Yaesu FT2DR Manual

Specications
Exploded View & Miscellaneous Parts
Block Diagram
Alignment
Board Unit (Schematics, Layouts & Parts)
RF Unit
CNTL Unit
SUB Unit
USB Unit
ENC Unit
MIC Unit
Caution
Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to the instruc-
tions.
144/430 MHz Dual-Band Digital Transceiver
FT2DR/DE
Introduction
This manual provides the technical information necessary for ser-
vicing the FT2DR/DE 144/430 MHz Dual Band Digital Trans-
ceiver.
Servicing this equipment requires expertise in handing surface-
mount chip components. Attempts by non-qualified persons
to service this equipment may result in permanent damage not
covered by the warranty, and may be illegal in some countries.
Two PCB layout diagrams provided for each double-sided
board in this transceiver. Each side of the board is referred to
by the type of the majority of components installed on that side
("Side A" or "Side B"). In most cases one side has only chip
components, and the other has either a mixture of both chip and
leaded components (trimmers, coils, electrolytic capacitors,
ICs, etc.), or leaded components only.
While we believe the information in this manual to be correct,
YAESU assumes no liability for damage that may occur as a
result of typographical or other errors that may be present. Your
cooperation in pointing out any inconsistencies in the technical
information would be appreciated.
Contents
TECHNICAL SUPPLEMENT
EH060M90C
©2016 YAESU MUSEN CO., LTD.
Important Note
This transceiver was assembled using Pb (lead) free
solder, based on the RoHS specication.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-
0.5Cu) should be used for repairs performed on this
apparatus. The solder stated above utilizes the alloy
composition required for compliance with the lead-free
specication, and any solder with the above alloy com-
position may be used.

FT2DR/DE Technical Supplement
Specications
SPECIFICATIONS-1
General
Frequency Range:
A Band RX
0.52 - 1.71 MHz (AM Radio)
1.8 - 30 MHz (SW Radio)
30 - 76 MHz (USA version)
30 - 88 MHz (EXP/EU version)
76 - 108 MHz (USA version)
88 - 108 MHz (EXP/EU version)
108 - 137 MHz (Air Band)
137 - 174 MHz (144 MHz HAM)
174 - 222 MHz (VHF Band)
222 - 420 MHz (GEN1)
420 - 774 MHz (USA version)
420 - 800 MHz (EXP/EU version)
803 - 999 MHz (GEN2, Cellular Blocked: USA version)
800 - 999 MHz (GEN2: EXP/EU version)
B Band RX
108 - 137 MHz (Air Band)
137 - 174 MHz (144 MHz HAM)
174 - 222 MHz (VHF Band)
222 - 420 MHz (GEN1)
420 - 470 MHz (430 MHz HAM)
470 - 580 MHz (UHF Band)
TX
144 - 146 MHz or 144 - 148 MHz
430 - 440 MHz or 430 - 450 MHz
Channel Spacing: 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 50, 100 kHz
(8.33 kHz: only for Air Band, 9 kHz: only for AM Radio)
Frequency Stability: ±2.5 ppm (–4 °F to +140 °F [–20 °C to +60 °C])
Emission Type: F1D, F2D, F3E, F7W
Supply Voltage: Nominal: 7.2 V DC, Negative Ground SBR-14LI
Nominal: 7.4 V DC, Negative Ground FNB-101LI
Operating: 4 - 14 V, Negative Ground (EXT DC JACK)
11 - 16 V, Negative Ground (EXT DC JACK with SDD-13)
Current Consumption: 120 mA (Mono band Receive)
180 mA (Dual band Receive)
80 mA (Mono band Receive, Standby)
110 mA (Dual band Receive, Standby)
50 mA (Mono band Receive, Standby, Saver On “Save Ratio 1:5”)
50 mA (Dual band Receive, Standby, Saver On “Save Ratio 1:5”)
+20 mA (GPS On)
+20 mA (Digital)
400 μA (Auto Power O)
1.6 A (5 W TX, 144 MHz 7.2 V DC)
1.8 A (5 W TX, 430 MHz 7.2 V DC)
Operating Temperature: –4 °F to +140 °F (–20 °C to +60 °C)
Case Size (W x H x D): 2.4” x 4.3” x 1.3” (62 x 110 x 32.5 mm)
(w/ SBR-14LI, w/o knob, antenna and belt clip)
Weight: 10.93 oz (310 g) (with SBR-14LI and Antenna)

