ENGLISH
BLENDER SET VT-3422
The blender is included into the blender set
and intended for whisking, mixing, chopping
and combined processing of liquid and solid
products.
DESCRIPTION
1. Detachable blender attachment
2. Attachment installation place
3. Attachment release buttons
4. Motor unit
5. “TURBO” mode button
6. On/off button « »
7. Rotation speed control knob
8. Chopper geared lid
9. Knife
10. Chopper bowl
11. Whisk attachment gear
12. Whisk attachment
13. Cup
SAFETY PRECAUTIONS
Before using the blender set, read this instruc-
tion carefully. Keep these instructions for fur-
ther reference. Use the blender set for its
intended purpose only as specified in this
manual.
Mishandling the unit may lead to its breakage
and cause harm to the user or damage to his/
her property.
• Before connecting the unit to the mains,
make sure that the voltage specified on
the unit corresponds to your home mains
voltage.
• Do not use the unit outdoors.
• Do not use the unit near hot surfaces (such
as gas or electric stove, oven).
• Make sure that the power cord does not
touch sharp edges of furniture and hot sur-
faces.
• Do not touch the motor unit body, the power
cord and the power plug with wet hands.
• To avoid risk of electric shock or fire, do not
immerse the unit body, the power cord and
the power plug into water or any other liq-
uids.
• If the unit is dropped into water:
– do not touch the water;
– unplug the unit immediately and only after
that you may take the unit out of water;
– apply to the authorized service center for
testing or repairing the unit.
• Before using the unit for the first time, thor-
oughly wash all the removable attachments
and containers that will contact food.
• Use only the attachments supplied with the
unit.
• Before using the unit, make sure that the
attachments are set and fixed properly.
• It is not allowed to switch the unit on without
attachments and foodstuffs for processing.
• Never leave the unit connected to the mains
unattended.
• Always unplug the unit before changing the
attachments and after using it.
• Place the chopper bowl on a dry, flat and
steady surface.
• Put the products into the chopper bowl
before the unit is switched on.
• Cool down hot products before putting them
into the measuring cup or the chopper bowl.
• Do not overfill the chopper bowl with prod-
ucts and watch the level of poured liquids.
• If rotation of the knife is hindered during the
operation of the chopper, unplug the unit
and carefully remove foodstuffs that prevent
the knife rotation.
• Remove products and pour out liquids from
the chopper bowl only after complete stop
of the knife.
• The cutting edges of the chopping knife and
of the blender attachment are very sharp
and can be dangerous. Handle these attach-
ments very carefully!
• Do not touch the rotating parts of the unit.
Do not let hair or free hanging clothes get
into the rotation area of the blender attach-
ment knife or whisk.
• To unplug the unit do not pull the power
cord, take the power cord plug directly and
disconnect it from the mains.
• Do not place the chopper bowl and the mea-
suring cup into a microwave oven.
• Do not put the attachments and bowls in a
dishwashing machine.
• For children safety reasons do not leave
polyethylene bags used as a packaging
unattended.
Attention! Do not allow children to play with
polyethylene bags or packaging film. Danger
of suffocation!
• Close supervision is necessary when chil-
dren or people with disabilities are near the
operating unit.
IM VT-8503.indd 3 10/6/20 3:41 PM

4
ENGLISH
• This unit is not intended for usage by chil-
dren.
• Do not leave children unattended to prevent
using the unit as a toy.
• Do not allow children to touch the body
of the motor unit, the power cord and the
power plug during operation of the unit.
• During the unit operation and breaks
between operation cycles, place the unit out
of reach of children.
• The unit is not intended for usage by physi-
cally or mentally disabled persons (including
children) or by persons lacking experience
or knowledge if they are not under supervi-
sion of a person who is responsible for their
safety or if they are not instructed by this
person on the usage of the unit.
• Do not use the unit if the power cord is dam-
aged. If the power cord is damaged, it should
be replaced by the manufacturer, service or
similar qualified personnel to avoid danger.
• Do not attempt to repair the unit by your-
self. Do not disassemble the unit; if any mal-
function is detected or after it was dropped,
unplug the unit and apply to any authorized
service center from the contact address list
given in the warranty certificate and on the
website www.vitek.ru.
