WIKA F1106 User manual

Operating instructions
Betriebsanleitung
EN
DE
Hydraulic compression force transducers
Hydraulische Druckkraftaufnehmer
Examples/Beispiele

2
ADPR1X914105.01 04/2019 EN/DE
Operating instructions, Hydraulic compression force transducers
EN
DE
Operating instructions
Hydraulic compression force transducers Page 3 - 38
Betriebsanleitung
Hydraulische Druckkraftaufnehmer Seite 39 - 75
© 04/2019 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®and tecsis®are registered trademarks in various countries.
WIKA®and tecsis®sind geschützte Marken in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!

3
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
Contents
Contents
1. General information 4
2. Design and function 5
2.1 Overview. . . . . . . . . . . . . . . . . . . . . . . .5
2.2 Description . . . . . . . . . . . . . . . . . . . . . . .6
2.3 Scope of delivery . . . . . . . . . . . . . . . . . . . . .6
3. Safety 6
3.1 Explanation of symbols . . . . . . . . . . . . . . . . . . .6
3.2 Intended use . . . . . . . . . . . . . . . . . . . . . .7
3.3 Improper use . . . . . . . . . . . . . . . . . . . . . .8
3.4 Responsibility of the operator . . . . . . . . . . . . . . . . .8
3.5 Personnel qualification . . . . . . . . . . . . . . . . . . .9
3.6 Personal protective equipment . . . . . . . . . . . . . . . .9
3.7 Labelling, safety marks . . . . . . . . . . . . . . . . . . 10
4. Transport, packaging and storage 11
4.1 Transport. . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Packaging and storage . . . . . . . . . . . . . . . . . . 11
5. Commissioning, operation 12
5.1 Precautions before commissioning . . . . . . . . . . . . . . 12
5.2 To be observed during installation . . . . . . . . . . . . . . 12
5.3 Mounting of the hydraulic force measuring unit with pressure gauge. . . 13
5.4 Commissioning of the hydraulic force measuring unit with digital pressure
gauge . . . . . . . . . . . . . . . . . . . . . . . . 14
5.5 Mounting of the hydraulic force measuring unit with digital pressure gauge 16
5.6 Electrical connection - hydraulic force measuring unit with built-in pressure
sensor. . . . . . . . . . . . . . . . . . . . . . . . 17
5.7 Mounting of the hydraulic force measuring unit with pressure sensor . . 18
6. Faults 19
6.1 Faults of the hydraulic force measuring unit with pressure gauge / digital
pressure gauge . . . . . . . . . . . . . . . . . . . . 19
6.2 Faults of the hydraulic force measuring unit with pressure sensor. . . . 20
7. Maintenance and cleaning 21
7.1 Maintenance . . . . . . . . . . . . . . . . . . . . . 21
7.2 Recalibration . . . . . . . . . . . . . . . . . . . . . 21
8. Dismounting, return and disposal 22
8.1 Dismounting . . . . . . . . . . . . . . . . . . . . . 22
8.2 Return. . . . . . . . . . . . . . . . . . . . . . . . 22
8.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . 22
9. Specifications 23
10. Accessories 35
10.1 Cable . . . . . . . . . . . . . . . . . . . . . . . 35
10.2 Spacer discs/mounting flanges. . . . . . . . . . . . . . . 36
11. Appendix: EU declaration of conformity 37

4
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
1. General information
1. General information
■
The hydraulic force measuring unit described in the operating instructions has been
designed and manufactured using state-of-the-art technology. All components
are subject to stringent quality and environmental criteria during production. Our
management systems are certified to ISO 9001.
■
These operating instructions contain important information on handling the instru-
ment. Working safely requires that all safety instructions and work instructions are
observed.
■
Observe the relevant local accident prevention regulations and general safety regula-
tions for the instrument's range of use.
■
The operating instructions are part of the product and must be kept in the immediate
vicinity of the instrument and readily accessible to skilled personnel at any time. Pass
the operating instructions onto the next operator or owner of the instrument.
■
Skilled personnel must have carefully read and understood the operating instructions
prior to beginning any work.
■
The general terms and conditions contained in the sales documentation shall apply.
■
Subject to technical modifications.
■
Factory calibrations / DKD / DAkkS calibrations are carried out in accordance with
international standards.
Further information:
- Internet address: www.wika.de / www.tecsis.de
- Relevant data sheet: FO 52.10 - DE 816 (F1119, F1136)
FO 52.11 - DE 810 (F1108, F1125, F1142, F1157)
FO 52.12 - DE 812 (F1115)
FO 52.13 - DE 813 (F1106)
FO 52.14 - DE 814 (F1101, F1102)
FO 52.15 - DE 815 (F1135, F1145)
- Application consultant: Phone: [phone]
Fax: [phone]
[e-mail], inf[email protected]
Abbreviations, definitions
2-wire The two connection lines are used for the voltage supply.
The measuring signal also provides the supply current.
3-wire Two connection lines are used for the voltage supply.
One connection line is used for the measuring signal.
UB+ Positive power supply terminal
UB- Negative power supply terminal
S+ Positive output terminal
S- Negative output terminal

