Wincor Nixdorf TA61-2 User manual

TA61-2
POS Keyboard
User Guide

Wincor Nixdorf International GmbH
Dokumentation RD PD1
Rohrdamm 7
Haus 16
D-13629 Berlin
E-Mail: [e-mail]
Order No. 01750170065A
We would like to know your opinion on this
publication.
Please send us a copy of this page if you have any constructive
criticism.
We would like to thank you in advance for your comments.
With kind regards.
Your opinion:

Published by Wincor Nixdorf International GmbH
D-33094 Paderborn
Order No. 01750170065A

TA61-2
POS Keyboard
User Guide
Edition February 2009

All brand and product names mentioned in this document are trademarks of
their respective owners.
Copyright© Wincor Nixdorf International GmbH, 2009
The reproduction, transmission or use of this document or its contents is not
permitted without express authority.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility
model or design, are reserved.
Delivery subject to availability; technical modifications possible.

Contents
Manufacturer’s Declaration and Approval ........1
General Authorization ...........................1
FCC-Class A Declaration .........................1
User Information .............................1
Safety Instructions ............................2
Cleaning Instructions ...........................2
Warranty .................................2
About this Manual .............................3
Scope of Supply..............................3
Mounting Keys.......................5
Exchanging the Keys and Key Labels...................5
Inserting Key Labels ...........................6
Inserting Key Caps ............................7
The TA61-2 Keyboard ...................8
General ..................................8
Keypad ..................................9
Key Switch ................................10
Swipecard Reader (optional).......................11
Using the Swipecard Reader .....................11
Cleaning Instructions .........................11
Connection Method ...........................11
Releasing the Cable Connection ...................12
Self-Test .................................12
Appendix .........................13
Technical Data ..............................13
Keyboard Layout.............................14

Manufacturer’s Declaration and Approval
General Authorization
This device complies with the requirements of the directi-
ve 2004/108/EC with regard to “Electromagnetic Compati-
bility” and 2006/95/EC "Low Voltage Directive".
Therefore, you will find the CE mark on the device or packaging.
FCC-Class A Declaration
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense. Modifications not authorized by the
manufacturer may void users authority to operate this device.
This class A digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe A est conforme à la norme NMB-003
du Canada.
User Information
Repair work on the devices should only be carried out by authorized and
specially trained personnel. Improper repairs will lead to the loss of any
guarantee and liability claims.
1
GENERAL AUTHORIZATION

Safety Instructions
Note the following safety information:
nLay all cables and supply lines so that nobody can tread on them or trip
over them.
nData cables should be neither connected nor removed during thunders-
torms.
nProtect the device from dust, moisture and heat.
nTake care to ensure that no foreign objects (e.g. paper clips) or liquids
can get into the inside of the device, as this could cause electrical shocks
or short circuits.
nPlace the keyboard on a non-slip surface.
Cleaning Instructions
The keyboard should be cleaned with a germicide from time to time. Make
sure no moisture penetrates the spaces between keys. Before cleaning in
between the keys on the keyboard with a brush, loosen and remove the key
caps using the key removing device. Do not allow dust to get in through the
open keyboard mechanics.
Warranty
Wincor Nixdorf guarantees generally a warranty engagement for 12 months
beginning with the date of delivery. This warranty engagement covers all
those damages which occur despite a normal use of the product.
Damages because of
nimproper or insufficient maintenance,
nimproper use of the product or unauthorized modifications of the product,
ninadequate location or surroundings
will not be covered by the warranty.
SAFETY INSTRUCTIONS
2

