Worksman TT User manual

Worksman Heavy-Duty Tri-Tandem Tricycle Owner’s Manual and Parts List
Worksman Trading Corporation –94-15 100th Street –Ozone Park, NY 11416 –[phone]
www.worksmancycles.com Parts list: Tandem Trike
Model: TT, TT-3CB
Worksman Heavy-Duty Bicycles - The Strongest Bikes in the World!
Congratulations! You have purchased an American-made Worksman Tandem
Tricycle. Worksman tricycles are considered the most durable bicycles available.
Before assembling and riding, make certain to read this manual and any other
literature provided thoroughly. Always follow the rules of safe riding. Always keep
your Worksman in tip-top shape by replacing worn parts as needed with genuine
Worksman Cycles parts. (Do not use generic bicycle parts.) With simple
maintenance, your Worksman will perform reliably day after day, year after year.
Your bicycle has been hand-made in the USA by our American craftspeople. Our reputation rides along with
you, so your ultimate satisfaction is our goal.
This manual is intended as an assembly and maintenance guideline for a professional and qualified bicycle mechanic.
Failure to have this cycle professionally assembled could result in injury or death.
Worksman Tri-Tandem Parts List (For all coaster brake andthree-speed coaster brake Tandem Tricycles.)
Frame, Fork and Related Parts (Forks include Bottom Cone # 51.)
Part # Description Part # Description
3400 Tri-Tandem Frame (Specify color)
60HD Fork w/ Drum Brake Tab - Black
50A Headset Complete (48, 49, 52, 53, 54) 48 Headset Cups (pair)
49 Headset Bearings (pair) 51 Bottom Cone (Pressed on fork)
52 Top Adjusting Cone (threaded) 53 Key Washer
54 Fork Top Lock nut 55B Handgrips (pair)
55F Handlebar - Junior High Rise (Chrome) 55F-BLK Handlebar - Junior High Rise (Black)
55A Stem for Front Handlebar (Chrome) 55GA Stem for Rear Handlebar (Chrome)
Front Drum Brake Parts (Old style hubs had loose bearings. New style hub has pressed bearings.)
Part # Description Part # Description
OLD STYLE pre 2010 models
L918 Bearing Cup (pair) L709 Front Axle Set for Drum Brake
F817 Wheel Bearings –Loose, 11 Balls L725-1 Drum Brake Plate Kit (Old or new style)
NEW STYLE since 2010
L500-F Hub - NEW STYLE w/ pressed bearing L509 Axle - NEW STYLE for pressed bearing
L517 Pressed Bearing - NEW STYLE L725-1 Drum Brake Plate Kit (Old or new style)
F719 Drum Brake Cable w/ F769 and F770 F816 Axle Washer
F769 Anchor Bolt Assembly for F719 Cable F770 Adjusting Barrel for F719 Cable
L752R Brake Lever (Right) w/ Parking Lock 160B Fork Retention Clip (each)
L752L Brake Lever (Left) w/ Parking Lock L815 Outside Axle Nut (each)
Rear Axle and Related Parts
Part # Description Part # Description
101 Hub for Free Wheel w/ Cups 102 Key Lock Washer
103 Cups for 101 Hub 105 Adjusting Cone (threaded)
106 Stationary Cone (presses onto axle) 109 Dust Washer
113 Locknut - Left Hand Thread - Free Wheel Side 146 Wheel Bearings (pair)
130 Axle Parts Set (102, 105, 109, 113, 146, 59A, 93D) 58A Rear Axle (31 ½”)
3980 Drive Wheel Hub 58 Rear Axle (34”- Pre 1965)
59A Locknut - Drive Side 69 Fixed Drive Sprocket
4129 Freewheel Sprocket (22T) 63AD Bushing for 4129 (freewheel models)
63B Set Screw for 69 and 4129 62C Keyway for Rear Sprocket
91 Pillow Block Bearings (each) 91A Bolt, Nut, Washer for 91 Bearing
93 Spacer Washer for Left Side Wheel 93D Washer - Drive Side Spacer
301 1 Speed Coaster Brake Hub 404N 3 Speed Coaster Brake Hub

