Wine racks America 4 Column Display RowCorner Kit User manual

Assembly GUIDE
*Please verify that you have the correct number of parts before proceeding.
Depending on the model you purchased, your bundle should contain the following:
Package Contents tools for assembly
Page 1
or visit
wineracksamerica.com
Questions?
888.373.6057
4 Column Display Row Corner
END LADDER ASSEMBLIES (x8)
77 1/8"
Cordless Drill Finish Nailer
Hammer Nail Setter
+
Screwdriver
Required
Wood Glue
Suggested
1 COLUMN SCREWLESS
CONNECTOR (x12)
1 COLUMN STANDARD
CONNECTOR (x24)
WOOD SCREWS
FINISH NAILS
WOOD PUTTY
CORNER WEDGE (x6)
DISPLAY TRAYS (x4)
IMPORTANT!
If you purchased a 2 Column Display Row
Corner Kit, your package will contain the
following parts:
END LADDER ASSEMBLIES - x4
1 COLUMN SCREWLESS CONNECTORS - x6
1 COLUMN STANDARD CONNECTORS - x12
CORNER WEDGE - x6
DISPLAY TRAYS - x2

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
Top of rack
4 Column Display Row Corner
Page 2
1. Find an open, flat area in which to work. Carefully remove all components from the box and remove banding
with a utility knife. Check the parts list to verify package contents.
1
BEGIN WITH BACK
OF RACK
2. Arrange two end ladders on the floor so that the bottle support pieces face one another. Align the large gaps on each
end ladder. The end with the larger gap is the top of your rack. Attach a standard column connector to the top
and bottom of your rack using the screws provided. Make sure the connectors are flush with the top and bottom
of your rack. (figure 1)
* Minimize the risk of splitting your ladders by drilling a 1/16" pilot hole before driving the wood screws.
For best results, drive the screw most of the way in with your drill, then finish tightening by hand.
3. Attach the middle standard connectors so that the top edge of the lower connector is 26 5/8" from the bottom
of the rack, and the top edge of the upper connector is 41 5/8" from the bottom of the rack. Secure the middle
connectors using the screws provided. This is the back of your rack. (figure 2)
26 5/8"
Back of rack
2
FINISH SECURING BACK
CONNECTORS
41 5/8"

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
4 Column Display Row Corner
Page 3
4. Flip rack over and secure a standard column connector to the top and bottom of your rack using the screws
provided. (figure 3)
3
FRONT OF RACK
Display corner kits are designed to show no visible hardware on the front of the rack. Use of of these following
methods to install the screwless connectors:
For no visible hardware, add wood glue to the inside of each connector notch. Place the connnector on your
rack and carefully press each notch into place. Hold until glue is dry. (figure A)
For a professional installation, secure the connectors using a finish nail gun to drive a nail through the connector
into each vertical ladder. If you do not have a finish nail gun, drive one of the provided finish nails through the
connector into each vertical ladder until it is flush. Then, countersink the nail using a nail setter until the head
of the nail is about 1/16" below the surface of the wood. (figure B)
(Optional) Purchase Crown and Base molding to cover the hardware of the top and bottom standard connectors
on the front of the rack. (figure C)
A B C
A
B
C
+
or
5. Attach the middle screwless connectors so that the top edge of the lower connector is 26 5/8" from the bottom
of the rack, the top edge of the middle connector is 37 1/4" from the bottom of the rack, and the top edge of the
upper connector is 51 3/4" from the bottom of the rack. Make sure the rack is flat on the floor while attaching the
screwless connectors. (figure 4)
Crown Molding
Base Molding

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
4 Column Display Row Corner
Page 4
4
ATTACH SCREWLESS
CONNECTORS
6. Fill the nail holes using the wood putty provided. Simply push the putty into each hole using your thumb and
wipe excess putty off the surface using a damp cloth.
Front of rack
26 5/8"
51 3/4"
37 1/4"
7. Insert a metal U-bar into the two pre-drilled holes of each display tray by pushing down on the U-bar until it
reaches the bottom of the holes. (figure 5)
Stand your rack upright. To secure your display trays to your rack,
apply a bead of wood glue to each of the two grooves on the back
of the tray. (figure 6)
Then, put the tray into place so that the grooves rest on the upper
middle connectors. (figure 7)
5
INSERT METAL
U-BARS
6
APPLY WOOD
GLUE
7
ATTACH DISPLAY
TRAYS

Assembly GUIDE or visit
wineracksamerica.com
Questions?
888.373.6057
4 Column Display Row Corner
Page 5
WINERACKSAMERICA.COM
360 North 700 West Suite F • North Salt Lake, UT 84054
(toll free) 888-373-6057
(fax) 801-936-0534
Once again, thank you for your business. Remember, customer
service is available to answer any questions Monday-Friday
7:00 am - 5:00 pm MST. Please feel free to contact us for any
wine storage needs.
We would love to see your wine racks in use! Please feel free to
send any photos of your racks to [email protected]
10. That’s it! Enjoy this beautiful rack with your favorite beverage. Pair with other rack styles for an ultimate
cellar storage look.
8. Repeat steps 1-7 until you have a total of 4 fully assembled 1 Column Display Cellar racks. If you purchased a
2 Column Display Row Corner kit, you will only assembly two - 1 Column Display Cellar racks.
TOP
9. To attach the 1 column racks together, use a screwdriver and provided wood screws to attach each wedge
piece to the vertical risers. Drill pilot holes to guide the wood screws and avoid splitting. Follow the same
procedure on the bottom of the rack. (figure 8)
4
ATTACH WEDGE PIECES
8
