12’ x 12’ MERIDIAN GAZEBO
with ALUMINUM ROOF
Installaon and Operang Instrucons – YM11769
Yardistry – North America
Toll Free Customer Support: 1.888.509.4382
[e-mail]
www.yardistrystructures.com
Yardistry / Selwood Products – Europe
Customer Support: [phone]
[e-mail]
www.selwoodproducts.com
Revised 06-18-2019
HEIGHT:
10’6” or 3.2m
Y40000-769
41
[12’ 1-3/16”]
[12’ 1-3/16”]
3.69 m
3.69 m

2 [email protected]
Important Safety Notice!
Yardistry components are intended for privacy, decorative and ornamental use only.
Product is NOT INTENDED for the following:
• A safety barrier to prevent unsupervised access to pools, hot tubs, spas or ponds.
• As load bearing support for a building, structure, heavy objects or swings.
• Used in structures that trap wind, rain or snow that would create extra load on the
product.
Accumulated snow must be removed from roof.
DO NOT climb or walk on roof for any reason.
Permanent structures may require a building permit. As the purchaser and or installer of this
product you are advised to consult local planning, zoning and building inspection departments for
guidance on applicable building codes and/or zoning requirements.
Wood is NOT ame retardant and will burn. Grills, re pits and chimineas are a re hazard if
placed too close to a Yardistry structure. Consult user’s manual of the grill, re pit or chimnea for
safe distances from combustible materials.
Wear gloves to avoid injury from possible sharp edges of individual elements before assembly.
During installation, follow all safety warnings provided with your tools and use OHSA
approved safety glasses. Some structures may require two or more people to install safely.
Check for underground utilities before digging or driving stakes into the ground!
It is important during assembly to closely follow the instructions, complete the assembly
on a solid level surface and that you follow the instruction to square up, level and anchor the
structure, this will reduce the gap at wood connections during assembly.
General Information: Wood components are manufactured with Cedar (C. Lanceolata)
which is protected with factory applied water-based stain. Knots, small checks (cracks)
and weathering are naturally occurring and do not a󰀨ect the strength of the product.
Annual application of a water-based water repellent sealant or stain is important and will
help reduce weathering and checks.
www.yardistrystructures.com
Questions?
Call toll free or write us at:
1 [phone]
[email protected]
Patents Pending
General Information

3 [email protected]
July 27, 2018
Limited Warranty
This Warranty gives you specic legal rights. You may have other rights as well which vary from state to state
or province to province. This warranty excludes all consequential damages, however, some states/provinces
do not allow the limitation or exclusion of consequential damages, and therefore this limitation may not apply
to you.
Yardistry warrants that this product is free from defect in materials and workmanship for a
period of one (1) year from the original date of purchase. In addition, for any product with
lumber, all lumber is warranted for ve (5) years against rot and decay. This warranty applies
to the original owner and registrant and is non-transferable.
Regular maintenance is required to assure the integrity of your product and is a requirement of
the warranty. This warranty does not cover any inspection costs.
This Limited Warranty does not cover:
• Labour for replacement of any defective item(s);
• Incidental or consequential damages;
• Cosmetic defects which do not a󰀨ect performance or integrity;
• Vandalism; improper use or installation; acts of nature, including but not limited to wind,
storms, hail, oods, excessive water exposure;
• Minor twisting, warping, checking or any other natural occurring properties of wood that do
not a󰀨ect performance or integrity.
Yardistry products have been designed for safety and quality. Any modications made to
the original product could damage the structural integrity of the product leading to failure
and possible injury. Yardistry cannot assume any responsibility for modied products.
Furthermore, modication voids any and all warranties.
This product is warranted for RESIDENTIAL USE ONLY. Yardistry disclaims all other
representations and warranties of any kind, express or implied.

