Yardistry YM12721 User manual

4.27 m (14 ) OCTAGON GAZEBO
Installaon and Operang Instrucons – YM12721
Revised 12-1-2022
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Yardistry – North America
Toll Free Customer Support:
1.888.509.4382
[e-mail]
www.yardistrystructures.com
Y40000-2721
YM11924 - Meridian Octagon
12' 0"
3.658 m
12' 0"
3.658 m
4.267m
(14’)
Height: 10’ 5-5/8” (3.192 m)
4.267m
(14’)
Regular Hours: Mon - Fri, 8:30 am - 5:00
pm EST (excl. holidays)
(For extended hours see our website)
English and French Spoken

2 [email protected]
Important Safety Notice!
Yardistry components are intended for privacy, decorative and ornamental use only.
Product is NOT INTENDED for the following:
• A safety barrier to prevent unsupervised access to pools, hot tubs, spas or ponds.
• As load bearing support for a building, structure, heavy objects or swings.
• Used in structures that trap wind, rain or snow that would create extra load on the
product.
Accumulated snow must be removed from roof.
DO NOT climb or walk on roof for any reason.
Permanent structures may require a building permit. As the purchaser and or installer of this
product you are advised to consult local planning, zoning and building inspection departments for
guidance on applicable building codes and/or zoning requirements.
Wood is NOT ame retardant and will burn. Grills, re pits and chimineas are a re hazard if
placed too close to a Yardistry structure. Consult user’s manual of the grill, re pit or chimnea for
safe distances from combustible materials.
Wear gloves to avoid injury from possible sharp edges of individual elements before assembly.
During installation, follow all safety warnings provided with your tools and use OHSA
approved safety glasses. Some structures may require two or more people to install safely.
Check for underground utilities before digging or driving stakes into the ground!
It is important during assembly to closely follow the instructions, complete the assembly
on a solid level surface and that you follow the instruction to square up, level and anchor the
structure, this will reduce the gap at wood connections during assembly.
General Information: Wood components are manufactured with Cedar (C. Lanceolata)
which is protected with factory applied water-based stain. Knots, small checks (cracks)
and weathering are naturally occurring and do not a󰀨ect the strength of the product.
Annual application of a water-based water repellent sealant or stain is important and will
help reduce weathering and checks.
www.yardistrystructures.com
Questions?
Call toll free or write us at:
1 [phone]
[email protected]
Patents Pending
General Information
Regular Hours: Mon - Fri, 8:30 am - 5:00 pm EST
(excl. holidays)
(For extended hours see our website)
English and French Spoken

3 [email protected]
July 27, 2018
Limited Warranty
This Warranty gives you specic legal rights. You may have other rights as well which vary from state to state
or province to province. This warranty excludes all consequential damages, however, some states/provinces
do not allow the limitation or exclusion of consequential damages, and therefore this limitation may not apply
to you.
Yardistry warrants that this product is free from defect in materials and workmanship for a
period of one (1) year from the original date of purchase. In addition, for any product with
lumber, all lumber is warranted for ve (5) years against rot and decay. This warranty applies
to the original owner and registrant and is non-transferable.
Regular maintenance is required to assure the integrity of your product and is a requirement of
the warranty. This warranty does not cover any inspection costs.
This Limited Warranty does not cover:
• Labour for replacement of any defective item(s);
• Incidental or consequential damages;
• Cosmetic defects which do not a󰀨ect performance or integrity;
• Vandalism; improper use or installation; acts of nature, including but not limited to wind,
storms, hail, oods, excessive water exposure;
• Minor twisting, warping, checking or any other natural occurring properties of wood that do
not a󰀨ect performance or integrity.
Yardistry products have been designed for safety and quality. Any modications made to
the original product could damage the structural integrity of the product leading to failure
and possible injury. Yardistry cannot assume any responsibility for modied products.
Furthermore, modication voids any and all warranties.
This product is warranted for RESIDENTIAL USE ONLY. Yardistry disclaims all other
representations and warranties of any kind, express or implied.

