Wasp WWS800 User manual

WWS800/850 Bluetooth Wireless Scanners
User’s Manual
© 2008 Wasp Technologies
Table of Contents
Revision History .......................................... Error! Bookmark not defined.
Restore Default Settings ...........................................................................1
Exit Setup without Changes .....................................................................1
Set Connection...........................................................................................1
RF Auto Shutdown Duration ...................................................................1
Transmit Buffer Setting............................................................................1
Memory Mode Parameters.......................................................................2
List Setting.................................................................................................3
Buzzer Settings ..........................................................................................3
Reading Redundancy Setting ...................................................................4
Scan Mode Setting.....................................................................................4
Auto-Sense Setting ....................................................................................4
Scanner Time-out Duration......................................................................5
Negative Barcode Setting..........................................................................5
Delay between Reread ..............................................................................5
Keyboard Wedge Parameters ..................................................................6
RS-232 Parameters....................................................................................9
Bluetooth Serial Port Parameters..........................................................11
Bluetooth HID Parameters.....................................................................12
Prefix / Postfix Settings...........................................................................15
Character Substitution ...........................................................................15
Code ID Selection ....................................................................................15
Code ID Setting .......................................................................................16
Length Code Setting (2 digits)................................................................17
Select Readable Codes ............................................................................20
Code39 Parameters .................................................................................25
Italy Pharmacode Parameters................................................................25
French Pharmacode Parameters............................................................26
Industrial 25 Parameters........................................................................26
Interleave 25 Parameters........................................................................27
Matrix 25 Parameters.............................................................................29
Codabar Parameters...............................................................................30
Plessey Parameters..................................................................................31
Telepen Parameters.................................................................................31
MSI Parameters ......................................................................................32
EAN128 Parameters................................................................................33
EAN8 Parameters....................................................................................34
UPCA Parameters...................................................................................34
UPCE Parameters ...................................................................................35
EAN13 Parameters..................................................................................36
RSS Code ID Selection............................................................................37

RSS14 Parameters...................................................................................37
RSS Limited Parameters ........................................................................38
RSS Expanded Parameters ....................................................................38
Activate Editing Formats .......................................................................39
Editing Format Parameters....................................................................40
Decimal Digits..........................................................................................52
Hexadecimal Digits..................................................................................53
Key Type..................................................................................................54
Key Status................................................................................................54
KBD Wedge Character Table................................................................55
RS-232 Character Table.........................................................................55

1
Update
Restore Default Settings
Restore Default SettingsRestore Default Settings
Restore Default Settings
Exit Setup without Changes
Exit Setup without ChangesExit Setup without Changes
Exit Setup without Changes
Set Connection
Set ConnectionSet Connection
Set Connection
*
Programming Instructions: (1) Read the label. (2) Read the Serial Number barcode
on the bottom of the desired 3666 Base Station within 5 seconds to complete this
setting.
RF Auto Shutdown Duration
RF Auto Shutdown DurationRF Auto Shutdown Duration
RF Auto Shutdown Duration
*
Programming Instructions: (1) Read the label. (2) Program the desired auto
shutdown duration (in minutes) by reading Decimal Digits on page 53. (3) Read the
“Validate” label (also on page 53) to complete this setting.
Transmit Buffer Setting
Transmit Buffer SettingTransmit Buffer Setting
Transmit Buffer Setting
Enable
< Disable >
2
Enter Setup
Memory
Memory Memory
Memory Mo
MoMo
Mode
dede
de arameters
arameters arameters
arameters
•Memory Mode
Enable
< Disable >
• Clear Data
Clear
Confirm
•Send Data
•Memory Data Delay
< 0 >
2 sec
250 ms
3 sec
500 ms
5 sec
1 sec
8 sec

