Wilfa XPLODE BLS-1200S User manual

WILFA XPLODE
BLENDER BLS-1200S, BLP-1200W, BLP-1200B
EN ·Instruction manual NL ·Instructies
NO ·Bruksanvisning PL ·Instrukcje
SE ·Bruksanvisning FR ·Instructions
DK ·Betjeningsvejledning IT ·Manuale di istruzioni
FI ·Käyttöohje ES ·Manual de instrucciones
DE ·Anleitung

NO
SE
DK
FI
EN
NL
PL
FR
IT
ES
DE
LES ALLE ANVISNINGER FØR BRUK
LÄS IGENOM ALLA INSTRUKTIONER INNAN PRODUKTEN ANVÄNDS
LÆS ALLE VEJLEDNINGER INDEN BRUG
LUE OHJEET HUOLELLISESTI ENNEN KÄYTTÖÄ
READ ALL INSTRUCTIONS BEFORE USE
LEES VÓÓR GEBRUIK ALLE INSTRUCTIES
PRZED UŻYCIEM ZAPOZNAĆ SIĘ ZE WSZYSTKIMI ZALECENIAMI
PRENEZ CONNAISSANCE DE TOUTES LES INSTRUCTIONS AVANT UTILISATION
LEGGERE TUTTE LE ISTRUZIONI PRIMA DELL’USO
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
LESEN SIE DIE ANLEITUNG VOR DEM GEBRAUCH GRÜNDLICH DURCH

2
INSTRUCTION MANUAL ·WILFA XPLODE
EN

3
EN
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
CONTENTS
4 IMPORTANT SAFETY INSTRUCTIONS
6 CAUTION
7 SPECIAL SAFETY INSTRUCTIONS FOR THIS UNIT
8 PRODUCT OVERVIEW
9 BEFORE USE
9 OPERATION
10 AFTER USING THE BLENDER
11 CLEANING & MAINTENANCE
12 GUARANTEE
13 PRODUCT SPECIFICATIONS
13 SUPPORT AND SPARE PARTS
13 RECYCLABILITY

4
INSTRUCTION MANUAL ·WILFA XPLODE
EN
IMPORTANT SAFETY INSTRUCTIONS
• Read this user manual carefully before you use the
appliance and save it for future reference.
• Never leave the appliance unattended when it is
connected to the mains.
• Never immerse the appliance in water.
• If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard.
• Is there damage to the device or that it does
not work, it must be serviced only by authorized
personnel.
• Connect the appliance only to a properly installed
wall socket with a voltage matching the technical
data of the appliance.
• Do not let the cord hang over edge of the table or
counter or touch hot surface.
• The motor must not come into contact with water
or any other liquid, as there is the danger of an
electric shock. Therefore, do not use the appliance
near to a wash Basin, not with wet hands or while
standing on a wet ground. If the appliance has
turned wet, pull the mains plug immediately out
of the socket before touching the appliance.

5
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
EN
• Do not use the appliance outdoors.
• This product is intended for household use and
not for commercial use.
• Use the appliance only for the purpose it was
designed for.
• Do not use appliance, if it or parts of it show visible
damage or if the appliance was dropped.
• Always disconnect the appliance from the supply
if it is left unattended and before assembling,
disassembling or cleaning.
• Appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and if they understand
the hazards involved.
• This appliance shall not be used by children. Keep
the appliance and its cord out of reach of children.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made
by children unless they are aged from 8 years and
above and supervised.

6
INSTRUCTION MANUAL ·WILFA XPLODE
EN
CAUTION
We are very safety conscious when designing and
manufacturing consumer products, but it is essential
that the product user also exercise care when using
an electrical appliance. Listed below are precautions
which are essential for the safe use of an electrical
appliance:
• There is a potential injury from misuse. The care
shall be taken when handling the sharp cutting
blades, emptying the bowl and during cleaning.
• To reduce the risk of injury, never place cutter-
assembly blades on base without jar properly
attached.
• Switch off the appliance and disconnect
from supply before changing accessories or
approaching parts that move in use.
• The use of accessory attachments not
recommended by the appliance manufacturer
may cause injuries.
• Be careful is hot liquid is poured into the blender
as it can be ejected out of the appliance due to a
sudden steaming.

7
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
EN
SPECIAL SAFETY INSTRUCTIONS FOR THIS UNIT
• Operate the blender with lid closed.
• Blades are very sharp. Handle with care.
• Only remove the jar while motor is off.
• Avoid overwork of motor.
• Handle carefully with glass jar.
• Never place your hands into the glass jar while
the motor is on.
• Avoid contact with moving parts.