FT2DR/DE Technical Supplement
Specications
SPECIFICATIONS-2
Transmier
RF Power Output: 5 W (@ 7.2 V DC or EXT DC )
Modulation Type: F1D, F2D, F3E : Variable Reactance modulation
F7W: 4 FSK (C4FM)
Spurious Emission: USA/EXP version
At least 60 dB below (@TX Power HI, L3)
At least 50 dB below (@TX Power L2, L1)
European version
At least 60 dB below (@TX Power HI, L3, L2)
At least -36 dBm below (@TX Power L1)
Receiver
Circuit Type: Double-Conversion Super heterodyne (NFM, AM)
Single-Conversion Super heterodyne (AM/FM Radio)
Intermodiate Frequencies: 1 st: 47.25 MHz (AM, NFM A Band)
1 st: 46.35 MHz (AM, NFM B Band)
2 nd: 450 kHz (AM, NFM)
Sensitivity: 3 μV for 10 dB SN (0.5 - 30 MHz, @AM)
0.35 μV TYP for 12 dB SINAD (30 - 54 MHz, @NFM)
1 μV TYP for 12 dB SINAD (54 - 76 (88) MHz, @NFM)
1.5 μV TYP for 12 dB SINAD (76 (88) - 108 MHz, @WFM)
1.5 μV TYP for 10 dB SN (108 - 137 MHz, @AM)
0.2 μV for 12 dB SINAD (137 - 140 MHz, @NFM)
0.16 μV for 12 dB SINAD (140 - 150 MHz, @NFM)
0.2 μV for 12 dB SINAD (150 - 174 MHz, @NFM)
1 μV for 12 dB SINAD (174 - 222 MHz, @NFM)
0.5 μV for 12 dB SINAD (300 - 350 MHz, @NFM)
0.2 μV for 12 dB SINAD (350 - 400 MHz, @NFM)
0.18 μV for 12 dB SINAD (400 - 470 MHz, @NFM)
1.5 μV for 12 dB SINAD (470 - 540 MHz, @NFM)
3 μV TYP for 12 dB SINAD (540 - 800 MHz, @NFM)
1.5 μV TYP for 12 dB SINAD (800 - 999 MHz, @NFM, Cellular Blocked)
0.19 μV TYP for BER 1 % (Digital Mode)
Selectivity: NFM, AM 12 kHz / 35 kHz (–6 dB / –60 dB)
AF Output: 700 mW (8 Ωfor 10 % THD 7.2 V) internal speaker
300 mW (8 Ω for 10 % THD 7.2 V) external speaker
Performance specications are nominal, unless otherwise indicated, and are subject to change without no-
tice. Measured in accordance with TIA/EIA-603.