3
Update
List Setting
List SettingList Setting
List Setting
Page1
Page 6
Page 2
Page 7
Page 3
Page 8
Page 4
Page 9
Page 5
Page 10
Buzzer Settings
Buzzer SettingsBuzzer Settings
Buzzer Settings
< Buzzer Enable>
Buzzer Disable
•Buzzer Frequency
8 kHz
< 4 kHz >
2 kHz
1 kHz
4
Enter Setup
Reading Redundancy Setting
Reading Redundancy SettingReading Redundancy Setting
Reading Redundancy Setting
< No Redundancy >
2 Times
3 Times
4 Times
Scan Mode Setting
Scan Mode SettingScan Mode Setting
Scan Mode Setting
< Auto Off Mode >
Continuous Mode
Auto Power Off Mode
Alternate Mode
Momentary Mode
Repeat Mode
Laser Mode
Test Mode
Auto
AutoAuto
Auto-
--
-Sense Setting
Sense SettingSense Setting
Sense Setting
Enable
<Disable>

5
Update
Scanner Ti
Scanner TiScanner Ti
Scanner Time
meme
me-out Duration
out Durationout Duration
out Duration
*
Programming Instructions: (1) Read the label. (2) Program the desired time-out
duration by reading Decimal Digits on page 53. (3) Read the “Validate” label (also
on page 53) to complete this setting.
Negative Barcode Setting
Negative Barcode SettingNegative Barcode Setting
Negative Barcode Setting
Enable
< Disable >
Delay between Reread
Delay between RereadDelay between Reread
Delay between Reread
100 ms
1 sec
200ms
2 sec
< 400 ms >
3 sec
800 ms
5 sec
6
Enter Setup
Keyboard Wedge arameters
Keyboard Wedge arametersKeyboard Wedge arameters
Keyboard Wedge arameters
•Activate and Select Keyboard Type
*
Programming Instructions: (1) Read the label. (2) Program the desired keyboard
number (shown in the following table) by reading Decimal Digits on page 53. (3)
Read the “Validate” label (also on page 53) to complete this setting.
•Keyboard Table
No. Keyboard Type
1 PCAT (US)
2 PCAT (French)
3 PCAT (German)
4 PCAT (Italy)
5 PCAT (Swedish)
6 PCAT (Norwegian)
7 PCAT (UK)
8 PCAT (Belgium)
9 PCAT (Spanish)
10 PCAT (Portuguese)
11 PS55 A01-1
12 PS55 A01-2
13 PS55 A01-3
14 PS55 001-1
15 PS55 001-81
16 PS55 001-2
17 PS55 001-82
18 PS55 001-3
19 PS55 001-8A
20 PS55 002-1, 003-1
21 PS55 002-81, 003-81
22 PS55 002-2, 003-2
23 PS55 002-82, 003-82
24 PS55 002-3, 003-3
25 PS55 002-8A, 003-8A
26 IBM 3477 (Japanese)
27 PS2-30
28 IBM 34XX/319X, Memorex Telex 122 Keys

7
Update
•Keyboard Alphabets Layout
< Default Layout >
AZERTY
QWERTZ
•Keyboard Digits Layout
< Default Layout >
Lower Row
Upper Row
•Keyboard Capital Lock Type
< Default >
Shift Lock
Capital Lock
•Capital Lock Setting
Capital Lock ON
< Capital Lock OFF >
Auto Detection
8
Enter Setup
•Alphabet Transmission
< Case Sensitive >
Ignore Case
•Digits Transmission
< Alphanumeric Key >
Numeric Key
•Alt Composing
Yes
< No >
•Inter-Character Delay
*
Programming Instructions: (1) Read the label. (2) Program the desired inter-
character delay by reading Decimal Digits on page 53. (3) Read the “Validate” label
(also on page 53) to complete this setting.
•Laptop Support
<Disable>
Enable

9
Update
RS
RSRS
RS-
--
-232 arameters
232 arameters232 arameters
232 arameters
•Activate RS232 Interface
•Baud Rate
115200
38400
119200
< 9600 >
4800
2400
1200
arity
Even
Odd
< No Parity >
•Data Bit
< 8 >
7
10
Enter Setup
•Flow Control (single port only)
< None >
Scanner Ready
Data Ready
INV. Data Ready
•Inter-Character Delay
*
Programming Instructions: (1) Read the label. (2) Program the desired inter-
character delay by reading Decimal Digits on page 53. (3) Read the “Validate”
label (also on page 53) to complete this setting.