• To avoid damages, transport the unit in the
original package only.
• Keep the unit out of reach of children and
people with disabilities.
THE UNIT IS INTENDED FOR HOUSEHOLD USE
ONLY, ITS COMMERCIAL USAGE AND USAGE
IN PRODUCTION AREAS AND WORK SPACES
IS PROHIBITED.
BEFORE THE FIRST USE
After unit transportation or storage at low
temperature keep it for at least three hours
at room temperature before switching on.
• Unpack the blender and remove any adver-
tising stickers and package materials that
can prevent the unit operation.
• Check the unit for damages, do not use it in
case of damages.
• Before switching the unit on, make sure that
the mains voltage corresponds to the volt-
age specified on the unit body.
• The unit is intended for operation with AC sys-
tem and 50 or 60 Hz frequency. The unit does
not need any additional settings for operating
with the required nominal frequency.
• Before using the unit wash the attachments
(1, 12), the bowl (10) and the knife (9) of the
chopper, the cup (13) with warm water and a
neutral detergent and dry them thoroughly.
• Wipe the motor unit (4), the chopper geared
lid (8) and the whisk attachment gear (11)
with a soft slightly damp cloth and then wipe
them dry.
ATTENTION!
• Do not immerse the motor unit (4), the
chopper geared lid (8), the whisk attach-
ment gear (11), the power cord and the
power plug into water or any other liquids.
• Wash only the operating part of the blender
attachment (1), clean the outer surface with
a damp cloth. Never immerse the blender
attachment (1) into water or any other liq-
uids completely.
• Do not put the attachments and bowls in a
dishwashing machine.
OPERATION TIME
The blender set allows quick and effective
operation, but continuous operation time with
the whisk attachment (12) should not exceed
1 minute, with the blender attachment (1) –
30 seconds, and operation time with the chop-
per attachment is no more than 20 seconds.
Make at least 10 minute break between 3 oper-
ation cycles.
USING THE BLENDER ATTACHMENT (pic. 1)
Use the detachable blender attachment (1) for
making fruit puree, baby food, sauces, may-
onnaise, for mixing various ingredients and
making cocktails, for processing fruit and veg-
etables containing enough juice.
WARNING: Before installing the attach-
ment (1), make sure that the power plug is not
inserted into the mains socket.
• Install the detachable blender attachment
(1) to the installation place (2), press on
the attachment (1) bottom-upwards until the
release buttons (3) clicking, make sure that
the attachment (1) is fixed properly.
• Insert the power plug into the mains socket,
the illumination around the speed control
knob (7) will light up.
• Immerse the blender attachment (1) into the
bowl with products that you want to chop/mix.
IM VT-8503.indd 4 10/6/20 3:41 PM

5
ENGLISH
Note: - You can put the foodstuffs into the
cup (13).
ATTENTION!
While processing products keep the unit ver-
tically.
• To switch the blender on, press and hold
down the button (6). Use this operation
mode for mixing liquid products. Turn the
attachment rotation speed control knob (7)
to change the attachment (1) rotation speed.
• If you press and hold down the «TURBO»
button (5), the unit will operate at maximum
rotation speed. Use this operation mode
for combined processing of liquid and solid
foodstuffs.
Notes:
– products should be put into the bowl before
the unit is switched on. The amount of prod-
ucts to be processed should not exceed 2/3
of the capacity of the bowl in which they are
processed.
– before starting to chop/mix, we recommend
to peel fruit, remove inedible parts, such as
stones, and cut fruit into 2х2 cm cubes.
• After you finish using the unit, take the power
plug out of the mains socket and detach the
detachable blender attachment (1) by press-
ing the release buttons (3) simultaneously.
ATTENTION!
– Do not remove the blender attachment (1)
during operation.
– To avoid damaging the blades, do not pro-
cess too hard products such as cereals, rice,
spices, coffee beans, hard cheeses, frozen
products etc.
– If the foodstuffs are hard to chop with the
blender attachment (1), add some liquid if
possible.