4 [email protected]
Instructions for Proper Maintenance
Your Yardistry structure is designed and constructed of quality materials. As with all outdoor
products it will weather and wear. To maximize the enjoyment, safety and life of your structure
it is important that you, the owner, properly maintain it.
Symbols:
Throughout these instructions symbols are provided in the top, right-hand corner of the page.
If you dispose of your Yardistry structure: Please disassemble and dispose of your
unit so that it does not create any unreasonable hazards at the time it is discarded. Be
sure to follow your local waste ordinances.
HARDWARE:
• Check metal parts for rust. If found, sand and repaint using a non-lead paint complying
with 16 CFR 1303.
• Inspect and tighten all hardware after completion of assembly; after rst month of use; and
then annually. Do not over-tighten as to cause crushing and splintering of wood.
• Check for sharp edges or protruding screw threads, add washers if required.
WOOD PARTS:
• Applying a water repellent or stain (water-based) on a yearly basis is important
maintenance to maintain maximum life and performance of the product.
• Check all wood members for deterioration, structural damage and splintering. Sand down
splinters and replace deteriorated wood members. As with all wood, some checking and
small cracks in grain is normal
• Some gapping may occur at some wood connections.
• Tape Measure
• Carpenters Level
• Standard or Cordless Drill
• #2 Phillips Bit or Screwdriver
• 7/16” & 9/16” Wrench
Assembly Guides
• 8’ Step Ladder
• Safety Glasses
• Adult Helper
• Safety Gloves
• Hard Hat
Tools Required:
• Use Help, where this is shown, 2, 3 or 4
people are required to safely complete
this step. To avoid injury or damage to the
assembly make sure to get some help.
• Use a measuring tape to assure proper
location
• Pre-drill a pilot hole before fastening
screw or lag to prevent splitting of wood.
• 6’ Step Ladder x 2
• Square
• Rachet
• 7/16, 1/2 & 9/16 Socket

5 [email protected]
Following are some helpful tips to make the assembly process smooth and e󰀩cient.
PRE-ASSEMBLIES:
(i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc)
• Work on a raised, solid and at surface such as, a table or saw horse.
• Keep all connections ush where shown in the instructions.
• When assembling the beams keep parts at, straight and snug when
connecting.
METAL PARTS:
• Roong material may have sharp edges, wear safety gloves.
• Remove all plastic covering, on both sides of the metal panels, directly
before installing each piece.
• Place roong material on a non-abrasive surface before and after assembly
as it can bend, dent and scratch easily.
• The roong screws can easily crush the roof panels and roof edges when
using a power drill. We recommend hand tightening the roong screws so
they sit snug and tight to the roong material.
Assembly Tips

6 [email protected]
Note: It is critically important you start with square, solid and level footings, concrete
pad or deck to attach your Pergola Room.
We supply Post Mounts with this structure which gives you the exibility to permanently install your structure
to a pre-existing or new wood or concrete surface.
• The hardware to attach the Post Mount to the structure is included.
• The hardware to mount the structure permanently will need to be purchased separately at your local
hardware store.
If you are mounting to concrete footers see below for the correct locations and placement. Please double
check for possibility of any underground utilities such as gas, telephone, cable or sprinkler lines.
Following are some examples of how to mount the structure to wood or concrete surfaces.
Refer to your local building and city codes, ordinances, neighbourhood covenants, or height restrictions
regarding this type of structure for guidance on acceptable installation requirements.
Permanent Installation Examples
Concrete Footer
To
Required
Depth
Anchoring Hardware not included
Post Mount
42
[14’ 1-3/4]
Post to Post
Post to Post
[11’ 0”]
Plinth to Plinth
[9’ 10-1/2”]
Post to Post
[11’ 0”]
Plinth to Plinth
[9’ 10-1/2”]
3.35 m
3.35 m 4.31 m
3.01 m
3.01 m

7 [email protected]
Permanent Installation Examples cont.
Anchoring Hardware not included
Anchoring Hardware not included
Concrete Patio [min. 3.66 m x 3.66 m (12’ x 12’)] with 1.83 m (6”) clearance on all sides
Wood Deck [min. 3.66 m x 3.66 m (12’ x 12’)] with 1.83 m (6”) clearance on all sides
40
40
Anchoring Hardware (not included)
Post Mount

