Wincor Nixdorf BEETLE /M-II Manual

BEETLE /M-II
Project Version
Technical Information

All brand and product names mentioned in this document are trademarks of their respective
owners. The reproduction, transmission or use of this document or its contents is not permitted
without express authority. Offenders will be liable for damages. All rights, including rights created
by patent grant or registration of a utility model or design, are reserved.
Delivery subject to availability; technical modifications possible.
Copyright © Wincor Nixdorf International GmbH, 2005
Published by
Wincor Nixdorf International GmbH
D-33094 Paderborn

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
1
Introduction
The BEETLE /M-II, a compact and expandable new POS system, offers
well proven PC technology on the base of Intel Pentium4 processors
with Intel 845 GV-Chipset.
For the connection of peripheral devices there are a multitude of
standard and retail specific powered and non-powered interfaces for
scanners, printers, Touchscreen, customer displays etc. via USB and
RS232 interfaces.
The BEETLE /M-II is an ideal system platform for high-capacity
Windows32 and Linux-based applications with graphical user interface.
Thus, the high processor performance allows -besides the “normal”
POS functions -multi media features up to video and audio solutions.

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
2
Exterior View
ON/OFF Button
LED Harddisk
LED Power
2x
USB

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
3
Interior View
Hard disc Disk Drive carrier

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
4
PCI
-
COM card
Power supply unit
TFT
PanelLink
adapter
CPU
-
f
an
Heat sink
Housing
-
fan

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
5
Backside
Dimensions
Width: 288 mm
Height: 150 mm
Depth: 286 mm (without cable cover)
348 mm (with optional cable cover)
MIC
KYBD
DC24V
COM1
CDRW
COM2
Internal
use
LPT1
C
OM6*
COM5*
TFT A
LAN
MICR
COM7(*)
COM8(*)
Power input
AC Outlet
ON/OFF
COM3*
COM4*
USB1
USB2

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
6
Setting up the Device
Set up the BEETLE /M-II POS system so that it is not subject to any
extreme environmental conditions. Protect the device from shocks, dust,
moisture, heat and strong magnetic fields. Always be sure that the side
ventilation slots of the BEETLE /M-II are not blocked, thus ensuring that
the device always has sufficient ventilation. Mind the minimum
clearances indicated below! If you plan to install the unit into a confined
space, also always be sure to maintain the specified minimum clearance
and ensure constant air flow for effective ventilation. The immediate
ambient temperature for the system must not exceed
40° C/104° F. These requirements can be best met, if you do not install
the unit into a completely confined furniture.
The maximum depth of installation can be equal to the entire depth of
the unit including the optionally available cable cover, i.e. 348 mm.
80 mm
8
0 mm

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
7
Vertical Installation
The following minimum clearances must also be provided in vertical
mounting into a confined furniture in free convection to ensure sufficient
ventilation:
upwards: 80 mm
downwards: 80 mm
A vertically installed device therefore has to be placed on a rig
(spacer made of non-combustible material) that guarantees sufficient
ventilation and a minimum clearance of 80 mm to the bottom of the
furniture.
A surface made of nonflammable material (e.g. concrete or metal) must
be located underneath the vertically mounted BEETLE.

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
8
Technical Specifications
Footprint
Width
Depth (w/o cable cover)
288 mm
286 mm
Height 150 mm
Weight approx. 7 kg (depending on the installation)
Current consumption (max.) 100 –120 V / 5A Max.
200 –240 V / 3A Max.
Line voltage frequency 50 / 60 Hz
Noise generation < 47 dB (A)
Ratings of AC-outlet 100 –120 V / 2A Max.
200 –240 V / 1A Max.
Total 12V current for all external loads is 5A max, including displays.
Total 5V current for all external loads is 5A max.
Operating temperature
EN 60721-3-3, class 3k3
Environmental test IEC 68 / EN60068
Air temperature: +5° C to +40° C
Humidity: 5% r.h. (1 g/m 3 ) –85% r.h. (25 g/m 3 )
Temperature fluctuation: 0.5 K/min (max. 7.5K/30 min)
Atmospheric pressure 70 kPa –106 kPa
(70 kPa corresponds to installation approx. 3000m above sea level) Installation
environments with long exposure to the sun should be avoided.