USING THE WHISK ATTACHMENT (pic. 2)
Use the whisk attachment (12) only for beating
cream and egg whites, making biscuit dough or
for mixing ready desserts.
WARNING: Before installing the whisk (12) and
the gear (11) make sure that the power plug is
not inserted into the mains socket.
• Insert the whisk attachment (12) into the
whisk gear (11).
• Install the gear (11) with attached whisk (12)
to the installation place (2), press on the
gear (11) bottom-upwards until the release
buttons (3) clicking, make sure that the gear
(11) and the whisk (12) are fixed properly.
• Insert the power plug into the mains socket,
the illumination around the speed control
knob (7) will light up.
• Immerse the whisk attachment (12) into the
bowl with products.
Note: - You can put the foodstuffs into the
cup (13).
• To switch the blender on, press and hold
down the button (6). Turn the attachment
rotation speed control knob (7) to change
the attachment (12) rotation speed.
• If you press and hold down the «TURBO»
button (5), the unit will operate at maximum
rotation speed.
• After you finish using the unit, take the power
plug out of the mains socket, disconnect
the whisk gear (11) from the motor unit (4)
by pressing the release buttons (3) simul-
taneously.
• Remove the whisk (12) from the gear (11).
ATTENTION!
– Do not use the whisk attachment (12) to
knead tight dough.
– Put products into the bowl before switching
the unit on.
USING THE CHOPPER (pic. 3)
The unit is used to chop meat, cheese, onion,
herbs, garlic, carrots, walnuts, almonds,
prunes, vegetables and fruit.
ATTENTION!
Do not chop very hard products, such as ice
cubes, frozen products, nutmegs, coffee beans,
cereals etc.
Before you start chopping:
– Cut meat, cheese, onions, vegetables or fruit
into pieces approximately 2x2 cm in size.
– Remove stems of herbs, shell nuts.
– Remove bones, sinews and cartilage from
meat.
Chopping
Caution: the blades of the knife (9) are very
sharp! Always hold the knife (9) by the upper
plastic end.
• Place the chopper bowl (10) on a dry, flat
and steady surface.
• Set the knife (9) on the axis inside the chop-
per bowl (10).
• Put the food into the chopper bowl (10).
Note: - do not switch the unit on when the
chopper bowl (10) is empty.
IM VT-8503.indd 5 10/6/20 3:41 PM

6
ENGLISH
• Place the geared lid (8) on the chopper
bowl (10) and rotate it clockwise until
bumping.
• Install the motor unit (4) on the geared
lid (8) chute, press on the motor unit (4)
downwards until the buttons clicking (3),
make sure that the motor unit (4) is fixed
properly.
• Install the motor unit (4) strictly in the vertical
position and evenly.
• Connect the unit to the mains by inserting
the power plug into the mains socket, the
illumination around the speed control knob
(7) will light up.
• To switch the blender on, press and hold
down the button (6). Turn the attachment
rotation speed control knob (7) to change
the knife (9) rotation speed.
• If you press and hold down the «TURBO»
button (5), the unit will operate at maximum
rotation speed.
• During operation hold the motor unit (4) with
one hand and the chopper bowl (10) with the
other hand.
• After the unit operation, wait till the knife (9)
fully stops.
• Remove the power plug from the mains socket.
• Disconnect the motor unit (4) from the
geared lid (8) chute by pressing the release
buttons (3) simultaneously.
• Remove the geared lid (8) having turned it
counterclockwise.
• Carefully remove the knife (9) taking it by the
plastic end.
• Take the chopped products out of the chop-
per bowl (10).
To achieve the best results, refer to the table below:
Recipe Recommended
attachments
Weight,
amount
of products
Cooking method Approximate
time
of readiness
Mayonnaise 250 ml Crack 1 egg into the measuring
cup, add salt, several drops of
vinegar or lemon juice and the
required amount of vegetable oil.
Switch the blender on and mix the
products until the oil emulsifies to
the desired consistency.
30 sec.
Smoothies --- Put the fruit into the measuring
cup and chop to the homogeneous
mass with the blender attachment.
