Wilson Electronics SLEEK 2B5225 User manual

Signal Booster
Installation
Guide
SIGNALBOOST™Sleek ™
Universal Dual-Band Signal Booster with Built-in Antenna
Warning: This manual contains important safety and operating information. Please read and follow the instructions
in this manual. Failure to do so could be hazardous and result in damage to your SleekTM.
Contents:
How it Works · · · · · · · · · · · · · · · · · · · · 2
Install Diagrams - Vehicle · · · · · · · · · · · · · · 2
Vehicle Installation · · · · · · · · · · · · · · · · · · 3
Power up the Wilson Sleek™· · · · · · · · · · · 4
Adjusting the SleekTM Arms · · · · · · · · · · · · · · 4
Understanding the SleekTM Lights · · · · · · · · · 5
Troubleshooting · · · · · · · · · · · · · · · · · · 5
Building Installation · · · · · · · · · · · · · 5
About Wilson Electronics · · · · · · · · · · · · · 6
Signal Booster Specications · · · · · · Back Cover
Warnings · · · · · · · · · · · · · · · · · · Back Cover
To amplify your phone’s signal power,
the phone must be placed in the SleekTM cradle.
To achieve the best performance while the phone remains in the Sleek™,
use a Bluetooth headset or hands free device.
Wilson®Electronics, Inc.
Model # 2B5225 FCC ID: PWO2B5225 IC: 4726A-2B5225
U.S. Patent No. 7,684,838
The weak link in cell phone systems, is the low
signal power of the cell phone. The SleekTM
boosts the cell phone power many times.
Cell Phone

1For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
Wilson®Electronics, Inc.
Accessory Antenna Options
In addition to the convenient mini magnet roof mount antenna included with your kit, Wilson
Electronics offers a wide variety of outside antennas to help you customize your amplier for a
specic application. All models shown below double the power to the cell site compared to the
mini magnet antenna. See your dealer or visit www.wilsonelectronics.com for more information.
* 859969
AC Power Supply
901120
Gooseneck
Suction Cup
Cradle Mount
901130
Cup Holder
Cradle Mount
* 901132
Adjustable
Suction Cup
Cradle Mount
Accessories for your Sleek™
301104
NMO Mount
Antenna
For permanent
vehicle roof mount
on cars and
pickup trucks.
Mounts on
Wilson NMO style
mounts: 901101,
901102, and
901103
* Must utilize
971119 Adapter
(SMA-FME)
301101
Trucker
Antenna
Designed for
mirror mounting
on large trucks.
Mounts on Wilson
3/8” mounts:
901104 and
901106
* Must utilize
971119 Adapter
(SMA-FME)
301225
12” Magnet
Mount Antenna
301133
RV
Antenna
Ideal for mounting
on non-metal
surfaces.
* Must utilize
971119 Adapter
(SMA-FME)
* 901128
Antenna Window Mount
(Used with Mini-Magnet
Mount Antenna)
Inside this Package
Mini-Magnet Mount
Antenna
Vehicle Dash
Adhesive
Mounting Bracket
DC Plug-In
Power Supply
Sleek™Universal Cell
Phone Signal Booster
NOTE: If product# 815225 was ordered, package will only include Sleek™ wireless amplier cradle and DC power supply.
901134
Vehicle Dash
Mounting Kit
-Rugged/Screw Mount-
-Adhesive Mount-
-Vent Clip Mount
* All 3 available together in the Home Accessory Kit - 859970
Adjustable Arms

For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
2
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
General
Your Wilson Sleek™ has been carefully engineered to signicantly improve the performance of
your phone. Together with an outside antenna, the Sleek’s state-of-the-art circuitry is designed
to increase your phone’s signal to and from the cell site. The Sleek™reduces disconnects and
dropouts and increases data communication rates on 2G and 3G networks.
How it Works
With the phone in the cradle and while using a wireless Bluetooth headset (or hands free device)
the outside antenna collects the cell tower signal and sends it through its cable to the Sleek™.
The signal is then boosted by the Sleek™and sent to the phone. When the phone transmits, the
signal is picked up wirelessly and boosted by the Sleek™and broadcasted back to the cell tower
via the outside antenna.
Vehicle Installation Diagram
Exterior antenna
communicates
with cell site
Sleek™boosts
signal to and from
cell site
Various
mounting
options
available Provides power to the Sleek™
Wiring Diagram
Exterior
Antenna
NOTE: The cell phone must be placed in the cradle to work properly.
Warning: This manual contains important safety and operating information. Please read and follow the instructions
in this manual. Failure to do so could be hazardous and result in damage to your SleekTM.
Warning: DO NOT use phone covers that have chrome or any other metallic surface. It may block
cellular signals