8 [email protected]
M Post
152.4 x 152.4 x 2336.8mm (6 x 6 x 92")
4pc. (696) -
Y70131-696
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly.Actual dimensions may be smaller or larger.
Y50131-717
38.1 x 139.7 x 2413mm (1-1/2 x 5-1/2 x 95")
4pc. (717) - Beam
Y50131-422
19.1 x 133.4 x 190.5mm (3/4 x 5-1/4 x 7-1/2")
16pc. (422) - Plinth
Y70131-705
34.9 x 190.5 x 1015mm (1-3/8 x 7-1/2 x 40")
4pc. (705) - Gusset Right
Y70131-706
34.9 x 190.5 x 1015mm (1-3/8 x 7-1/2 x 40")
4pc. (706) - Gusset Left
Y50131-333
25.4 x 88.9 x 2631.5mm (1 x 3-1/2 x 103-5/8")
4pc. (333) - Rafter Corner Left
Beam End Short
38.1 x 139.7 x 584.2mm (1-1/2 x 5-1/2 x 23")
8pc. (720) -
Y50131-720
Beam End Left
38.1 x 139.7 x 1790.7mm (1-1/2 x 5-1/2 x 70-1/2")
4pc. (718) -
Y50131-718
Beam End Right
38.1 x 139.7 x 1790.7mm (1-1/2 x 5-1/2 x 70-1/2")
4pc. (719) -
Y50131-719
Rafter Corner Right
25.4 x 88.9 x 2631.5mm (1 x 3-1/2 x 103-5/8")
4pc. (334) -
Y50131-334
Y50131-339
31.8 x 76.2 x 1062mm (1-1/4 x 3 x 41-13/16")
4pc. (339) - Rafter Short Left
Strap Short
31.8 x 82.6 x 1561.3mm (1-1/4 x 3-1/4 x 61-7/16")
4pc. (337) -
Y50131-337
Y50131-340
31.8 x 76.2 x 1937.1mm (1-1/4 x 3-1/4 x 76-1/4")
4pc. (340) - Rafter
Y50131-342
31.8 x 82.6 x 1866.9mm (1-1/4 x 3-1/4 x 73-1/2")
4pc. (342) - Fascia Right
Strap
31.8 x 82.6 x 2628.1mm (1-1/4 x 3-1/4 x 103-7/16")
4pc. (336) -
Y50131-336
Y50131-341
31.8 x 82.6 x 1866.9mm (1-1/4 x 3-1/4 x 73-1/2")
4pc. (341) - Fascia Left Y50131-338
31.8 x 76.2 x 1062mm (1-1/4 x 3 x 41-13/16")
4pc. (338) - Rafter Short Right
Y70131-785
152.4 x 152.4 x 2336.8mm (6 x 6 x 92")
1pc. (785) - Electrical Post

9 [email protected]
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc. - Roof Peak Set
(Y70829-221)
1pc.
Peak Post
(Y01000-094)
1pc.
1/4" Nut
(Y08490-200)
1pc. - Weather Seal -
Ridge Clip (8Pk)
(Y70818-074)
1pc.
Spring Clip
(Y09490-001)
1pc. - Roof To Post
Bracket Set (4Pk)
(Y70829-070)
1pc.
Carriage Bolt
(Y07490-260)
4pc. - Left Long Panel
(Y01033-097)
1pc.
Peak Loop
(Y20018-003)
1pc. - Corner Cap Set (4Pk)
(Y70833-103)
1pc. - Roof Panel Set
(Y70833-084)
1pc. - Gazebo ID Plaque
(Y70800-104)
2pc. - 50mm
Hook
(Y00418-050)
4pc.
Ridge Cap Long 81.5
(Y01033-131)
4pc. - Left Short Panel
(Y01033-099)
8pc. Ridge Clip 102.5 - (Y01033-133)
4pc. - Right Long Panel
(Y01033-098)
4pc. - Right Short Panel
(Y01033-100)
4pc.
Ridge Cap Short 25.2
(Y01033-132)
1pc. - Post
Mount Set (8Pk)
(Y70819-109)
4pc. Roof Edge Left - (Y01033-091)
4pc. Roof Edge Right - (Y01033-092)
2pc.
Roof Peak Bracket
(Y00429-068)
1pc. - Roof To Beam
Bracket Set (12Pk)
(Y70829-151) 1pc.
Peak Cap (Y01033-095)