11
Update
Bluetooth Serial ort arameters
Bluetooth Serial ort arametersBluetooth Serial ort arameters
Bluetooth Serial ort arameters
•Activate Bluetooth Serial ort Interface
•Device Name Broadcasting
< Yes >
No
•Authentication
Yes
< No >
•IN Code
*
Programming Instructions: (1) Read the label. (2) Program the desired character
string by reading Hexadecimal Digits on page 54. One character consists of 2
hexadecimal digits. (3) Read the “Validate” label (also on page 54) to complete
this setting. (4) Max 6 characters for this PIN Code setting.
12
Enter Setup
Bluetooth HID arameters
Bluetooth HID arametersBluetooth HID arameters
Bluetooth HID arameters
•Activate and Select Keyboard Type
*
Programming Instructions: (1) Read the label. (2) Program the desired
keyboard number (shown in the following table) by reading Decimal Digits on
page 53. (3) Read the “Validate” label (also on page 53) to complete this
setting.
•HID Keyboard Table
No. Keyboard Type
64 PCAT (US)
65 PCAT (French)
66 PCAT (German)
67 PCAT (Italy)
68 PCAT (Swedish)
69 PCAT (Norwegian)
70 PCAT (UK)
71 PCAT (Belgium)
72 PCAT (Spanish)
73 PCAT (Portuguese)
•Reset Connection
Please read this label when switching connection from one PC to another and
the reconnection is needed.
•Device Name Broadcasting
< Yes >
No

13
Update
•Authentication
Yes
< No >
•IN Code
*
Programming Instructions: (1) Read the label. (2) Program the desired character
string by reading Hexadecimal Digits on page 54. One character consists of 2
hexadecimal digits. (3) Read the “Validate” label (also on page 54) to complete
this setting. (4) Max 6 characters for this PIN Code setting.
•Keyboard Alphabets Layout
< Default Layout >
AZERTY
QWERTZ
•Keyboard Digits Layout
< Default Layout >
Lower Row
Upper Row
14
Enter Setup
•Keyboard Capital Lock Type
< Default >
Shift Lock
Capital Lock
•Capital Lock Setting
Capital Lock ON
< Capital Lock OFF >
Auto Detection
•Alphabet Transmission
< Case Sensitive >
Ignore Case
•Digits Transmission
< Alphanumeric Key >
Numeric Key
•Alt Composing
Yes
<No>

15
Update
refix / ostfix Settings
refix / ostfix Settingsrefix / ostfix Settings
refix / ostfix Settings
Prefix Code *
Postfix Code *
Character Substitution
Character SubstitutionCharacter Substitution
Character Substitution
Set 1 *
Set 2 *
Set 3 *
Programming Instructions: (1) Read the label. (2) Program the desired
character string by reading Hexadecimal Digits on page 54. One character
consists of 2 hexadecimal digits. (3) Read the “Validate” label (also on page
54) to complete this setting.
Code ID Selection
Code ID SelectionCode ID Selection
Code ID Selection
•Clear All Code ID Settings
•Select Code ID Set
Set 1
Set 2
Set 3
Set 4
Set 5
16
Enter Setup
Code ID Setting
Code ID SettingCode ID Setting
Code ID Setting
Code 39 *
Italy Pharmacode *
French Pharmacode *
Industrial 25 *
Interleave 25 *
Matrix 25 *
Codabar *
UPCA *
UPCE *
EAN8 *
EAN13 *
Code 93 *
Code 128 *
MSI *
Plessey *
Telepen *
Programming Instructions: (1) Read the label. (2) Program the desired character
string by reading Hexadecimal Digits on page 54. One character consists of 2
hexadecimal digits. (3) Read the “Validate” label (also on page 54) to complete
this setting.