---
Bechamel
sauce
600 ml Melt 30 g butter in a casserole over
low heat, add 100 g flour and 30 g
fried onion (preliminarily chopped),
mix the ingredients and gradually
add 500 ml milk.
15 sec.
Whipped egg
whites
3 egg whites Add the egg whites into the
measuring cup and whip them
moving the whisk up and down.
1 min.
Baby food 300 g Cut 100 g apples and 100 g banana,
crumble 50 g cookies with your
hands and put all the ingredients
into the measuring cup, add some
fruit juice and mix to the desired
consistency.
25 sec.
IM VT-8503.indd 6 10/6/20 3:41 PM

7
ENGLISH
Recipe Recommended
attachments
Weight,
amount
of products
Cooking method Approximate
time
of readiness
Mashed
potatoes
400 g Cool potatoes and mash them.
You can make mashed potatoes in
the same container you boiled the
potatoes in.
30 sec.
Bread
crumbs
50 g Cut some stale bread and put
it into the chopper bowl, chop
to the desired consistency.
20 sec.
Hard cheese 100 g Cut cheese into approximately
1 x 1 cm cubes and put it into the
chopper bowl, chop to the desired
consistency.
10 sec.
Meat 450 g Cut meat into small cubes and put it
into the chopper bowl, chop to the
desired consistency.
10 sec.
Nuts 200 g Shell nuts, put them into the
chopper bowl and chop to the
desired consistency.
10 sec.
Note: - all data in this table are given as recommendations.
CLEANING
Attention! The blades of the knife (9) are
very sharp and may be dangerous. Handle the
knife (9) very carefully!
• Unplug the unit before cleaning.
• Remove the attachments. Use a slightly
damp cloth to clean the motor unit (4) and
the gears (8, 11), then wipe them dry.
• After processing salty or sour products, it is
necessary to rinse the blender attachment (1)
or the knife (9) with water immediately.
• While possessing products with strong
dyeing properties (for instance, carrot or
beetroot) the attachments and bowls can
get colored, wipe the attachments and the
bowls with a cloth dampened in vegetable
oil; after that wash the attachments and
bowls with a neutral detergent.
• Wash the attachments that contacted prod-
ucts with warm water and a neutral detergent
and dry them thoroughly after use.
• Wash the whisk attachment (12) all over
and wash only the lower part of the blender
attachment (1).
• Do not immerse the motor unit (4) and the
gears (8, 11) into any liquids, do not wash
them under water jet or in a dishwashing
machine.
STORAGE
• Clean and dry the unit thoroughly before tak-
ing it away for long storage.
• Do not wind the power cord around the
motor unit (4).
• Keep the blender set in a dry cool place
out of reach of children and disabled per-
sons.
DELIVERY SET
Motor unit – 1 pc.
Blender attachment – 1 pc.
Whisk gear – 1 pc.
Whisk attachment – 1 pc.
Geared lid – 1 pc.
Knife – 1 pc.
Chopper bowl – 1 pc.
Сup – 1 pc.
Instruction manual – 1 pc.
IM VT-8503.indd 7 10/6/20 3:41 PM

8
ENGLISH
TECHNICAL SPECIFICATIONS
Power supply: 220-240 V ~ 50/60 Hz
Rated input power: 400 W
Max. power 1000 W
Capacity of the chopper bowl: 500 ml
Capacity of the cup: 600 ml
RECYCLING
For environment protection do not throw out the
unit and the batteries (if included), do not dis-
card the unit and the batteries with usual house-
hold waste after the service life expiration; apply
to specialized centers for further recycling.
The waste generated during the disposal of
the unit is subject to mandatory collection and
consequent disposal in the prescribed manner.
For further information about recycling of this
product apply to a local municipal administra-
tion, a disposal service or to the shop where you
purchased this product.
The manufacturer preserves the right to
change design, structure and specifica-
tions not affecting general principles of the
unit operation without a preliminary notifica-
tion due to which insignificant differences
between the manual and product may be
observed. If the user reveals such differences,
please report them via e-mail [email protected]
for receipt of an updated manual.
Unit operating life is 3 years
Guarantee
Details regarding guarantee conditions can be
obtained from the dealer from whom the appli-
ance was purchased. The bill of sale or receipt
must be produced when making any claim un-
der the terms of this guarantee.
