VISIONARY DESIGNS MOD-1299 Manual

© 2021
Order #XXXXX
Locked layer contains
placeholder marks.
Completed Assembly
Item
1
2
3
4
5
6/6A
Qty.
1
1
1
1
1
1/1
Description
40” Vertical Extrusion
40” Vertical Extrusion
40.418” Curved Extrusion
40.418” Curved Extrusion
40.418” Curved Extrusion
23.55” Horizontal Extrusion
1
3
2
Infill
Infill
Steps:
1) Attach Curved Extrusions [3, 4, 5] to Verticals [1, 2], with Infills between as shown.
2) Attach Horizontals [6, 6A] between Verticals [1, 2].
3) Place lower Shelf on Lip of Curved Extrusion [4]. See Extrusion Lip detail.
4) Attach Shelf Supports to Velcro inside of assembled Pedestal base.
5) Place upper Shelf on top of Shelf Supports.
6) Place Pedestal Top on top of assembled Pedestal base. See
Pedestal Top Attachment detail.
*
*
4
5
6
6A
Pedestal Top
(3) Shelf
Supports
Shelf
Shelf
Extrusion [4] has a Lip
for the Shelf to rest upon.
Lip
Extrusion Lip
Align hole with pin Rotate pin. Spring
will push pin into hole.
Pedestal Top Attachment
12
*
Pin
Hole
**
MOD-1299 Pedestal
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2021
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2021
Cate 1 of 1
Order #XXXXX
Locked layer contains
placeholder marks.
Setup Hardware
Top View of Each Level
Level 1
(Bottom level)
Level 2 Level 3
Infills
1, 2
6, 6A
3
4
5
Pedestal Top
Shelf
Case Packing