3For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
2. Attach the Mounting Bracket
A mounting bracket is provided for attaching the Sleek™ to your vehicle’s dash. Other options are also
available from Wilson Electronics.
The outside antenna must be installed vertically.
Antenna performance will be degraded if the antenna
is not vertical.
The antenna cable is small yet strong enough that it
may be shut in most vehicle doors without damaging
the cable.
For a more professional-looking installation, the antenna
cable may be run under the door seal. Carefully pull down
the door seal. Run the cable under the seal and push
the seal back into place. This prevents constant wear
and tear on the cable as the door opens and closes. The
antenna cable is small enough to easily tuck under the
door seal or plastic molding.
Mini Magnet-
Mount Antenna
Shown
Carefully
Pull Down
Door Seal
Run Cable
Under Seal
Vehicle Installation
1. Install the Outside Antenna
To receive the best cell signal, select a location for the outside antenna that is preferably in the center of
the vehicle’s roof, 12 inches away from any other antennas, free of obstructions, and at least 6 inches
from the rear or side windows or sunroof.
RF Safety Warning: The “outside antenna” must be either a Wilson Magnetic-Mount or Mini Magnetic-
Mount antenna and requires at least an 8 inch separation distance from all persons. Other outside
antennas may be used with xed building installations provided that (a) they are located with at least a 30
inch separation distance from all persons, (b) their gain less cable loss does not exceed 15 dBi, and (c)
they are not operating in conjunction with any other antenna or amplier.
ADHESIVE BRACKET- Included in this package
1.Clean the area where the bracket is to be mounted with the alcohol wipe
provided. Allow to dry.
2. Peel the backing to expose the adhesive and press the bracket onto
the desired location in the vehicle. Note: be sure the tab is positioned
vertically, not horizontally.
3. Allow the adhesive to cure for 24 hours before you attach the Sleek™.
4. Once the cradle is attached, you can adjust the angle of the adhesive
bracket by applying gentle pressure to the top or bottom of the Sleek™.
The bracket is designed to swivel when the knurled nut is loosened for
greater adjustability of the Sleek™ viewing angle. To lock bracket into
position, tighten large nut.

For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
4
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
Sleek™ Power connector.
Connect to Wilson’s power supply
Antenna
connection
Accessory USB Power port
3. Attach the Sleek™ to the Bracket
Once you have installed the bracket in the desired location, and waited 24 hours for adhesive to cure, attach
the Sleek™ by aligning the rectangular hole on its back with the tab on the mount bracket, grasping the sides
of the Sleek™, and sliding it downward approximately ¼ inch into place.
Adjusting the SleekTM Arms
Included with your Sleek are various sized arms, which will provide you with multiple options
to customize the SleekTM to t your phone.
1. Change arms
Gently grab the arm and lift
upward until the arm breaks
free from the Sleek™.
2. Reposition arms
Position the arm above a different slot on
the SleekTM (indicated by the yellow in the
drawing). Gently slide the arm down until
the arm is rmly in place.
Power up the Wilson Sleek™
IMPORTANT: Make sure the outside antenna cable is
connected before powering up the Sleek™.
Connect the mini-USB plug on the power cable to the Sleek’s
mini USB port located on the bottom of the Sleek™and insert
the adapter into the cigarette lighter outlet of your vehicle.
The Sleek™may remain on all the time. However, leaving the
Sleek™on in a vehicle when it is not running can discharge the
battery in a day or two.
Note: The 12V DC power source on many vehicles is shut off
with the ignition key.
WARNING: Use only the supplied Wilson power supply.
NOTE: The cell phone must be placed in the Sleek™to work properly. Use a Bluetooth or wired
hands free device.
4. Attach the Outside Antenna cable to the Sleek
Attach the cable from the outside antenna to the antenna connector on
the Sleek.