17
Update
Length Code Setting (2 digits)
Length Code Setting (2 digits)Length Code Setting (2 digits)
Length Code Setting (2 digits)
•Code 39 Length Code
Enable
< Disable >
•Italy harmacode Length Code
Enable
< Disable >
•French harmacode Length Code
Enable
< Disable >
•Industrial 25 Length Code
Enable
< Disable >
•Interleave 25 Length Code
Enable
< Disable >
18
Enter Setup
•Matrix 25 Length Code
Enable
< Disable >
•Codabar Length Code
Enable
< Disable >
•U CA Length Code
Enable
< Disable >
•U CE Length Code
Enable
< Disable >
•EAN8 Length Code
Enable
< Disable >
•EAN13 Length Code
Enable
< Disable >

19
Update
•Code 93 Length Code
Enable
< Disable >
•Code 128 Length Code
Enable
< Disable >
•EAN128/RSS Length Code
Enable
< Disable >
•MSI Length Code
Enable
< Disable >
•lessey Length Code
Enable
< Disable >
•Telepen Length Code
Enable
< Disable >
20
Enter Setup
Select Readable Codes
Select Readable CodesSelect Readable Codes
Select Readable Codes
•Code 39
< Enable >
Disable
•Italy harmacode
Enable
< Disable >
•French harmacode
Enable
< Disable >
•Industrial 25
< Enable >
Disable
•Interleave 25
< Enable >
Disable
•Matrix 25
Enable
< Disable >

21
Update
•Codabar
< Enable >
Disable
•Code 93
< Enable >
Disable
•Code 128
< Enable >
Disable
•EAN128
Enable
< Disable >
•MSI
Enable
< Disable >
•lessey
Enable
< Disable >
22
Enter Setup
•Telepen
Enable
< Disable >
•U CA
< Enable No Addon >
Disable No Addon
Enable Addon2
< Disable Addon2 >
Enable Addon5
< Disable Addon5 >
•U CE
< Enable No Addon >
Disable No Addon
Enable Addon2

23
Update
< Disable Addon2 >
Enable Addon5
< Disable Addon5 >
•EAN8
< Enable No Addon >
Disable No Addon
Enable Addon2
< Disable Addon2 >
Enable Addon5
< Disable Addon5 >
•EAN13
< Enable No Addon >
Disable No Addon
Enable Addon2
< Disable Addon2 >
Enable Addon5
< Disable Addon5 >
24
Enter Setup
•RSS14
Enable
< Disable >
•RSS Limited
Enable
< Disable >
•RSS Expanded
Enable
< Disable >

25
Update
Code39 arameters
Code39 arametersCode39 arameters
Code39 arameters
•Standard / Full ASCII Code39
< Standard >
Full ASCII
•Start / Stop Transmission
Enable
< Disable >
•Checksum Verification
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
Italy harmacode arameters
Italy harmacode arametersItaly harmacode arameters
Italy harmacode arameters
•Checksum Transmission
< Enable >
Disable
26
Enter Setup
French harmacode arameters
French harmacode arametersFrench harmacode arameters
French harmacode arameters
•Checksum Transmission
< Enable >
Disable
Industrial 25 arameters
Industrial 25 arametersIndustrial 25 arameters
Industrial 25 arameters
•Start / Stop Selection
< Industrial 25 >
Interleave 25
Matrix 25
•Checksum Verification
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable

27
Update
•Max / Min Code Length Qualification
Select Max / Min Length Qualification
Max Length *
Min Length *
•Fixed Code Length Qualification
Select Fixed Length Qualification
Fixed Length 1 *
Fixed Length 2 *
Programming Instructions: (1) Read the label. (2) Program the desired length
by reading Decimal Digits on page 53. (3) Read the “Validate” label (also on
page 53) to complete this setting.
Interleave 25 arameters
Interleave 25 arametersInterleave 25 arameters
Interleave 25 arameters
•Start / Stop Selection
Industrial 25
< Interleave 25 >
Matrix 25
28
Enter Setup
•Checksum Verification
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
•Max / Min Code Length Qualification
Select Max / Min Length Qualification
Max Length *
Min Length *
Programming Instructions: (1) Read the label. (2) Program the desired length by
reading Decimal Digits on page 53. (3) Read the “Validate” label (also on page
53) to complete this setting.