10 [email protected]
Hardware Identification ( )
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
1pc. - 1/8" Drill Bit
(Y00400-002)
80pc. Wood Screw #8 x 2 1/2" - (Y06091-522)
1pc. #2 x 2" Robertson Driver (Y00400-005)
40pc. Pan Screw #10 x 1-1/4"
(Y06491-711)
8pc. - 3/8" Lock Nut
(Y08318-803)
52pc. 5/16" Lock Washer
(Y05318-300)
52pc. 5/16 - T-Nut
(Y08518-300)
24pc. Hex Bolt 5/16 x 1-1/2" - (Y07718-312)
8pc. Lag Screw 5/16 x 4-3/4" - (Y06218-343)
22pc. Pan Screw #8 x 1"
(Y06491-510)
208pc. Hex Roofing Screw
#8x 1" (Y06733-510)
160pc. Wood Screw #8 x 1-1/2"
(Y06091-512)
24pc. Sheet Metal Screw
#8 x 3/4"
(Y06433-503)
1pc. - Hex Driver
(Y00400-004)
12pc. 1/4 x 2-3/4 Hex Bolt - (Y07718-223)
36pc. Pan Screw #12 x 1-1/2"
(Y06491-612)
108pc.
1/4-5/16 x 1-1/4" Large Washer
(Y05118-311)
56pc. Wood Screw #8 x 2 1/4" - (Y06091-521)
12pc. - 1/4" Lock Nut
(Y08318-203)
40pc. Wood Screw #7 x 3/4"
(Y06091-003)
16pc.
3/8 x 1-1/4" Large Washer
(Y05118-811)
12pc. Hex Bolt 5/16 x 1-1/4"
(Y07718-311)
16pc. Hex Bolt 5/16 x 3-3/4" - (Y07718-333)
8pc. Hex Bolt
3/8 x 9-1/2"
(Y07718-892)
24pc. Hex Lag Screw 1/4 x 1-15/16" with #12 Shank - (Y06218-219)

11 [email protected]
PRODUCT NUMBER: YM11769
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 3)
STOP STOPSTOP STOP
1-888-509-4382
[email protected]
C. Read the assembly manual completely, paying special attention to ANSI
warnings; notes; and safety/maintenance information on pages 1 - 4.
• Follow the instructions in order.
• This structure is designed to be assembled and installed ideally by four
people, DO NOT attempt to install alone.
• Consider the slope of elevation where you plan to install the structure. Also, check
for gas, telephone, other utilities or sprinkler line locations prior to excavating any
holes.
D. Before you discard your cartons ll out the form below.
• The carton I.D. stamp is located on the end of each carton.
• Please retain this information for future reference. You will need this information if
you contact the Consumer Relations Department.
• Each step indicates which bolts and/or screws you will need for assembly, as
well as any at washers, lock washers, t-nuts or lock nuts.
A. This is the time for you to inventory all your hardware, wood and accessories,
referencing the parts identication sheets. This will assist you with your
assembly.
Step 1: Inventory Parts - Read This Before Starting Assembly
B. If there are any missing or damaged pieces or you need assistance with
assembly please contact the consumer relations department directly. Call us
before going back to the store.

12 [email protected]
12 X 12 Meridian
1
12 X 12 Meridian
1
A: At the bottom of each (696) M Posts insert two 5/16” T-Nuts as shown in g. 2.1 and 2.2.
B: At the bottom of each (696) M Post place two Post Mounts tight to the bottom and inside faces as shown in g.
2.1 and 2.2. Loosely attach with one 5/16 x 1-1/4” Hex Bolt (with 5/16” lock washer and 1/4-5/16” large washer) per
mount so they connect to the T-Nuts.
C: On each side of the Posts, place one (422) Plinth ush to the bottom and attach with four #8 x 1-1/2” Wood
Screws per plinth. Rounded edges on top. (g. 2.1 and 2.3)
D: From the bottom of each Post Mount attach to posts with two #8 x 1-1/2” Wood Screws per mount and then from
the inside with two #10 x 1-1/4” Pan Screws per mount These screws are installed at a slight angle. Tighten all
bolts. There will be four M Post Assemblies. (g. 2.4)
12 X 12 Meridian
1
12 X 12 Meridian
1
Step 2: Post Assemblies
HardwareWood Parts
Fig. 2.2
(422) Plinth
4 x (696) M Post
16 x (422) Plinth
Top
Bottom #8 x 1-1/2” Wood Screws
(x 2 per Post Mount, from
bottom)
#8 x 1-1/2”
Wood Screws
(x 4 per Plinth)
Post
Mount
Fig. 2.3
16 x #10 x 1-1/4” Pan Screw
80 x #8 x 1-1/2” Wood Screw
8 x Post Mount
8 x 5/16” T-Nut
8 x 5/16 x 1-1/4” Hex Bolt
(with 5/16” lock washer, 1/4-5/16” large washer)
Fig. 2.1
Post
Mount
(696) M Post
Rounded
Edge on Top
Fig. 2.4
Post
Mount
#10 x 1-1/4” Pan Screws (x 2
per Post Mount, from inside)
1/4 - 5/16”
Large Washer
5/16” Lock
Washer
5/16 x 1-1/4”
Hex Bolt
5/16” T-Nut (x 2
per Post)
Post
Mount
(696) M Post
(696) M
Post
(696) M Post