302 Coaster Brake Conversion Kit (for freewheel) SS13N-1 3 Speed Cable and Trigger for 404N
405 3 Speed Conversion Kit (for freewheel) SS721 Coaster Brake Internal Part Kit (for 301)
Crank Parts (Pedal Section)
Part # Description Part # Description
1265 Crank Parts Set (1266, 1268, 1269, 1271-1274) 1265BMXS Deluxe Sealed Crank Set-front crank
(only for front crank-does not fit rear)
1266 Crank Bearings (pair) 1268 Cups for Crank Housing (pair)
1267J Complete Front Crank Set (1380EA, 1265, 1275) 1269 Stationary Washer (inside)
1267K Complete Rear Crank Set (1380AA, 1265, 1275)
1271 Key Washer (outside) 1272 Adjusting Cone (threaded, outside)
1273 Stationary Cone (inside) 1274 Crank Locknut
1275 Crank (one piece, forged, 6½”, plated) 1275-EDB Crank (one piece, forged, 6½”, black)
1380EA Sprocket –40T (3/16”, Black)
1380AA Double Rear Sprocket –40T/48T
7217 Pedal Set –½”Reflectorized 7217-EXT Pedal Extenders
Note - The Tri-Tandem comes standard with a 40-Tooth front sprocket and 1265 crank parts set. Smaller sprockets in the
front will reduce the gear ratio, making it easier to start pedaling. The 1265BMXS is a sealed, heavier duty upgrade for
crank parts, but only fits front crank
Chain Parts
Part # Description Part # Description
4910B Chainguard –Extra Long (Specify Color)
4914B Chain (freewheel models) 4914M Chain Connecting Link (1/2”x1/8”)
4914EE Chain (for coaster brake) 4914P Front Chain (1/2”x1/8”x132.5)
4915 Chain Adjusters (for coaster brake) 4914Q Rear Chain (1/2”x1/8”x113)
4916 Chain Idler Sprocket
Seats, Seatpost, Baskets, Cabinets and Fenders (Black Polycarbonate Fenders standard since 2013.)
Part # Description Part # Description
6910V Saddle (wide w/o springs - standard) 6911V Saddle (wide w/ springs - optional)
Only for upgrade on rear seat
4909 Bolt, Nut, Washer for 4911C 4911C Seatpost Clamp (seatpost to frame)
4908C Seatpost Front (12”x7/8”) 4908D Seatpost Rear
3927 Rear Cabinet (22”x15”x16”) 5927 Rear Wire Basket (21”x15”x9”)
7227-P Rear Flat Steel Basket (24”x17”x12”) 133WH Removable Front Basket (14.5”x9.5”x9”)
7228 Front Wire Basket (21”x15”x9”) 139 Front Wire Basket (18”x13”x6”)
82 Front Fender (Chrome) 82-C Front Fender w/ all parts attached (Chr)
82P-BLK Front Fender (Black Polycarbonate) 82P-BLK-C Front fender w/ all parts attached (Blk)
83A Front Fender U-Brace
82K Front Fender Hardware Kit (95, 4907, 4907A) 95 Front “L”Bracket (fender to fork)
4907 Bolts, Nut, Washer (U-brace to fender) 4907A Bolt, Nut, Washer (“L”bracket to fork)
4902 Rear Fender (Fits 24”& 26”- Chrome) AD26* Complete Rear Fender Kit (26”Chrome)
4902P-BLK Rear Fender (Fits 24”& 26”–Black) AD24* Complete Rear Fender Kit (24”Chrome)
84 Rear Fender Brace Set (26”, one side) AD26P-BLK* Complete Rear Fender Kit (26”Black)
84A Rear Fender Brace Set (24”, one side) AD24P-BLK* Complete Rear Fender Kit (24”Black)
4902K Rear Fender Hardware (6-4905, 6-4906) 4905 Bolt, Nut, Washer (rear fender to brace)
4906 Bolt, Nut, Washer (rear fender brace to 92) 92 Rear Fender Brace Bracket (on frame)
* Complete rear fender kits include 2 rear fenders, 6 braces, and all nuts and bolts. Bracket #92 is not included.
Wheels and Tires
Part # Description Part # Description
77A 26”Front Wheel w/ Drum Brake 77 26”Front Drum Brake Wheel w/ Air Tire
77S 26”Front Wheel w/ Drum Brake w/ Solid Tire
77CAR 26”Alloy Front Wheel w/ Stainless Steel Spokes and Drum Brake (No tire or tube.)
