Zip HydroTap G5 Touch-Free Wave Instruction Manual

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
1
Zip
HydroTap G5
Quick Start Installation Guide
Command Center
Boiling/Chilled models
AFFIX PRODUCT LABEL HERE
Visit our website to
download the manuals
English French

2Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
Table of contents
SECTION 1: Using these instructions
This document is a Quick Start Installation Guide.
For further details on installing and operating your HydroTap
download & read the Command Center installation and user
instructions , which can be found online at:
na.zipwater.com
!
Read and use the instructions supplied with individual kit
components for a safe installation.
Before you start
!
!
Explanation of symbols
Read the
instructions
WARNING
!
!
Danger of
electric shock
!
!
Hot surface
SECTION 1: Using these instructions ..................................................................2
SECTION 2: IMPORTANT SAFETY INSTRUCTIONS..............................................3
SECTION 3: WARNINGS & REGULATORY INFORMATION...................................5
SECTION 4: Technical data.................................................................................7
SECTION 5: Parts supplied................................................................................. 8
SECTION 6: Set up the ventilation ............................................................................ 9
SECTION 7: Connect the water supply ............................................................. 12
SECTION 8: Set the bypass & install the limescale filter ................................... 13
SECTION 9: Connect the Command Center .................................................... 14
SECTION 10: Commissioning ........................................................................... 18
SECTION 11: Performance data sheets .............................................................23
Warranty...........................................................................................................25

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
3
SECTION 2: IMPORTANT SAFETY INSTRUCTIONS
Safety
This appliance is not intended for use by children under 8 years or persons
(including children under 8 years) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by
a person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
Ventilation
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
Qualifications
To avoid hazards, all installation procedures must be carried out by a
suitably qualified tradesperson. The power cable and power outlet must be
in a safe visible position for connection.
Venting
Sometimes steam and / or boiling water droplets may discharge through a
vent outlet on the tap. If not using the font, ensure the tap body is located
so the tap outlet safely dispenses into the sink bowl.
!
!
Compliance
All Plumbing and Electrical connections must comply with local, state
and federal codes.
All Plumbing and Electrical connections must be made in accordance with local
regulations.
Ensure the electrical power supply at the installation site is suitable for your
HydroTap.
HydroTap models are rated for the following installations:
• Commercial - 220-240VAC 50/60Hz.
• Residential (120V) - 110-120VAC 50/60Hz.
Refer to updated online guide for all variants.

4Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 2: IMPORTANT SAFETY INSTRUCTIONS
Lifting
Take care when lifting. The Command Center may exceed safe lifting limits.
If you feel this is beyond your personal capabilities, please seek assistance
with the lift. The weight of the Command Center is marked on the
packaging. Do not lift the Command Center by the front cover or any of its
connections.
Airflow
The ambient operating temperatures, when installed in a cabinet, must be
between 41 - 95ºF, (5 - 35ºC) . The system will operate satisfactorily only
with proper air ventilation. Air gaps of 2”, (50mm) on each side, and 8”,
(200mm) above must be provided. See section 6 for correct ventilation
details.
Altitude
Water boils at varying temperatures at different altitudes. The HydroTap
adjusts for this during startup calibration and will recalibrate itself on a
regular basis.
Frost protection
If the HydroTap is located where the ambient air temperature could
fall below 41ºF, (5ºC) when the system is not in use, do not turn off the
Command Center electrically. This safeguard does not offer the same
protection to the connecting pipework and fittings.
Application
The HydroTap G5 Home series is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other working environments;
• Farm houses and by clients in hotels, motels and other residential type
environments;
• Bed and breakfast type environments;
• Catering and similar non-retail applications.

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
5
SECTION 3: WARNINGS & REGULATORY INFORMATION
• All installation and service work must be completed by trained and
suitably qualified tradespeople. Faulty operation due to unqualified
persons working on this product may void warranty coverage.
• As the installer, it is your responsibility to supply and install all valves as
required by local regulations and relevant standards.
• Do not remove the cover of the appliance under any circumstances
without first isolating the appliance from the power supply.
• Connect only to a potable mains water supply.
• The new hose sets supplied with the product must be used. Do not
re-use old hose sets.
• Never locate the system near, or clean with water jets.
• Do not expose the Zip HydroTap to the elements of nature.
• Use of tools can be hazardous. Assess the risks before you start.
• A clearance envelope around all Command Centers must be provided
to allow adequate ventilation for the safe and effective use of the
HydroTap system.
• Valve and fitting threads must be sealed appropriately with PTFE tape
where compression seals are not provided.
• Always flush new filter before use.
• Do not over tighten plumbing and hose connections.
• Braided hoses supplied cannot be lengthened.
• The power cord and general power outlet must be in a safe and
accessible position after installation. When positioning the appliance,
ensure the power supply cord is not trapped or damaged. If the power
!
!
• For continued safety of this appliance it must be installed,
operated and maintained in accordance with the
manufacturer’s instructions.
• The Zip HydroTap must be grounded. Grounding is
provided via the supplied power cord. The resistance of the
earth connection to each exposed metal part must be less
than 1Ω. Use the power cable supplied. It is the responsibility
of the installer to ensure the power point is earthed.

6Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 3: WARNINGS & REGULATORY INFORMATION
supply cord is damaged it must be replaced by a Zip service provider or
a qualified electrician.
• Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
• For safe operation, the HydroTap is designed to be installed,
commissioned and used within 48 hours. Should the HydroTap not be
required for an extended period of time (72 hours or more), do not fill
and commission the HydroTap until ready for first use.
• For water taste and quality reasons, following any non-use period of
more than 72 hours, Zip recommends to perform a system flush. Failure
to flush the system may affect water quality.

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
7
SECTION 4: Technical data
Water supply requirements
• A cold water supply with a working pressure range of
37 - 100 psi , (250 - 700 kPa) connected via an isolation valve.
• Water inlet connection size is 1/2” BSP. The system shall only be supplied
with cold water.
• Potable water should have a minimum TDS (Total Dissolved Solids) of 50
ppm. In areas where the TDS exceeds 150 ppm and where mineral scale
could be a problem, consideration should be given to the maintenance
required. Adding a water softener or reverse osmosis system should be
considered.
Electricity supply requirements
110-120VAC 60Hz or 230VAC 60Hz (for power requirement see table above).
Region Power outlets required
USA 1x 110-120VAC 60Hz or 230VAC 60Hz outlet
Water supply connection
1/2” BSP
A pressure limiting valve must be fitted for mains water pressures
above the maximum limits stated above in accordance with local
plumbing regulations.
Note: All models have an internal pressure limiting device to reduce the
maximum mains regulated pressure protecting the system against pressure
surges above 73 psi, (500kPa).
!
Model 220-240V
50/60Hz
110-120V
50/60Hz
Dimensions
W x D x H inch, (mm)
Weight
lb (kg)
BC40 9.5A
(1970W) N/A
15.5 (395) x 18.3 (464) x 13.1 (333)
With Duct
17.7 (450) x 18.3 (464) x 13.1 (333)
With Duct and Vent Tray:
19.7 (500) x 20.5 (520) x 14.7 (373)
66 (30)
BC Home N/A 9.12A
(1100W) 13.3 (339) x 18.2 (462) x 13.1 (333) 66 (30)
Technical data

8Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 5: Parts supplied
Parts supplied with the HydroTap BC
for Work
BC
for Home
Tap
HydroTap  
HydroTap pipes, tubes hoses and fittings  
Separate vented Mixer kit  
Separate Mains mixer, fittings & instructions Optional Optional
Command Center
Command Center  
Mains electrical supply cable  
Water supply inlet hose  
Water supply inlet adaptor and strainer  
Ventilation kit (inc. vent tray BC40 models)  
Filters
Water filter & instructions  
Limescale filter kit Optional Optional
Drip tray
Drip tray kit Optional Optional
Note: Mains water isolation valve is not supplied with the kit.
Contact Zip for the full range of consumables and accessories.

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
9
SECTION 6: Set up the ventilation
Command Center width
!
A clearance envelope around all Command Centers must be
provided to allow ventilation for the safe and effective use of the
HydroTap system.
Use instructions supplied with individual kit parts.
!
!
Use of tools can be hazardous. Assess the risks before you start.
8”
(200mm)
2”, (50mm) 2”, (50mm)

10 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 6: Set up the ventilation
BC40 models
Vent tray
The vent tray must be fitted. It provides a safe exhaust for
refrigerant gas in the unlikely event of a leak.
!
!
Vent tray dimensions WxDxH inch(mm):
19.7 (500) x 20.3-21.8 (515-555) x 1.6 (40)
• Cold air is drawn in through the inlet vent and gap provided by the door
buffers.
• Inlet vent is mounted over cupboard side, door or floor cut-out (see
below).
• Warm air is exhausted through vent tray.
• Observe 4”, (100mm) inlet / outlet vent separation (see below).
Air outlet
4”
Door buffers
(supplied)
Air inlet options

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
11
SECTION 6: Set up the ventilation
BC Home models
If cupboard temperature exceeds 95°F, (35°C) additional ventilation is required.
Contact your Zip service provider for options (including additional vents and
fan kit).
All models
• Cold air is drawn in through the inlet vent and lower gap provided by the
door buffers.
• Inlet vent is mounted over cupboard side, door or floor cut-out.
• Warm air is exhausted through upper gap provided by the door buffers.
Door buffers
(supplied)
Inlet vent
Air inlet
Air outlet