5For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
Green light is on : Sleek™ is operating properly
SYMPTOM: No light, or light always off
1) Make sure that the power supply for the Sleek™ is
functioning properly, by making sure the light located
on the power supply is lit.
2) If the DC plug-in power supply is properly inserted,
but the plug’s light doesn’t come on, then check the
12 volt power from the car socket, and check the
fuse in the DC plug-in power supply.
Installing a Wilson Outside Antenna in a Building
Follow the specic antenna instructions included with the outside antenna (sold separately except for
certain kits). These instructions assume that you are using a Wilson Mini Magnet-Mount Antenna and
the optional suction-cup window bracket.
To receive the best signal, select a window on the side of your building where your outside signal is
the strongest.
Attach the suction-cup bracket to the inside of a window so
that the cable will reach the location of the Sleek™. Place
the bracket as high on the window as possible for best
performance.
Once the bracket is in place, attach the magnet base of the
antenna to the at surface of the bracket. Note: the antenna
must be installed vertically. Signal performance will be
degraded if the antenna is not vertical.
Building Installation
Suction cup Antenna Window Mount is
available from Wilson Electronics.
www.wilsonelectronics.com or call 800-204-4104
SYMPTOM: No increase in Bars
1) Make sure that the antenna connector is tight.
2) The cell phone must be placed in the
Sleek™ cradle to amplify properly.
3) Call Wilson Technical Support at 866-294-1660.
Understanding the SleekTM Lights
Separation of Sleek™ and the outside antenna is very important. In a vehicle, the metal roof
acts as a barrier and helps shield the two antennas from each other, preventing oscillation.
Oscillation can occur when the roof mounted antenna is too close to the Sleek™ inside the vehicle.
An oscillation (or feedback) in the Sleek™ is similar to when a microphone is too close to a speaker
in a sound system, resulting in a loud whistle. An oscillation in the Sleek™, if allowed to occur, can
affect nearby cell sites’ ability to handle calls.
Warning: DO NOT use phone covers that have chrome or any other metallic surface. It may block cellular signals

For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
6
For free U.S. based technical support or to order accessory items please call
800-204-4104 or visit www.wilsonelectronics.com
The Wilson Sleek™ may be placed in any convenient indoor location, such as a desk or tabletop.
The cell phone must be in the cradle and a Bluetooth® headset used for voice communications.
Attaching the Antenna
Once you have selected the location for the Sleek™, run the cable from the outside antenna and
attach it to the SMA connector on the bottom of the Sleek™.
Note: The Sleek™ and the outside antenna must have a minimum separation of 3 feet to prevent
oscillation. Note: The cell phone must be placed in the Sleek™ cradle to amplify properly.
Installing the Wilson Sleek™Signal Booster in a Building
About Wilson Electronics
Wilson Electronics, Inc. has been a leader in the wireless communications industry for nearly 40
years. The company designs and manufactures signal boosters, antennas and related components
that signicantly improve cellular telephone signal reception and transmission in a wide variety of
applications, both mobile and in-building.
With extensive experience in antenna and amplier research and design, the company’s engineering
team uses a state-of-the-art testing laboratory, including an anechoic chamber and network analyzers,
to ne-tune antenna designs and performance. For its ampliers, Wilson uses a double-shielded RF
enclosure and cell site simulators for compliance testing.
All products are engineered and assembled in the company’s 55,000-square-foot headquarters in St.
George, Utah. Wilson has product dealers in all 50 states as well as in countries all over the world.
Understanding the SleekTM Lights
Separation of Sleek™ and the outside antenna is very important. In a vehicle, the metal roof
acts as a barrier and helps shield the two antennas from each other, preventing oscillation.
Oscillation can occur when the roof mounted antenna is too close to the Sleek™ inside the vehicle.
An oscillation (or feedback) in the Sleek™ is similar to when a microphone is too close to a speaker
in a sound system, resulting in a loud whistle. An oscillation in the Sleek™, if allowed to occur, can
affect nearby cell sites’ ability to handle calls.