This product conforms to the EMC
Directive 2014/30/EU and to the Low
Voltage Directive 2014/35/EU.
IM VT-8503.indd 8 10/6/20 3:41 PM

9
РУССКИЙ
БЛЕНДЕРНЫЙ НАБОР VT-3422
Блендер представлен в составе блендерного
набора и предназначен для взбивания, смеши-
вания, измельчения и совместной обработки
жидких и твёрдых продуктов.
ОПИСАНИЕ
1. Съёмная насадка-блендер
2. Место установки насадок
3. Кнопки фиксатора насадок
4. Моторный блок
5. Кнопка включения режима «TURBO»
6. Кнопка включения « »
7. Регулятор скорости вращения
8. Крышка-редуктор измельчителя
9. Нож
10. Чаша измельчителя
11. Редуктор насадки венчика
12. Насадка-венчик
13. Стакан
МЕРЫ БЕЗОПАСНОСТИ
Перед началом эксплуатации блендерного
набора, внимательно прочитайте настоящую
инструкцию по эксплуатации и сохраните её
для использования в качестве справочного
материала. Используйте блендерный набор
только по его прямому назначению, как изло-
жено в данной инструкции.
Неправильное обращение с устройством
может привести к его поломке, причинению
вреда пользователю или его имуществу.
• Прежде чем подключить устройство к элек-
тросети, проверьте, соответствует ли
напряжение, указанное на устройстве,
напряжению электросети в вашем доме.
• Запрещается использовать устройство вне
помещений.
• Не используйте устройство вблизи горячих
поверхностей (таких как газовая или элек-
трическая плита, духовой шкаф).
• Следите, чтобы шнур питания не прика-
сался к острым кромкам мебели и горячим
поверхностям.
• Не прикасайтесь к корпусу моторного блока,
к шнуру питания и к вилке шнура питания
мокрыми руками.
• Во избежание поражения электрическим
током или возгорания не погружайте кор-
пус устройства, шнур питания и вилку шнура
питания в воду или в любые другие жидко-
сти.
• Если устройство упало в воду:
– не прикасайтесь к воде;
– немедленно извлеките вилку шнура пита-
ния из электрической розетки, и только
после этого можно достать устройство
из воды;
– обратитесь в авторизованный (уполно-
моченный) сервисный центр для осмо-
тра или ремонта устройства.
• Перед первым использованием устройства
тщательно промойте все съёмные насадки
и ёмкости, которые будут контактировать
с продуктами.
• Используйте только те насадки, которые
входят в комплект поставки.
• Прежде чем начать пользоваться устрой-
ством, убедитесь в том, что насадки
установлены правильно и надёжно зафик-
сированы.
• Запрещается включать устройство без
использования насадок и продуктов для
переработки.
• Не оставляйте устройство, включённое
в электрическую сеть, без присмотра.
• Отключайте устройство от электрической
сети перед сменой насадок и после исполь-
зования.
• Устанавливайте чашу измельчителя на ров-
ной сухой и устойчивой поверхности.
• Продукты помещайте в чашу измельчителя
до включения устройства.
• Охлаждайте горячие продукты, прежде чем
поместить их в мерный стакан или в чашу
измельчителя.
• Не переполняйте чашу измельчителя про-
дуктами и следите за уровнем налитых жид-
костей.
• При работе с измельчителем в случае
затруднения вращения ножа отключите
устройство от электрической сети и акку-
ратно удалите продукты, мешающие вра-
щению ножа.
• Извлекать продукты и сливать жидкости из
чаши измельчителя можно только после
полной остановки вращения ножа.
• Режущие кромки ножа измельчителя
и насадки-блендера очень острые и могут
представлять опасность. Обращайтесь
с данными насадками крайне осторожно!
• Не прикасайтесь к вращающимся частям
устройства. Не допускайте попадания волос
или свободно висящих элементов одежды
IM VT-8503.indd 9 10/6/20 3:41 PM

10
РУССКИЙ
в зону вращения ножа насадки-блендера
или венчика.