12 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 7: Connect the water supply
!
Note correct strainer orientation.
Isolation valve
(not supplied) Strainer
(supplied)
Male - Female
adaptor
(supplied)
Connect together
Connect to
Command Center,
see pages 16,17
Connect to
Command Center,
see pages 16,17
Note Mixer installations also use a ‘Tee piece’ as part of the water supply
plumbing connections, see the faucet installation instructions supplied with
the Mixer faucet to connect the water supply if using the mixer option.
Valves and fittings must be sealed with PTFE
tape if compression seals are not included.

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
13
SECTION 8: Set the bypass & install the limescale filter
Water
in
Bypass out
see pages 16,17
Water
out
Bypass in
see pages 16,17
Insert
Remove
Insert
Remove
For filter head and scale filter installation use the guide supplied
with the filter head and filter respectively.
Bypass valve
(Rear of the Command
Center)
Available as optional accessory.

14 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
For HydroTap, mixer faucet and any optional accessories, use
instructions supplied with individual kit components.
Connections key
HydroTap
Braided hose
Command
Center
USB
Tap
Generic installation instructions
Mains power cable
Do not connect to the mains
socket until commissioning
SECTION 9: Connect the Command Center
Warning: HydroTap models are available for either 110-120VAC
50/60Hz or 220-240VAC 50/60Hz installations. Ensure the
electrical power supply at the installation site is suitable for
your HydroTap. Use only the power lead supplied with the
product. Connect the power lead to the HydroTap and connect
the plug into the electrical power outlet, ensuring both ends are securely
engaged to reduce the risk of overheating.
!
Power lead for 110-120V, 60Hz
ONLY (NEMA 5-15 / IEC C19)
Power lead for 230V, 60Hz
ONLY (NEMA 6-15 / IEC C13)

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
15
Installation diagrams are for illustrative purposes only.
Hoses are not shown to scale and cannot be lengthened.
!
Tips for hose connection
• Push the silicone hose over the
connector for a minimum of 0.6”,
(15mm).
• Ensure there is a constant fall from
the tap down to the command
Center.
• Hoses must be trimmed to avoid
loops and kinks. Take care when
positioning before cutting and make
a clean cut straight across the hose,
using a sharp blade.
• The hoses must not be under tension
when installed.
SECTION 9: Connect the Command Center
2. Pull pipe
out
1. Press collet
down
Insert Remove
2. Push pipe to
end stop
1. Cut pipe
clean & square
John Guest pipe and fittings
Take care to use correctly, see below :

16 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 9: Connect the Command Center
USB CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
SPARKLING
OUTLET
CO2
IN
USB
BCS comm
BCS res
BC comm
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
USB
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
USB
BC res
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
AMBIENT
OUTLET
USB
BA res comm
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
B res comm
USB
MAINS
IN
C 175 comm
USB
CHILLED
OUTLET
CS 175 comm
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
C res
CHILLED
OUTLET
MAINS
IN
USB
CS75 res
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
USB
check USB
position
check which way round
still / sparkling
USB CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
SPARKLING
OUTLET
CO2
IN
USB
BCS comm
BCS res
BC comm
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
USB
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
USB
BC res
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
AMBIENT
OUTLET
USB
BA res comm
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
B res comm
USB
MAINS
IN
C 175 comm
USB
CHILLED
OUTLET
CS 175 comm
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
C res
CHILLED
OUTLET
MAINS
IN
USB
CS75 res
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
USB
check USB
position
check which way round
still / sparkling
Mains
Water
Lime- scale Filter
!
BC40 models
Fit foam insulation
(supplied) to the
BLUE pipe
BC Comm
Example installation
BLUE RED CLEAR
Limescale filter
(optional)
Diagram for illustrative purposes only.
Optional
limescale filter
!
Do not
connect
without
HydroTap
Venturi kit