EXPLODED VIEW-1 FT2DR/DE Technical Supplement
Exploded View & Miscellaneous Parts
1. Please order the screw M2.6X30 (P/N;
U00230001).
2. Remove the DIAL KNOB (A) and VOL
KNOB (B).
3. Remove the two screws (C).
4. Turn the M2.6x30 screw several times to af-
x the screw to the bottom right corner.
5. Press the top of the screw toward to a panel
top to remove the CHASSIS Assy from the
front panel.
Removing the Rear Case Assy
screw M2.6X30
(A)
(C)
(C)
(B)
RF-UNIT
CQ0585001 (CE OFF)
CQ0585002 (CE ON)
FRONT CASE ASSY
REF. YAESU P/N Description Qty.
①U9900277 PAN HEAD TAPTITE-B M2X3 #3 3KA 12
②RA1011800 STUD 5
③U07230102 PAN HEAD SCREW M2X3NI #1 1
④RA1084800 WASHER 4.3X2.0 2
⑤U24110020 BIND HEAD TAPTITE-B 2X10SUS 2
⑥U24310020 BIND HEAD TAPTITE-B M3X10SUS 2
⑦U9900293 SPECIAL TAPTITE-B 2X3.5B(CAP) 1
⑧U9900300 TAPPING SCREW M2X4(3KA) 3
⑨U9900278 PAN HEAD TAPTITE-B M2X5 #3 3KA 2
⑩RA6024200 SPECIAL SCREW(M1.4X4) 4
⑪U9900308 SPECIAL SCREW FX0240E M2X4 5
⑫U9900302 PANHEAD TAPTITE-B M1.7X3 #1(3KA) 4
Non-designated parts are available only as part of a designated assembly.
①
②
③
⑦
⑥
⑨
⑧
⑩
④
⑤
CQ0584001
CHASSIS ASSY
w/ SPECIAL NUT (M), PACKING PAD (POW),
O RING (4.8X1.9), O RING (6.5X2),
SHEET(MOTOR), SMA CONNECTOR,
COVER(REAR)
RA6023900
HOLDER(MOTOR)
①
①
M2190034
VIBRATION MOTOR
①
①
①①
①
①
①
①
①
②
②
②
②
SUB-UNIT
RA060450B
SPECIAL NUT(M)
RA1037500
O RING(6.5X2)
Q9001004
ROTARY ENCODER
RA6023400
CHASSIS
RA602350A
SMA CONNECTOR
RA1012800
PACKING PAD (POW)
RA136190A
SHEET(MOTOR)
RA1037400
O RING (4.8X1.9)
RA6023800
COVER(REAR)
RA1512500
SHEET(LCD)
RA6024100
LCD HOLDER
RA1512400
DOUBLE FACE(LCD)
RA6044000
SHEET(14.5X14.5)
RA1107900
PORON SHEET5X15X1
RA110190A
CAPTON TAPE(5X15)
Q7000678
LCD MODULE
RA6043000
SPACER(SD)
RA6041700
DOUBLE FACE TAPE
RA6021400
RUBBER KNOB(PTT)
RA6021500
SUPPORT(PTT)
RA1355300
MIC HOLDER RUBBER
MIC-UNIT
RA6022300
DOUBLE FACE(P-L)
RA6022100
PROTECTOR(L)
RA6022200
DOUBLE FACE
RA6022000
PROTECTOR(R)
RA6023700
GASKET
④
⑤
RA6020600 VOLUME KNOB
※The Material Description was corrected from
"ENCODER KNOB" to "VLOUME KNOB" in accordance
with description of the Operating Manual.
RA602040A DIAL KNOB (ASSY)
※The Material Description was corrected from
"VLOUME KNOB" to "DIAL KNOB" in accordance
with description of the Operating Manual.
RA6021800
CAP(SIDE)
RA6023600
CAP(SW)
RA1359400
MASK SHEET
RA6044100
SHEET(EN514)
⑥
⑧
⑧
⑨
⑩
⑩
⑩
⑪
⑪⑪
⑪
⑪
⑫
⑫
⑫
⑫
CNTL-UNIT
RA6022500
KNOB(TOP)
RA6022400
KEY PAD
RA602310C
LCD SHEET
RA6022800
DOUBLE FACE(SP)
RA6022900
PLATE(SP)
RA604310A
SPACER(SP)
RA6022600
GASKET (SP)
M4090250
SPEAKER
RA6020800
FRONT CASE ASSY
RA6021900
CAP(DC)
RA008890A
O RING
RA603400A
SEAL(REAR)

