Whalen BJAVCL65 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2019-11-07 Rev. 0001-B
Classic Farmhouse TV Stand
Model # BJAVCL65
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
Or visit our website 24 hours a day, 7 days a week for product assistance at
www.whalenfurniture.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASE
D
:
/
/

2
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manuals.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE
WIPED OFF WITH A DAMP CLOTH.
Insert Dowel at least half way by tapping lightly with a rubber mallet (not included), IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the pre-drilled small holes on the panel. Connect both panels together; making sure
the Cam Bolt goes into the pre-drilled hole at the end of the panel with the Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole in the panel. Make sure the arrow on the Cam Lock is
pointed towards the Cam Bolt.
3. Once the Cam Bolt is connected inside the Cam Lock, take a Phillips screwdriver (not included) and
tighten the Cam Lock clockwise.
4. Plug the Cam Lock Cover into the cross slot of the Cam Locks to conceal the cam.
You are now ready to assemble the KD unit.
XX
1 2 43

3
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B-Left Side Frame (Qty. 1)
C- Right Side Frame (Qty. 1) D- Left Partition Panel (Qty. 1)
E- Right Partition Panel (Qty. 1) F- Bottom Panel (Qty. 1)
G- Top Front Stretcher (Qty. 1) H- Middle Stile (Qty. 2)
I- Door (Qty. 2) J- Small Shelf (Qty. 2)
K- Large Shelf (Qty. 1) L- Back Panel (Qty. 1) M- Center Support (Qty. 2)

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 21+1 extra) (Qty. 21+1 extra) (Qty. 26+1 extra)
(4) M3.5 x 15 mm Washer Head Screw (5) M4 x 50 mm Screw (6) 5/32" x 22 mm Handle Bolt
(Qty. 28+1 extra) (Qty. 4+1 extra) (Qty. 4+1 extra)
(7) Cam Lock Cover (8) Acrylic Stopper (9) Handle
(Qty. 12+1 extra) (Qty. 1) (Qty. 2)
(10) Shelf Support (11) Door Stopper (12) M3.5 x 15 mm Screw
(Qty. 12+1 extra) (Qty. 2) (Qty. 2)
Glue Touch-up Pen Tipping Restraint Hardware Kit (Qty. 2)
(Qty. 1) (Qty. 1) (Included in plastic bag)
Tools required (not included): Phillips screwdriver, stud finder, power drill, pencil, tape measure, and
3 mm/0.1 drill bit.

5
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), both Side
Frames (B and C) and Middle Stile (H) with a Phillips screwdriver.
NOTE: Screw-in cam bolts must be screwed down flush.
3. Insert two Wood Dowels (3) into the inner holes on the long edge of each Partition Panel (D and E).
Make sure that you use a small amount of glue with both ends of all dowels.
NOTE: It is very important to use a small amount of glue on both ends of dowels.
A
H
H
B
C
D
E
3
3
3
3

6
Assembly Instructions
4. Attach the Middle Stile (H) to the Left Partition Panel (D) by engaging two Cam Locks (1). Make sure
that the middle stile is flush with the side with cam lock housing. (Refer to page 3 on Cam Lock system
operation supplement).
5. Attach the other Middle Stile (H) to the Right Partition Panel (E) by engaging two Cam Locks (1).
Make sure that the middle stile is flush with the side with cam lock housing.
D
H
1
E
H
1

7
Assembly Instructions
6. Glue two Wood Dowels (3) into the inner holes on the bottom edge of each Partition Panel (D and E).
7. Glue two Wood Dowels (3) into the drilled holes on both ends of Middle Stile (H).
8. Glue four Wood Dowels (3) into the inner holes of the Bottom Panel (F) at both short edges.
3
3
3
3
F
3
3
3
3
3
3
D
E
3
3

8
5
55
5
D
E
F
Assembly Instructions
9. Using the wood dowels as a guide, firmly press the assembled Partition Panels (D and E) to the Bottom
Panel (F) and fasten them in place with four 50 mm Screws (5). Fully tighten the screws with a Phillips
screwdriver.
10. Use the pilot hole as a guide, fasten two Door Stoppers (11) onto the Top Front Stretcher (G) with two
12mm Screws (12). Make sure that the brackets are overhang the front stretcher.
12
12
11
11
G
G

9
Assembly Instructions
11. Attach the Top Front Stretcher (G) onto the Middle Stiles (H) with the installed wood dowels fully
inserted.
12. Align the large holes on the Side Frames (B and C) with the installed Wood Dowels (3) on the Bottom
Panel (F) and press them together. Attach the Side Frames (B and C) into place by engaging four Cam
Locks (1).
B
C
F
1
1
1
1
G
H
H
G
D
E
F

10
Assembly Instructions
13. Ask for assistance to lift the assembly upright and proceed to fasten the Top Front Stretcher (G) to both
Side Frames (B and C) by engaging two Cam Locks (1).
14. Glue the Wood Dowers (3) into the top inner holes of the unit. DO NOT inert the wood dowels into the
cam lock holes.
C
B
E
D
1
1
G
C
B
E
D
G
3
333
3
3
3
3
33
3
3