8
INSTRUCTION MANUAL ·WILFA XPLODE
EN
PRODUCT OVERVIEW
1. Measuring cup
2. Lid
3. Glass jar with level indication
4. Sealed ring
5. Blade assembly unit
6. Blade assembly unit interface
7. Control panel
8. Motor unit
6
English
P.
PARTS DESCRIPTION
1Measuring cup
2Lid
3Glass jar with level indication
4Sealed ring
5Blade assembly unit
6Blade assembly unit interface
7Control panel
8Motor unit
1
2
3
5
6
7
8
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
LITRE OZsCUPS
8
16
32
24
40
48
56
64
MAX
8
7
6
5
4
3
2
1
4

9
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
EN
BEFORE USE
BUILT-IN SAFETY LOCK
This function ensures that user can only switch the appliance on when the acces-
sories have been placed on the unit in correct position. When the accessories
have been xed properly, the unit can only be switched on. (i.e. Built-in safety
lock function is disabled at this moment)
BEFORE FIRST USE
Clean the unit and parts thoroughly before you use the appliance for the rst time.
OPERATION
To switch on the appliance, turn the knob to “ON” position. The “ON” light will
be illuminated. To control the rotary speed, turn the knob at between “MIN” &
“MAX” position.
CONTROL PANEL
1. ON/ OFF switch
2. Speed control (MIN -> MAX)
3. Pulse/Auto clean button
Pulse/Auto clean button
This function is only working when blender is already running. When blender is
running, button is pushed to get blender quickly up to full speed. When button
is released, blender gets down to pre-set speed again. This function is suitable
for ice crushing or cleaning.
Warning: Do not add more than than 8pcs ice cubes (less than 20 x 20 x 20mm
size of the ice) in glass jar at a time.
7
English
P.
Built-in safety lock
This function ensures that user can only switch the appliance on when the
accessories have been placed on the unit in correct position. When the
accessories have been fixed properly, the unit can only be switched on.
Before first use
Clean the unit and parts thoroughly before you use the appliance for the
first time.
USING THE APPLIANCE
To switch on the appliance, turn the knob to “ON” position. The “ON” light
will be illuminated. To control the rotary speed, turn the knob at between
“MIN” & “MAX” position.
1ON/ OFF switch
2Speed control (MIN -> MAX)
3Pulse/Auto clean button
Warning:
Do not add more than than 8pcs ice cubes (less than 20 x 20 x 20mm size
of the ice) in glass jar at a time.
2
3
1

10
INSTRUCTION MANUAL ·WILFA XPLODE
EN
HOW TO USE THE GLASS JAR
1. Place the ingredients in the glass jar.
2. Place the lid on the jar and close it tightly.
3. Insert the measuring cup into the lid opening.
4. Select the speed by turning the control knob or press the Quick-select button.
Note: Do not let the appliance to operate more than 2 minutes continuously.
Let the appliance to cool down to room temperature before continue operating
the appliance.
Note that the glas jar can only withstand temperatures up to 60° C.
AFTER USING THE BLENDER
1. Disconnect the power from main supply.
2. Remove the lid (together with measuring cup) from the jar.
3. Remove the jar (together with blade assembly unit interface) from the motor
part.
Note: Always clean the removable parts immediately after use.
Note: It is recommended to cut the meat or other food into smaller pieces
before putting them in the jar. Do not operate with large quantities of food at
one time.
10
English
P.
4. Place the glass jar with blade assembly unit interface on the motor unit.
The handle can be placed in two positions: either located at the right
hand side or left hand side.
5. Connect to main power supply.
HOW TO USE THE GLASS JAR
1. Place the ingredients in the glass jar.
2. Place the lid on the jar and close it tightly.
3. Insert the measuring cup into the lid opening.

11
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
EN
CLEANING & MAINTENANCE
Always clean the removable parts immediately after use.
Note: Be careful when cleaning the parts. Avoid touching the sharp blades!
1. Disconnect the power from main supply.
2. Disassemble all removable parts before cleaning.
3. Clean all removable parts in lukewarm water with dishwashing liquid.
4. Use dry cloth to clean the main body.