BLOCK DIAGRAM-1 FT2DR/DE Technical Supplement
Block Diagram

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-1
Introduction and Precautions
The FT2DR/FT2DE has been carefully aligned at
the factory for performance across the specified
amateur bands. Realignment should therefore
not be necessary except in the event of a compo-
nent failure. All component replacement and ser-
vice should be performed only by an authorized
YAESU representative, or the warranty policy may
be voided.
The following procedures cover the sometimes crit-
ical and tedious adjustments that are not normally
required once the transceiver has left the factory.
However, if damage occurs and some parts are re-
placed, realignment may be required. If a sudden
problem occurs during normal operation, it is like-
ly due to component failure; realignment should
not be done until after the faulty component has
been replaced.
We recommend that servicing be performed only
by authorized YAESU service technicians, who are
experienced with the circuitry and fully equipped
for repair and alignment. Therefore, if a fault is
suspected, contact the dealer from whom the trans-
ceiver was purchased for instructions regarding re-
pair. Authorized YAESU service technicians realign
all circuits and make complete performance checks
to ensure compliance with factory specifications
aer replacing any faulty components.
Those who do undertake any of the following
alignments are cautioned to proceed at their own
risk. Problems caused by unauthorized aempts at
realignment are not covered by the warranty pol-
icy. Also, YAESU must reserve the right to change
circuits and alignment procedures in the interest of
improved performance, without notifying owners.
Under no circumstances should any alignment be
attempted unless the normal function and opera-
tion of the transceiver are clearly understood, the
cause of the malfunction has been clearly pinpoint-
ed and any faulty components replaced, and the
need for realignment determined to be absolutely
necessary.
Required Test Equipment
RF Signal Generator with calibrated output level
at 500 MHz
Deviation Meter (linear detector)
 In-line Wameter with 5% accuracy at 500 MHz
50-ohm, 10-W RF Dummy Load
8-ohm AF Dummy Load
Regulated DC Power Supply adjustable from
8 to 16 V DC, 3 A
Frequency Counter: 0.2-ppm accuracy at
500 MHz
AF Signal Generator
AC Voltmeter
DC Voltmeter: high impedance
UHF Sampling Coupler
SINAD Meter
Alignment Preparation & Precautions
A 10-W RF dummy load and in-line wattmeter
must be connected to the main antenna jack in all
procedures that call for transmission; alignment
is not possible with an antenna. After complet-
ing one step, read the next step to see if the same
test equipment is required. If not, remove the test
equipment (except dummy load and wattmeter,
if connected) before proceeding. Correct align-
ment requires the transceiver and test equipment
be maintained at a constant ambient temperature
between 68~86 °F (20~30 °C). When the transceiv-
er is brought into the shop from hot or cold air,
it should be allowed some time to come to room
temperature before alignment. Whenever possible,
alignments should be made with oscillator shields
and circuit boards rmly axed in place. Also, the
test equipment must be thoroughly warmed up be-
fore beginning.
Note: Signal levels in dB referred to in the alignment
procedure are based on 0 dBμ=0.5 μV (closed circuit).
Important Notice
Do not adjust the alignment menus that are
not mentioned in this manual.