5
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
 










 



2. Design and function
2. Design and function
2.1 Overview

Pressure gauge / digital pressure gauge (display instrument) or pressure sensor
(output instrument)
Adapter
Case
Measuring piston (force introduction)
The case and the measuring piston together form the hydraulic compression force
transducer - and including the pressure gauge / digital pressure gauge (display
instrument) or the pressure sensor (output instrument) this is referred to as the
hydraulic force measuring unit.
Electrical connection
Protective bellows
Capillary

6
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
2. Design and function / 3. Safety
2.2 Description
Hydraulic compression force transducers are designed for measuring static and
dynamic compression forces. The hydraulic force measuring unit consists of a hydraulic
compression force transducer and a pressure gauge or digital pressure gauge (display
instrument) or a pressure sensor (output instrument).
The measuring body is manufactured from non-rusting stainless steel. The force acting
on the measuring piston is transmitted as pressure, proportional to the cylinder area, via
the pressure-transmitting fluid to the measuring instrument.
2.3 Scope of delivery
■
Hydraulic force measuring unit
■
Operating instructions
3. Safety
3.1 Explanation of symbols
WARNING!
... indicates a potentially dangerous situation that can result in serious
injury or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in light injuries
or damage to property or the environment, if not avoided.
Information
... points out useful tips, recommendations and information for efficient
and trouble-free operation.

7
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
3. Safety
3.2 Intended use
The hydraulic compression force transducers are designed for measuring static and
dynamic compression forces.
Defective instruments must be returned to the manufacturer.
Model Design
F1106 / F1115 / F1135 / F1145 Hydraulic compression force transducer
Standard design
F1101 Hydraulic compression force transducer
Closing force design
F1102 Hydraulic compression force transducer
Welding tongs design
F1119 / F1136 Hydraulic compression force transducer
Clamping force design
F1108 / F1125 / F1142 / F1157 Hydraulic compression force transducer
Heavy-duty design
Valid for the hydraulic compression force transducer with built-in pressure
sensor, digital pressure gauge or pressure gauge with switch contacts:
These instruments have been designed and tested in accordance with the relevant
safety regulations for electronic measuring instruments. Any usage outside of this is
deemed to be improper. The perfect functioning and operational safety of the transdu-
cers can only be guaranteed when complying with the instructions given in the operating
instructions. During its use, the legal and safety regulations (e.g. VDE 0100) required for
the particular application must additionally be observed. This also applies accordingly
when using accessories. Faultless and safe operation of this measuring unit requires
proper transport, professional storage, installation and mounting and careful operation
and corrective maintenance.
The instrument has been designed and built solely for the intended use described here,
and may only be used accordingly.
The technical specifications contained in these operating instructions must be obser-
ved. Improper handling or operation of the instrument outside of its technical specifica-
tions requires the instrument to be taken out of service immediately and inspected by an
authorised service engineer.

8
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
3. Safety
Handle electronic precision measuring instruments with the required care (protect from
humidity, impacts, strong magnetic fields, static electricity and extreme temperatures,
do not insert any objects into the instrument or its openings). Plugs and sockets must be
protected from contamination.
The manufacturer shall not be liable for claims of any type based on operation contrary
to the intended use.
3.3 Improper use
WARNING!
Injuries through improper use
Improper use of the instrument can lead to hazardous situations and
injuries.
▶
Refrain from unauthorised modifications to the instrument.
Any use beyond or different to the intended use is considered as improper use.
3.4 Responsibility of the operator
The instrument is used in the industrial sector. The operator is therefore responsible for
legal obligations regarding safety at work.
The safety instructions within these operating instructions, as well as the safety,
accident prevention and environmental protection regulations for the application area
must be maintained.
The operator is obliged to maintain the product label in a legible condition.
To ensure safe working on the instrument, the operating company must ensure
■
that suitable first-aid equipment is available and aid is provided whenever required.
■
that the skilled electrical personnel are regularly instructed in all topics regarding
work safety, first aid and environmental protection and know the operating instruc-
tions and in particular, the safety instructions contained therein.
■
that the instrument is suitable for the particular application in accordance with its
intended use.
■
that personal protective equipment is available.