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
17
SECTION 9: Connect the Command Center
USB CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
SPARKLING
OUTLET
CO2
IN
USB
BCS comm
BCS res
BC comm
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
USB
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
USB
BC res
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
AMBIENT
OUTLET
USB
BA res comm
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
B res comm
USB
MAINS
IN
C 175 comm
USB
CHILLED
OUTLET
CS 175 comm
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
C res
CHILLED
OUTLET
MAINS
IN
USB
CS75 res
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
USB
check USB
position
check which way round
still / sparkling
USB CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
SPARKLING
OUTLET
CO2
IN
USB
BCS comm
BCS res
BC comm
CHILLED
OUTLET
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
USB
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
CHILLED
OUTLET
USB
BC res
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
AMBIENT
OUTLET
USB
BA res comm
MAINS
IN
MIXER
OUT
MIXER
IN
BOILING
OUT
BYPASS
IN
VENT BYPASS
OUT
B res comm
USB
MAINS
IN
C 175 comm
USB
CHILLED
OUTLET
CS 175 comm
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
C res
CHILLED
OUTLET
MAINS
IN
USB
CS75 res
CO2
IN
CHILLED
OUTLET
SPARKLING
OUTLET
MAINS
IN
USB
check USB
position
check which way round
still / sparkling
Mains
Water
!
BC Home models
Fit foam insulation
(supplied) to the
BLUE pipe
BC Compact
Example installation
BLUERED
Diagram for illustrative purposes only.
Lime- scale Filter
CLEAR
Limescale filter
(optional)
Optional
limescale filter
!
Do not
connect
without
HydroTap
Venturi kit

18 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 10: Commissioning
Install the filter cartridge
For a more detailed description of the commissioning process,
refer to the Command Center installation and user instructions
!
• Unpack filter cartridge, remove sanitary cap.
• Write today’s date where shown on the label.
• Avoid touching the filter o-rings and
filter opening as this may cause bacterial
contamination of the cartridge.
• Moisten the o-rings with water.
• Open the filter door on the Command Center.
• Align the front cartridge label to the left, and
push the new cartridge up into the filter head.
• Turn the cartridge a quarter turn anticlockwise
until it comes to a complete stop and locks,
with the front label facing forward.
Turn on the supplies & familarize yourself with the system
• Connect the mains electrical power cable to the supply.
• Turn the power and water on and check for any leaks.
• Familiarize yourself with the operation of the tap and GUI screen in
preparation for use, see the user guide.
Select the language, date / time & drain away options
12:12 PMCOMMISSIONING
Rev 024-H5v0.1.16
Mod BCS100
S/N 0000000000000
P/N H50063000US
HydroTap G5
Language
LANGUAGE 10:50
Imperial
Metric
Units :
English
• Initial commissioning screen touch
Language option.
• Touch the appropriate button to select
the language and units of choice.
• Touch the back arrow to go back to
previous menu.
• In the previous menu, touch the arrow to
begin the commissioning process.

Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
19
SECTION 10: Commissioning
12:12 PMCOMMISSIONING
Your HydroTap is designed to be used frequently,
do not commission until ready for use.
Please follow commissioning guidelines
in the manual.
• Touch the arrow to continue when ready
to start using the HydroTap.
DATE & TIME 10:50
2021
Dec
06
10 50
:24 hr
Time
• Touch the date and time, use "-" or "+" to
make adjustments. When ready, touch
the arrow to continue.
9:26DRAIN AWAY OPTION
Does your tap drain into a:
Or
Sink/Container Drip tray
If you are not clear on your selection options
refer to the commissioning instructions.
• Select 'Sink / Container' or 'Drip tray'
depending on the model , see below.
• Select 'Drip tray' if the HydroTap is
mounted on a drip tray.
• Select 'Sink / Container' if the HydroTap
is mounted such that the waste water
dispenses into a sink, or container.
• Note This selection will determine if water is dispensed automatically or
requires operation of the tap during the tank flush process.
• Touch the arrow to continue.
Drip tray Sink
Container

20 Quick Start Installation Guide
807118US v1.02 11.22 G5 BC Quick Start Guide
SECTION 10: Commissioning
| |
FILTER FLUSH
RUNNING.....
Water is now being flushed through the filter.
This process is automatic and will take 2 minutes.
Press pause to pause filter flush.
12:12 PM
12:12 PMFILTER FLUSH
FILTER HAS BEEN FLUSHED!
Turn the flush line SHUT-OFF VALVE
back to the OFF position
Your filter has now been flushed and is ready to use.
You will need to check the life span of the filter
in filter settings
12:12 PMFILTER FLUSH
STEP 1.
Open the filter access door and turn the flush line
SHUT-OFF VALVE to the ON position.
STEP 2.
Place a 3 gal. bucket under the flush line valve to catch
the water flushed through the filter.
Filter flush
• Follow the steps on-screen to flush the
filter.
• Open filter door & uncoil flush line.
• Direct flush line into bucket.
• Place a cloth or towel under the filter
cartridge to catch any water that may
spill.
• Open the shut-off valve.
• Start filter flush.
• Once the filter flush is finished, close the
shut-off valve.
• Wipe up any spills.
• Close the door to secure the appliance.
Shut-off valve open
Shut-off valve closed
