Vision Fitness T80 User manual

T80
Read the TREADMILL GUIDE before using this OWNER’S MANUAL.
Lisez le GUIDE DU TAPIS ROULANT avant de vous référer au MANUEL DU PROPRIÉTAIRE.
Lea la GUÍA DE LA CAMINADORA antes de utilizar este MANUAL DEL PROPIETARIO.
TREADMILL OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE DU TAPIS ROULANT
MANUAL DEL PROPIETARIO DE LA CAMINADORA

2
3 ENGLISH
32 FRANÇAIS
62 ESPAÑOL

3
IMPORTANT PRECAUTIONS
SAVE THESE INSTRUCTIONS
When using an electrical product, basic precautions should always be followed, including the following: Read all instructions
before using this treadmill. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of
all warnings and precautions. If you have any questions after reading this guide, contact Customer Tech Support at the number
listed on the back cover.
This product is intended for commercial use. To ensure your safety and protect the equipment, read all instructions
before operating.

4
TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS:
• If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness of breath, stop
exercising immediately and consult your physician before continuing.
• When exercising, always maintain a comfortable pace.
• Do not wear clothes that might catch on any part of the treadmill.
• Always wear athletic shoes while using this equipment.
• Do not jump on the treadmill.
• At no time should more than one person be on treadmill while in operation.
• This treadmill should not be used by persons weighing more than specified in the OWNER’S MANUAL SPECIFICATIONS
SECTION. Failure to comply will void the warranty.
• Disconnect all power before servicing or moving the equipment. To clean, wipe surfaces down with soap and slightly damp cloth
only; never use solvents. (See MAINTENANCE)
• The treadmill should never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or
taking off parts.
• Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury to persons.
• Connect this exercise product to a properly grounded outlet only.
WARNING
TO REDUCE THE RISK OF ELECTRICAL SHOCK:
Always unplug the treadmill from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or
taking off parts.
DANGER
CAUTION
If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness of breath, stop
exercising immediately and consult your physician before continuing.

5
(CONT.)
• At NO time should children under the age of 13 or pets be within 10 feet of the machine.
• At NO time should children under the age of 13 use the treadmill.
• Children over the age of 13 or disabled persons should not use the treadmill without adult supervision.
• Use the treadmill only for its intended use as described in the treadmill guide and owner’s manual.
• Do not use other attachments that are not recommended by the manufacturer. Attachments may cause injury.
• Never operate the treadmill if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or
immersed in water. Call Customer Tech Support for examination and repair.
• Keep power cord away from heated surfaces. Do not carry this unit by its supply cord or use the cord as a handle.
• Never operate the treadmill with the air opening blocked. Keep the air opening clean, free of lint, hair, and the like.
• To prevent electrical shock, never drop or insert any object into any opening.
• Do not operate where aerosol (spray) products are being used or when oxygen is being administered.
• To disconnect, turn all controls to the off position, then remove plug from outlet.
• Do not use treadmill in any location that is not temperature controlled, such as but not limited to garages, porches, pool rooms,
bathrooms, car ports or outdoors. Failure to comply may void the warranty.
• Do not remove the console covers unless instructed by Customer Tech Support. Service should only be done by an authorized
service technician
It is essential that your treadmill is used only indoors, in a climate controlled room. If your treadmill has been exposed to colder
temperatures or high moisture climates, it is strongly recommended that the treadmill is warmed up to room temperature before
first time use. Failure to do so may cause premature electronic failure. The initial (default) starting speed is 0.5mph (0.8 km/h).
The default starting speed set too high can be dangerous.
WARNING
WARNING
This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