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-2
Internal System Alignment Routine
This uses a programmed routine in the transceiver
which simplies many previously complex discrete
component seings and adjustments with digital-
ly-controlled settings via front panel buttons and
LCD indications.
1. To begin, set the transceiver to the VFO mode
on the "A-Band, FM-mode" in the "Mono" band
mode.
2. Program a password for the Alignment
(AH060M) according to the following proce-
dure:
1) Press and hold the [DISP]key for one second
to enter the Set mode.
2) Touch [DISPLAY] briefly to enable adjust-
ment of this Set Mode Item.
3) Rotate the DIAL knob to select Set Mode Item
8: OPENING MESSAGE.
4) Press the [DISP] key briey to enable adjust-
ment of this Set Mode Item.
5) Rotate the DIAL knob to select Set Mode Item
MESSAGE.
6) Press the [DISP] key briey to enable adjust-
ment of this Set Mode Item.
7) Input the password "AH060M" (toggle the
alphabet input screen, and the number input
screen when necessary).
8) When you have completed the password,
press the [DISP]key briefly, then press the
PTT switch to exit to normal operation.
Note: Remember to delete the password "AH060M"
from the Set Mode Item 8: OPENING MESSAGE when
the alignment adjustments are nished by pressing and
holding in the [GM] key for two seconds (as in step 8
above).
3. Press the [PWR]switch for two seconds to turn
the transceiver "o".
4. Press and hold in the [GM]key while powering
the transceiver "on" again. The transceiver will
enter the adjustment mode, and the display
will show the rst alignment seing. Thereaf-
ter, the frequencies used during alignment will
automatically be set without action by the tech-
nician.
In the alignment process, each adjustment is se-
lected by rotating the DIAL knob. The alignment
is performed by: pressing the [V/M]key injecting a
signal of the required frequency and level; making
the adjustment; and then pressing the [V/M]key
again (the "Data" will disappear from the display),
to store the adjustment.
To exit the alignment routine, press the [GM]key.
After performing the system alignment in its en-
tirety, individual settings can be returned to and
adjusted individually, should the need arise.
As each transceiver is individually optimized at
the factory, the precise seings for the transceiver
on your bench may be slightly dierent.
PLL Reference Frequency Adjustment (PLL REF)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "PLL REF".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the frequency counter seing
is 440.000 MHz (±100 Hz).
Release the PTT switch, then press the [V/M]
buon (the "Data" will disappear from the dis-
play).
Figure 1: TX Alignment Setup
Regulated
9.4 VDC P.S.
Sampling
Coupler
50-ohm RF
Dummy Load
In-Line
Wattmeter
Deviation
Meter
Frequency
Counter

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-3
A-Band 430 MHz Band Adjustment
Receiver Sensitivity Adjustment (TUNE DEV)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 435.100
MHz, at a level of -10.0 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIAL knob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Figure 2: RX Alignment Setup
Squelch Hysteresis Conrmation (HIS SQL)
Rotate the DIAL knob to select the Alignment
Menu "HIS SQL".
 Conrm that the alignment value is "0".
Squelch Threshold Adjustment (THLD SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "THLD SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -12 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Threshold level
Press the [V/M]button (the "Data" will disap-
pear on the display).
Tight Squelch Adjustment (TIGH SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter S-1 Adjustment (S1 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter Full-Scale Adjustment (S9 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter Full Scale level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Regulated
9.4 VDC P.S.
SINAD
Meter
8-ohm
AF Load
RF Signal
Generator
AF Generator