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
9
Storage requirements
EN 60721-3-1, class 1k2
Environmental test IEC 68 / EN60068
Air temperature: +5° C to +40° C
Humidity: 5% r.h. (1g/m 3 ) –85% r.h. (25 g/m 3 ) 0.5 K/min
Temperature fluctuation:0.5 K/min (max. 7.5K/30min)
Transport requirements
EN 60721-3-2, class 2k2
Environmental test IEC 68 / EN60068
Air temperature: -25° C to +60° C
Humidity: 15% r.h. (1 g/m3 ) –98% r.h. (32 g/m3 )
Temperature fluctuation: --25° C / +25° C

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
10
Manufacturer Certification
This device fulfills the requirements of EU Regulations
89/336/EEC "Electromagnetic Compatibility Directive" and
73/23/EEC "Low Voltage Directive".
The device carries the CE logo on its rear side, or the logo
is located on the packaging.
Tested Safety
This POS sys tem has been pro vi ded with the
symbol for “Tested Safety”.

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
11
BEETLE /M-II: CPU Characteristics
Supported System BEETLE /M-II
Architecture PC-AT compatible and POS -specific
functional units
Technology TTL,CMOS,LVT; SMD
+ 5V, +3.3V, AGTL+ Technology
Operating Modes Normal mode, Power save mode
Power management ACPI 1.0, APM 1.2
Operating systems WIN XP, WIN XP Embedded, LINUX
Microprocessor: INTEL PentiumR4-M (mobile, 478 Pin
uFCPGA package, 0.13 u technology)
or
INTEL Mobile CeleronR(478 Pin
uFCPGA package, 0.13 u technology)
Frequencies from 1.7GHz to 2.4GHz
(Processor dependent)
8 KB L1 data cache, 12 KB L1 program
cache, up to 512KB L2 cache (Processor
dependent)
Chipset: INTEL Chipset 845GV (contains 2 ICs):
Graphic and Memory Controller Hub
(GMCH) with following functions:
Memory Controller supports DDR SDRAM
with 266MHz system memory Bus,
Video memory is part of main memory,
supports 2D and 3D and video streams
Plug and Display functionality
Video memory for resoution max. 8 MB,
Video memory with INTEL Extreme
Graphics Driver max. 64MB (Dynamic
Video memory technology)

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
12
Max. resolution CRT:2048 x 1536 x 32 @
60Hz
Max. resolutionTFT screen:1600 x 1200 x
32 @ 60Hz
I/O Controller Hub 4 (ICH4) with following
functions:
LAN 10/100 Controller., IDE-Controller with.
UDMA,
USB Controller. UHCI and EHCI, AC97
Link for Audio and telephony CODEC,
Interrupt-Controller., DMA-Controller., LPC-
Interface, RTC, SMBus-Host Interface
Super I/O: NS87366 with following functions
Functions: Floppy Controller, Parallel port, 2 serial
ports, Keyboard interface, PS/2-Mouse
interface, HW-Monitor
Sound-Controller: CS4299 Audio Codec Controller with
following AC`97 functions:
20 Bit Stereo DAC and 18 Bit Stereo ADC
Analog Line-Level Input (CD)
Mono Mic input (MIC)
Stereo Line-Level output
Sound connection: Mono Mikrophone input, Stereo speaker
Output (2 x 1,25 W@ 8 Ohm)
Main memory: 128 MB up to2GB, 2 DIMM sockets (184
pin), 2.5 V
DDR SDRAM Technology, unbuffered
nonECC, DDR266 -Standard DIMM
Height up to35 mm
Riser-Card Interface: PCI-Bus (32 bit Interface, 33MHz)
BIOS: Firmware Hub 82802 (FWH):
512MB Flash Memory, Phoenix BIOS,
PnP, PCI Rev.1.0A, DMI –support
Battery: 3 V Lithium for RTC and SIO
Typ: CR1/3 N , 160 mAh

