Weider Core Spacesaver 100 User manual

BEFORE YOU BEGIN
Thank you for purchasing the sturdy and stylish Adjustable-weight
Dumbbells and Stand. The Adjustable-weight Dumbbells and
Stand will speed up your workouts, provide convenient access to
your dumbbells, and keep your workout area organized. Each han-
dle weighs 10 pounds and each weight plate weighs 2.5 pounds.
Each Adjustable-weight Dumbbell handle can hold from two to six-
teen weight plates in pairs.
For your safety and benefit, please read this guide before
using the Adjustable-Weight Dumbbells and Stand. If you have
questions after reading this guide, or if you need to order replace-
ment parts, please call Customer Care toll-free at 1-800-288-4802,
Mon.–Fri., 6 a.m.–6 p.m. Mountain Time (closed on holidays).
ADJUSTABLE-WEIGHT DUMBBELLS AND STAND OWNER’S GUIDE
WARNING: To reduce the risk of
serious injury, read the following important pre-
cautions before using the dumbbells and stand.
1. It is the responsibility of the owner to ensure
that all users of the dumbbells and the stand
are adequately informed of all precautions.
2. Do not place your fingers between the dumb-
bells and the stand.
3. Inspect the dumbbells and the stand regular-
ly.Make sure that all parts are properly tight-
ened.
4. Keep children under age 12 and pets away
from the dumbbells and the stand.
5. If you feel pain or dizziness while exercising,
stop immediately and begin cooling down.
6. Place only the included dumbbells on the
stand. Use the dumbbells and the stand only
as described in this guide.
LIMITED WARRANTY
ICON Health & Fitness, Inc. (ICON) warrants this product to be
free from defects in workmanship and material, under normal
use and service conditions, for a period of ninety (90) days
from the date of purchase. This warranty extends only to the
original purchaser.ICON's obligation under this warranty is lim-
ited to replacing or repairing, at ICON's option, the product
through one of its authorized service centers. All repairs for
which warranty claims are made must be pre-authorized by
ICON. If the product is shipped to a service center, freight
charges to and from the service center will be the customer’s
responsibility. This warranty does not extend to any damage to
aproduct caused by or attributable to freight damage, abuse,
misuse, improper or abnormal usage, or repairs not provided
by an ICON authorized service center; products used for com-
mercial or rental purposes; or products used as store display
models. No other warranty beyond that specifically set forth
above is authorized by ICON.
ICON is not responsible or liable for indirect, special or conse-
quential damages arising out of or in connection with the use or
performance of the product; damages with respect to any eco-
nomic loss, loss of property, loss of revenues or profits, loss of
enjoyment or use, or costs of removal or installation; or other
consequential damages of whatsoever nature. Some states do
not allow the exclusion or limitation of incidental or consequen-
tial damages. Accordingly, the above limitation may not apply to
you. The warranty extended hereunder is in lieu of any and all
other warranties, and any implied warranties of merchantability
or fitness for a particular purpose are limited in their scope and
duration to the terms set forth herein. Some states do not allow
limitations on how long an implied warranty lasts. Accordingly,
the above limitation may not apply to you.
This warranty gives you specific legal rights. You may also
have other rights which vary from state to state.
ICON Health & Fitness, Inc.
1500 S. 1000 W., Logan, UT 84321-9813
WARNING: Before beginning this or
any exercise program, consult your physician.
This is especially important for persons over
the age of 35 or persons with pre-existing
health problems. Read all instructions before
using. ICON assumes no responsibility for per-
sonal injury or property damage sustained by
or through the use of this product.

ASSEMBLY
Note: Some parts may be pre-assembled.
1. Attach the four Feet (E) to the Bottom Plate (A) with
four M8 x 15mm Screws (F).
2. Attach the Upright (B) to the Bottom Plate (A) with
three M8 x 15mm Screws (F).
3. Attach the two Trays (D) to the Top Plate (C) with four
M8 x 40mm Bolts (G) and four M8 Nylon Locknuts (H).
4. Attach the Top Plate (C) to the Upright (B) with three
M8 x 15mm Screws (F).
HOW TO USE THE ADJUSTABLE-
WEIGHT DUMBBELLS
Each handle can
hold from two to
sixteen weight
plates, in pairs.
Always attach
the same num-
ber of weight
plates to both
ends of a
handle.
To select the
desired number
of weight plates,
first set a dumb-
bell on a tray as
shown. Next, lift
one of the selec-
tor pins, slide it
to one of the
adjustment holes
between the
weight plates,
and then release
it. Rock the
selector pin from side to side to make sure that it
is fully inserted into an adjustment hole. Adjust the
other selector pin on the dumbbell in the same way.
To use the dumbbell, lift it straight upward off the tray,
making sure that the unattached weight plates remain
in the tray. When you are finished using the dumbbell,
carefully set it back on the tray.
IMPORTANT: To prevent damage to the dumb-
bells, be careful not to drop them while lifting
them, using them, or setting them down.
Part No. 245228 R1106A Printed in China ©2006 ICON IP
,Inc.
D
E
E
B
A
H
H
C
D
GG
F
F
F
F
Handle
Weight
Plates
Selector
Pins
Tray
