Xilinx ZCU102 User manual
ZCU102 Software
Install and Board
Setup
February 2019
XTP435
© Copyright 2019 Xilinx, Inc. Xilinx, the Xilinx logo, Artix, ISE, Kintex, Spartan, Virtex, Vivado, Zynq, and other designated brands included herein are
trademarks of Xilinx in the United States and other countries. All other trademarks are the property of their respective owners.
NOTICE OF DISCLAIMER: The information disclosed to you hereunder (the “Information”) is provided “AS-IS” with no warranty of any kind, express or implied.
Xilinx does not assume any liability arising from your use of the Information. You are responsible for obtaining any rights you may require for your use of this
Information. Xilinx reserves the right to make changes, at any time, to the Information without notice and at its sole discretion. Xilinx assumes no obligation to
correct any errors contained in the Information or to advise you of any corrections or updates. Xilinx expressly disclaims any liability in connection with technical
support or assistance that may be provided to you in connection with the Information. XILINX MAKES NO OTHER WARRANTIES, WHETHER EXPRESS,
IMPLIED, OR STATUTORY, REGARDING THE INFORMATION, INCLUDING ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR NONINFRINGEMENT OF THIRD-PARTY RIGHTS.
Revision History
Date Version Description
02/25/19 10.1 Updated document format.
12/10/18 10.0 Updated for 2018.3.
06/18/18 9.0 Updated for 2018.2
04/09/18 8.0 Updated for 2018.1.
12/20/17 7.0 Updated for 2017.4
10/09/17 6.0 Updated for 2017.3.
06/20/17 5.0 Updated for 2017.2.
04/19/17 4.0 Updated for 2017.1. Added AR67775 and AR68682.
12/19/16 3.0 Updated for 2016.4.
10/13/16 2.0 Updated for 2016.3, Rev 1.0, and ES2 silicon.
05/27/15 1.0 Initial version.
ZCU102 Software Install and Board Setup
˃Xilinx ZCU102 Board
˃Software Requirements
˃ZCU102 Hardware Setup
˃UART Driver Install
˃Terminal Setup
˃Clock Setup
˃Ethernet Setup
˃Optional Hardware Setup
˃References
Note: This presentation applies to the ZCU102
Xilinx ZCU102 Board
Software Requirements
˃Xilinx Vivado Design Suite 2018.3, HL System Edition with SDK
Note: Presentation applies to the ZCU102
ZCU102 Hardware Setup
˃ZCU102 Kit Hardware
contents
ZCU102 Board
Ethernet cable
USB Hub
2 Micro USB cables
Power supply
Note: Presentation applies to the ZCU102
ZCU102 Hardware Setup
˃Set S6 to 1111 (1 = GND, Position 1 →Position 4)
Used for most tutorials; this sets the Boot Mode to 0x0000, JTAG as per UG1085
ZCU102 Hardware Setup
˃Set S6 to 1011 (1 = GND, Position 1 →Position 4)
For booting from QSPI, as seen in XTP434
ZCU102 Hardware Setup
˃Connect a USB Type-A to Micro-B
cable to the USB UART connector (J4)
on the ZCU102 board
˃Connect a USB Type-A to Micro-B
cable to the USB JTAG (Digilent) (J87)
connector on the ZCU102 board
˃Connect these cables to your PC
Note: Presentation applies to the ZCU102
ZCU102 Hardware Setup
˃Connect the included Ethernet cable
to the ZCU102 and connect it to the
Host computer
Note: Presentation applies to the ZCU102
ZCU102 Hardware Setup
˃Connect the power supply to the
ZCU102 (J15)
Connect this cable a power outlet
˃Power on the ZCU102 board for the
UART driver installation
Note: Presentation applies to the ZCU102
UART Driver Install
˃Determine the COM Port numbers for your system
˃Open the Device manager
Control Panel →System →Device Manager
There will be four “Silicon Labs Quad CP210x” COM ports, 0 through 3
Interface 0 & 1 are for the ARM processor
Interface 2 is for PL Fabric (MicroBlaze) use
Interface 3 is for the MSP430
The COM Port numbers will vary from system to system
Note: Sometimes the x in “CP210x” will show up as “5” or “8”
Clock Setup
˃See XTP433 for details on using the System Controller GUI
˃The latest firmware must be used with this GUI; details on updating it are in
XTP433
Note: Presentation applies to the ZCU102
Setting the clocks
˃Select the Set tab underneath the Clocks tab
˃Enter 156.25 for the Si5328 and click the Set Si5328 Frequency button
Note: Presentation applies to the ZCU102
Ethernet Setup
˃Open the Windows Control Panel
Set to View by Category
˃Click on “View network status and tasks”
Note: Presentation applies to the ZCU102
Ethernet Setup
˃Click on “Change adapter settings”
Note: Presentation applies to the ZCU102
Ethernet Setup
˃Right-click on the Gigabit Ethernet Adapter that you will be using for this
test and select Properties
Note: Presentation applies to the ZCU102
Ethernet Setup
˃Click Configure
Set the Link Speed & Duplex to Auto Negotiation then click OK
Note: Presentation applies to the ZCU102