9
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
3. Safety
3.5 Personnel qualification
WARNING!
Risk of injury should qualification be insufficient
Improper handling can result in considerable injury and damage to equip-
ment.
▶
The activities described in these operating instructions may only be
carried out by skilled personnel who have the qualifications described
below.
Skilled electrical personnel
Skilled electrical personnel are understood to be personnel who, based on their techni-
cal training, know-how and experience as well as their knowledge of country-specific
regulations, current standards and directives, are capable of carrying out work on
electrical systems and independently recognising and avoiding potential hazards. The
skilled electrical personnel have been specifically trained for the work environment they
are working in and know the relevant standards and regulations. The skilled electrical
personnel must comply with current legal accident prevention regulations.
3.6 Personal protective equipment
The requirements for the required protective equipment result from the ambient condi-
tions at the place of use, other products or the connection to other products.
The requisite personal protective equipment must be provided by the operating compa-
ny. The operator is in no way relieved of his obligations under labour law for the safety
and the protection of workers' health.
The design of the personal protective equipment must take into account all operating
parameters of the place of use.

10
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE













3.7 Labelling, safety marks
Product label
Model
Nominal size
Measuring range
Serial number, TAG number
Date of manufacture calendar week/year
Output signal
Address
Product label with mechanical display unit (pressure gauge)
Product label with pressure sensor
3. Safety

11
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
4. Transport, packaging and storage
4. Transport, packaging and storage
4.1 Transport
Check the hydraulic force measuring unit for any damage that may have been caused
by transport. Obvious damage must be reported immediately.
CAUTION!
Damage through improper transport
With improper transport, a high level of damage to property can occur.
▶
When unloading packed goods upon delivery as well as during inter-
nal transport, proceed carefully and observe the symbols on the
packaging.
▶
With internal transport, observe the instructions in chapter 4.2
“Packaging and storage”.
As precision measuring instruments, force measuring units require careful handling
during transport and mounting. Load impacts during transport (e.g. hitting a hard
surface) can lead to permanent damage, resulting in measuring errors in the subse-
quent measuring operation.
4.2 Packaging and storage
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. change
in installation site, sending for repair).
The hydraulic compression force transducer is made fully from stainless steel.
■
The design with pressure gauge fulfils IP65 ingress protection.
■
The design with digital pressure gauge fulfils IP65 ingress protection.
■
The design with pressure sensor fulfils IP67 ingress protection. The design of the
accessory cable fulfils IP67 ingress protection.The ingress protection IP67 is only
guaranteed in the plugged-in state.
During storage the protection cap must always be on the electrical connection to avoid
entry of moisture and dirt.
Permissible conditions at the place of storage:
■
Storage temperature: -25 ... +70 °C
■
Humidity: 35 ... 85 % relative humidity (non-condensation)
Avoid exposure to the following factors:
■
Mechanical vibration, mechanical shock (putting it down hard)
■
Dust, dirt, and other objects may not be deposited in such a way that they form a
force shunt with the measuring piston, since this will falsify the measuring signal.