#110807 - Sleek™ Install Guide English - REV.02-- 08.26.10
Wilson®Electronics, Inc.
30-Day Money-Back Guarantee
All Wilson Electronics products are protected by Wilson’s 30-day money-back guarantee. If, for any reason, the performance of any product is not acceptable, simply return
the product directly to the reseller with a dated proof of purchase.
1-Year Warranty
Wilson Electronics ampliers are warranted for one (1) year against defects in workmanship and / or materials. Warranty issues may be resolved by returning the
product directly to the reseller with a dated proof of purchase.
Ampliers may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a Returned Material Authorization (RMA)
number supplied by Wilson Electronics. Wilson shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced
product back to the original consumer within the continental United States.
This warranty does not apply to any ampliers determined by Wilson Electronics to have been subjected to misuse, abuse, neglect, or mishandling that alters or
damages physical or electronic properties.
RMA numbers may be obtained by phoning Technical Support at 866-294-1660.
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of this device.
Disclaimer: The information provided by Wilson Electronics, Inc. is believed to be complete and accurate. However, no responsibility is assumed by Wilson
Electronics, Inc. for any business or personal losses arising from its use, or for any infringements of patents or other rights of third parties that may result from its
use.Copyright © 2008 Wilson Electronics, Inc. All rights reserved.
Warning: Do not plug in the power supply until the outside antenna cable is attached to the Sleek™.
Warning: RF Safety: The Sleek™ cradle/amplier must be installed with a separation of at least 8
inches from all persons and must not be located in conjunction with any other antenna or
amplier.
Warning RF Safety: The FCC requires that a cell phone with cradle attached may only be used
with the cradle mounted as illustrated in this installation guide. A cell phone held near the
ear must be without the cradle attached.
Warning: RF Safety: The Outside Antennas authorized for use with this amplier are shown on page
1 of this guide. Other antennas may be used, but only in xed installations when located
outside of a building or structure (not in mobile/ portable installations), provided that:
(a) antenna location ensures at least a 30 inch separation distance from all persons,
(b) antenna gain less cable loss does not exceed 15 dBi, and
(c) such antennas are not operating in conjunction with any other antennas, or transmitting devices.
Warning: DO NOT use phone covers that have chrome or any other metallic surface. It may block
cellular signals
Phone: [phone] Fax: [phone]
Signal Booster Specications
Dual Band
800/1900 MHz Specications
Model Number / Part Number 2B5225/815225,815226, 815226F
Connectors SMA Female
Impedance (input/output) 50 ohms
Frequency 824-894 MHz / 1850-1990 MHz
1Passband Gain (nominal)
20 dB (typical) / 30 dB (maximum)
220 dB Bandwidth (nominal)
800 MHz (uplink/downlink) 43 MHz / 45 MHz
1900 MHz (uplink/downlink) 112 MHz / 84MHz
Power output for single cell phone (uplink) 800 MHz 1900 MHz
CDMA 28.9 dBm 31.8 dBm
GSM 30.9 dBm 32.6 dBm
EDGE 30.9 dBm 31.9 dBm
WCDMA 30.13 dBm 31.4 dBm
Power output for single received channel (downlink) 800 MHz 1900 MHz
CDMA -9 dBm 1.0 dBm
GSM -1.3 dBm 1.8 dBm
EDGE -1.3 dBm 2.1 dBm
WCDMA .32 dBm 2.3 dBm
3,4Power output for multiple
received channels (downlink). The
maximum power is reduced by the
number of channels:
Number of
channels
Maximum Power3
800 MHz 1900 MHz
2 -1.1 dBm 2.2 dBm
3 -4.7 dBm -1.4 dBm
4 -7.2 dBm -3.9 dBm
5 -9.1 dBm -5.8 dBm
6 -10.7 dBm -7.4 dBm
Noise Figure (typical) 3 dB nominal
Isolation > 40 dB
Power Requirements 5V DC, 1A
Notes:
1. Nominal gain is the maximum gain at any frequency in the passband.
2. Nominal bandwidth is the difference between two frequencies that are adjacent to the passband where the amplication is 20 dB
lower than the passband amplication. One of the frequencies is lower than the passband and the other is higher.
3. The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier
signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can
cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by
an attenuator at the output of the device.
4. The maximum power for 2 or more simultaneous signals will be reduced by 6 dB every time the number of signals is doubled.
Warnings:
