Visionis VIS-8013 User manual

Indoor Access Control 433MHz Wireless
Request to Exit Button Battery Operated
VIS-8013
User Manual
www.visionistech.com

INTRODUCTION
•433MHz Communication Frequency
•Easy installation by 3M stickers
•Dry contact version optional (current: 2A)
•2032 lithium battery operated
•Dimension: L80 x W38 x D15(mm) - L3.15 x W1.50 x D0.59(in.)
Specifications
Operating Voltage
1unit of 2023 Lithium battery (INCLUDED)
Current
Idle Current
Working Current
≤10uA
≤30mA
Communication Frequency
433MHz
Communication Distance
50m Maximum (165 feet)
Environment
Operating Temperature
Operating Humidity
Indoor
-20°C~60°C (-4°F~140°F)
0%~86%RH
Physical
Dimensions
Unit Weight
ABS Shell
L80 x W38 x D15(mm) - L3.15 x W1.50 x D0.59(in.)
34g
INSTALLATION
Attention: there is a battery spacer inside the Wireless Exit Button, please take it off before
installation.
Stick by 3M stickers
The device packed with 3M double-side Sticker, can easily stick-on Metal door, Glass Door, Wooden Door, or Smooth
Wall.
Pair with Controller
To pair the Wireless Exit Button and Mini Controller:
To pair the wireless button and the controller:
Mini Controller: Remove the back cover and press the button “Pair”.
Wireless Button: Remove the back cover and press the button “Pair”.
After hearing one beep, press “Pair” again to exit pairing mode.
If pair successfully, there will be one beep from both the controller and the exit button; if not, there will be three short
beeps, then please repeat the setting.

To pair the wireless button with multiple mini controllers:
Wireless Button: Remove the back cover and press the button “Pair”.
Mini Controller: Remove the back cover and press the button “Pair”.
(Same settings for multiple controllers)
If pair successfully, there will be one beep from both the controller and the button, press the button “Pair” on the button to
exit pairing mode, if not, there will be three short beeps, then please repeat the setting.
Users need to finish the pairing within 30s for multiple controllers, or else, the keypad will exit pairing mode
automatically.