• При отключении устройства не тяните за
шнур питания, возьмитесь непосредственно
за вилку шнура питания и выньте её из
розетки.
• Запрещается помещать чашу измельчителя
и мерный стакан в микроволновую печь.
• Не помещайте насадки и ёмкости в посудо-
моечную машину.
• Из соображений безопасности детей
не оставляйте полиэтиленовые пакеты,
используемые в качестве упаковки, без над-
зора.
Внимание! Не разрешайте детям играть
с полиэтиленовыми пакетами или упаковоч-
ной плёнкой. Опасность удушья!
• Будьте особенно внимательны, если побли-
зости от работающего устройства находятся
дети или лица с ограниченными возможно-
стями.
• Данное устройство не предназначено для
использования детьми.
• Осуществляйте надзор за детьми, чтобы
не допустить использования устройства
в качестве игрушки.
• Не разрешайте детям прикасаться к кор-
пусу моторного блока, к шнуру питания
и к вилке шнура питания во время работы
устройства.
• Во время работы и в перерывах между
рабочими циклами размещайте устройство
в местах, недоступных для детей.
• Прибор не предназначен для использова-
ния лицами (включая детей) с пониженными
физическими, психическими или умствен-
ными способностями или при отсутствии
у них опыта или знаний, если они не нахо-
дятся под контролем или не проинструкти-
рованы об использовании прибора лицом,
ответственным за их безопасность.
• Запрещается использовать устройство при
наличии повреждений шнура питания. При
повреждении шнура питания его замену во
избежание опасности должны производить
изготовитель, сервисная служба или подоб-
ный квалифицированный персонал.
• Запрещается самостоятельно ремонтиро-
вать прибор. Не разбирайте прибор само-
стоятельно, при возникновении любых
неисправностей или после падения устрой-
ства выключите прибор из электрической
розетки и обратитесь в любой авторизован-
ный (уполномоченный) сервисный центр по
контактным адресам, указанным в гаран-
тийном талоне и на сайте www.vitek.ru.
• Во избежание повреждений перевозите
устройство только в заводской упаковке.
• Храните устройство в местах, недоступных
для детей и людей с ограниченными воз-
можностями.
УСТРОЙСТВО ПРЕДНАЗНАЧЕНО ТОЛЬКО ДЛЯ
БЫТОВОГО ИСПОЛЬЗОВАНИЯ В ЖИЛЫХ
ПОМЕЩЕНИЯХ, ЗАПРЕЩАЕТСЯ КОММЕР-
ЧЕСКОЕ ИСПОЛЬЗОВАНИЕ И ИСПОЛЬЗО-
ВАНИЕ УСТРОЙСТВА В ПРОИЗВОДСТ-
ВЕННЫХ ЗОНАХ И РАБОЧИХ ПОМЕЩЕНИЯХ.
ПЕРЕД ПЕРВЫМ ВКЛЮЧЕНИЕМ
После транспортировки или хранения
устройства при пониженной температуре
необходимо выдержать его при комнатной
температуре не менее трёх часов.
• Извлеките блендер из упаковки и уда-
лите упаковочные материалы и рекламные
наклейки, мешающие работе устройства.
• Проверьте целостность устройства, при
наличии повреждений не пользуйтесь
устройством.
• Перед включением убедитесь, что напряжение
в электрической сети соответствует напряже-
нию, указанному на корпусе устройства.
• Устройство предназначено для работы
в сети переменного тока с частотой 50 Гц или
60 Гц, для работы устройства при требуемой
номинальной частоте никакая настройка не
требуется.
• Перед использованием устройства про-
мойте насадки (1, 12), чашу (10) и нож (9)
измельчителя, стакан (13) тёплой водой
с нейтральным моющим средством и тща-
тельно просушите их.
• Моторный блок (4), крышку-редуктор
измельчителя (8) и редуктор насадки вен-
чика (11) протрите мягкой, слегка влажной
тканью, после чего вытрите насухо.
ВНИМАНИЕ!
• Не погружайте моторный блок (4), крышку-
редуктор измельчителя (8), редуктор
IM VT-8503.indd 10 10/6/20 3:41 PM