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
13
System Bus Frequency 400MHz
RAM Bus Frequency: 266 MHz
PCI Bus Frequency: 33 MHz
Wake On features: Wake On LAN (with connector for Standard
LAN adapter), Wake On MODEM,
Wake On Time, Wake On USB
Keyboard connection: PC-AT compatible
PS/2-Mouse connection: via Y-cable together with keyboard,
optional internal connection
Serial interface COM1, COM2*
COM3*, COM4* adapter
optional and alternatively for
(USB2plus, USB3plus, USB4plus)- Adapter
Parallel Interface: IEEE1284 compatible (ECP, EPP, PS/2-
compatible)
Loudspeaker: AT-compatible,
volume control defined by BIOS Setup, 3
steps: high, medium, low volume
Floppy Disk connection: Standard interface CMOS, NEC 765
compatible, foil connector
Hard Disk Connection: Local Bus IDE Interface,
Primary/Secondary
for 4 drives, PIO Mode 0 -Mode 4,
ULTRA DMA Mode 0 –Mode 2
primary: 2mm secondary: 2mm Connection
USB Connection: USB1.1, USB 2.0
USB1, 2: Standard 2 port Connection,
Series A ; USB3,USB4,USB5 and USB6:
Several adapters and possibilities for
connecting at rear and front (tbd)
Cash Drawer Connection: Up to two cash drawers can be connected.

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
14
Connection via internal RJ12 connector
inside power supply (only for one cash
drawer)
Gameport 2 x 8 pin 2.54 mm connector
PCI Plug-in card Interface: 32 bit Interface, 33 MHz
Status display connection: Support for LEDs: Power On and HD
activity
Current consumption: +3,3 V ~ 3,5 A
(E1 with Pentium 4-M/2GHz + 5 V ~ 0,7 A
and 512MB Ram) + 12 V ~ dependent on processor
Max. Current for keyboard +5V: 500 mA
Max. Current per port
(for COM2*,3*,4*) +12V: 600 mA
Max. Current in total
(for COM2*,3*,4*) +12V: 900 mA
Max. Current per port
(for COM2*,3*,4*) + 5V: 300 mA
Max. Current in total
(for COM2*,3*,4*) + 5V: 500 mA
Max. Current per port
Standard USB1,USB2 + 5V: 500 mA
Max. Current in total
Standard USB1,USB2 + 5V: 1,0 A
Max. Current per port + 5V: 500 mA
Powered USB +12V: 1,5 A
+24V: 3,0 A
Max. Current in total + 5V: 1,5 A
Powered USB +12V: 2,0 A
+24V: 3,0 A
Fuses (Polyswitches):
+5V: COM2*, COM3*, COM4*,

BEETLE/ M-II
_________________________________________________________
_________________________________________________________
15
USB1, USB2, Keyboard, Mouse
Powered USB (Fuse on adapter)
+12V: COM2*
COM3*, COM4* (Fuse on adapter)
Powered USB (Fuse on adapter)
+24V: Powered USB (Fuse on adapter)
Board Dimensions: approx. 255mm x220mm
Jumper Setting
PT 3 PT 2 PT 1 VIDEO-
Mode DISPLAY- Size Display Typ / Clock Freq.
closed
closed
closed
SVGA TFT 12" BA 72A (30 MHz)
closed
closed
open XGA TFT 15" BA 73A (65 MHz)
closed
open open SVGA TFT 12" BA 72A–1 (38 MHz)
open closed
closed
VGA TFT 10" 640 x 480
12” Monitor BA72A PT:
1
15” Monitor BA73A PT:
1
12” Monitor BA72A-1 PT:
1
10” Monitor 640 x 480 PT:
1
Using a PnP TFT Monitor the jumper have no function.