4 [email protected]4 [email protected]
Instructions for Proper Maintenance
Your Yardistry structure is designed and constructed of quality materials. As with all outdoor
products it will weather and wear. To maximize the enjoyment, safety and life of your structure
it is important that you, the owner, properly maintain it.
Symbols:
Throughout these instructions symbols are provided in the top, right-hand corner of the page.
If you dispose of your Yardistry structure: Please disassemble and dispose of your unit
so that it does not create any unreasonable hazards at the time it is discarded. Be sure to
follow your local waste ordinances.
HARDWARE:
• Check metal parts for rust. If found, sand and repaint using a non-lead paint complying
with 16 CFR 1303.
• Inspect and tighten all hardware after completion of assembly; after rst month of use; and
then annually. Do not over-tighten as to cause crushing and splintering of wood.
• Check for sharp edges or protruding screw threads, add washers if required.
WOOD PARTS:
• Applying a water repellent or stain (water-based) on a yearly basis is important
maintenance to maintain maximum life and performance of the product.
• Check all wood members for deterioration, structural damage and splintering. Sand down
splinters and replace deteriorated wood members. As with all wood, some checking and
small cracks in grain is normal
• Some gapping may occur at some wood connections.
• Tape Measure
• Carpenters Level
• Standard or Cordless Drill
• 7/16”, 1/2” Wrench
• 7/16”, 1/2” Socket
Assembly Guides
• 8’ Step Ladder
• Safety Glasses
• Adult Helper
• Safety Gloves
• Hard Hat
Tools Required:
• Use Help, where this is shown, 2, 3 or 4
people are required to safely complete
this step. To avoid injury or damage to the
assembly make sure to get some help.
• Use a measuring tape to assure proper
location.
• Pre-drill a pilot hole before fastening
screw or lag to prevent splitting of wood.
• 6’ Step Ladder x 2
• Square
• Ratchet
• Check that assembly is square before
tightening bolts.

5 [email protected]
Following are some helpful tips to make the assembly process smooth and e󰀩cient.
PRE-ASSEMBLIES:
(i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc)
• Work on a raised, solid and at surface such as, a table or saw horse.
• Keep all connections ush where shown in the instructions.
• When assembling the beams keep parts at, straight and snug when
connecting.
METAL PARTS:
• Roong material may have sharp edges, wear safety gloves.
• Remove all plastic covering, on both sides of the metal panels, directly
before installing each piece.
• Place roong material on a non-abrasive surface before and after assembly
as it can bend, dent and scratch easily.
• The roong screws can easily crush the roof panels and roof edges when
using a power drill. We recommend hand tightening the roong screws so
they sit snug and tight to the roong material.
Assembly Tips

6 [email protected]
"B"
"B"
"C" "B"
"C"
"C" "B"
YM11924 - Meridian Octagon
Marker Metric Dimension Imperial Dimension
"A" 3.429 m 11'- 3"
"B" 1.420 m 4'- 7-15/16"
"C" 1.004 m 3'- 3-9/16'
"D" 3.712 m 12'- 2-1/8"
"A"
"A"
"C"
135"
3.43
Post to Post
135"
3.43
Post to Post
139.63
3.55
Post to Post
Note: It is critically important you start with square, solid and level footings, concrete
pad or deck to attach your structure.
We supply Post Mounts with this structure which gives you the exibility to permanently install your structure
to a pre-existing or new wood or concrete surface.
• The hardware to attach the Post Mount to the structure is included.
• The hardware to mount the structure permanently will need to be purchased separately at your local
hardware store.
If you are mounting to concrete footers see below for the correct locations and placement. Please double
check for possibility of any underground utilities such as gas, telephone, cable or sprinkler lines.
Following are some examples of how to mount the structure to wood or concrete surfaces.
Refer to your local building and city codes, ordinances, neighbourhood covenants, or height restrictions
regarding this type of structure for guidance on acceptable installation requirements.
Permanent Installation Examples
Concrete Footer
To
Required
Depth
Anchoring Hardware not included
Post Mount
Outside Post to
Outside Post
A
AD
B
C
C
CC
B
B
Layout Dimensions for Octagon Gazebo
A13'3-5/8"(4.054 m)
B56-1/8"(1.679 m)
C3' 10-3/4"(1.188 m)
D 14' 4-3/4"(4.389 m)
Layout Dimensions for Octagon Gazebo
Actual for Gazebo Octagon Shape
(conrete or wood)
Concrete Footing
(centre of post)
A12' 3" (3.734 m) 10' 10-1/8" (3.305 m)
B5' 7/8" (1.546 m) 4' 5-7/8" (1.346 m)
C3' 7-1/16" (1.092 m) 3' 2-1/8" (0.968 m)
13'3-5/8"(4.054 m)
56-1/8" (1.679m)
3' 10-3/4"(1.188 m)