78A 24”Free Side Wheel 79A 24”Drive Wheel
78 24”Free Side Wheel w/ Air Tire 79 24”Drive Wheel w/ Air Tire
78SA 26”Free Side Wheel 79SA 26”Drive Wheel
1007 26”Free Side Wheel w/ Air Tire 1010 26”Drive Wheel w/ Air Tire

1007CAR 26”Alloy Rear Free Side Wheel w/ Stainless Steel Spokes (No tire or tube.)
79SA-ALUM 26”Alloy Rear Drive Side Wheel w/ Stainless Steel Spokes (No tire or tube.)
4922A 26”x2.125”WTC Sup-r-Tire 4922E 24”x2.125”WTC Sup-r-Tire
4922AKV 26”x2.125”WTC KEVLAR Sup-r-Tire 4922EKV 24”x2.125”WTC KEVLAR Sup-r-Tire
4922AWSW 26”x2.125”White Wall Sup-r-Tire 4922EWSW 24”x2.125”White Wall Sup-r-Tire
4923A 26”x2.125”Tube 4923E 24”x2.125”Tube
6023A 26”x2.125”Puncture Resistant Tube 6023B 24”x2.125”Puncture Resistant Tube
1017 26”Rim Strip 1017B 24”Rim Strip
1017T 26”Tire Liner 1017T24 24”Tire Liner
101 Hub for Free Side Wheel 3980 Hub for Drive Side Wheel
1016 26”Rim Only (no spokes - rim only) 1016C 24”Rim Only (no spokes - rim only)
1016A 26”Alloy Rim Only (no spokes - rim only)
1014A Spokes for 78S, 78SA, 1007 (11G, 10 9/16”) 1014B Spokes for 77A, 77, 77S (11G, 9 13/16”)
1014C Spokes for 79, 79A (11G, 9 9/16”)
CALL FOR PART #’s TO UPGRADE TO KEVLAR TIRES AND PUNCTURE RESISTANT TUBES!
Tri-Tandems come standard with WTC Clincher Wheels with 11 gauge spokes. They are very durable. Kevlar tires are
belted air tires - ideal for preventing flats alloy rim upgrades increase rear wheels to 26”. Tri-Tandems come with 26”front
and 24”rear wheels
Safety and Comfort Accessories
Part # Description Part # Description
3979 Ding Dong Chime Bell 303 Squeeze Bulb Horn (chrome w/ rubber)
3973 Mega-Horn (battery operated) 201 Cable and Lock set (with keyed padlock)
4963 Rear View Mirror (Chrome, rectangular) 5030T Reflector Kit
3978 Safety Flag on Pole P19 Bicycle Helmet
101710 Flashing Strobe Light (clear lens) 101714 Flashing Strobe Light (red lens)
7217-41197 Pedals with Velcro Foot Straps (pair) 3975 Generator Light Set
1006 Air Foot Pump 1000 Spoke Wrench
202 Mini-Frame Pump w/ Attachment Strap 2000 Chain Rivet Remover Tool
1265TW Crank Cone Wrench 95021 Water Bottle w/ Cage, Attachment Strap
1001 Pedal Wrench 7917A Backrest w/ Mounting Hardware
6001A Patch Kit (5) 3976 Battery Operated Headlight
7217GS12 “Glowspek”Flashing Pedals –Flashes without batteries!
Part #’s and Specifications subject to change without notice, as we are constantly seeking ways to improve our products.

ASSEMBLY INSTRUCTIONS FOR THE WORKSMAN TRI-TANDEM™TRICYCLE (rev. Aug 2014):
Please read this manual carefully prior to performing the finishing assembly and prior to riding. We recommend that a qualified
bicycle mechanic assemble this cycle. Carefully remove the tricycle components from the carton, and follow the instructions in the
order presented. Keep in mind that the “left”or “right”side of the cycle is when viewed from the rear.
TOOLS REQUIRED FOR ASSEMBLY
Socket Set Flat-head Screwdriver Phillips-head Screwdriver
Allen Wrench Set Adjustable Wrench Pliers
You will notice the tandem tricycle is mostly pre-assembled at the factory. Some finishing assembly is required. The front
wheel and fork assembly is pre-assembled at the factory.
