Worx HYDROSHOT WG630E.X Series Installation manual

2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
SAFETY AND OPERATING MANUAL
ORIGINAL INSTRUCTIONS

3
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
TABLE OF CONTENT
1. SAFETY INSTRUCTIONS
2. COMPONENT LIST
3. TECHNICAL DATA
4. INTENDED USE
5. OPERATING INSTRUCTIONS
6. ATTACHMENT OF ACCESSORIES
7. MAINTENANCE
8. CLEANINGSTORAGE
9. ENVIRONMENTAL PROTECTION
10. TROUBLESHOOTING
11. DECLARATION OF CONFORMITY
1. SAFETY INSTRUCTIONS
PRODUCT SAFETY
GENERAL SAFETY WARNINGS
WARNING Read all
safety warnings and all
instructions. Failure to follow
the warnings and instructions
may result in electric shock,
fire and/or serious injury.
Save all warnings and
instructions for future
reference.
- This appliance can be used
by persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
- The appliance is only to be
used with the power supply
unit provided with the
appliance.
- This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
- Children should be
supervised to ensure that
they do not play with the
appliance.
ADDITIONAL SAFETY
WARNINGS
ADDITIONAL SAFETY
WARNINGS FOR CLEANER
1. The liquid must not be
directed towards equipment
containing electrical
components.
2.Remove or disconnect
the battery pack after use
and before carrying out
user maintenance on the
appliance.
3.The appliance shall not be
left unattended while it is

4
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
connected to the battery
pack.
4.The appliance is not to be
used if it has been dropped,
if there are visible signs of
damage or if it is leaking.
5.Keep the appliance out of
reach of children when it is
energized.
SAFETY WARNINGS FOR
BATTERYOPERATED
APPLIANCES
1. Non-rechargeable batteries
are not to be recharged.
2.Rechargeable batteries
are to be removed from
the appliance before being
charged.
3.Different types of batteries
or new and used batteries
are not to be mixed.
4.Batteries are to be inserted
with the correct polarity.
5.Exhausted batteries are
to be removed from the
appliance and safely
disposed of.
6. If the appliance is to be
stored unused for a long
period, the batteries should
be removed.
7. The supply terminals are not
to be short-circuited.
SAFETY WARNINGS FOR
BATTERY PACK
a)Do not dismantle, open
or shred cells or battery
pack.
b)Do not short-circuit a
battery pack. Do not
store battery packs
haphazardly in a box or
drawer where they may
short-circuit each other
or be short-circuited by
conductive materials.
When battery pack is not
in use, keep it away from
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from one
terminal to another. Shorting
the battery terminals
together may cause burns or
a fire.
c) Do not expose battery
pack to heat or fire. Avoid
storage in direct sunlight.
d)Do not subject battery
pack to mechanical
shock.
e) In the event of battery
leaking, do not allow
the liquid to come into
contact with the skin or
eyes. If contact has been
made, wash the affected

5
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
area with copious
amounts of water and
seek medical advice.
f) Keep battery pack clean
and dry.
g)Wipe the battery pack
terminals with a clean
dry cloth if they become
dirty.
h)Battery pack needs to
be charged before use.
Always refer to this
instruction and use
the correct charging
procedure.
i) Do not maintain battery
pack on charge when not
in use.
j) After extended periods
of storage, it may be
necessary to charge and
discharge the battery
pack several times
to obtain maximum
performance.
k)Recharge only with the
charger specified by
Worx. Do not use any
charger other than that
specifically provided for
use with the equipment.
l) Do not use any battery
pack which is not
designed for use with the
equipment.
m)Keep battery pack out of
the reach of children.
n)Retain the original
product literature for
future reference.
o) Remove the battery from
the equipment when not
in use.
p)Dispose of properly.
q)Do not mix cells of
different manufacture,
capacity, size or type
within a device.
r) Keep the battery away
from microwaves and
high pressure.
SYMBOLS
Warning
Read operator’s manual
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
Do not burn
Remove battery from the socket
before carrying out any adjust-
ment, servicing or maintenance.
Unlock

6
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
Lock
Waste electrical products must
not be disposed of with household
waste. Please recycle where fa-
cilities exist. Check with your local
authorities or retailer for recycling
advice.
Li-Ion battery This product has
been marked with a symbol
relating to ‘separate collection’
for all battery packs and battery
pack. It will then be recycled or
dismantled in order to reduce the
impact on the environment. Battery
packs can be hazardous for the
environment and for human health
since they contain hazardous
substances.
RCM marking
ABN: Australian Business Number.
By this number, business informa-
tion such as entity type, status,
business location etc. can be found
at website http://abr.business.
gov.au.
ABN of Positec Australia Pty Lim-
ited is 14 101 682 357.

7
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
19*
7
89
15
*
14 13 1210 11
16
*
20*
21*
22*
23*24*25*
17
*
1
2
5
6
4
3
26
*
27
*
28
*
OPTIONAL ACCESSORIES

8
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
2
1
100%
0%
WA3880
WA3867
D
A3
A2
A1
A4
A5
100%
0%
1
2
B1

9
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
1
2
DC
D1 DD2
1
2
1
2
1
2
B3B2
B4

10
2 in 1: Portable Power Cleaner/Water Sprayer
WG630E WG630E.X
1
2
E1
FG
DD3
E2 E3
