Vivo DESK-E151EW User manual

White Compact Electric Single Motor Desk Frame
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/desk-e151ew
SKU: DESK-E151EW
[email protected]om www.vivo-us.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2
If you do not understand these directions, or if you have any doubts about the safety of the installation,
please call a qualified technician. Check carefully to make sure there are no missing or defective parts.
Improper installation may cause damage or serious injury. Do not use this product for any purpose that is
not explicitly specified in this manual and do not exceed weight capacity. We cannot be liable for damage
or injury caused by improper mounting, incorrect assembly, or inappropriate use.
WARNING!
PACKAGE CONTENTS
A (x1)
Telescopic
Crossbar
B x1)
Motorized Leg
C(x1)
Leg
D(x1)
Crossbar
Spacer
E(x2)
Side Bracket
F(x1)
Sync Rod
G (x2)
Foot
H x1)
Adapter Holder
I(x1)
AC Adapter
J(x1)
Power Cable
K(x1)
Controller
ELECTRICAL SAFETY INSTRUCTIONS
THIS PRODUCT IS POWERED BY ELECTRICITY. IN ORDER TO AVOID BURNS, FIRE AND ELECTRIC
SHOCK, PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY.
• DO NOT CLEAN PRODUCT WHILE POWER IS CONNECTED.
• DO NOT DISASSEMBLE OR REPLACE COMPONENTS WHILE POWER IS CONNECTED.
• NEVER OPERATE THE SYSTEM WITH A DAMAGED CORD OR PLUG. PLEASE CONTACT YOUR
SELLER TO REPLACE DAMAGED PARTS.
• NEVER OPERATE SYSTEM IN DAMP ENVIRONMENTS OR IF ANY ELECTRICAL COMPONENTS HAVE
MADE CONTACT WITH LIQUIDS.
• ALTERATIONS OF THE GIVEN POWER UNIT ARE NOT ALLOWED.
• OUTDOOR USE IS PROHIBITED.
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
S-A (x16)
M6x12
Bolt
S-B x10)
7/8" Screw
S-C (x2)
3/4" Screw
S-D (x3)
Cable Clip
S-E (x10)
Anti-Vibration
Pad
S-F (x1)
Allen
Wrench

3
176lbs
(79.8 kg)
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
ASSEMBLY STEPS
STEP 1
Loosen the two set screws on the telescopic crossbar (A) using the Allen wrench (S-F). Adjust the
crossbar length to suit the desktop. Retighten all screws.
TOOLS NEEDED
Phillips
Screwdriver
STEP 2
Place the crossbar spacer (D) on the motorized leg (B) as shown. Attach the
telescopic crossbar to the legs (B, C) as shown using M6x12mm bolts (S-A),
and tighten with the Allen wrench (S-F).
Drill
NOTE: Insert all necessary
screws into holes before
tightening.
Level

4
STEP 3
STEP 4
Attach the side brackets (E) to both ends of the frame using four M6x12mm bolts (S-A). Tighten with
the Allen wrench (S-F).
STEP 5
Loosen the knob on the socket end of the sync
rod (F) and slide the sync rod onto the sha of
the motorized leg. Tighten the knob.
Loosen the knob on the other end of the sync rod and extend the
hex sha into the socket in the leg, making sure the sha is fully
inserted. Tighten the knob.

5
STEP 6
STEP 8
Place the adapter holder (H) over the telescopic crossbar and tighten
the two thumbscrews. Place the AC adapter (I) into the adapter holder.
Place the frame upside down on desktop and drill pilot holes for the screws. Use a 3/32” or 3mm bit,
and drill holes to a depth of 3/8” (10mm). Readjust the sync rod if necessary.
STEP 7
Place the feet (G) on the
legs as shown. Insert and
tighten bolts (S-A) using
the Allen wrench (S-F).

6
STEP 9
STEP 10
STEP 11
Insert the anti-vibration pads (S-E) into the desktop mounting holes in the crossbar and side brackets.
Place the assembled frame on the desktop, making sure the pre-drilled holes are aligned with the desk
frame, and secure the frame using 7/8" screws (S-B).
Connect the AC adapter and motorized leg to the controller (K).
Connect the power cable (J) to the AC adapter.

7
STEP 12
STEP 13
Attach the controller to the underside of the desktop using 3/4" screws (S-C) as shown. Once controller
is installed, cable clips (S-E) can be attached to the desk for cable management. Refer to the Controller
User Guide for operational instructions.
If necessary, adjust foot pads to level desk.
CAUTION!
Failure to follow these instructions may result in property damage and/or personal injury.
Do not exceed desk
weight limit.
Keep area of vertical
motion free of
obstacles.
Keep weight on desk
balanced for correct
operation and longer
life of components.
Leave enough slack in
cables to allow for full
range of vertical motion.

LAST UPDATED: 03/04/2020