6
ELECTRICAL REQUIREMENTS
For your safety and to ensure good treadmill performance,
the ground on this circuit must be non-looped. Please
refer to NEC article 210-21 and 210-23. Your Treadmill is
provided with a power cord with a plug listed below and
requires the listed outlet. Any alterations of this power
cord could void all warranties of this product.
120 NEMA 5-20R 120 NEMA 5-20R
North American power cord plugs shown. Depending on your country, the plug type may vary.
DEDICATED CIRCUIT AND ELECTRICAL INFO
All Vision units require the use of a 20 amp “dedicated circuit,” with a non-looped (isolated) neutral/ground, for the power
requirement. Quite simply this means that each outlet you plug into should not have anything else running on that same circuit.
The easiest way to verify this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time. Once a breaker
has been turned off, the only thing that should not have power to it are the units in question. No lamps, vending machines, fans,
sound systems, or any other item should lose power when you perform this test.
Non-looped (isolated) neutral/grounding means that each circuit must have an individual neutral/ground connection coming from
it, and terminating at an approved earth ground. You cannot “jumper” a single neutral/ground from one circuit to the next.
In addition to the dedicated circuit requirement, the proper gauge wire must be used from the circuit breaker box, to each outlet
that will have the maximum number of units running off of it. If the distance from the circuit breaker box, to each outlet, is 100
ft or less, then 12 gauge wire may be used. For any distance greater than 100 ft from the circuit breaker box to the outlet, 10
gauge wire must be used.

7
GROUNDING INSTRUCTIONS
The treadmill must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric
current to reduce the risk of electric shock. The treadmill is equipped with a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances. If the user does not follow these grounding instructions, the user could void the Vision
limited warranty.
Connect this exercise product to a properly grounded outlet only.
Never operate product with a damaged cord or plug even if it is working properly. Never operate any product if it appears
damaged, or has been immersed in water. Contact Customer Tech Support for replacement or repair.
WARNING
DANGER
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.
120V UNITS
The T80 treadmill is for use on a nominal 120-volt circuit and has a non-looped grounding plug. Make sure that the 110-volt treadmill
is connected to an outlet, NEMA 5-20R, having the same configuration as the plug. No adapter should be used with this product.
(This product is rated more than 15 A and is for use on a circuit having a nominal rating of 120 V ²) and is factory-equipped with a
specific electric cord and plug to permit connection to a proper electric circuit. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapter should be used with this product. If the product must be reconnected for use
on a different type of electric circuit,the reconnection should be made by qualified service personnel.

8

9
BASIC OPERATION

10
LOCATION OF THE TREADMILL
LOCATION OF THE TREADMILL
Place the treadmill on a level and stable surface.
Place the treadmill on a level and stable surface.
Please leave a clear zone behind the treadmill that
Please leave a clear zone behind the treadmill that
is at least the width of the treadmill and at least 79” (2000 mm) long. This zone must be clear of any
is at least the width of the treadmill and at least 79” (2000 mm) long. This zone must be clear of any
obstruction and provide the user a clear exit path from the machine. In case of an emergency, place
obstruction and provide the user a clear exit path from the machine. In case of an emergency, place
both hands on the side arm rests to hold yourself up and place your feet onto the side rails.
both hands on the side arm rests to hold yourself up and place your feet onto the side rails.
For ease of access, there should be an accessible space preferentially on both sides of the treadmill
For ease of access, there should be an accessible space preferentially on both sides of the treadmill
equal to 36” (915 mm) to allow a user access to the treadmill from either side.
equal to 36” (915 mm) to allow a user access to the treadmill from either side.
While you are preparing to use the treadmill, do not stand on the belt. Place your feet on the side rails
before starting the treadmill. Start walking on the belt only after the belt has begun to move. Never start
the treadmill at a fast running speed and attempt to jump on!
USING THE SAFETY KEY
Your treadmill will not start unless the safety key is inserted. Attach the clip end securely to your
clothing. This safety key is designed to cut the power to the treadmill if you should fall. Check the
operation of the safety key every 2 weeks.
Never use the treadmill without securing the safety key clip to your clothing. Pull on the safety
key clip first to make sure it will not come off your clothing.
CAUTION – RISK OF INJURY TO PERSONS
WARNING
79" 2000 mm
12" 305 mm