1) FRONT ASSEMBLY (See illustrations)
Bearing cups have been pressed into the headtube at the factory.
1. Grease bearing cups (#48) with Rustolene 200 or equivalent lubricant. Bearings are pre-greased.
2. Place one bearing (#49) onto the fork steerer tube, balls facing up.
3. Slide the steerer tube through the headtube from the bottom.
4. Place the other bearing (#49) onto the steerer tube, balls facing down.
5. Install the top-adjusting cone (#52) onto the steerer tube. Hand-tighten until just before the bearings bind, then turn
back a quarter-turn.
6. Slide the key washer (#53) onto the steerer tube, then the reflector bracket (#5031).
7. Install the head lock nut (#54) and securely tighten, again making sure the bearings do not bind. The fork should
rotate freely without excess play.
8. Install the handlebar stem (#55A) into the steerer tube, withthe handlebar clamp facing forward.Itmust be inserted
beyond the minimum insertion line. Loosen the handlebar clamp nut. Insert and center the handlebar into the
clamp.
9. Rotate the handlebar within the clamp to the desired angle, then tighten the clamp. Pivot the handlebar about the
steerer fork until it is perpendicular to the front wheel, then tighten the stem bolt. Recommended torques are 300
in.lbs. and 240 in.lbs., respectively.
10. Attach brake hand lever (and shift lever for three-speed models) onto the handlebar. Cables should not be tangled.
Slide handlebar grips completely onto the handbar until tight. Do not use lubricants.
2) PEDAL ASSEMBLY (See illustrations)
Pedals are marked on the shaft with either an Lor Rdenoting left or right. The Rpedal fits on the right (sprocket) side
of the crank arm. Tighten clockwise. The Lpedal fits on the left side of the crank arm and is reverse-threaded. Tighten
counter-clockwise. Tightening in the wrong direction will strip the threads. Recommended torque for the pedals is
275 in.lbs.

3) REAR STEM ASSEMBLY (See illustrations)
1. Slide rear stem over front seatpost.
2. Adjust stem to desired height and tighten hex bolts.
3. Slide rear handlebar through stem.
4. Center handlebar in stem, set to desired angle, and tighten stem bolt.
5. Install handlebar grips, as instructed for front handlebar.
SEAT ADJUSTMENTS
Although the seats are already installed at the factory, adjust the heights to your desired levels by loosening the seat
clamp nut at the top of the frame’s seat tube. Re-tighten at desired height. Make sure a minimum of 3 1/2”of the
post remains in the frame tube. Never adjust post above this level. Adjust angle of seat with nose raised slightly.
Tighten seat clamp securely. Recommended torque for the seat clamps nuts is 240 in.lbs.

MAINTENANCE TIPS
Always inspect your Worksman Cycle to ensure that all nuts, bolts, screws and hardware are tight and that no parts are worn or damaged. Do not
attempt to straighten bent forks or frames.
Chain:
Lubricate chain once a month or as needed with light oil. Replace sprockets when teeth become worn,
bent or broken. Keep chain adjusted so there is no more than 3/8”slack. Note that we make the chains
tight at the factory, as we do know they will stretch during the break-in period. Lubricate crank parts
every six months. Replace pedals when the surface is worn or if axle becomes “tight”or frozen.
Drum Brake:
Some Worksman bicycles are equipped with a front drum brake. It is engaged by squeezing the hand lever on the handlebar.
To use “Park”feature, when cycle is completely stopped, squeeze hand lever and push in parking plunger button on lever. To
disengage, simply squeeze lever until parking plunger button releases. Drum brakes are pre-adjusted at the factory. Readjust
the cable tension as necessary using the adjusting barrel so that wheel spins freely and stops when brake is applied. Always
replace worn brake cables and damaged hand levers.
Coaster Brake (if applicable):
Foot activated coaster brakes are easy to use and reliable. To activate this internal brake, reverse the pedaling motion until
the brake engages. To avoid skidding and maintain control, apply care when braking. This is especially true on wet surfaces.
Apply brakes gently, gradually increasing pressure. Replace coaster brakes when they become worn. Check chain tension
regularly. Coaster brake hubs may make a vibrating noise under braking until they are broken in. For multi-speed units, pause
pedaling when shifting to help mesh gears. (Let the cycle coast.) Multi-speed hubs make a slight ticking sound.