12
EN
INSTRUCTION MANUAL ·WILFA XPLODE
GUARANTEE
Wilfa issues a 5 year guarantee on this product from the day of purchase. The
guarantee covers production failure or defects that arise during the guarantee
period. Your purchase receipt works as proof towards retailer if claiming your
guarantee.
The guarantee is valid only for products that are bought and used in private
households. The guarantee is not valid if the product is used commercially.
The guarantee is not valid if the product is misused, used by negligence, if not
following instructions given by Wilfa, if modied or if unauthorized reparation
is done. The guarantee is also not valid for normal wear of the product, misuse,
lack of maintenance, use of wrong electrical voltage or:
• Overloading of product
• Damage on glass
• Parts which are normally worn down

13
AS Wilfa Nydalsveien 24, 0484 Oslo, Norway
EN
BLENDER ·BLS-1200S, BLP-1200W, BLP-1200B
PRODUCT SPECIFICATIONS
220-240V~ 50/60Hz, 1200W
SUPPORT AND SPARE PARTS
For support please visit us at wilfa.com, and see our customer service/support
page. Here you will nd frequently asked questions, spare parts, tips and tricks
and all our contact information.
RECYCLABILITY
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems or
contact the retailer where the product was purchased. They can take this product
for environmentally safe recycling free of charge.

14
BRUKSANVISNING ·WILFA XPLODE
NO

15
NO
BLENDERE ·BLS-1200S, BLP-1200W, BLP-1200B
INNHOLD
16 VIKTIGE SIKKERHETSINSTRUKSJONER
18 FORSIKTIG
19 FORHOLDSREGLER FOR BLENDEREN
20 PRODUKTOVERSIKT
21 FØR BRUK
21 BRUK
22 ETTER BRUK AV BLENDEREN
23 RENGJØRING OG VEDLIKEHOLD
24 GARANTI
25 PRODUKTSPESIFIKASJONER
25 SUPPORT OG RESERVEDELER
25 GJENVINNING

16
BRUKSANVISNING ·WILFA XPLODE
NO
VIKTIGE SIKKERHETSINSTRUKSJONER
• Les denne bruksanvisningen nøye før du bruker
apparatet, og lagre den for fremtidig referanse.
• La aldri produktet være uten oppsyn mens den er
koblet til strømnettet!
• Ikke dypp apparatet i vann.
• Hvis ledningen er skadet, må den erstattes av
produsenten, forhandleren eller tilsvarende
kvalisert personell for å unngå farlige situasjoner.
• Hvis apparatet er skadet eller ikke fungerer, må
det bare repareres av autorisert personell.
• Koble produktet kun til stikkontakter som er i
orden og som matcher spenningen som står i de
tekniske spesikasjonene.
• Ikke la ledningen henge over kanten av bord eller
benker, eller berøre varme overater.
• Motoren må ikke komme i kontakt med vann eller
andre væsker, da dette kan resultere i elektrisk
sjokk. Bruk derfor ikke produktet i nærheten av
vasker, eller når du er våt på hendene eller står på
vått underlag. Hvis produktet er blitt vått, må du
trekke støpslet ut av kontakten med en gang (og
før du tar i produktet).

17
NO
BLENDERE ·BLS-1200S, BLP-1200W, BLP-1200B
• Ikke til bruk utendørs.
• Dette produktet er kun beregnet til bruk i private
husholdninger og ikke til kommersielt bruk.
• Bruk produktet kun til det som det er laget for.
• Ikke bruk dette produktet hvis det er synlige
skader på det, eller hvis produktet har falt i gulvet.
• Trekk alltid ut stikkontakten når apparatet ikke er
i bruk, før montering eller demontering og ved
rengjøring.
• Dette apparatet skal ikke håndteres av barn.
Apparatet og apparatets strømledning må
oppbevares utenfor barns rekkevidde.
• Apparatet kan brukes av personer med nedsatte
fysiske, sansemessige eller mentale evner eller
mangel på erfaring og kunnskap, hvis de er under
tilsyn av eller har fått anvisninger om sikker bruk
av apparatet og er klar over farene forbundet med
bruk.
• Barn skal ikke leke med apparatet.
• Rengjøring og vedlikehold skal ikke utføres av
barn, med mindre de er over 8 år og under tilsyn.

18
BRUKSANVISNING ·WILFA XPLODE
NO
FORSIKTIG
Sikkerheten er veldig viktig ved design og fremstilling
avforbruksartikler,mendeterogsåveldigviktigatman
utviser forsiktighet ved bruk av elektriske apparater.
Nedenfor er en liste over sikkerhetsforanstaltninger
som det er viktig at man følger ved bruk av elektriske
apparater.
• Det nnes en risiko for skade ved feil bruk. Du
må være forsiktig når du håndterer de skarpe
skjærebladene, tømmer bollen og ved rengjøring.
• Ikke la skjærebladene stå på basen uten at
beholderen er skikkelig festet til basen.
• Slå av apparatet og trekk ut støpselet før du
skifter utstyr eller håndterer deler som beveger
seg under bruk.
• Bruk av tilbehør som ikke er anbefalt av apparatets
produsent, kan forårsake skader.
• Vær forsiktig hvis varme væske helles over i
blenderen da den kan sprute ut igjen av apparatet
på grunn av plutselig fordamping.
