General characteristics and functions
GENERAL CHARACTERISTICS AND FUNCTIONS
Thermostat
Touch screen electronic thermostat for room temperature
control (heating and air conditioning) of 2 independent
zones, KNX standard home automation system, 1 NO relay
output 4 A 24 V~, 1 input for electronic temperature sensor
or wired temperature sensor, 1 programmable digital input,
RGB LED backlighting, to be completed with Eikon Evo,
Eikon, Arké or Plana cover plates, grey - 2 modules.
General characteristics
The thermostat is suitable for controlling room temperature
(heating/air-conditioning) in 2 or 4 pipe systems (heating/air-
conditioning) and neutral zone (only in 4-pipe systems), with
the "boost" function to activate a second source that makes
it possible to reach the desired thermal comfort faster; it can
interact with other thermostats and with a monitoring unit (PC
with Well-contact Suite software). It can manage 2 climate
zones completely independently (equivalent to two thermostats
A and B). For each zone the heating/air-conditioning modes are
managed according to the related reference temperature. It is
equipped with a relay programmable as NC or NO that can be
used for general use (e.g. lighting, zone solenoid valve closing,
activating electric towel warmer, etc.) or to control speed 1 of
the fan coil, which is managed by thermostat A or thermostat
B. It also has a digital input programmable as NC or NO,
which can be used for other applications such as detecting an
open window. The thermostat features an RGB display with 5
capacitive buttons for controlling the temperature setpoint and
the speed of the fan coil, the configuration of the operating
modes and the selection of thermostat A or B to view/control; it
has an RGB backlit display whose colours can be adjusted via
parameters with ETS.
Display icons Note. In 4- pipe systems, the display may show errors (E1, E2,
E3, E4) as illustrated on the next page.
Behaviour after bus power on/off
Bus power off: -.
Bus power on: the status will be set based on the setting of the
parameters and the corresponding telegrams sent over the Bus.
Behaviour after reset
As for Bus power-on.
N.B. The thermostat saves the comfort and standby setpoints
set manually by the user; if you wish to reset them, set the ETS
parameter "Reset Setpoint Shift in Economy Mode=YES".
When switched to "Economy" mode, the thermostat will reset
the STBY and CNF values.
FRONT VIEW.
02952
Heating with boost function
Air-conditioning with boost function
Temperature display and thermostat B menu
Temperature alarm due to exceeding threshold
Window open indicator
Temperature measurement unit (°C or °F)
Relative humidity (displayed to the left of the tem-
perature)
Dewpoint alarm (linked to item no. 21, appears to the
left of the temperature)
Fan coil with 3 speeds and proportional control
The 3 speeds of the fan coil are indicated by the
symbols v1, v2 and v3
The proportional speed control is indicated by the
circular icon divided into 10 parts, each one of which
corresponds to 10% of the maximum speed
Comfort (Guest in room)
Standby (Guest not in room)
Economy (Room free)
Off
Protected mode
Buttons locked
Heating valve on
HVAC valve on
Heating valve on
Operation
setup button
Fan coil speed button
Setpoint increase button
Setpoint decrease
button
Ambient
humidity
Fan coil
speed
Thermostat
selection
button
v1
v2
v3
Comfort operation
mode on
Current temperature

6
General characteristics and functions
Thermostat
Neutral zone
The "Neutral Zone" is an operating mode of the thermostat (only
for 4-pipe systems) in which the device keeps the temperature
within a temperature range preset by the Winter Setpoint
and Summer Setpoint (basically, there is no longer the usual
Summer/Winter mode).
If the measured temperature is below the Winter Setpoint, the
thermostat switches on the heating valve and heats the room until
the temperature exceeds the set value (e.g. 20°C for Comfort
mode or 18°C for Standby mode). If the measured temperature
exceeds the Summer Setpoint then the thermostat switches
on the cooling valve and keeps it on until the temperature falls
below the set Summer Setpoint value.
Within the Neutral Zone the thermostat does not switch on any
valves and the temperature can vary freely; this zone is therefore
nothing more than the difference between the Summer and
Winter Setpoints when the room temperature is between the
winter setpoint and the summer one.
To avoid excessive temperature fluctuations, set a limited range
(≤ 2°C) as shown in the figure below.
Setpoint displayed in Neutral Zone operation
When the thermostat is working in the neutral zone, the setpoint
used for the adjustment is always the Current Setpoint, namely
the one relating to the last heating/cooling mode that came into
operation; the value displayed is instead a new setpoint named
"Neutral Zone Setpoint”, which is the average value between
the current summer and winter setpoints.
Changing the temperature of the "Neutral Zone Setpoint” (with
the "+” and "-” buttons on the thermostat) will also cause a
change to the value of the "Shift Setpoint” resulting in a shift
of the two current summer/winter setpoint values; the room
temperature will therefore not become the one set by the guest
but that of the summer/winter setpoint which at that moment
is closest to the value of the current temperature in the room.
Between the two summer/winter setpoints, there is the neutral
zone in which the system is not activated.
Configuration
The KNX 02952 thermostat is configured in Neutral Zone mode
if the following object is NOT connected: "Enable A: Summer -
Winter – control" or "Enable B: Summer - Winter – control".
The KNX 02952 thermostat can operate in Neutral Zone IF:
• The system has 4 pipes
• Winter Comfort Setpoint < Summer Comfort Setpoint
• Winter Standby Setpoint < Summer Standby Setpoint
• Winter Economy Setpoint < Summer Economy Setpoint
• Antifreeze < Too Hot
If these conditions are not satisfied, you can still commission
the thermostat; if there is an error while starting up, the device
will remain in "Protected” mode and an error message will be
displayed.
For example, the following picture shows error 2 which is
equivalent to Winter Comfort Setpoint ≥ Summer Comfort
Setpoint.
Types of errors at the time of configuration
Error No. Description
E1 Selected 2-pipe system instead of 4-pipe
system
E2 Winter Comfort Setpoint ≥ Summer Comfort
Setpoint
E3 Winter Standby Setpoint ≥ Summer Standby
Setpoint
E4 Winter Economy Setpoint ≥ Summer Economy
Setpoint
E5 Antifreeze ≥ Too Hot
N.B. Errors E2, E3, E4 and E5 may also be displayed if the
thermostat is programmed in "4-pipe system" mode without
the neutral zone according to the type of Setpoint shown in the
table.
Winter Setpoint
Summer Setpoint
COOLING
HEATING
NEUTRAL ZONE