Tires:
Always check for wear or damage. See tire sidewall for proper level of inflation. Replace worn or cut tires and leaking tubes immediately.
Tri Tandems should only be ridden in safe environments, away from traffic areas as these are long vehicles requiring a longer turning radius than many
other bicycles and tricycles. Tri-Tandems will pull slightly to one side when pedaled, which is perfectly normal and easy to compensate for when
steering. Always have the captain in front position and smaller or less able riders on rear. When going down inclines, always engage the front drum
brake to control speed. Turns should be subtle, not sharp.
LIMITED WARRANTY:
This cycle is warrantied against faulty parts under the following conditions: this warranty does not cover any failure due to accident, abuse, misuse, neglect
or as the result of normal wear and tear, or improper assembly. The entire frame, including all welded joints, is warranted to be free from defects and
material for one year while in possession of the original purchaser. All other parts on this cycle, except tires and tubes, are warrantied for 90 days from
the date of purchase. Repair and replacement of these parts is to be according to the Worksman Cycles parts and service procedures and must be
handled directlythrough the source where the cycle was purchased. If upon examination of the parts in question, theWorksman Cycles dealer determines
that it is defective, either repair or replacement will be made at no cost except the cost of transportation and labor charges (if any). unauthorized repairs
or replacement automatically voids warranty. Proper maintenance is required for warranty to be valid. In the event that it was determined that the warranty
claim is the result of misuse, abuse, improper maintenance or simply not defective or beyond the warranty period, Worksman Cycles or the dealer will
advise you as to the cost of repair, replacement or labor prior to performing any work or replacing any parts. If you choose not to have the dealer or
Worksman cycles perform the work, the parts will be returned to you at your expense or discarded if no reply is received within 2 weeks of notification.
The sole responsibility of the manufacturer to the terms of this warranty, if any, shall be the repair and/or replacement of the parts as indicated above. The
liability of the manufacturer shall in no event exceed the original purchase price of the product, and the manufacturer shall not be responsible for any
consequential damages of any nature, including, but not by way of limitation, damages for personal injury or property. This statement constitutes the
exclusive expression of warranties by the manufacturer and is in lieu of any or all other warranties such as expressed warranties, implied warranties,
including but not limited to warranties of merchantability, and fitness or purpose, are limited in duration for one year from the date of purchase of the frame
only and 90 days for all other parts, except tires and tubes which are not warrantied. Worksman Trading Corporation is the manufacturer. Misuse of the
cycles including off road riding, installation of motors or power assists, alterations, repairs using parts other than Worksman Cycles parts voids warranty.
Worksman Trading Corporation is not responsible for maintaining records of serial numbers. Void where prohibited by state law.
RULES FOR SAFE RIDING AND RESPONSIBLE OPERATION: Carefully read this manual before operating the cycle.
·It is the responsibility of the assembler to properly install all parts included and to inspect the cycle prior to riding to insure proper operation.
·Operator is responsible for required maintenance and for observing all traffic regulations in the operating environment. (Stop signs, etc.)
·Keep to the right and in a straight line. Ride in single file. Operate cycle at slow speeds, particularly in high traffic areas.
·Do not ride outdoors at night, and have appropriate signaling device as needed. (We recommend the 3973 Mega Horn.)
·Give pedestrians the right of way. Always look around you to understand the riding environment and hazards.
·Do not carry passengers, and check brakes prior to riding. Never ride the cycle if there are known repairs required.
·Slow down when approaching turns or intersections. Use proper hand signals when turning or stopping.
·Recommended safety options include, but are not limited to, an approved helmet, audible warning device, front/rear lights and/or reflectors.
·Do not exceed the recommended weight capacity. (300 lbs., including the rider.) Always secure cargo with appropriate tie down straps.
·Wipe surface of cycle clean and dry when exposed to corrosive substances or environment.
·Operators of cycles should be in good physical condition. Ride at your own risk.
·Wear proper riding attire. Check shoelaces and pant legs prior to riding so they do not become engaged in the chain and sprocket.
·Ride only on smooth, paved surfaces. Do not use off road. Always keep both hands on the handlebars.
·Always replace worn parts with genuine Worksman Cycle Repair Parts.
Visit us online at www.worksmancycles.com or call us at 888-3WHEELER!
