red LED o)
5. Camerafailedtoconnect:ashingredLED.(BlueLEDo )
Red LED Blue LED Indication
On On System booting up
O On Successfully established network connection
On O Performing hardware test
O O Powered o
Blinking (every 0.5 sec.) O Failed to connect to network / failed to
establish a WPS connection
O Blinking (every 0.5 sec.) Attempting to establish a WPS connection
O Blinking (every 0.2 sec.
in a 3-second period) Successfully established a WPS connection
Blinking (every 0.5 sec.) Blinking Attempting to establish network connection
Table 1-1. LED status
Table 1-2.
Figure 1-3. Normal connection

2-5Digital I/O Connector Block
LED Status Indicator
Chapter 2: Product Overview
Digital I/O Connector Block
The I/O connector on the back of the camera provides a central interface between your home security system
and various output devices.
The two digital inputs are normally used with security sensors, e.g. passive infrared sensors (PIR), smoke
detectors, door/window sensors, etc. They work by detecting a change in the state of open and closed circuit.
You can check the status of the circuit in [Setup] > [Event Setup] > [I/O Status].
The output port is normally used to trigger external audio or visual indicators, e.g. sirens or strobe lights, etc.
Pin Name Specications Note
1 – 4 Digital Input Ports 1 & 2 Max 5VDC, 60mA Floating, TTL
5 - 7 Digital Output Port Max 24V DC, 1A or
Max 125V AC, 1A
You can only use either
the Normally Open (NO) or
Normally Closed (NC) at any
given time.
Table 1-3. Digital I/O Connector
Figure 1-4. Schematic diagram of digital IO
Note:
The above output scenario is where the siren will only sound when the input has
been triggered. Should you wish to use the opposite way in which the output device
keeps staying on until the input has been triggered, please use NC.
IP55/60/70 IP55/60/70

2-6
<頁頁頁頁頁頁>
Digital I/O Connector Block
Compro TN65/TN65W Network Camera

3-1Connect the Cables
<頁頁頁頁頁頁>
Chapter 3: Installation
Chapter 3: Installation
Connect the Cables
The illustration below shows the basic cabling of your network camera.
Setup Network Camera from iPhone/Android phone or tablet
Figure 3-1. Connection of cables
Connect an Ethernet cable between your network camera and your network switch/router.
If your package include a wireless adaptor, please plug it into the USB port of network camera for
wireless reception. The camera’s USB port only supports the wireless adapters from Compro. Do not use
any other USB adapters on Compro IP cameras. You must setup the network camera with Ethernet cable
connected then go to wireless setup.
Attach the power adapter to the camera’s power connector and connect the power plug to a
power outlet. When it power on successfully, the LED indicator will shows blue light.
Make sure your smartphone is able to go to internet via your wireless router. Then download the
C4Home app from Apple app store or Google Play and install to your smartphone. Start C4Home app and
register your personal C4Homeaccount..

3-2
Connect the Cables
Connect the Cables
Compro TN65/TN65W Network Camera
Login to the C4HomeTM accountandclick"+"toaddnewcamera,weprovide3waystoaddyour
camera:
• Scan the QR code from the back side of camera, it will automatically add your camera to the list.
• Direct input the camera ID (10 digitals under the QR code) and password (default: admin) to add
your camera.
• Click “iWizard” button on add camera page to search the available camera from your local network
and setup. In this wizard, you can setup camera and wireless connection (TN65W only).
Now you can watch live video of your network camera from your smartphone or tablet.
Setup TN65W Network Camera from WPS Connection
If your wireless router support WPS connection setup, you can use it to setup TN65W network camera directly
from WPS and no Ethernet cable required.
Plug in the power of your TN65W nerwork camera and install the wireless adaptor to camera's USB
port. Do not connect the Ethernet cable to the network camera. (If you connect the Ethernet cable, the
network camera will running the cable mode.) The LED indicator in the front of network camera will shows
blinking red.
Press the WPS button on the wireless router about 3 sec. to turn on the WPS setup. (The WPS setup
maybe vary from dierent router manufacturers, please refer to the user’s manual of your wireless router
for WPS setup.)
WPS
WPS Button
One-click the RESET button on the network camera within 1 minute. And wait for about 1 minute
for the connection between wireless router and nerwork camera.
One-click the reset button to setup WPS
When the connection is established, the LED indicator will shows blue light.
0123456789
00:12:34
RESET Button

3-3Connect the Cables
Connect the Cables
Chapter 3: Installation
Open the C4Home app from your smartphone and add camera to your list.
If the WSP setup is not working, please try to setup the network camea with Ethernet cable connection.
!
Important:
• WiththeComprowirelessantennainstalledonTN500Wmodel,you
can also option for using the wireless connection. Please keep in mind
that you can only have one active connection at a given time, either
through LAN or wireless network.
• IfyouconnecttheIPcameratotheIntranet,thenthesamegroup
of users can share the access of IP camera. Please also ensure that
the wireless antenna has been securely installed, or it could lead to
unstable connection.
• Ifthewirelessconnectiondropsrandomlyorplainlyseemsslow,try
bringing your IP camera in closer proximity to the wireless AP/router
and then see if the situation improves.
• Havingmorewallsandceilingsbetweenthewirelesslyconnected
Compro camera and your wireless AP/router will negatively aect your
wireless connection speed. Generally, the number of walls and ceilings
shall be kept in minimum.
• Materialsandobjectslikesolidmetal,aluminum,steel,water,brick,
and concrete will weaken the strength of the wireless signal. Allow
the wireless signal from your wirelessly connected camera and your
wireless AP/router to pass through open doorways when positioning
them.
• Theoperationofthewirelessnetworkmaybeinterferedshouldthere
be other 2.4 GHz devices working in the vicinity, e.g. microwave oven,
digital cordless camera, etc. You may experience slow frame rate or
dropsofconnection;insuchsituation,wesuggestyoutrymovingthe
IP camera away from the area or turning o other appliances.
• Sincewirelesscamerascancauseinterferencesontransmission,you
may encounter erratic behavior when there are more than 10 cameras
operating in close proximity.
• Thedefaultwirelessconnectionmethoduses802.11nstandardand
you should experience a stable connection on your camera within 20
meters of the access point. .

3-4
Connect the Cables
Connect the Cables
Compro TN65/TN65W Network Camera
Setup Network Camera from PC and Installation CD
Figure 3-2. Connection of cables
Connect an Ethernet cable between your PC and your network switch/router.
Connect an Ethernet cable between your network camera and your network switch/router.
If your package include a wireless adaptor, please plug it into the USB port of network camera for
wireless reception. The camera’s USB port only supports the wireless adapters from Compro. Do not use
any other USB adapters on Compro IP cameras. You have to setup the network camera with Ethernet cable
connected then go to wireless setup.
Attach the power adapter to the camera’s power connector and connect the power plug to a
power outlet. When it power on successfully, the LED indicator will shows blue light.
Complete the cable connection, we provide 2 ways to add your camera:
• Login to C4HomeTM website (www.c4home.com) and add camera to the list. C4Home website not
support the wireless setup of network camera. Please use C4Home app or installation CD for
wireless setup.
• Insert the installation CD to your CD/DVD drive, and running the iWizard.exe to install IP camera.
Caution!
• ThewirelessconnectionportonlysupportstheComprowireless
adapters;pleasedonotuseotherUSBadaptersonComproIPcamera.
Should you remove the wireless adapter during camera operation,
you need to power o the camera rst before re-plugging it.
• Whenyouunplugthepowerplugfromthewalloutletwhilethe
camera is still in operation, wait for 4 seconds before plugging the
power plug back in the wall outlet. And avoid too frequent plugging
and unplugging of power cable.
• Ifthepowercableandthenetworkcableconnectedtothecameraare
not securely fastened, it could lead to unstable connection.

3-5Connect the Cables
Connect the Cables
Chapter 3: Installation
Note:
You can add more Compro cloud network camera to your account for
management. C4HomeTM app allow maximum 16 network cameras
installed.
To begin setup, insert the installation CD into your CD-ROM drive, and the iWizard will start automatically.
Note:
If Autorun has been disabled in your computer, please browse the
contentsoftheinstallationCDanddouble-clickonthe"iWizard.exe"
le to run the setup wizard.
1. Select the language for installation
network camera.
Figure 3-3. Language selection
2. Select your camera from the list, and
wait until the live video and camera
information are displayed on the right. (You
can double-check the device name and
the MAC ID which are printed on the serial
number sticker on the back of the camera
and on the package). Click [Next] when
you’re ready .
Figure 3-4. Camera selection

3-6
Connect the Cables
Connect the Cables
Compro TN65/TN65W Network Camera
3. The default password is `admin.’ Enter a
new password here (please note down
your new password). You can also click
[Next] to skip this process.
Figure 3-5. Password setup
4. Check the camera name, date and time
setting.
Figure 3-6. Camera conguration
5. Choose whether to use C4Home service
to remotely access your camera. C4Home
is a platform for viewing, managing
and sharing network cameras over the
internet. You may also use a different
C4Home server by clicking on [Advanced
Settings]. (Default server is www.c4home.
com) (If C4Home service is enabled, iDDNS
service will not be available for use on the
camera.)
Figure 3-7. C4Home setup
Note:
C4Home video streams are encrypted end-to-end and most of the
streams are sent through direct channels and don't pass through
C4Home server, which helps protect user privacy.

3-7Connect the Cables
Connect the Cables
Chapter 3: Installation
6. Choose to have the camera obtain
IP address automatically (DHCP) or
manually assign its IP address. Then set
the connection port and local power
line frequency settings (not available for
change when C4Home service is enabled)
Figure 3-8. Device conguration
7. (For wireless connection setup) If you have
purchased and connected the Compro
wireless adapter to your IP camera, you can
choose to connect wirelessly by default.
The wizard will search for available access
points. Then select one access point to use.
Figure 3-9. Wireless connection setup
8. (For wireless connection setup) Enter the
correct passphrase, and choose the IP
address conguration.
Figure 3-10. Wireless connection setup

3-8
Connect the Cables
Connect the Cables
Compro TN65/TN65W Network Camera
9. (Skip here if you have enabled C4Home
service)IfyouareusingoatingIP,youcan
use DDNS service and create a hostname
that links to your camera’s IP address. Click
[Yes] and input an address name. Then
click [Check Availability] button.
Figure 3-11. iDDNS conguration
Note:
iDDNS is a free DDNS (Dynamic Domain Name Service) service offered by
Compro. iDDNS service is not be available for use when C4Home service is
enabled.IfyouareusingoatingIPaddress,youcanuseDDNSservicetocreatea
hostname that links to your home or oce IP address. Having created the iDDNS
address name, you can then enter `http://xxx (input by yourself).iddns.org’ into
your browser’s address bar to remotely access your camera.
If your local LAN and router have rewall to block attack from outside, you have
to congure the HTTP port on your router. For example, if you set the HTTP port
“2001” for your IP camera, your IP camera’s address will be http://xxx (entered by
you).iddns.org:2001.
10.(Skip here if you didn’t enable C4Home
service.) You need to login to your C4Home
account. If you don’t have a C4Home
account yet, choose to create a C4Home
account and continue with account
registration.
Figure 3-12. C4Home account setup