13 [email protected]
Step 3: Beam Assembly
Part 1
HardwareWood Parts
A: Connect one (718) Beam End Left and one (719) Beam End Right using two 5/16 x 1-1/2” Hex Bolts (with
5/16” lock washer, 1/4 - 5/16” large washer and 5/16” t-nut) as shown in g. 3.1 and 3.2.
B: Connect one (720) Beam End Short to each end of one (717) Beam using two 5/16 x 1-1/2” Hex Bolts (with
5/16” lock washer, 1/4 - 5/16” large washer and 5/16” t-nut) per end as shown in g. 3.1 and 3.2.
C: Repeat Steps A and B three more times to make four Beam Short Assemblies and four Beam End
Assemblies.
4 x (718) Beam End Left
4 x (719) Beam End Right
8 x (720) Beam End Short
4 x (717) Beam
24 x 5/16 x 1-1/2” Hex Bolt
(5/16” lock washer, 1/4-5/16” large washer, 5/16” t-nut)
(718) Beam
End Left
Fig. 3.1
Fig. 3.2
1/4 -5/16”
Large Washer
5/16 x 1-1/2”
Hex Bolt
5/16”
T-nut
Tight
(719) Beam
End Right
(717) Beam
(720) Beam
End Short
(720) Beam
End Short
5/16” Lock
Washer
Make sure bolt heads
are on the outside of
each Beam Assembly

14 [email protected]
3
3
Hardware
72 x #8 x 2-1/2” Wood Screw
Fig. 3.3
Beam Short
Assembly
Fig. 3.4
Flush
Beam End
Assembly
Step 3: Beam Assembly
Part 2
D: Place one Beam Short Assembly on one Beam End Assembly so the ends are ush. Match the bolt holes in
each (720) Beam End Short with the bolt holes in (718) Beam End Left and (719) Beam End Right. Attach with
18 #8 x 2-1/2” Wood Screws. (g. 3.3 and 3.4)
E: Repeat Step D three more times to make four Beam Assemblies.
Flush
Beam Short
Assembly
Beam End
Assembly
#8 x 2-1/2” Wood
Screws (x 18 per
assembly)
(718) Beam
End Left
(719) Beam
End Right
(720) Beam
End Short
(720) Beam
End Short
Match bolt holes

15 [email protected]
31
29
Step 4: Frame Assembly and Anchoring
Part 1
Fig. 4.1
A: Move your Post Assemblies to the nal location. Make sure the ground is at and level before continuing
assembly.
B: With one person at each Post stand two complete Post Assemblies. A third person places one Beam
Assembly against the outside of each Post, ush to the tops and outside corners. Notice bolt hole orientation on
the Beam Assembly. A fourth person attaches Beam to Post with one 3/8 x 10-1/2” Hex Bolt (with two 3/8” large
washers and one 3/8” lock nut) per Post. The distance from the outside of one Post to the outside of the second
Post should be 11’ 0”. (g. 4.1, 4.2 and 4.3)
C: Continue until all four Beam Assemblies are attached and the corners are tight together. (g. 4.1 and 4.2) See
g. 4.3 for accurate positioning of Posts.
Fig. 4.2
Hardware
8 x 3/8 x 10-1/2” Hex Bolt (3/8” large washer x 2, 3/8” lock nut)
Note hole
orientation (on
bottom)
Fig. 4.3
3/8” Lock
Nut
3/8” Large
Washer
3/8” Large
Washer
3/8 x 10-1/2”
Hex Bolt
3/8 x 10-1/2”
Hex Bolt
Beam
Assembly
Beam
Assembly
Beam
Assembly
Post Assembly
Post
Assembly
Post
Assembly
Post
Assembly
Plinth
Note hole
orientation (on
bottom)
42
[14’ 1-3/4]
Post to Post
Post to Post
[11’ 0”]
Plinth to Plinth
[9’ 10-1/2”]
Post to Post
[11’ 0”]
Plinth to Plinth
[9’ 10-1/2”]
3.35 m
3.35 m 4.31 m
3.01 m
3.01 m