29
Update
•Fixed Code Length Qualification
Select Fixed Length Qualification
Fixed Length 1 *
Fixed Length 2 *
Programming Instructions: (1) Read the label. (2) Program the desired length
by reading Decimal Digits on page 53. (3) Read the “Validate” label (also on
page 53) to complete this setting.
Matrix 25 arameters
Matrix 25 arametersMatrix 25 arameters
Matrix 25 arameters
•Start / Stop Selection
Industrial 25
Interleave 25
< Matrix 25 >
•Checksum Verification
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
30
Enter Setup
•Max / Min Code Length Qualification
Select Max / Min Length Qualification
Max Length *
Min Length *
•Fixed Code Length Qualification
Select Fixed Length Qualification
Fixed Length 1 *
Fixed Length 2 *
Programming Instructions: (1) Read the label. (2) Program the desired length by
reading Decimal Digits on page 53. (3) Read the “Validate” label (also on page
53) to complete this setting.
Codabar arameters
Codabar arametersCodabar arameters
Codabar arameters
•CLSI Conversion
Enable
< Disable >
•Start / Stop Transmission
Enable
< Disable >

31
Update
Start / Stop Selection
< abcd / abcd >
abcd / tn*e
ABCD / ABCD
ABCD / TN*E
lessey arameters
lessey arameterslessey arameters
lessey arameters
•Convert to UK lessey
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
Telepen arameters
Telepen arametersTelepen arameters
Telepen arameters
•Telepen Output
< AIM Telepen >
Original Telepen
32
Enter Setup
MSI arameters
MSI arametersMSI arameters
MSI arameters
•Checksum Verification
< Single Modulo 10 >
Double Modulo 10
Modulo 11 & 10
•Checksum Transmission
< Last digit not Transmitted >
Transmitted
Last 2 Digits not Transmitted
•Max / Min Code Length Qualification
Select Max / Min Length Qualification
Max Length *
Min Length *
Programming Instructions: (1) Read the label. (2) Program the desired length by
reading Decimal Digits on page 53. (3) Read the “Validate” label (also on page
53) to complete this setting.

33
Update
•Fixed Code Length Qualification
Select Fixed Length Qualification
Fixed Length 1 *
Fixed Length 2 *
Programming Instructions: (1) Read the label. (2) Program the desired length
by reading Decimal Digits on page 53. (3) Read the “Validate” label (also on
page 53) to complete this setting.
EAN128 arameters
EAN128 arametersEAN128 arameters
EAN128 arameters
•Code ID Transmission
Enable
<disable>
•Field Separator
*
Programming Instructions: (1) Read the label. (2) Program the desired
character string by reading Hexadecimal Digits on page 54. One character
consists of 2 hexadecimal digits. (3) Read the “Validate” label (also on page
54) to complete this setting.
34
Enter Setup
EAN8 arameters
EAN8 arametersEAN8 arameters
EAN8 arameters
•Convert to EAN13
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
U CA
U CA U CA
U CA arameters
arametersarameters
arameters
•Convert to EAN13
< Enable >
Disable
•System Number Transmission
< Enable >
Disable
•Checksum Transmission
< Enable >
Disable

35
Update
U CE arameters
U CE arametersU CE arameters
U CE arameters
•System Number Selection
System Number 0 and 1
< System Number 0 only >
•Convert to U CA
Enable
< Disable >
•System Number Transmission
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
36
Enter Setup
EAN13 arameters
EAN13 arametersEAN13 arameters
EAN13 arameters
•ISBN Conversion
Enable
< Disable >
•ISSN Conversion
Enable
< Disable >
•Checksum Transmission
< Enable >
Disable