7
Thermostat
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
0 Internal sensor Internal probe temperature
To see the temperature read by the thermostat sensor
(to see the temperatures measured by thermostats A/B
with Well-Contact Suite software, objects nos. 10/11
should be used)
2 byte C R - T - - Low
1 External sensor External NTC probe temper-
ature
To see the temperature read by the wired NTC probe
connected to the thermostat (to see the temperatures
measured by thermostats A/B with Well-Contact Suite
software, objects nos. 10/11 should be used)
2 byte C R - T - - Low
2 External Temperature 1 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
3 External Temperature 2 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
4 External Temperature 3 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
5 External Temperature 4 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
6 External Temperature 5 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
7 External Temperature 6 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
8 External Temperature 7 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
9 External Temperature 8 KNX probe temperature on bus
To see the temperature read by a KNX sensor con-
nected to the bus (to see the temperatures measured
by thermostats A/B with Well-Contact Suite software,
objects nos. 10/11 should be used)
2 byte C - W - U - Low
10 Current Temperature A: Temperature
To see the current temperature associated with ther-
mostat-A (weighted average of the various associated
probes): this object is used with Well-Contact Suite
software to see the temperature measured by thermo-
stat A
2 byte C R - T - - Low
11 Current Temperature B: Temperature
To see the current temperature associated with ther-
mostat-B (weighted average of the various associated
probes): this object is used with Well-Contact Suite
software to see the temperature measured by thermo-
stat B
2 byte C R - T - - Low
THERMOSTAT A:
12 Comfort A: Mode - control To select COMFORT operating mode by sending a 1 bit
or to set the thermostat to STANDBY by sending a 0 bit 1 bit C - W - U - Low
13 Energy Saving A: Mode - control To select ECONOMY operating mode by sending a 1
bit (a 0 bit is ignored) 1 bit C - W - U - Low
14 Protected A: Mode - control To select OFF-ANTIFREEZE operating mode (or Too
Hot in the case of air conditioning) by sending a 1 bit. 1 bit C - W - U - Low
15 Off A: Mode - control To select OFF operating mode by sending a 1 bit (a 0
bit is ignored) 1 bit C R W - U - Low
16 Thermostat Mode A: Mode - control
To select operating mode by sending a Byte (1 =
Comfort, 2 = StandBy, 3 = Economy, 4 = Protection). If
you use supervision with Well Contact Suite this object
must be associated with a group.
1 byte C - W - U - Low
17 Thermostat Mode A: Mode - status
To read the set operating mode by sending a Byte (1 =
Comfort, 2 = StandBy, 3 = Economy, 4 = Protection). If
you use supervision with Well Contact Suite this object
must be associated with a group.
1 byte C R - T - - Low
List of existing communication objects and standard settings
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update
Communication objects and ETS parameters
COMMUNICATION OBJECTS