11
PROPER USAGE
Your treadmill is capable of reaching high speeds. Always start off using a slower speed and adjust the speed in small
increments to reach a higher speed level. Never leave the treadmill unattended while it is running. When not in use turn
the on/off switch to off and unplug the power cord. Make sure to follow the MAINTENANCE schedule in this guide to
maintain optimal performance and prevent premature electronic failure. Keep your body and head facing forward. Do not
attempt to turn around or look backwards while the treadmill is running. Stop your workout immediately if you feel pain,
faint, dizzy or are short of breath.
Our treadmills are heavy; use care and additional help if necessary when moving. Do not attempt to move or
transport treadmill unless it is in the upright, folded position with the lock latch secured. Failure to follow these
instructions could result in injury.
LEVELING THE TREADMILL
Your treadmill should be level for optimum use. Once you have placed your treadmill where you
intend to use it, raise or lower one or both of the adjustable levelers located on the bottom of
the treadmill frame. A carpenter’s level is recommended. If your treadmill is not level, the running
belt may not track properly. Once you have leveled your treadmill, lock the levelers in place by
tightening the nuts against the frame. LOCK
ADJUSTMENT
ADJUST
HEIGHT
WARNING

12
TENSIONING THE RUNNING BELT
For more information and/or how-to videos, visit our Customer Support section on our
website. Contact information is located on the back panel.
Running belt should NOT be moving during tensioning. Over-tightening
the running belt can cause excessive wear on the treadmill as well as its
components. Never over-tighten the belt.
If you can feel a slipping sensation when running on the treadmill, the running belt
must be tightened. In most cases, the belt has stretched from use, causing the belt
to slip. This is a normal and common adjustment. To eliminate this slipping, turn
the treadmill off and tension both the rear roller bolts using the supplied Allen
wrench, turning them ¼ turn to the right (clockwise) as shown. Turn the treadmill on
and check for slipping. Repeat if necessary, but never turn the roller bolts more than
¼ turn at a time. Belt is properly tensioned when the slipping sensation is gone.
TIGHTENS RIGHT SIDE OF ROLLER
TIGHTENS LEFT SIDE OF ROLLER
CAUTION

13
CENTERING THE RUNNING BELT
For more information and/or how-to videos, visit our Customer Support section on our
website. Contact information is located on the back page of the OWNER’S MANUAL.
If the running belt is too far to the right side: Using the supplied Allen wrench
and with the treadmill running at 3 mph/4 kmh turn the LEFT adjustment bolt counter-
clockwise a ¼ turn and wait for the belt to adjust itself. Repeat if necessary, until the
belt remains centered during use.
If the running belt is too far to the left side: Using the supplied Allen wrench and
with the treadmill running at 3 mph/4 kmh turn the LEFT adjustment bolt clockwise a
¼ turn and wait for the belt to adjust itself. Repeat if necessary, until the belt remains
centered during use.
• If you find the belt is slipping because it is too loose, center it then tension as
needed.
• For easier adjustment bolt access, remove the end caps.
Do not run belt faster than 3 mph/4 kmh while centering. Keep fingers, hair
and clothing away from belt at all times.
BELT IS TOO FAR TO THE RIGHT SIDE
BELT IS TOO FAR TO THE LEFT SIDE
CAUTION

14
USING THE HEART RATE FUNCTION
Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip the bars for your heart rate
to register. It takes 5 consecutive heart beats (15-20 seconds) for your heart rate to register. When gripping the pulse
handlebars, do not grip tightly. Holding the grips tightly may elevate your blood pressure. Keep a loose, cupping hold. You
may experience an erratic readout if consistently holding the grip pulse handlebars. Make sure to clean the pulse sensors
to ensure proper contact can be maintained.
The heart rate function on this product is not a medical device. While heart rate grips or a thumb pulse sensor can
provide a relative estimation of your actual heart rate, they should not be relied on when accurate readings are
necessary. Some people, including those in a cardiac rehab program, may benefit from using an alternate heart
rate monitoring system like a chest or wrist strap. Various factors, including movement of the user, may affect the
accuracy of your heart rate reading. The heart rate reading is intended only as an exercise aid in determining heart
rate trends in general. Please consult your physician.
Always stand still on side rails when measuring your heart rate. Checking your heart rate while in motion will cause
inaccurate readings. Do not press excessively hard on the sensor as this may cause damage.
CAUTION