BEETLE/ M-II
_____________________________________________________________________
_____________________________________________________________________
16
Pentium 4 - M , 1.7GHz
Graphics & Memory
Controller Hub
GMCH
82845GV
I/O Controller Hub
ICH4
82801DB
Super I/O
PC87366
Firmware Hub
FWH
82802
Synthesizer
A
u
d
i
o
C
o
d
e
c
`
9
7
C
S
4
2
9
9
PCI Serial Port Cn
t
r
l
.
3V
Lithium
S
t
e
r
e
o
A
m
p
l
i
f
i
e
r
T
E
A
2
0
2
5
B
F
l
o
p
p
y
I
n
t
e
r
f
a
c
e
E
I
D
E
In
t
e
r
f
a
c
e
PCI Onboard
Interface
Serial
Interface
RS232
Parallel
Interface
C
a
s
h
d
r
a
w
e
r
I
n
t
e
r
f
a
c
e
Voltage
Regulator
2x22 pol. 2x8 pol. 2x13 pol.
1x4pol.
Flatpanel
Interface CRT
Interface Parallel
Interface
S
tatus Display
R
i
s
e
r
c
a
r
d
I
n
t
e
r
f
a
c
e
2
x
3
8
p
o
l
.
2
x
6
2
p
o
l
.
2
x
2
2
p
o
l
.
S
e
c
o
n
d
a
r
y
P
r
i
m
a
r
y
2
x
2
2
p
o
l
.
2
.
5
m
m
M
o
n
o
2
.
5
m
m
S
t
e
r
e
o
M
i
c
S
p
e
a
k
e
r
1
x
4
p
o
l
.
1
x
3
p
o
l
.
C
D
-
A
u
d
i
o
L
i
n
e
I
n
Loudspeaker
1x4pol.
2x4 pol.
USB
9pol.
COM1
2
x
9
p
o
l
.
P
S
U
2
SMBus
PCI Bus
System Bus
Memory Bus
DDR-Ram
2 DIMMs
128 MB up to 2 GB
U
S
B
2
I
T
8
8
7
4
F
U
S
B
p
l
u
s
I
n
t
e
r
f
a
c
e
C
O
M
*
I
n
t
e
r
f
a
c
e
2
x
2
2
p
o
l
.
2
x
1
3
p
o
l
.
2
x
9
p
o
l
.
1
x
3
p
o
l
.
1
x
4
p
o
l
.
1
x
3
p
o
l
.
W
O
L
N
P
O
N
F
A
N
1
1x80pol.
2
x
9
p
o
l
.
2
x
1
0
p
o
l
.
2
x
5
p
o
l
.
P
S
U
1
P
U
S
B
P
S
U
2
P
o
w
e
r
S
u
p
p
l
y
Connectors
1
x
3
p
o
l
.
F
A
N
2
1
x
4
p
o
l
.
M
o
u
s
e
2x2pol.
PSATX
U
S
B
5
,
6
I
n
t
e
r
f
a
c
e
U
S
B
5
,
6
2
x
5
p
o
l
.
F
l
o
p
p
y
I
n
t
e
r
f
a
c
e
2
x
1
7
p
o
l
.
G
a
m
e
p
o
r
t
I
n
t
e
r
f
a
c
e
G
a
m
e
p
o
r
t
2
x
5
p
o
l
.
9p
o
l
.
COM2
*
6
p
o
l
.
M
i
n
i
D
I
N
K
e
y
b
o
a
r
d
/
M
o
u
s
e
L
A
N
1
0
/
1
0
0
2
6
p
o
l
.
F
o
i
l
2
x
2
2
p
o
l
.
Pentium 4-M

2.4GHz
Mobile Celeron2.4 GHz

Wincor Nixdorf International GmbH, May 2005
D-33094 Paderborn
Order No.: 01750076023C