8
Thermostat
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
18 Status A: Summer - Winter - status To read the seasonal mode set on the thermostat (0 =
Summer, 1 = Winter) 1 bit C R - T - - Low
19 Enable A: Summer - Winter - control
To set the seasonal mode on the thermostat (1 = Win-
ter, 0 = Summer). If it is NOT associated with a group
then thermostat A will function in Neutral Zone mode.
1 bit C - W - U - Low
20 Thermostat Off A: OFF communication - bus
- control
This function is useful in the event of faults on the heat-
ing system to disable the valves with a 1 bit. 1 bit C - W - U - Low
21 Dewpoint A: Thermostat - control
If a 1 bit is sent to this object, the thermostat will show
the specific icon on the display, turn OFF and stop the
air conditioner (this works only in air conditioning mode
and serves for example to avoid condensation on the
floor) - Note: The thermostat requires a cyclical send to
this object, with a time that can be set in the parameter
"Dewpoint Supervision Time"
1 bit C - W - U - Low
22 NOT USED
23 Current Setpoint A: Setpoint - status
To read the temperature setpoint set on the thermostat.
If you want Well-contact Suite to know the setpoint cur-
rently set on the thermostats, this object must be linked
to a group
2 byte C R - T - - Low
24 Setpoint Shift A: Setpoint - status, control
To read and control a temperature shift with respect to
the current setpoint (setpoint set by ETS on the thermo-
stat for the various operating modes CMF, STBY, etc.).
The temperature shift permitted is limited to the range
set by the parameter: Guest Control Permitted.
If parameter Guest Control Permitted is set to Off the
“Setpoint Shift” object does not shift the active setpoint.
2 byte C R W T - - Low
25 Winter Comfort A: Setpoint - status, control To read and set the Winter Comfort setpoint. 2 byte C R W T U - Low
26 Winter Standby A: Setpoint - status, control To read and set the Winter Standby setpoint 2 byte C R W T U - Low
27 Winter Energy Saving A: Setpoint - status, control To read and set the Winter Economy setpoint 2 byte C R W T U - Low
28 Winter Protected A: Setpoint - status, control To read and set the Winter Antifreeze setpoint 2 byte C R W T U - Low
29 Summer Comfort A: Setpoint - status, control To read and set the Summer Comfort setpoint 2 byte C R W T U - Low
30 Summer Standby A: Setpoint - status, control To read and set the Summer Standby setpoint 2 byte C R W T U - Low
31 Summer Energy Saving A: Setpoint - status, control To read and set the Summer Economy setpoint 2 byte C R W T U - Low
32 Summer Protected A: Setpoint - status, control To read and set the Summer Too Hot setpoint (power-off
of climate control if the window is opened, for instance) 2 byte C R W T U - Low
33 NOT USED
Thermostat A: Valves
34 Cooling/Heating Valve A: Valve
If the "Valve" parameter is set for 2-pipe systems for
valve management: to be used to control the head of a
radiating system or the On/Off valve of a fan coil
1 bit C R - T - - Low
34 Cooling Valve A: Valve
If the "Valve" parameter is set for 4-pipe systems for
valve management in Summer: to be used to control
the head of a radiating system or the On/Off valve of a
fan coil
1 bit C R - T - - Low
35 Heating Valve A: Valve
If the "Valve" parameter is set for 4-pipe systems for
valve management in Winter: to be used to control the
head of a radiating system or the On/Off valve of a fan
coil
1 bit C R - T - - Low
34 Cooling/Heating Valve A: Valve
If the "Valve" parameter is set for 2-pipe proportional
systems for proportional valve management: to be
used to control the head of a radiating system or for the
proportional valve of a fan coil
1 byte C R - T - - Low
34 Cooling Valve A: Valve
If the "Valve" parameter is set for 4-pipe proportional
systems for Summer valve management: to be used to
control the head of a radiating system or for the propor-
tional valve of a fan coil
1 byte C R - T - - Low
Continued
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update
Communication objects and ETS parameters

9
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
35 Heating Valve A: Valve
If the "Valve" parameter is set for 4-pipe proportional
systems for Winter valve management: to be used to
control the head of a radiating system or for the propor-
tional valve of a fan coil
1 byte C R - T - - Low
Thermostat A: Second Stage
36 Cooling Valve A: 2nd Cooling Stage If second cooling stage is enabled to be used for the
boost function (cooling) for on/off valve control 1 bit C R - T - - Low
36 Cooling Valve A: 2nd Cooling Stage If second cooling stage is enabled to be used for the
boost function (cooling) for proportional valve control 1 byte C R - T - - Low
37 Heating Valve A: 2nd Heating Stage If second heating stage is enabled to be used for the
boost function (heating) for on/off valve control 1 bit C R - T - - Low
37 Heating Valve A: 2nd Heating Stage If second heating stage is enabled to be used for the
boost function (heating) for proportional valve control 1 byte C R - T - - Low
Thermostat A: Fan
38 Proportional (0- 100%) A: Fan Inputs
Used to set a proportional speed for the fan coil fan (if
the selected fan is proportional with 3 speeds) via a su-
pervisor (e.g., touch screen)
1 byte C - W - U - Low
39 NOT USED
40 V1 speed A: Fan Inputs Used to force activation of fan coil speed V1 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
41 V2 speed A: Fan Inputs Used to force activation of fan coil speed V2 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
42 V3 speed A: Fan Inputs Used to force activation of fan coil speed V3 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
43 Automatic A: Fan Inputs Used to force activation of fan coil speed AUTO (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
44 Proportional (0- 100%) A: Fan Outputs
Used to read the proportional speed of the fan coil fan
(if the selected fan is proportional with 3 speeds with the
8-Bit Object - Proportional (0-100%). This object is used
for controlling proportional actuators.
1 byte C R - T - - Low
45 Off A: Fan Outputs
Used to read the deactivation status of all 3 speeds (if
the selected fan has 3 speeds). The thermostat sends a
1 bit when the fan is off (fan coil speed 0).
1 bit C R - T - - Low
46 V1 speed A: Fan Outputs
This is the object to pair with the relay of speed 1 of the
fan coil (to read the status of speed V1 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
47 V2 speed A: Fan Outputs
This is the object to pair with the relay of speed 2 of the
fan coil (to read the status of speed V2 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
48 V3 speed A: Fan Outputs
This is the object to pair with the relay of speed 3 of the
fan coil (to read the status of speed V3 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
49 V1 speed A: Fan Disable To disable speed V1 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
50 V2 speed A: Fan Disable To disable speed V2 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
51 V3 speed A: Fan Disable To disable speed V3 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
Thermostat A: Window
52 Window Sensor A: Window
Object to be paired with the input to which a win-
dow-contact is connected so that the thermostat
switches to OFF-PROTECTED when the window is
opened, depending on whether the mode is Air Condi-
tioning or Heating
1 bit C - W - U - Low
Thermostat
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update
Continued
Communication objects and ETS parameters
COMMUNICATION OBJECTS