16 [email protected]
29
D: Make sure each corner is square and level then attach Beam Assemblies to Post Assemblies with two 5/16
x 4-3/4” Lag Screws (with 1/4-5/16” large washer) per corner. (g. 4.4)
E: Depending on what you are placing the Pergola Room on will determine how you anchor it to that surface.
Please refer to pages 6 and 7 for installation examples.
Any hardware or extra materials for
mounting will have to be purchased in advance.
Hardware
8 x 5/16 x 4-3/4” Lag Screw (1/4-5/16” large washer)
1/4-5/16”
Large
Washer
5/16 x 4-3/4”
Lag Screw
5/16 x 4-3/4”
Lag Screw
Fig. 4.4
Beam
Assembly
Beam
Assembly
Post Assembly
Step 4: Frame Assembly and Anchoring
Part 2
1/4-5/16”
Large
Washer

17 [email protected]
Note: The bevelled ends on each gusset should always face away from the wood it is attaching to.
A: Make sure the assembly is still square and level then facing one Beam Assembly place one (705) Gusset
Right on the right hand side so the top ts tight to the Beam Assembly and the bottom ts tight to the Post
Assembly. Attach gusset to Beam Assembly with two 5/16 x 3-3/4” Hex Bolts (with 5/16” lock washer, 1/4-5/16”
large washer and 5/16” t-nut) and to Post Assembly with three 1/4 x 1-15/16” Hex Lags (with 1/4-5/16” large
washer). (g. 5.1, 5.2 and 5.3)
B: Repeat Step A on the left hand side with one (706) Gusset Left. (g. 5.1, 5.2 and 5.3)
C: Repeat Steps A and B for each Beam Assembly/Post Assembly. (g. 5.1, 5.2 and 5.3)
D: At each corner, tight to the outside edges of the joining Beam Assemblies attach one Roof to Post Bracket with
two #10 x 1-1/4” Pan Screws. (g. 5.3 and 5.4)
Step 5: Attach Gussets and Roof Brackets
Fig. 5.1
HardwareWood Parts
Fig. 5.2
Fig. 5.3 Fig. 5.4
Roof to Post
Bracket
#10 x 1-1/4”
Pan Screw
Beam
Assembly
Beam
Assembly
Tight
(705) Gusset
Right
(706) Gusset
Left
Post
Assembly
(705) Gusset
Right
(706) Gusset
Left
Post
Assembly
1/4 x
1-15/16”
Hex Lag
5/16”
T-nut
5/16” Lock
Washer
1/4-5/16”
Large Washer
5/16 x 3-3/4”
Hex Bolt
5/16 x 3-3/4”
Hex Bolt
Beam
Assembly
Beam
Assembly
1/4-5/16”
Large Washer
1/4-5/16”
Large Washer
1/4 x
1-15/16”
Hex Lag
(706)
Gusset
Left (706) Gusset
Left
(706) Gusset
Left
(705)
Gusset
Right
(706) Gusset
Left
(705) Gusset
Right
(705) Gusset
Right
(705)
Gusset
Right
4 x (705) Gusset Right
4 x (706) Gusset Left
24 x 1/4 x 1-15/16” Hex Lag (1/4-5/16” large washer)
16 x 5/16 x 3-3/4” Hex Bolt
(5/16” lock washer, 1/4-5/16” large washer, 5/16” t-nut)
8 x #10 x 1-1/4” Pan Screw
4 x Roof to Post Bracket