12
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
5. Commissioning, operation
5. Commissioning, operation
5.1 Precautions before commissioning
■
Hydraulic compression force transducers are sensitive measuring instruments and
must be handled with appropriate care.
■
With the commissioning of hydraulic compression force transducers, make sure they
are on a level mounting surface.
■
The sealed threaded connections of the hydraulic force transducer must not be
loosened! Non-compliant handling invalidates the warranty and a measuring function
is no longer assured.
5.2 To be observed during installation
CAUTION!
Damage to the instrument through improper installation
■
When installing the hydraulic force measuring unit, pay attention to the
installation position and thus to the direction of loading.
■
If the display instrument (pressure gauge, digital pressure gauge) or
output instrument (pressure sensor) rests on the contact surface during
installation, an adapter plate must be mounted under the hydraulic
compression force transducer (accessories, see chapter 10).
■
Torsional and transverse forces must be avoided. Transverse loads
and lateral forces also include the corresponding components of the
measurands that are introduced slanted.
■
Torsional moments, eccentric loads and transverse loads or lateral
forces cause measuring errors and may permanently damage the
hydraulic compression force transducer.
■
The hydraulic compression force transducer should only be loaded in
the intended position.
■
The hydraulic compression force transducer shall be mounted so that
at least one support surface is designed as a moveable bearing.
■
During installation of the hydraulic compression force transducer, the
output signal or the display instrument (force value) must always be
monitored to avoid mechanical overload.
■
When subjected to loads in other devices, a change in the zero signal
may result in permanent damage (leakage with jamming of the piston).
■
An overload must be excluded at all times.
■
Do not use the hydraulic compression force transducer as a climbing
aid.

13
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE













5.3 Mounting of the hydraulic force measuring unit with pressure gauge
■
Place the hydraulic force measuring
unit with its underside on the
contact surface of the measuring
object.
■
If the display instrument rests on the
contact surface during installation,
an adapter plate with suitable screws
must be mounted under the hydraulic
compression force transducer .
■
In order to prevent a change of position
on the contact surface , the hydraulic
compression force transducer can be
secured to the contact surface with
screws .
■
Load the hydraulic compression force
transducer .
■
The display value can be read.
Hydraulic force measuring unit
consisting of:

Hydraulic compression force transducer
and
Pressure gauge (display instrument)
Support surface for measuring object
Adapter plate (optional)
Screws (optional)
5. Commissioning, operation

14
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
Digital pressure gauge
5. Commissioning, operation
5.4 Commissioning of the hydraulic force measuring unit with digital pressure
gauge
Key Function / Action
■
Switches the instrument on
■
Switches the instrument off
■
Display indicates the Max value, while
the key is pressed
■
Display indicates the Min value, while
the key is pressed
■
Resets the max. value to “ 0 ”
■
Resets the min. value to “ 0 ”
+
+

15
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
Display
Bar graph display
Unit
Full scale
Max. value
Min. value
Main display
Special function
2nd display
Ta r e
Battery charge-level
indicator LO-BAT
Min / Max memory
The min./max. memory is reset to the current measured value with each measuring
cycle.
■
The display of the Min. value is achieved by pressing the Min. key.
■
The display of the Max. value is achieved by pressing the Max. key.
■
The resetting of the current measured value is achieved by holding down the respec-
tive key (Min or Max) and additionally briefly pressing the Menu key.
Bar graph with drag pointer function
The additional integrated bar graph with drag-pointer function within the display indica-
tes the trend of the current working pressure directly, independently from the digital
display. Using the drag-pointer function, the max. memory value is also displayed in the
bar graph display in the form of a bar segment, as well as in the digital display. On reset-
ting the min./max. value, this bar graph is then updated to the current measured value.
Voltage supply
The digital pressure gauge is operated with 2 AA Mignon batteries. The status of the
batteries is shown in the display . With a low battery charge level, a blinking battery
symbol is shown on the indicator display - the batteries should then be changed as soon
as possible.
■
Open the battery cover of the digital pressure gauge on the rear of the instrument.
■
Replace the batteries with 2 new mignon cells.
■
Close the battery cover again.
5. Commissioning, operation

16
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE













Hydraulic force measuring unit
consisting of:

Hydraulic compression force trans-
ducer and
Digital pressure gauge (display
instrument)
Support surface for measuring object
Adapter plate (optional)
Screws (optional)
■
Place the hydraulic force measu-
ring unit with its underside on the
contact surface of the measuring
object.
■
If the display instrument rests on the
contact surface during installation,
an adapter plate with suitable screws
must be mounted under the hydraulic
compression force transducer .
■
In order to prevent a change of position
on the contact surface , the hydraulic
compression force transducer can be
secured to the contact surface with
screws .
■
Load the hydraulic compression force
transducer .
■
The display value can be read.
5. Commissioning, operation
5.5 Mounting of the hydraulic force measuring unit with digital pressure gauge