15
WIRELESS HEART RATE RECEIVER
When used in conjunction with a wireless chest transmitter, your heart rate can be transmitted wirelessly to the treadmill and
displayed on the console. All but the CLASSIC console include a wireless chest transmitter.
Prior to wearing the wireless chest transmitter on your chest, moisten the two rubber electrodes with water. Center the chest strap
just below the breast or pectoral muscles, directly over your sternum, with the logo facing out. NOTE: The chest strap must be tight
and properly placed to receive an accurate and consistent readout. If the chest strap is too loose, or positioned improperly, you may
receive an erratic or inconsistent heart rate readout.
BACKSIDE OF CHEST TRANSMITTER
APPLY MOISTURE HERE
LOGO

17
TROUBLESHOOTING
& MAINTENANCE

18
RECOMMENDED CLEANING TIPS
A Use a soft, clean cotton cloth. DO NOT use paper towels to
clean surfaces on the treadmill. Paper towels are abrasive
and can damage surfaces.
B Use a mild soap and damp cloth. DO NOT use ammonia
based cleaner. This will cause discoloring of the aluminum
and plastics it comes into contact with.
C Do not pour water or cleaning solutions on any surface. This
could cause electrocution.
D Wipe the console and side rails after every use.
E Be sure to remove any obstructions from the path of the
elevation wheels including power cords.
F Monthly, unplug the treadmill and remove the motor cover.
Check for debris and clean with a dry cloth or small vacuum
nozzle.
WARNING: Do not plug the treadmill in until the motor
cover has been reinstalled.
CAUTION: Be sure to have proper assistance to install and
move the unit in order to avoid injury or damage to the treadmill.
DECK AND BELT REPLACEMENT
One of the most common wear and tear items on a treadmill is
the deck and belt combination. If these two items are not properly
maintained they can cause damage to other components. This
product has been provided with the most advanced maintenance
free lubricating system on the market. The treadmill deck does
not require any maintenance, other than cleaning and belt
tightening.
WARNING: Do not run the treadmill while cleaning the belt and
deck. This can cause serious injury and can damage the machine.
Maintain the belt and deck by wiping the sides of the belt and
deck with a clean cloth. The user can also wipe under the belt
2 inches on both sides removing any dust or debris.
The deck can be flipped and reinstalled or replaced by an
authorized service technician. Please contact Vision Fitness for
more information.
To remove power from the treadmill, the power cord must
be disconnected from the wall outlet.
WARNING

19
CHECK FOR DAMAGED PARTS
DO NOT use any equipment that is damaged or has worn or
broken parts. Use only replacement parts supplied by Vision
Fitness.
MAINTAIN LABELS AND NAMEPLATES Do not remove
labels for any reason. They contain important information. If
unreadable or missing, contact Vision Fitness for a replacement
or an authorized service provider.
MAINTAIN ALL EQUIPMENT Preventative maintenance is
the key to smooth operating equipment, as well as keeping the
user’s liability to a minimum. Equipment needs to be inspected
at regular intervals. Defective components must be replaced
immediately. Improperly working equipment must be kept out
of use until it is repaired. Ensure that any person(s) making
adjustments or performing maintenance or repair of any kind
is qualified to do so. Vision Fitness will provide service and
maintenance training at our corporate facility upon request or in
the field if proper arrangements are made.
CARE AND MAINTENANCE
HOW DO I CLEAN MY MACHINE?
Clean with soap and water cleaners only. Never use solvents
on plastic parts. Cleanliness of your treadmill and its operating
environment will keep maintenance problems and service calls to
a minimum. For this reason, Customer Tech Support recommends
that the following preventive maintenance schedule be followed.
DAILY
• Clean entire machine using water and mild detergent such as
“Simple Green”, or other Vision approved solution (cleaning
agents should be alcohol and ammonia free).

21
ASSEMBLY
There are several areas during the assembly process when special attention must be paid. It is very important to follow the
assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed
correctly, the treadmill could have parts that are not tightened and will seem loose and may cause irritating noises. To prevent
damage to the treadmill, the assembly instructions must be reviewed and corrective actions should be taken.
Before proceeding, find your treadmill’s serial number located on a white barcode sticker
on the base frame as shown in this image.
ENTER YOUR SERIAL NUMBER IN THE BOX BELOW:
SERIAL NUMBER:
MODEL NAME: VISION T80 TREADMILL
WARNING
SERIAL NUMBER LOCATION