For further information of the stipulation look at your contract.
All parts of the product which are subject to wear and tear are not included
in the warranty engagement.
Please order spare parts at the Wincor Nixdorf customer service.
About this Manual
This manual informs you about everything you might need to know for the
installation (software and hardware), the operation and the maintenance of
your TA61-2.
Some parts of this book require familiarity and experience in working with
operating systems and installation and configuration procedures.
Notes in the manual are marked by this symbol.
This symbol is used for warnings.
Scope of Supply
The product includes one TA61 keyboard, one User Guide and one
accessories kit containing the following:
1 * triple “0" key cap
1 * double “0" key cap
1 * single “00" key cap
2 * quadruple key caps
6 * double key caps
Transparent plates
Blank sheets for labeling
1 key cap remover
1 set of keys
The set of keys contains:
Key REG for key position 1
Key MGR for key positions 1 and 2
Key X for key positions 1, 2 and 3
Key Z for key positions 1, 2, 3 and 4
3
ABOUT THIS MANUAL

The following items can be ordered optionally:
Accessories kit 1: 20 dummy keys (1 x 1)
Accessories kit 2: 6 double key caps
2 quadruple key caps
Accessories kit 3: 12 single key caps
Depending on your order, the keyboard may have a swipecard reader.
If damage has occurred during shipping or if the package contents do not
match the delivery note, promptly notify your Wincor Nixdorf sales outlet.
SCOPE OF SUPPLY
4

Mounting Keys
Exchanging the Keys and Key Labels
You can remove each of the key caps
using the key removal device enclosed,
pulling the key upwards.
Place the key removal device on the
selected key until you hear a click.
Now remove this key from the keyboard
by pulling upwards.
5
EXCHANGING THE KEYS AND KEY LABELS

6
If the key that has been removed has a
number or character on it, you can
change the lettering as follows:
Using a thin object (e.g. paper-clip etc.),
press upwards against the plastic cover
through the opening on the underside of
the key. Please refer to the next chapter
for instructions on how to insert the new
label.
Inserting Key Labels
Below, you will find instructions on how to insert the key labels. Each key
should be labelled individually.
You can use the empty labels delivered with the system to do so.
Place the written label on the key cap. Insert the transparent key cover with
the mat and concave side upwards until it clicks into place in the key cap.
INSERTING KEY LABELS
Label for keys
Key cap
Transparent key cover with
mat and concave side up

The labels are replaced as follows:
nRemove the key cap from the keyboard (see removing the key cap) and
pull the transparent key cap upwards.
nThe transparent key cover is then released and the label can be remo-
ved.
nReplace the label and fit the transparent key cover (with the mat and con-
cave side facing upwards) back into the key cap until it engages.
Inserting Key Caps
Insert the key cap in the keyboard and press firmly into place.
When inserting double or triple keys,
please ensure that the actuating cylinder
is on the left. The quadruple key caps
are corresponding - with the actuating
cylinder arranged on the upper left.
Ensure while putting on the key caps
that all white cam of the rocker plate are
in the planned bulge of the keyboard
(see arrows below).
If you hear a click, the key caps are
inserted correctly.
7
INSERTING KEY CAPS
Rocker
plate
Cam
Quadruple key cap with scissors

The TA61-2 Keyboard
General
The TA61-2 keyboard has a keypad with maximum 60 usable keys. Except
for the numeric keys (0 to 9), the C key and the 0.00 key, the key layout is
flexible, i.e. any two contiguous keys can be replaced by a double key and
any four keys can be replaced by a quadruple key, either horizontally or
vertically.
The TA61-2 keyboard is equipped with a key switch with 6 switch positions
and is available with or without a swipecard reader.
A power-up reset and an automatic self-test are performed each time the
POS terminal is switched on. Following these self-tests, the keyboard is
ready for operation. The keyboard receives its power from the POS system.
TA61-2 keyboard with swipecard reader
GENERAL
8

TA61-2 keyboard without swipecard reader
Keypad
In the TA61-2 keypad, two keys can be replaced by a double key and four
keys to form a quadruple key, either horizontally or vertically. Only one key
code is generated by each double or quadruple key. Different key codes can
be set for the multiple keys by rotating the key caps. These caps have a
actuating cylinder that is shifted when the cap is rotated, resulting in
different key codes.
Key caps can be changed on the spot using the key cap remover included in
the scope of supply. When using the key caps for multiple keys, note the
position of the pin on the underside, making sure that the desired code is
set.
9
KEYPAD

