SAFETY AND OPERATING MANUAL
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5

3
2
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases
or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep cord
away from heat, oil, sharp edges or
moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected
supply. Use of an RCD reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use a
power tool while you are tired or under the
influence of drugs, alcohol or medication.
A moment of inattention while operating
power tools may result in serious personal
injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use
of these devices can reduce dust-related
hazards.

3
2
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the
switch does not turn it on and off.
Any power tool that cannot be controlled
with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, flush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
ADDITIONAL SAFETY
POINTS FOR YOUR HEDGE
TRIMMER
1. Keep all parts of the body away from
the cutter blade. Do not remove
cut material or hold material to
be cut when blades are moving.
Make sure the switch is off when
clearing jammed material. A moment
of inattention while operating the hedge
trimmer may result in serious personal
injury.
2. Carry the hedge trimmer by the
handle with the cutter blade stopped.
When transporting or storing the
hedge trimmer always fit the cutting
device cover. Proper handling of the
hedge trimmer will reduce possible
personal injury from the cutter blades.
3. Hold the power tool by insulated
gripping surfaces only, because the
cutter blade may contact hidden

5
4
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
wiring. Cutter blades contacting a “live”
wire may make exposed metal parts of
the power tool “live” and could give the
operator an electric shock.
4. Check the hedge for foreign objects,
e.g. wire fences
5. Hold the hedge trimmer properly, e.g.
with both hands if two handles are
provided
SAFETY WARNINGS FOR
bATTERY PACk
a) Do not dismantle, open or shred cells
or battery pack.
b) Do not short-circuit a battery pack. Do
not store battery packs haphazardly
in a box or drawer where they may
short-circuit each other or be short-
circuited by conductive materials.
c) Do not expose battery pack to heat or
fire. Avoid storage in direct sunlight.
d) Do not subject battery pack to
mechanical shock.
e) In the event of battery leaking, do not
allow the liquid to come into contact
with the skin or eyes. If contact has
been made, wash the affected area
with copious amounts of water and
seek medical advice.
f) Seek medical advice immediately
if a cell or battery pack has been
swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with
a clean dry cloth if they become dirty.
i) Battery pack needs to be charged
before use. Always refer to this
instruction and use the correct
charging procedure.
j) Do not maintain battery pack on
charge when not in use.
k) After extended periods of storage,
it may be necessary to charge
and discharge the battery pack
several times to obtain maximum
performance.
l) Battery pack gives its best
performance when it is operated at
normal room temperature (20°C±5°C).
m)When disposing of battery packs,
keep battery packs of different
electrochemical systems separate
from each other.
n) Recharge only with the charger
specified by POSITEC. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
o) When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
p) Under abusive conditions, liquid may
be ejected from the battery pack;
avoid contact. If contact accidentally
occurs, flush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
q) Clean the battery pack contacts and also
those of the equipment prior to battery
installation.
r) Remove exhausted battery pack promptly.
s) Do not use any charger other than that
specifically provided for use with the
equipment.
t) Do not use any battery pack which is not
designed for use with the equipment.
u) Keep battery pack out of the reach of
children.
v) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
w) Retain the original product literature for
future reference.
x) Remove the battery from the equipment
when not in use.
y) Dispose of properly.

5
4
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
SYMbOLS
Warning
To reduce the risk of injury, user
must read instruction manual
Wear ear protection
Wear eye protection
Wear dust mask
Do not dispose of batteries. Return
exhausted batteries to your local
collection or recycling point.
Do not expose to moisture
Do not burn
Do not expose to rain or water
Always charge the battery pack
between temperatures 40°F
(4.5°C)-105°F (40.5°C).
C-tick marking

7
6
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
1. BATTERY PACK
2. REAR HANDLE
3. FRONT HANDLE
4. SAFETY GUARD
5. FRONT SWITCH LEVER (ALL AROUND SWITCH FUNCTION)
6. REAR SWITCH LEVER
7. BATTERY PACK RELEASE LATCH
8. BLADE
9. BLADE SHEATH
Not all the accessories illustrated or described are included in standard delivery.
9
8
4
3
2
1
7
5
6

7
6
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
TECHNICAL DATA
WG255E WG255E.5
Voltage 20V Max* Lithium Ion
No load speed 2200/min
Blade length 52cm
Max.cutting diameter 14mm
Charging time 3hr approx. 1hr approx.
Machine weight 2.3kg
*Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
ACCESSORIES
WG255E WG255E.5
Blade sheath 1 1
Safety guard 1 1
Charger 1 (WA3739) 1 (WA3843)
Battery pack 1 (WA3520) 1 (WA3525)
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.

