WATSON C9 Height Adjustable Desk User manual

V.1.00 06/2020 360.394.1300 watsonfurniture.com
ASSEMBLY
C9 Acrylic Desk Screen

2 C9 ACRYLIC DESK SCREEN ASSEMBLY INSTRUCTIONS
Back ScreenSide Screen
Side Screen Medallion Back Screen
Medallions
Brackets Brackets
C9 Acrylic Desk Screen Basic Components

Hardware
Tools
3mm Hex Wrench 7/16’ Wrench
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
C9T-RAL-KIT Rail
Attachment (0001120)
1/4-20 Flange Nut,
Zinc (090770)
090770
1/4"-20 FLANGE NUT
0001140
M6 x 1 x 12mm Low Profile Screw
0001120
C9T-RAL-KIT
RAIL ATTACHMENT
0001612
FLAT TIP SET SCREW M4-0.7 x 5mm
0000631
USE EXISTING IMAGERY IN INS

4 C9 ACRYLIC DESK SCREEN ASSEMBLY INSTRUCTIONS
Position Rail Nuts
Note the location of the screen brackets in relation to the desk.
Rotate the rail nuts (0001120) into place inside the frame rail
channel. Firmly push them together until the angled surfaces
are touching. Place two sets of rail nuts per screen.
Attach Screen Bracket
Align the desk screen brackets with the holes in the rail nuts
and attach with (2) screws (0001140) for each bracket. The
brackets should face outward as shown. It is helpful to leave
the brackets a bit loose for side to side adjustments when
mounting screen.
Rail Nut (0001120)
M6-1.0 x 12mm Low Profile
Cap Screw (0001140)
1.
2.
a.
b.

5 C9 ACRYLIC DESK SCREEN ASSEMBLY INSTRUCTIONS
Attach Screen Medallions
Carefully place the medallions thru the screen. Spin the flange
nuts (090770) onto both upper threaded studs of the screen
medallions. Do not thread on all the way, leave enough space
to set the screen into the brackets mounted on desk rail.
Place Screen into Brackets
Align the top studs, with the flange nuts, into the upper slots on
the screen brackets. Gently lower the screen into place on the
brackets. While one person holds the screen in place the other
person can move to step 5.
Note: Use two people on larger screens.
1/4-20 Flange Nut,
Zinc (090770)
3.
4.
a.
b.

6 C9 ACRYLIC DESK SCREEN ASSEMBLY INSTRUCTIONS
Secure Screen
Once the screen is in place, thread the remaining flange nuts
onto the lower threaded studs of the screen medallion. Snug
all flange nuts using a 7/16” wrench. Tighten up 6 x 12mm low
profile screws (0001140) securing the screen brackets to the
rail using 3mm hex wrench.
Repeat steps for side screens.
1/4-20 Flange Nut,
Zinc (090770)
M6-1.0x12mm Low Profile
Cap Screw (0001140)
5.