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-4
TX Power (HI) Adjustment (HI POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "HI POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter reading is
5.0 W (±0.05 W).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
TX Power (L3) Adjustment (L3 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L3 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
2.5 W (±0.1 W).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
TX Power (L2) Adjustment (L2 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L2 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
0.85 W (+0.05/-0.1 W).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
TX Power (L1) Adjustment (L1 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L1 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
0.1 W (±0.05 W).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
Digital TX Deviation Adjustment (DIG DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "DIG DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the [BAND]button to select the
“PLL REF”. (Don't touch alignment menu
"VCO MOD")
Press the PTT switch to transmit and rotate the
DIAL knob so that the Deviation Meter seing is
4.5 kHz ± 0.1 kHz.
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
TX Deviation Adjustment (MAX DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "MAX DEV".
Set the AF Signal Generator output to 50 mVrms
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Deviation Meter seing
is 4.2 kHz ± 0.05 kHz (USA version) or 4.5 kHz
± 0.05 kHz (EXP, EU versions).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-5
CTCSS TX Deviation Adjustment (TONE DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TONE DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit without the
microphone input and rotate the DIAL knob so
that the Deviation Meter seing is 0.7 kHz (±0.1
kHz).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
DCS TX Deviation Adjustment (DCS DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "DCS DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit without the
microphone input and rotate the DIAL knob
so that the Deviation Meter setting is 0.7 kHz
(±0.1 kHz).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
A-Band 50 MHz Band Adjustment
Press the [BAND]key to select the 50 MHz Ama-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
Receiver Sensitivity Adjustment (TUNE DEV)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 52.100
MHz, at a level of -8 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIAL knob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Squelch Hysteresis Conrmation (HIS SQL)
Rotate the DIAL knob to select the Alignment
Menu "HIS SQL".
 Conrm that the alignment value is "0".
Squelch Threshold Adjustment (THLD SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "THLD SQL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to read the Squelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-6
Tight Squelch Adjustment (TIGH SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter S-1 Adjustment (S1 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 52.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter Full-Scale Adjustment (S9 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 52.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter Full Scale level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
A-Band 144 MHz Band Adjustment
Press the [BAND]key to select the 144 MHz Ama-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
Receiver Sensitivity Adjustment (TUNE DEV)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 145.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIAL knob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Squelch Hysteresis Conrmation (HIS SQL)
Rotate the DIAL knob to select the Alignment
Menu "HIS SQL".
 Conrm that the alignment value is "0".
Squelch Threshold Adjustment (THLD SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "THLD SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -12 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-7
Tight Squelch Adjustment (TIGH SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter S-1 Adjustment (S1 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter Full-Scale Adjustment (S9 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter Full Scale level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
TX Power (HI) Adjustment (HI POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "HI POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
4.9 W (±0.05 W).
Release the PTT switch, then press the [V/M]
button (the "Data" will disappear on the dis-
play).
TX Power (L3) Adjustment (L3 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L3 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
2.5 W (±0.1 W).
Release the PTT switch, then press the [V/M]
button (the "Data" will disappear on the dis-
play).
TX Power (L2) Adjustment (L2 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L2 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
0.9 W (+0.05/-0.1 W).
Release the PTT switch, then press the [V/M]
button (the "Data" will disappear on the dis-
play).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-8
TX Power (L1) Adjustment (L1 POWER)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "L1 POWER".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Power Meter setting is
0.1 W (±0.05 W) (USA, EXP versions), 50 mW (+30
mW/-0 mW) (EU version).
Release the PTT switch, then press the [V/M]
button (the "Data" will disappear on the dis-
play).
Digital TX Deviation Adjustment (DIG DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "DIG DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the [BAND]button to select the
“DIG DEV”. (Don't touch alignment menu
"PLL REF")
Press the PTT switch to transmit and rotate the
DIAL knob so that the Deviation Meter seing is
4.5 kHz ± 0.1 kHz.
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
TX Deviation Adjustment (MAX DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "MAX DEV".
Set the AF Signal Generator output to 50 mVrms
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit and rotate the
DIAL knob so that the Deviation Meter seing
is 4.2 kHz ± 0.05 kHz (USA version) or 4.5 kHz
± 0.05 kHz (EXP/EU versions).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
CTCSS TX Deviation Adjustment (TONE DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TONE DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit without the
microphone input and rotate the DIAL knob so
that the Deviation Meter seing is 0.7 kHz (±0.1
kHz).
Release the PTT switch, and then press the
[V/M]button (the "Data" will disappear on the
display).
DCS TX Deviation Adjustment (DCS DEV)
Connect the test equipment as shown in Figure 1:
TX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "DCS DEV".
Press the [V/M]button (the "Data" will appear
on the display).
Press the PTT switch to transmit without the
microphone input and rotate the DIAL knob
so that the Deviation Meter setting is 0.7 kHz
(±0.1 kHz).
Release the PTT switch, then press the [V/M]
button (the "Data" will disappear on the dis-
play).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-9
B-Band 430 MHz Band Adjustment
NOTICE: Do not touch the following Alignment
Menus in B-Band 430 MHz Band Adjustment:
"PLL REF "
"HI POWER"
"L3 POWER"
"L2 POWER"
"L1 POWER"
"MAX DEV"
"TONE DEV"
"DCS DEV"
Press the [A/B]key to change the operating band
to the "B-Band".
Press the [BAND]key to select the 430 MHz Ama-
teur band.
Note: When the transceiver recalls Alignment Menu
"PLL REF", the [A/B]and [BAND] key operation is
ignored. In this case, rotate the DIAL knob to select an
Alignment Menu other than "PLL REF".
Receiver Sensitivity Adjustment (TUNE DEV)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 435.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIAL knob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Squelch Hysteresis Conrmation (HIS SQL)
Rotate the DIAL knob to select the Alignment
Menu "HIS SQL".
 Conrm that the alignment value is "0".
Squelch Threshold Adjustment (THLD SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "THLD SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Tight Squelch Adjustment (TIGH SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter S-1 Adjustment (S1 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-10
FM S-Meter Full-Scale Adjustment (S9 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 435.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter Full Scale level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
B-Band 144 MHz Band Adjustment
NOTICE: Do not touch the following Alignment
Menus in B-Band 144 MHz Band Adjustment:
"PLL REF"
"HI POWER"
"L3 POWER"
"L2 POWER"
"L1 POWER"
"MAX DEV"
"TONE DEV"
"DCS DEV"
Press the [BAND]key to select the 144 MHz Ama-
teur band.
Note: When the transceiver recalls Alignment
Menu "PLL REF", the [A/B]and [BAND]key oper-
ation is ignored. In this case, rotate the DIAL knob
to select an Alignment Menu other than "PLL REF".
Receiver Sensitivity Adjustment (TUNE DEV)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TUNE DEV".
Set the RF Signal Generator output to 145.100
MHz, at a level of -10 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Rotate the DIAL knob for maximum deection
on the SINAD meter.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Squelch Hysteresis Conrmation (HIS SQL)
Rotate the DIAL knob to select the Alignment
Menu "HIS SQL".
 Conrm that the alignment value is "0".

