Operation Manual
Power Socket
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.
© by WilTec Wildanger Technik GmbH Seite 6
http: www.WilTec.de
http: www.aoyue.eu
http: www.teichtip.de

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel Fax:__________________
I would like to report the following mistakes:
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury by means of fire or
electric shock we urge that our clients take some basic safety precautions when using this
device. Please read the operation instructions carefully and make sure you have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can
nd the corresponding mains voltage on the type plate. If you have any doubts about the
connection being grounded, have it checked by a qualied professional. Never use a
faulty electric cable.
o not inspect the electrical part of the pressure pond lter in a wet or damp
environment or when you are wet yourself and protect it from direct sunlight. Install this
device in a safe location so that nobody can step on the cable, fall over or damage it.
isconnect the power plug before cleaning it and use only a damp cloth for cleaning.
Avoid using cleaning agents and make sure that no liquid enters the electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised
intervention the 2-year warranty is no longer valid! Keep these operation instructions safe.
© by WilTec Wildanger Technik GmbH Seite 7
http: www.WilTec.de
http: www.aoyue.eu
http: www.teichtip.de

Instructions for the following sockets:
61341, 61348, 61350, 61352
61347, 61349, 61351, 61353
WARNING: Please read these instructions carefully before using the product and keep them for fur-
ther references.
General Description
This two-part socket is designed for households. It meets the requirements of splashproof protection
(protection class IP44). This product is not suitable for use in construction sites or other rough areas.
Instructions
This product can only be connected to a protective contacting socket, which is grounded.
It must be placed on a solid place and horizontally respectively vertically.
Be careful that the socket should not be placed into a hollow. Rain might cause the socket to be
under water which must be avoided.
The socket must be installed at least 0.5 m away from any water place.
This socket has been designed to prevent it from spray water.
If you want to move the socket, it must be interrupted from the power supply before disconnecting
it.
Technical Data
Voltage: AC250V, 50 Hz
ominal Current: 16 A, 3680W
Protection Type: IP44
Safety Precautions
If this set is off its usual position, please check whether water could enter the socket before using
it again. Only use the socket again, when it is sure, that there is no water and it cannot enter.
It the protecting outside box is somehow damaged and cannot reach the IP44 requirements, it
must not be used anymore!
Important Hints for Installation of 61350 and 61352
The socket can be reconnected. Always cut it off from the power supply before opening the box.
For substitution of the connected wires, select 3G1.5~4.0.
Please connect the yellow and green ground wires to the marked connection locations.
© by WilTec Wildanger Technik GmbH Seite 8
http: www.WilTec.de
http: www.aoyue.eu
http: www.teichtip.de

Special Instructions for models: 61347, 61349, 61351, 61353
Adjust the Clock
Twist the circle to the right (clockwise) until the hands accord with the actual time. The time is marked
on the edge of the choice wheel by 24 hours.
Each part between two marks is equal to 15 minutes.
The circle finishes a round in 24 hours. The time can always be read from the hands. If the clock is re-
moved from the socket or turned off, it will not continue running. For the next use of the clock, it should
be readjusted.
Adjust the On-Off Program
The electrification time can be adjusted through the liftable and insertable parts on the outside of the
circle on the clock. Please press the corresponding part which represents the period during which you
want the electric equipment to be electrified.
For example:
If the part of 16 is pressed and the others are lifted, the equipment connected to the socket will
be electrified at 16:00 and be cut off at 16:15.
Please press these parts with a ballpen, a pencil or a small screwdriver.
Connect the electric equipment:
Make sure that the clock is adjusted to the right time, and check to see whether the socket has
been connected to the appliance socket. Insert the plug of the electric equipment to be electri-
fied into the socket. Check to see whether the on-off is turned on if there is one. Adjust the
mobile on-off on the edge of the clock to the mark of [Clock (Uhr)].
Compensate the On-Off Program
With the mobile on-off on the edge of the clock, the connected electric equipment can be directly elec-
trified independent of the program. And by this on-off you may check to see whether the connected
electric equipment has been electrified.
[I] – marking that the socket is always electrified
[Uhr] – marking that the socket is controlled by the clock program
© by WilTec Wildanger Technik GmbH Seite 9
http: www.WilTec.de
http: www.aoyue.eu
http: www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