10
Thermostat
Continued
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
Thermostat A: Scenario
53 Scenario A: Scenario To activate a scenario with a 1 Byte message 1 byte C - W - U - Low
Thermostat A: Auto/Man
54 Temperature: Automat-
ic/Manual A: Manual operation To see whether the guest has altered the thermostat temperature setpoint with respect to the default setting 1 bit C R - T - - Low
55 Fan coil: Automatic/
Manual A: Manual operation To see whether the guest has altered the fan coil speed with respect to the default setting 1 bit C R - T - - Low
56 Temperature: Disable
Local operation A: Manual operation
Activating this object prevents the guest from altering
the setpoint temperature by means of the thermostat
buttons with respect to the value set by the bus
1 bit C - W - U - Low
57 Fan coil: Disable Local
Operation A: Manual operation
Activating this object prevents the guest from altering
the fan coil speed by means of the thermostat buttons
with respect to the value set by the bus
1 bit C - W - U - Low
Thermostat A: Floor Probe Alarm
58 Floor Temperature A: Alarm If the temperature limitation is active an alarm is sent
when the temperature exceeds the set threshold 1 bit C R - T - - Low
THERMOSTAT B:
59 Comfort B: Mode - control To select COMFORT operating mode by sending a 1 bit
or to set the thermostat to STANDBY by sending a 0 bit 1 bit C - W - U - Low
60 Energy Saving B: Mode - control To select ECONOMY operating mode by sending a 1
bit (a 0 bit is ignored) 1 bit C - W - U - Low
61 Protected B: Mode - control To select ANTIFREEZE operating mode (or Too Hot in
the case of air conditioning) by sending a 1 bit. 1 bit C - W - U - Low
62 Off B: Mode - control To select OFF operating mode by sending a 1 bit (a 0
bit is ignored) 1 bit C R W - U - Low
63 Thermostat Mode B: Mode - control
To select operating mode by sending a Byte (1 =
Comfort, 2 = StandBy, 3 = Economy, 4 = Protection). If
you use supervision with Well Contact Suite this object
must be associated with a group.
1 byte C - W - U - Low
64 Thermostat Mode B: Mode - status
To read the set operating mode by sending a Byte (1 =
Comfort, 2 = StandBy, 3 = Economy, 4 = Protection). If
you use supervision with Well Contact Suite this object
must be associated with a group.
1 byte C R - T - - Low
65 Status B: Summer - Winter - status To read the seasonal mode set on the thermostat (0 =
Summer, 1 = Winter) 1 bit C R - T - - Low
66 Enable B: Summer - Winter - control
To set the seasonal mode on the thermostat (1 = Win-
ter, 0 = Summer). If it is NOT associated with a group
then thermostat B will function in Neutral Zone mode.
1 bit C - W - U - Low
67 Thermostat Off B: OFF communication - bus
- control
This function is useful in the event of faults on the heat-
ing system to disable the valves with a 1 bit. 1 bit C - W - U - Low
68 Dewpoint B: Thermostat - control
If a 1 bit is sent to this object, the thermostat will show
the specific icon on the display, turn OFF and stop the
air conditioner (this works only in air conditioning mode
and serves for example to avoid condensation on the
floor) - Note: The thermostat requires a cyclical send to
this object, with a time that can be set in the parameter
"Dewpoint Supervision Time"
1 bit C - W - U - Low
69 NOT USED
70 Current Setpoint B: Setpoint - status
To read the temperature setpoint set on the thermostat.
If you want Well-contact Suite to know the setpoint cur-
rently set on the thermostats, this object must be linked
to a group
2 byte C R - T - - Low
71 Setpoint Shift B: Setpoint - status, control
To read and control a temperature shift with respect to
the current setpoint (setpoint set by ETS on the thermo-
stat for the various operating modes CMF, STBY, etc.).
The temperature shift permitted is limited to the range
set by the parameter: Guest Control Permitted. If param-
eter Guest Control Permitted is set to Off the “Setpoint
Shift” object does not shift the active setpoint.
2 byte C R W T - - Low
Communication objects and ETS parameters

11
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
72 Winter Comfort B: Setpoint - status, control To read and set the Winter Comfort setpoint. 2 byte C R W T U - Low
73 Winter Standby B: Setpoint - status, control To read and set the Winter Standby setpoint 2 byte C R W T U - Low
74 Winter Energy Saving B: Setpoint - status, control To read and set the Winter Economy setpoint 2 byte C R W T U - Low
75 Winter Protected B: Setpoint - status, control To read and set the Winter Antifreeze setpoint 2 byte C R W T U - Low
76 Summer Comfort B: Setpoint - status, control To read and set the Summer Comfort setpoint 2 byte C R W T U - Low
77 Summer Standby B: Setpoint - status, control To read and set the Summer Standby setpoint 2 byte C R W T U - Low
78 Summer Energy Saving B: Setpoint - status, control To read and set the Summer Economy setpoint 2 byte C R W T U - Low
79 Summer Protected B: Setpoint - status, control To read and set the Summer Too Hot setpoint (power-off
of climate control if the window is opened, for instance) 2 byte C R W T U - Low
80 NOT USED
Thermostat B: Valves
81 Cooling/Heating Valve B: Valve
If the "Valve" parameter is set for 2-pipe systems for
valve management: to be used to control the head of a
radiating system or the On/Off valve of a fan coil
1 bit C R - T - - Low
81 Cooling Valve B: Valve
If the "Valve" parameter is set for 4-pipe systems for
valve management in Summer: to be used to control
the head of a radiating system or the On/Off valve of a
fan coil
1 bit C R - T - - Low
82 Heating Valve B: Valve
If the "Valve" parameter is set for 4-pipe systems for
valve management in Winter: to be used to control the
head of a radiating system or the On/Off valve of a fan
coil
1 bit C R - T - - Low
81 Cooling/Heating Valve B: Valve
If the "Valve" parameter is set for 2-pipe proportional
systems for proportional valve management: to be
used to control the head of a radiating system or for the
proportional valve of a fan coil
1 byte C R - T - - Low
81 Cooling Valve B: Valve
If the "Valve" parameter is set for 4-pipe proportional
systems for Summer valve management: to be used to
control the head of a radiating system or for the propor-
tional valve of a fan coil
1 byte C R - T - - Low
82 Heating Valve B: Valve
If the "Valve" parameter is set for 4-pipe proportional
systems for Winter valve management: to be used to
control the head of a radiating system or for the propor-
tional valve of a fan coil
1 byte C R - T - - Low
Thermostat B: Second Stage
83 Cooling Valve B: 2nd Cooling Stage If second cooling stage is enabled to be used for the
boost function (cooling) for on/off valve control 1 bit C R - T - - Low
83 Cooling Valve B: 2nd Cooling Stage If second cooling stage is enabled to be used for the
boost function (cooling) for proportional valve control 1 byte C R - T - - Low
84 Heating Valve B: 2nd Heating Stage If second heating stage is enabled to be used for the
boost function (heating) for on/off valve control 1 bit C R - T - - Low
84 Heating Valve B: 2nd Heating Stage If second heating stage is enabled to be used for the
boost function (heating) for proportional valve control 1 byte C R - T - - Low
Thermostat B: Fan
85 Proportional (0- 100%) B: Fan Inputs
Used to set a proportional speed for the fan coil fan (if
the selected fan is proportional or 8-bit with 3 speeds)
via a supervisor (e.g., touch screen)
1 byte C - W - U - Low
86 NOT USED
87 V1 speed B: Fan Inputs Used to force activation of fan coil speed V1 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
Continued
Thermostat
Communication objects and ETS parameters
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update
COMMUNICATION OBJECTS

12
Thermostat
Communication objects and ETS parameters
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
88 V2 speed B: Fan Inputs Used to force activation of fan coil speed V2 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
89 V3 speed B: Fan Inputs Used to force activation of fan coil speed V3 (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
90 Automatic B: Fan Inputs Used to force activation of fan coil speed AUTO (if the
selected fan has 3 speeds) 1 bit C - W - U - Low
91 Proportional (0- 100%) B: Fan Outputs
Used to read the proportional speed of the fan coil fan (if
the selected fan is proportional or 8-bit with 3 speeds).
This object is used for controlling proportional actuators.
1 byte C R - T - - Low
92 Off B: Fan Outputs
Used to read the deactivation status of all 3 speeds (if
the selected fan has 3 speeds). The thermostat sends a
1 bit when the fan is off (fan coil speed 0).
1 bit C R - T - - Low
93 V1 speed B: Fan Outputs
This is the object to pair with the relay of speed 1 of the
fan coil (to read the status of speed V1 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
94 V2 speed B: Fan Outputs
This is the object to pair with the relay of speed 2 of the
fan coil (to read the status of speed V2 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
95 V3 speed B: Fan Outputs
This is the object to pair with the relay of speed 3 of the
fan coil (to read the status of speed V3 of the fan coil,
this object can be polled by the bus)
1 bit C R - T - - Low
96 V1 speed B: Fan Disable To disable speed V1 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
97 V2 speed B: Fan Disable To disable speed V2 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
98 V3 speed B: Fan Disable To disable speed V3 (if the selected fan has 3 speeds) 1 bit C R W T U - Low
Thermostat B: window
99 Window Sensor B: Window
Object to be paired with the input to which a win-
dow-contact is connected so that the thermostat
switches to OFF-PROTECTED when the window is
opened, depending on whether the mode is Air Condi-
tioning or Heating
1 bit C - W - U - Low
Thermostat B: scenario
100 Scenario B: Scenario To activate a scenario with a 1 Byte message 1 byte C - W - U - Low
Thermostat B: Auto/Man
101 Temperature: Automat-
ic/Manual B: Manual operation To see whether the guest has altered the thermostat temperature setpoint with respect to the default setting 1 bit C R - T - - Low
102 Fan coil: Automatic/
Manual B: Manual operation To see whether the guest has altered the fan coil speed with respect to the default setting 1 bit C R - T - - Low
103 Temperature: Disable
Local operation B: Manual operation
Activating this object prevents the guest from altering
the setpoint temperature by means of the thermostat
buttons with respect to the value set by the bus
1 bit C - W - U - Low
104 Fan coil: Disable Local
Operation B: Manual operation
Activating this object prevents the guest from altering
the fan coil speed by means of the thermostat buttons
with respect to the value set by the bus
1 bit C - W - U - Low
Thermostat B: Floor Probe Alarm
105 Floor Temperature B: Alarm If the temperature limitation is active an alarm is sent
when the temperature exceeds the set threshold 1 bit C R - T - - Low
GLOBAL
106 Initialisation Alarm Do not use: it is used for automatic testing during
production of the device 1 bit C R - T - - Low
107 NOT USED
Continued
Continued C= Communication; R= Read; W= Write; T= Transmission; U= Enable update

13
No. ETS name Function Description Type Flag 1 Priority
C R W T U I
108 NOT USED
109 General Alarm Used for viewing, on the thermostat display, the trigger-
ing of a generic alarm on the KONNEX BUS 1 bit C R - T - - Low
110 Input Input Device IN control 1 bit C R - T - - Low
111 Input Status Input Device input status. It appears if the input is set as
"general use" and "Toggle rising/falling edge" 1 bit C - W - U - Low
112 On/Off Relay Device relay control (setting relay operating parameters
as "general use") 1 bit C - W - U - Low
113 Status Relay Device relay status (setting relay operating parameters
as "general use") 1 bit C R - T - - Low
114 Value Humidity To know and view the humidity read by a KNX probe
connected to the bus 1 byte C - W - U - Low
114 Value Humidity To know and view the humidity read by a KNX probe
connected to the bus (*) 2 byte C - W - U - Low
115 Setpoint shift increase Setpoint
To control an increase equivalent to “setpoint shift step”
of the current current setpoint (setpoint set by ETS on
the thermostat for the various operating modes CMF,
STBY, etc.). The temperature shift permitted is limited to
the range set by the parameter: Guest Control Permitted
1 bit C - W - U - Low
116 Setpoint shift decrease Setpoint
To control a decrease equivalent to “setpoint shift step”
of the current current setpoint (setpoint set by ETS on
the thermostat for the various operating modes CMF,
STBY, etc.). The temperature shift permitted is limited
to the range set by the parameter: Guest Control Per-
mitted.
1 bit C - W - U - Low
Thermostat
Communication objects and ETS parameters
Number of communication objects Max. number of group addresses Max. number of associations
109 254 255
Continued
(*) This datapoint is only available starting from firmware version 2.00 and later.
COMMUNICATION OBJECTS

14
Thermostat
Communication objects and ETS parameters
Reference ETS parameters
General
General parameters
ETS text Values available Comment
[Default value]
Displayed Value
0 = View Current Tem-
perature
You can choose
whether to view on
the display: the tem-
perature measured,
the fan coil speed
and the valve status,
no information, the
temperature delta
compared to the
Setpoint set by the
project
1 = Current setpoint
2 = Display Off
3 = View Setpoint
Difference
[0]
Visibility of operating
modes
Yes Possibility of disa-
bling the operating
mode setting button
on the display
No
[Yes]
Heating icon visible
Yes
Possibility of disa-
bling the heating icon
on the display
No
[Yes]
Cooling icon visible
Yes
Possibility of disabling
the air conditioning
icon on the display
No
[Yes]
Button Activation
0 = Enable You can choose
whether to make the
thermostat buttons
operative
1 = Disable
[0]
Temperature units
0 = Celsius
Only for the display1 = Fahrenheit
[0]
Enable Menu
0 = Disable If enabled, the
thermostat operating
mode can be
changed. The Re-
duced menu lets you
locally change the
thermostat operating
modes only from
Comfort to Protected
and vice versa.
1 = Enable
2= Enable Reduced
[1]
Percentage displayed
0 = None To view the humidity
on the display as a
percentage or a 2
Byte value.
1 = Humidity
2 = Percentage
[1]
CAUTION: If you use thermostats art. 02952 with firmware
version 1.00 do not use the setting:
Percentage displayed = Humidity.
General settings

15
Thermostat
Communication objects and ETS parameters
Value
Displayed Enable Menu=Enable Button Activation = Enable Enable Menu=Enable Button Activation = Disable Enable Menu=Disable Button Activation = Enable
Display Current
Temperature
Setpoint
Current
Display Off
View
Difference
Setpoint
Note: In "View Setpoint Difference" mode, the difference between the Setpoint set via configuration by ETS and the Setpoint modified
locally by the user is displayed. When the set Setpoint is the design Setpoint the thermostat displays 0.0.
COMMUNICATION OBJECTS

