Yale SL7000 Series User manual

Digital Lock Set
SL7000 Series
Digital Lock Set
Installation Instructions
Digital Lock Set-Changing the Code Number
6. Spindle Spring
7. Mortice Lock - 60mm Backset with
Strike Plate, Fixing Screws x 5,
Cylinder Retaining Screw x 1
8. Euro Profile Cylinder with 2 Keys
9. Cylinder Escutcheons
10. Instructions & Template
11. Allen key
5. 8mm Square Spindle (Drive Bar) x 78mm
2. Neoprene Seals x 2
(2 Spare 70mm & 2 Spare 80mm).
3. Digital Interior Code Pad Assembly
1. Digital Exterior Code Pad Assembly
4. Fixing Screws x 2 - 60mm
3
4
4
2
6
2
5
1
Components
* To cancel pull down outside handle and turn the passage knob
back to the 12 o’clock position.
and "Passage Mode is now set to give free access without
from 12 o'clock to 9 o'clock “P” position. Release the handle
* Turn the passage knob of Digital Interior Code Pad Assembly
Pad Assembly to 4 o'clock position and hold the handle in
* Enter correct code, turn the handle of Digital Exterior Code
passage
Digital Lock Set-Passage Mode Function
downward position.
the need to enter the code.
knob
door engaging the square spindle in the handle hub.
* Screw both side together using the fitting screws top and bottom.(FIG 1)
* Locate the Interior Handle Assembly on the inside of the
square bar engages the hub in the mortice lock assembly.
the spindle bar and spring in position and ensuring that the
Select the fixing screws to suit the door thickness.
* Fit the neoprene seals to both the Exterior Code Pad
* Hold the Exterior Code Pad Assembly onto the door with
and Interior Handle Assemblies.
A LOCKOUT BEFORE CLOSING THE DOOR.
NOTE: CHECK THAT THE CODE WORKS TO AVOID
DO NOT overtighten the fixing screws-this may cause
* Test the mechanism to ensure that the lock functions
* Before tightening of fixing screws make sure the lock is vertical
7) Mounting the Lock
FIG 1
distortion and lead to poor operation.
correctly and moves easily.
Assembly
Interior Code Pad
9
8
7
code
select
buttons
11
1) The digital lock is supplied with factory setcodes: C13579
2) Depress the code select button and slide the selector
from “NON CODE” to “CODE” position and the active
number is selected as shown by the RED indicator.
3) Any numbers not required to be part of the active code
should have the code selectors parked in the
“NON CODE” position.
4) The “CLEAR” button MUST always be used as the
first digit of a code.
5) For best security the code number selected should
contain 4 or 5 digits.
6) Check that the new code works before installation.
NOTE: THE CODE IS NON-SEQUENTIAL
MAY BE ENTERED IN ANY ORDER
Q25078 0312-2

Digital Lock Set
Installation Instructions
Handing the Latch Bolt
* Insert a flat blade screwdriver through the back of the lock
case and press on the latch handing screw until the latch bolt
is clear of the face plate.
* Then turn the screw 180 degrees to achieve required handing.
* Fit the lock into the mortice ensuring that the lock face plate is
flush with the edge of the door and screw into place
Fitting the Strike
* Close the door against the door frame and transfer the centre of
the latch bolt onto the jamb.
* Position the strike plate on the door so that it fits against the flat
of the latch bolt
* Close the door and mark the position of the strike plate on the door jamb
* Use the strike plate as a template and mark the inner & outer
edges on the jamb
* Cut a 1mm deep rebate so that the strike is flush with the door jamb
* Drill and chisel out hole to accomodate latch and deadbolt
* Fit strike using only the central screw at first to ensure that it is
positioned correctly
Spindle Length
* Maximum spindle projection on inside of door is 15mm.
* Trim spindle length to suit door thickness.
5) Handing and Fitting the Mortice Lock
6) Spindle Length
(HOLE A)
Assembly
(HOLE B)
Interior Handle
Head Cap Screw
Hexagon Socket
BLACK HANDING
SCREWS
4) Handing the Digital Interior Handle Assembly
sure the lever handle is in the horizontal position and the
handle hub aligns with the mortice lock spindle hub.
* Tightening the Hexagon Socket Head Cap Screw making
the spindle hub and rotate the lever handle from right to left.
* Loosen the Hexagon Socket Head Cap Screw located inside
To change factory handing to suit left hand door:
* Remove BLACK handling screw from hole A and relocate
Hole A is for left hand door and Hole B for right hand door.
Handing is for a right hand door with black factory handing
screw located in Hole B.
LEVEL HANDLE
Rotation
it in hole B.
15mm
Max
Digital Lock Set
Installation Instructions
2) Preparing the Door
Viewed from the OUTSIDE
1) Check the Handing of Your Door
(Code Pad Side),your door is
SPECIAL NOTES:
Before commencing installation check that all parts are working correctly.
* Digital Exterior Code Pad Assembly:Enter code C13579, turn handle in both directions.The handle
should turn and return freely under spring pressure.
If you need to change the code you should change and test prior to fitting. - see the Code Change
instructions
right handed if the hinges are
NOTE: ALL UNITS ARE SET
AT THE FACTORY TO SUIT
RIGHT HAND HUNG DOORS.
on the right and your door is
left handed if the hinges are
on the left.
Establish the height that the lock is to be mounted on door and mortice
out for the lock body as detailed on the template.
Fold template and tape to the face of the door aligning the centre line
of latch hub with the mortice lock latch hub.
With the lock body removed, drill mounting screw, cylinder and
escutcheon holes as shown.
NOTE: TO PREVENT DAMAGE TO THE DOOR FACE FROM DRILL
BREAKTHROUGH, MARK BOTH SIDES OF DOOR & DRILL HOLES
HALF WAY THROUGH FROM EACH SIDE
The external key pad handle is fitted with a
clutch to prevent damage from attempted
forced entry. To change the handing first
mount the keypad to the door as per
instruction 6) then apply force to rotate the
handle to the correct handing.
Rotation
3) Handing the Digital Exterior Code
Pad Assembly
HANDLE
HANDLE
OUTSIDE OUTSIDE
Right Hand
Left Hand Left Hand Right Hand
(LH )( RH ) ( LH ) ( RH )