17
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
Output 4 ... 20 mA, 2-wire
Circular connector M12 x 1, 4-pin
5. Commissioning, operation
Circular connector M12 x 1, 4-pin
4 ... 20 mA
2-wire
UB+ 1
0V/UB- 3
S+ 1
S- 3
Shield Case
5.6 Electrical connection - hydraulic force measuring unit with built-in pressure
sensor
To prevent interferences from coupling into the system, please observe the
following information:
■
Use only shielded and low-capacitance measuring cables (for cables, see chapter 10
“Accessories”).These cables fulfil the conditions.
■
Ground the shield of the measuring cable.
■
Connect the cable shield with the case of the hydraulic compression force transdu-
cer. In the cables of the accessories, the cable shield is connected by means of the
knurled nut, thus connecting it to the case of the pressure sensor (for cables, see
chapter 10 “Accessories”).
■
Do not install measuring cables in parallel to 3-phase-current cables and control
cables.
■
Avoid stray fields of transformers, motors and contactors.
■
Transducers, amplifiers and processing or display units must not be grounded sever-
al times. Connect all instruments to the same protective conductor.
The pin assignment of the connector or of the cable can be found on the product label.
When using extensions, only shielded and low-capacitance cables should be used. The
permitted maximum and minimum lengths of cable are defined in ISO 11898-2. Care
should be taken also to ensure a high-quality connection of the shielding.
5.6.1 Pin assignment of the analogue output - Hydraulic force measuring unit
with output instrument (pressure sensor)

18
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
5. Commissioning, operation
5.7 Mounting of the hydraulic force measuring unit with pressure sensor
■
Connect the cable to the electrical
connection of the pressure sensor
and screw down with the knurled nut.
■
Place the hydraulic force measuring
unit
with its underside on the contact
surface of the measuring object. If
the pressure sensor rests on the
contact surface during installation,
an adapter plate with suitable screws
must be mounted under the hydraulic
compression force transducer .
■
Optionally, the hydraulic compression
force transducer can also be faste-
ned to the contact surface of the test
object with suitable screws .
■
Load the hydraulic compression force
transducer .
Hydraulic force measuring unit
consisting of:
Hydraulic compression force
transducer and
Pressure sensor (output instrument)
Cable
Electrical connection
Support surface for measuring object
Adapter plate (optional)
Screws (optional)
















19
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
6. Faults
6. Faults
CAUTION!
Physical injuries, damage to equipment
If faults cannot be eliminated by means of the measures listed, the tensi-
on/compression force transducer must be taken out of operation immedi-
ately.
▶
Contact the manufacturer.
▶
If a return is needed, please follow the instructions given in chapter 9.2
“Returns”.
For contact details, please see chapter 1 “General information” or the back
page of the operating instructions.
Faults Causes Measures
No display Leaking of the hydraulic force
measuring unit or pressure
gauge
Visual check whether the
transmission medium has
leaked (glycerine/water
mixture)
Consult the manufacturer
Deviation of the zero point
display
Overload, load offset, defecti-
ve force introduction
Consult the manufacturer
Output signal constant
when changing force
Mechanical overload, defecti-
ve force introduction
Consult the manufacturer
Signal span varies EMC interference sources in
the environment; for example,
frequency converter
Shield instrument; cable
shield; remove source of
interference
Signal span drops/too small Mechanical overload, leaking
of the hydraulic force measu-
ring unit
Consult the manufacturer
Pointer jerks with force
increase
Stick-Slip effect (internal
pressure too low)
Consult the manufacturer
6.1 Faults of the hydraulic force measuring unit with pressure gauge / digital
pressure gauge

20
Operating instructions, Hydraulic compression force transducers
EN
ADPR1X914105.01 04/2019 EN/DE
Faults Causes Measures
No output signal No or wrong power supply,
current pulse
Rectify the power supply
Cable break Check the continuity
No or wrong output signal Wrong pin assignment Check pin assignment
Deviating zero point signal Overload, last offset, wrong
connection
Consult the manufacturer
Constant output signal
when changing force
Mechanical overload, wrong
pin assignment, defective
force introduction
Consult the manufacturer
Leaking of the hydraulic force
measuring unit
Visual check whether the
transmission medium has
leaked (glycerine/water
mixture)
Signal span varies EMC interference sources in
the environment; for example,
frequency converter
Shield instrument; cable
shield; remove source of
interference
Signal span drops/too small Mechanical overload, leaking
of the hydraulic force measu-
ring unit
Consult the manufacturer
6.2 Faults of the hydraulic force measuring unit with pressure sensor
6. Faults