16
Thermostat
Communication objects and ETS parameters
Backlighting
Backlighting Off
Backlighting On
Digital Input
ETS text Values available Comment
[Default value]
Backlighting
0 = Off Always off
1 = ON push button
On when pressing the touch
buttons.
Note: after some time of
inactivity, the backlighting
turns off.
2 =Ecometer Mode Ecometer Mode on
[1]
When Backlighting is set to "Ecometer Mode" the display
backlighting colour indicates the expected consumption
provided by the Ecometer with the background colour.
CAUTION: We do not recommend using the Ecometer view
when the thermostat is set to neutral zone mode as the
colour of the display depends on the active setpoint and
the information for the end user might not be clear.
Colour customisation
Ecometer Mode
ETS text Values available Comment
[Default value]
Input Function
0 = General Use If set as "General use", it
also sends 0/1 over the bus
towards a supervisor
1 = Window Sensor
[0]
Function (for gener-
al use)
0 = Switching on Rising
Edge Rising edge = close contact
1 = Toggle on Rising
Edge Falling edge = open contact
2 = Switching on Falling
Edge
Switching = sends a 1 bit
value (On/Off) on opening
and the opposite on closing
3 = Toggle on Falling
Edge
Toggle = on every defined
edge (opening or closure),
On and then Off is sent to
the cycle
4 = Status Send
To send the contact status
upon each switching and
also cyclically.
[0]
Window Sensor
Mode (for thermo-
stat-A and thermo-
stat-B)
0 = Deactivated Defines whether the window
sensor is normally open or
closed.
1 = Normally Open
2 = Normally Closed
[0]
Digital Input Parameters
Backlighting Parameters
Default colours
Digital Input - Window Sensor
Digital Input - General Use

17
Thermostat
Communication objects and ETS parameters
Internal/External Temperature Sensor (Thermostat-A,
Thermostat-B)
ETS text Values available Comment
[Default value]
Temperature Offset
-2 °C ... .+2 °C Calibration of ther-
mostat reading (or of
average of probes)
[0]
Cyclic Send Time
0...30 min.
0=Off.
Activates cyclic
send of object no.
0 "Internal Sensor"
or no. 1 "External
Sensor" (both for the
thermostat A and for
thermostat B)
[0 = Off]
Internal/external temperature sensor
Sensor parameters
ETS text Values available Comment
[Default value]
Send on Change
0... 1.0 °C Sets the minimum
measured tem-
perature change
with respect to the
setpoint that will
cause the thermostat
to send the current
value over the bus to
a supervisor.
[0 = Off]
Continued
Continued
Thermostat (A/B)
ETS text Values available Comment
[Default value]
Guest control per-
mitted
0 = Off
Determine how much the
guest can change the set-
point from the value set on
the thermostat (up/down)
1 = 1.0 °C
2 = 2.0 °C
3 = 3.0 °C
4 = 4.0 °C
5 = 5.0 °C
6 = No Limitation
[3]Thermostat (A/B)
Guest control permitted
Current Temperature (A/B)
ETS text Values available Comment
[Default value]
Temperature sen-
sor weightings
0... 100
For the thermostat's internal
sensor, the Vimar wired NTC
probe (if present) and the KNX
probes, this determines the
relative importance for calcu-
lating the weighted average
of the measured temperatures
[0]
Cyclic Send Time
0 = Off
Sets the frequency in
minutes with which the ther-
mostat (A/B) must send the
measured temperature value
(or the weighted average of
the probes) over the bus to
a supervisor. Activates cyclic
send of object no. 10 and
11 "Current Temperature" of
thermostat A/B
11 = 30 min.
[0 = Off]
Send on Change
0 = Off Sets the temperature difference
measured by the thermostat
(A/B) that results in the read val-
ue (or the weighted average of
the probes) being sent over the
bus towards a supervisor. Acti-
vates cyclic send of object no.
10 and 11 "Current Tempera-
ture" of thermostat A/B
1.0 = 1.0 °C
[0 = Off]
Current temperature (A/B)
Note: If you use the Well Contact Suite supervision system to
update the value displayed by the supervision station of the “A/B
Current Temperature" linked to objects nos. 10 and 11, you
must enable cyclic send or send on change. In the event of a
conjunction of a high number of thermostats, it is not advisable
to enable numerous cyclic sends with timing that is too low to
avoid overloading the BUS communications.
COMMUNICATION OBJECTS
ETS text Values available Comment
[Default value]
Setpoint shift step
0.1, 0.2....1 For thermostat A setpoint
shift step upon receipt of
control on objects 115 and
116
[1]