9
8
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
OPERATING INSTRUCTIONS
WARNING! DO NOT USE THE PRODUCT
WITHOUT ATTACHING THE GUARD AND
FRONT HANDLE.
INTENDED USE
The machine is intended for cutting and trimming
hedges and bushes in domestic use.
1. GUARD ASSEMBLY
Insert the Safety Guard (4) into the slot as illustrated in
Fig A; making sure it is securely attached.
Use two screws to fix the Safety Guard securely.
2. FRONT HANDLE (3) ASSEMBLY
The Front Handle must be assembled before use:
1) Attach the handle to the housing, aligning the mark
to housing and handle(See Fig. B,C,D).
2) Insert the locking bolt into the handle and fully
tighten the bolt. (See Fig. E )
3) Check whether handle is firmly secured, if not
retighten the locking bolt.
A
B
C
D
E
F
G
H
I
J
K

9
8
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
3. BEFORE USING YOUR CORDLESS HEDGE
TRIMMER
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or allow
metallic objects into your charger or battery pack
connections because of an electrical failure and hazard
will occur.
Your battery pack is UNCHARGED and you must charge
once before use.
The battery charger supplied is matched to the Li-ion
battery installed in the machine. Do not use another
battery charger.
4. CHARGING YOUR BATTERY PACK
The Li-Ion battery is protected against deep discharging.
When the battery is empty, the machine is switched off
by means of a protective circuit: In a warm environment
or after heavy use, the battery pack may become too hot
to permit charging. Allow time for the battery to cool
down before recharging.
5. TO REMOVE OR INSTALL BATTERY PACK
(See Fig. F)
Depress the Battery Pack Release Latch (7) to release
battery pack from your hedge trimmer. After recharging,
insert the battery pack into trimmer’s battery port. A
simple push and slight pressure will be sufficient. Check
to see if the battery is fully secured.
6. STARTING AND STOPPING
BEFORE STARTING YOUR HEDGE TRIMMER
Remove Blade Sheath (9).
TO START YOUR HEDGE TRIMMER
Your hedge trimmer is equipped with two Switch Levers
(5 & 6). Both Switch Levers need to be pressed for the
hedge trimmer to start. Depress and hold the Front
Switch Lever (5) and press the Rear Switch Lever (6)
(See Fig. G).
TO STOP YOUR HEDGE TRIMMER
Move hedge trimmer away from cutting area before
stopping.
To stop, release one of the switch levers (See Fig. H).
WARNING: If any parts are missing,
damaged or broken, do not operate your
hedge trimmer until all damaged parts have been
replaced or repaired. Failure to do so could result
in serious personal injury. DO NOT USE WITHOUT
HANDLE AND GUARD
A
B
C
D
E
F
G
H
I
J
K

11
10
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
7. HOW TO USE YOUR HEDGE TRIMMER
Note that the front switch lever can be activated on three
sides, giving you many choices for a comfortable grip.
Before cutting an area, inspect it first and remove any
foreign objects that could become thrown or entangled
in the blades. Always hold the trimmer with both hands
and with the blade away from you before turning it on.
When trimming new growth, use a wide sweeping
action so that the stems are fed directly into the blade.
(See Fig. I & J)
Allow the cutting blades to reach full speed before
cutting. When operating, keep the cutting blades away
from people and objects such as walls, large stones,
trees, vehicles, etc.
If the blade stalls, immediately stop the trimmer. Release
the two Switch Levels (5 & 6) before attempting to clear
jammed debris from the cutting blades.
Wear gloves when trimming thorny or prickly growth.
Do not attempt to cut stems that are too thick for the
cutting blade.
TOP CUTTING
Use a wide sweeping motion (See Fig. I). A slight
downward tilt of the cutting blades in the direction of
motion gives the best cutting results.
SIDE CUTTING
When trimming the sides of the hedge, begin at the
bottom and cut upwards (See Fig. J), tapering the hedge
inward at the top.This shape will expose more of the
hedge, resulting in a more uniformed growth.
8. CLEANING
REMOVETHE BATTERY PACK. Use a soft brush to
remove debris from all air intakes and cutting blade.
Wipe the surface with a dry cloth.
WARNING: Never use water for cleaning your
trimmer. Do not clean with chemicals, including
petrol, or solvents as this may damage your trimmer.
LUBRICATING THE CUTTING BLADE
For easier operation and longer life, lubricate the cutting
blades before and after each use. Before lubricating, make
sure the battery is removed from the trimmer. Apply oil
between the two blades periodically (See Fig. K).
AT THE END OF THE CUTTING SEASON
Clean your trimmer thoroughly.
Check that all nuts and bolts are secure.
Visually inspect the trimmer for any worn or damaged
parts.
A
B
C
D
E
F
G
H
I
J
K

11
10
Cordless Li-Ion
Hedge Trimmer
WG255E
WG255E.5
MAINTENANCE
Remove battery before carrying out any
adjustment, servicing or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free of
dust.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your Local Authority or
retailer for recycling advice.

Copyright © 2013, Positec. All Rights Reserved.
2CHT06EPK11005A0
