WATSON D9 User manual

ASSEMBLY
D9 Desk Accessories
V.2.01 08/2020 watsonfurniture.com360.394.1300

2 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
D9 Desk Accessories Basic Components
Hardware
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Tools
3mm Hex Key
Desk Screen Modesty Screen
M6-1.0x8mm Low
Profile Cap Screw
(0001259)
Desk Screen
Brackets
Modesty Screen
Brackets
E-chain E-chain
Brackets
Convenience
Power
Truss Head Panhead
Screw #10x5/8”
(122800)
Philips Head Screwdriver Bit Philips Head Screwdriver Bit
Glide, 34mm DIA,
M10x1.5 (0001154)
Nylon Shoulder
Washer .75 x
.075 x .408 x
.155 (0001408)
Glide, 5/16-18 x 1”
(0000229)
Corner Desk
Screen
Corner Desk
Screen with
Markerboard
Corner Screen
Back Brackets
Corner Screen
Side Bracket
Corner Screen
Medallion
Bracket
Pencil Cup Hook

3 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Attach Convenience Power to Desk
Place power unit clamp on the back surface of
the desk (a.). Once positioned, tighten clamping
screws until secure (b.).
a. b.
1.
Convenience Power

4 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Mount Brackets to Screen
Attach brackets to screen using (4) screws
(0001140), (2) screws per bracket, as shown below.
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Privacy Screen
1.
Insert Screen Clamping Glide
Slide the clamping glide into the bracket and screw
down through the hole in the bracket. Leave enough
space for the worksurface between the glide and the
top of the bracket.
2.

5 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Mount Screen on Desk
Slide brackets onto desk surface, and
position screen in place (a.). Secure
the screen to the desk by tightening the
clamping glide against the underside of the
worksurface with a flathead screwdriver (b.).
a.
b.
Privacy Screen (continued)
3.

6 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Truss Head Panhead
Screw #10x5/8”
(0001259)
Mount Modesty Brackets to Desk
Attach brackets to worksurface using (4) screws
(122800), (2) screws per bracket, as shown below.
Glide, 34mm DIA,
M10x1.5 (0001154)
Nylon Shoulder
Washer
.75x.075x.408x.155
(0001408)
Modesty Screen
1.
Attach Modesty Hardware to Screen
Attach the threaded knob to the modesty screen,
sandwiching the nylon shoulder washer with the
smaller side touching the screen. Complete on both
sides of screen.
2.

7 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Mount Screen to Desk
Slide the modesty hardware onto the brackets until
the screen is fully seated.
Modesty Screen (continued)
3.

8 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
E-Chain
1.
2.
Inner Rail E-Chain Bracket
Rotate the inner rail E-Chain bracket into the slot that
runs length-wise underneath the top plate of the rail.
Hold this bracket against the underside of the top
plate of the rail.
Outer Rail E-Chain Bracket
Slide the outer rail E-Chain bracket into the slot of the
inner rail E-Chain bracket.

9 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Truss Head Panhead
Screw #10x5/8”
(122800)
E-Chain (continued)
3.
4.
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Attach E-Chain Bracket to Rail
Place the free end of the E-Chain between the
inner and outer rail chain brackets and align the
holes. Attach the three parts with two screws
(0001140) into the tapped holes of the inner-most
bracket. The outer bracket should be pressed
against the rail.
Attach E-Chain to Worksurface
Attach the opposing end of the E-chain to the
underside of the worksurface with two screws
(122800).

10 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Glide, 5/16-18 x 1”
(0000229)
Glide, 5/16-18 x 1”
(0000229)
Corner Desk Screen
1.
2.
Secure Back Brackets
Position the rear mounting brackets on the back edge
of your desk and clamp them in place using a flathead
screwdriver.
Attach Side Bracket(s)
Position the side bracket on the desired side of
the desk and secure to the surface with a flathead
screwdriver.

11 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
M6-1.0x8mm Low Profile
Cap Screw (0001259)
Corner Desk Screen (continued)
3.
4.
Place Screen(s)
Drop the fabric portion of the screen into the rear
brackets.
Secure Side Medallion(s)
Insert the medallion bracket through the bottom
slot in the metal portion of the screen and align
it with the side bracket. Secure the medallion to
the side bracket with 2x M6 x 8mm (0001259)
screws.

12 D9 DESK ACCESSORY ASSEMBLY INSTRUCTIONS
Corner Desk Screen (continued)
5. Attach Accessory
Insert the hook or marker cup into the slot in the
metal portion of the screen.