Key Switch
The TA6-2 keyboard is equipped with a key switch with 6 switch positions.
Switch position 0 is the basic position; switch positions 1-4 are provided for
customer-specific applications. In positions 0 and 1, the key can be
removed.
The sixth switch position, which is
designated on the lock by T, is intended
for use by Field Engineering. From
switch position 0, the key provided can
be turned to position T only. This key is
not included in the scope of supply.
The key switch has only one closure, i.e.
there is only one set of keys for all
keylocks that includes the
above-mentioned key variants for the
various switch positions.
Note: For a better differentiation with
the TA61 and the TA61-1, the TA61-2
has a grey key switch and a different
key design!
KEY SWITCH
10
MGRMGR
REGREG
Z
Z
X
X
T
T
0
1
2
3
4
T
Keys for the TA61 and TA61-1.
These keys do not match with the
TA61-2 and vice versa!

Swipecard Reader (optional)
The TA 61-2 is equipped with a swipecard reader (SCR) which enables all
tracks of the swipecard reader to be read simultaneously when the card is
swiped through once.
Using the Swipecard Reader
Pull the magnetic card through the slot of the swipecard reader evenly and
quickly as far as it will go from right to left. Make sure that the magnetic
stripe is horizontally facing the keys.
Note the following precautions when handling magnetic cards:
nNever allow magnetic cards to come into contact with liquids.
nNever bend or fold magnetic cards.
nNever expose magnetic cards to a magnetic field.
Insert the magnetic card in the special slot provided on the reader from the
right-hand side only; inserting the card at another location could damage the
read heads.
Cleaning Instructions
In order to ensure that the quality of reading results is maintained, clean the
swipecard reader at least once a week. To do this, use the special cleaning
card that can be ordered from Wincor Nixdorf.
Connection Method
The connector for the keyboard is a standard 6-pin mini-DIN connector.
The cable is 1 meter long. This cable
can be extended an additional 2 meters
by means of a standard cable that can
be ordered optionally.
11
SWIPECARD READER (OPTIONAL)

Releasing the Cable Connection
Never remove a cable from a connector socket by simply pulling on the
cable. Always remove the cable by the connector housing. Please follow the
instructions below when removing cables:
nSwitch off your POS system.
The mini-DIN connectors are left plugged in until unlocked.
Using your thumb, pull gently on plastik
connector housing, removing the
connector from the socket. This unlocks
the connector. The metal part of the
connector is now visible.
Now remove the connector from the
socket.
Self-Test
A self-test of the keyboard is performed each time the POS terminal is
switched on. During this test, the interface to the system is disabled. The
system is informed of the successful completion of the test.
SELF-TEST
12

Appendix
Technical Data
Housing dimensions footprint: 280mm * 172mm
height: 49mm
Cable length Standard: 1.0 m
Optional: 2.0 m
Power Supply 5V +/- 10%, 30 mA typical
Protocol PC-AT interface, bidirectional, seriel, synchronous
Connection Mini- DIN- connector (6-pin)
Keyboard Keyboard with variable key assignment (1, 2, 3, 4),
two key rollover
Power-up Reset yes
Self-test yes
Technologiy CMOS, standard TTL
Key switch switch positions: 6 incl. 2 insertion positions
Swipecard Reader
Number of magnetic tracks: 3
Magnetic card coding: To ISO 3554
Reading rate: 12,5 to 125 cm/s
13
TECHNICAL DATA

Keyboard Layout
KEYBOARD LAYOUT
14
C
123
0
56
789
9
4
Labelled key, single (fitted at the factory)
Key with inscription (numeric keypad)
Freely assignable