18
Setpoint (A/B)
ETS text Values available Comment
[Default value]
Mode at bus power
on
1 = Comfort
Thermostat operating mode
at bus power on
2 = Standby
3 = Energy saving
4 = Protect
255 = Last Mode
Selected
[255]
Time between
Heating and
Cooling
1 min.
To avoid the formation of
condensation with radiating
systems during changes of
season
10 min.
15 min.
20 min.
25 min.
30 min.
45 min.
60 min.
[30]
Dewpoint
Supervision Time
0 = Off
Sets the time within which
the thermostat must
receive a message to the
"Dewpoint" object from
a device connected to a
humidistat.
A bit set to "1" will stop
heating/air conditioning and
set to "0" will cause it to
restart. If messages have
not arrived, when this time
has elapsed heating/air con-
ditioning will restart
30 sec
1 min.
2 min.
3 min.
4 min.
5 min.
10 min.
15 min.
20 min.
25 min.
30 min.
[0 = Off]
Cyclic Send Time
0 = Off
Sets the time for cyclic
sending of temperature
setpoint over bus towards a
supervisor
30 sec.
1 min.
2 min.
3 min.
4 min.
5 min.
10 min.
15 min.
20 min.
25 min.
30 min.
[0 = Off]
Send on Change
0 = Off
Sets the minimum temper-
ature change made by the
guest with respect to the
setpoint that results in the
current setpoint being sent
over the bus towards a
supervisor
0.1 °C
0.2 °C
0.3 °C
0.4 °C
0.5 °C
0.6 °C
0.7 °C
0.8 °C
0.9 °C
1.0 °C
[0 = Off]
Reset Setpoint
Shift in Economy
Mode
Yes By selecting “Yes”, when the
thermostat goes into Energy
Saving (Economy) mode,
the setpoint set by the user
in Comfort and Standby
mode is reset to the design
default value. This function
is useful for hotel appli-
cations and with the Well
Contact Suite supervision
software.
No
[Yes]
Setpoint parameters
Setpoint parameters
Thermostat
Communication objects and ETS parameters
Important: The "Time between Heating and Cooling” param-
eter is the wait time it takes for the thermostat to switch from
summer-winter and vice versa. This parameter is especially
useful in some underfloor radiant systems where you set a high
time value to prevent the formation of condensation; this applies
especially when the thermostats work with a neutral zone and
so there could be multiple seasonal changes in a single day.
If instead, depending on the type of system, you want a faster
response of the thermostat, it is necessary to reduce the value
of this parameter.

19
Thermostat
Communication objects and ETS parameters
Continued
Continued
Temperature Setpoint (A/B)
ETS text Values available Comment
[Default value]
Winter Comfort Setpoint [20] See "Range" table
Winter Standby Setpoint [18] See "Range" table
Winter Energy Saving
Setpoint [15] See "Range" table
Antifreeze
0 = Control Off
If you set "On"
you can set the
temperature the
thermostat goes to in
"Protected" mode; if
you set "Off", when
the thermostat is in
"Protected" mode it
will turn off tempera-
ture control and will
not send the current
setpoint temperature
1 = Control On
[1 = 011]
Summer Comfort Setpoint [25] See "Range" table
Summer Standby Setpoint [28] See "Range" table
Summer Energy Saving
Setpoint [30] See "Range" table
ETS text Values available Comment
[Default value]
Too hot
0 = Control Off
If you set "On"
you can set the
temperature the
thermostat goes to in
"Protected" mode; if
you set "Off", when
the thermostat is in
"Protected" mode it
will turn off tempera-
ture control and will
not send the current
setpoint temperature
1 = Control On
[1 = On]
Sensor parameters
Temp. °C
5
6
7
8
9
10
11
12
13
14
15
Temp. °C
16
17
18
19
20
21
22
23
24
25
26
Temp. °C
27
28
29
30
31
32
33
34
35
36
37
Temp. °C
38
39
40
41
42
43
44
45
Setpoint range
Note: In the case of a 4-pipe system, the winter setpoint cannot
take a higher value than the summer setpoint.
CAUTION: When the thermostat is in Neutral Zone mode,
the breadth of this must be progressively increasing for
the different operating modes of Comfort (minimum neutral
zone breadth), Standby, Energy Saving and Protected. This
setting made with ETS ensures that, when the thermostat
changes operating mode, the active setpoint is always at
a suitable value and the thermostat does not start cooling
if it was heating before or vice versa, causing considerable
energy consumption.
COMMUNICATION OBJECTS
Temperature setpoint parameters

20
Window sensor (A/B)
ETS text Values available Comment
[Default value]
Window sensor
delay
0 = Off Sets the time delay that
heating/air conditioning
stops after window open
detection
8 = 120 sec.
[4 = 30]
Window sensor (A/B)
Sensor parameters
Thermostat
Communication objects and ETS parameters
ETS text Values available Comment
[Default value]
Temperature
Control
0 = Control On/Off
Set according to the type of
control required for the heat-
ing/air conditioning system
1 = Integral Band
2 = Proportional/Integral
Band
[0]
Proportional
Cooling Value
1.0 °C
To be set according to the
characteristics of the system
and the room (consult a
heating engineer)
1.1 °C
1.2 °C
1.3 °C
1.4 °C
1.5 °C
1.6 °C
1.7 °C
1.8 °C
2.0 °C
2.2 °C
2.5 °C
3.0 °C
3.5 °C
4.0 °C
4.5 °C
5.0 °C
[3.0 °C]
Control On/Off (A/B)
Control parameters