FT2DR/DE Technical Supplement
Alignment
ALIGNMENT-11
Squelch Threshold Adjustment (THLD SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "THLD SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -11 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Threshold level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
Tight Squelch Adjustment (TIGH SQL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "TIGH SQL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -4 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the Squelch
Tight level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter S-1 Adjustment (S1 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S1 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of -7 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter S-1 level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
FM S-Meter Full-Scale Adjustment (S9 LEVEL)
Connect the test equipment as shown in Figure 2:
RX Alignment Setup.
Rotate the DIAL knob to select the Alignment
Menu "S9 LEVEL".
Set the RF Signal Generator output to 145.100
MHz, at a level of +20 dBμ, ±3.5 kHz deviation
with a 1 kHz audio tone.
Press the [V/M]button (the "Data" will appear
on the display).
Press the [X]key two times to store the FM
S-Meter Full Scale level.
Press the [V/M]button (the "Data" will disap-
pear on the display).
This completes the internal alignment routine
for all bands. To save all settings and exit, touch
[WRITE].

FT2DR/DE Technical Supplement
RF-1
Circuit Diagram
RF Unit (Lot. 1-2)

FT2DR/DE Technical Supplement
RF-2
A aB bC c
1 1
2 2
3 3
44
5 5
Parts Layout
Side A Side B
RF Unit (Lot. 1-2)

FT2DR/DE Technical Supplement
RF-3
RF Unit (Lot. 3)
Circuit Diagram

FT2DR/DE Technical Supplement
RF-4
A aB bC c
1 1
2 2
3 3
44
5 5
RF Unit (Lot. 3)
Parts Layout
Side A Side B