18 [email protected]
A: Tightly connect one (341) Fascia Left and one (342) Fascia Right using one 5/16 x 1-1/4” Hex Bolt (with 5/16”
lock washer, 1/4-5/16” large washer and 5/16” t-nut) as shown in g. 6.1 and 6.2.
B: Repeat Step A three more times to make four Fascia Beam Assemblies.
Step 6: Fascia Beam Assembly
HardwareWood Parts
4 x (341) Fascia Left
4 x (342) Fascia Right
4 x 5/16 x 1-1/4” Hex Bolt
(5/16” lock washer, 1/4-5/16” large washer, 5/16” t-nut)
Fig. 6.1
Fig. 6.2
(342) Fascia
RIght
(341) Fascia
Left
(342) Fascia
RIght
(341)
Fascia Left
1/4-5/16”
Large
Washer
5/16”
T-nut
5/16 x 1-1/4”
Hex Bolt
Tight
5/16” Lock
Washer

19 [email protected]
A: On each side of one (340) Rafter place one (333) Rafter Corner Left and one (334) Rafter Corner Right so
the tops and edges are ush then attach with two #8 x 2-1/4” Wood Screws per side. (Fig. 7.1 and 7.2)
B: Place Fascia Beam Assembly from Step 6 on the bottom of (333) Rafter Corner Left, (334) Rafter Corner
Right and (340) Rafter so the sides are ush then attach with two #8 x 2-1/4” Wood Screws at each end and two
in the middle. (g. 7.1, 7.3 and 7.4)
C: Repeat Steps A and B three more times to make four Roof Rafter Assemblies.
7
7
7
7
HardwareWood Parts
#8 x 2-1/4” Wood Screws
(x 6 per Fascia Beam
Assembly)
(340)
Rafter
Top View
Fascia Beam
Assembly
Step 7: Roof Rafter Assembly
Part 1
Fig. 7.1
40 x #8 x 2-1/4” Wood Screw
4 x (340) Rafter
4 x (333) Rafter Corner Left
4 x (334) Rafter Corner Right
Fig. 7.3
Fig. 7.4
Note notches
facing up
Flush
Fascia Beam
Assembly
Fascia Beam
Assembly
Flush
(340)
Rafter
(340)
Rafter
#8 x 2-1/4”
Wood Screws
#8 x 2-1/4”
Wood Screws
Flush
Fig. 7.2
(333) Rafter
Corner Left
(333) Rafter
Corner Left
(333) Rafter
Corner Left
(334) Rafter
Corner Right
(334) Rafter
Corner Right
Front View
Front View
Note angle
side up

20 [email protected]
8
HardwareWood Parts
#8 x 1-1/2” Wood Screws
x 20 per assembly
Fig. 7.5
Step 7: Roof Rafter Assembly
Part 2
80 x #8 x 1-1/2” Wood Screw
16 x #8 x 2-1/4” Wood Screw
4 x (337) Strap Short
4 x (336) Strap
4 x (338) Rafter Short Right
4 x (339) Rafter Short Left
D: Place one (337) Strap Short in the notches of (333) Rafter Corner Left, (334) Rafter Corner Right and (340)
Rafter so the ends do not overhang the outside edges of the outside boards then attach with six #8 x 1-1/2”
Wood Screws. (Fig. 7.5)
E: Place one (336) Strap in the notches of (333) Rafter Corner Left, (334) Rafter Corner Right and (340) Rafter
so the ends do not overhang the outside edges of the outside boards. Do not attach yet. (g. 7.5)
F: Place one (338) Rafter Short Right and one (339) Rafter Short Left in the notches of (336) Strap and attach
as shown in g. 7.5 with four #8 x 1-1/2” Wood Screws and two #8 x 2-1/4” Wood Screws per board.
G: Attach (336) Strap to (333) Rafter Corner Left, (334) Rafter Corner Right and (340) Rafter with six #8 x
1-1/2” Wood Screws. (g. 7.5)
H: Complete Steps D, E, F and G for all four Roof Rafter Assemblies.
(340)
Rafter
No
Overhang
Fascia Beam
Assembly
Flush
(333) Rafter
Corner Left
(334) Rafter
Corner Right
Front View
Flush
(337) Strap
Short
(339) Rafter
Short Left
(336) Strap
(338) Rafter
Short Right
#8 x 2-1/4”
Wood Screws
#8 x 2-1/4”
Wood Screws