7 [email protected]
STEP 12- Anchoring
A: After the all the walls have been installed, check that the unit is square, then anchor.
WOOD APPLICATION
CONCRETE APPLICATION
WOOD APPLICATION
CONCRETE APPLICATION
WOOD APPLICATION
CONCRETE APPLICATION
WOOD APPLICATION
CONCRETE APPLICATION
Permanent Installation Examples cont.
Anchoring Hardware not included
Anchoring Hardware not included
Anchoring Hardware (not included)
Post
Mount
Post Mounts have a 1/2” diameter
hole for anchoring hardware.
Concrete Patio [min. 4.361 m x 4.361 m (14’3-5/8” x 14’ 3-5/8”)]
with 15.24 cm (6”) clearance on all sides
Wood Deck [min. 4.361 m x 4.361 m (14’3-5/8” x 14’ 3-5/8”)]
with 15.24 cm (6”) clearance on all sides

8 [email protected]
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Y50229-1583
7pc. (1583) - Filler Insert 1567mm (61-11/16") FSC
1pc. (1059) - Post Left 2184.4mm (86") FSC Y70229-1059
Y50229-1589
8pc. (1589) - Gusset Right 610mm (24") FSC
Y50229-1582
7pc. (1582) - Rail Bot 1567mm (61-11/16") FSC
8pc. (1588) - Gusset Left 610mm (24") FSC
Y50229-1588
Y50229-1577
8pc. (1577) - Beam 1711mm (67-3/8") FSC
1pc. (1061) - Post Right 2184.4mm (86") FSC Y70229-1061
6pc. (1056) - Post Main 2184.4mm (86") FSC Y70229-1056
Y50229-1066
98pc. (1066) - Spindle 747.8mm (29-7/16") FSC
Y50229-1581
7pc. (1581) - Rail Top 1567mm (61-11/16") FSC

9 [email protected]
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
Y50229-1585
8pc. (1585) - Strap Top 562.2mm (22-1/8") FSC
Y50229-1578
8pc. (1578) - Rafter Centre 2263.4mm (89-1/8") FSC
8pc. (1586) - Strap Bot 1370.9mm (54") FSC Y50229-1586
Y50229-1579
8pc. (1579) - Rafter Corner LT 2415.5mm (95-1/8") FSC
8pc. (1587) - Strap Mid 966.6mm (38-1/16") FSC Y50229-1587
Y50229-1580
8pc. (1580) - Rafter Corner RT 2415.5mm (95-1/8") FSC
Y50229-1584
8pc. (1584) - Fascia 1750.4mm (68-15/16") FSC

10 [email protected]
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc. - Octagon Roof Peak Set
(Y70829-390)
1pc.
Carriage Bolt
(Y07490-260)
1pc.
Peak Loop
(Y20018-003)
1pc. - Gazebo ID Plaque
(Y70800-104)
1pc.
1/4" Nut
(Y08490-200)
1pc. - Peak Post
(Y01000-094) 1pc.
Spring Clip
(Y09490-001)
1pc. - Post to Roof
Tie Bracket Set
(8Pk) (Y70829-353)
1pc. - Post
Mount Set (8Pk)
(Y70829-355)
1pc. - Rafter/Beam
Bracket Set (8Pk)
(Y70829-281)
1pc. -135º Angle
Bracket Set (8Pk)
(Y70818-389)
1pc. - Corner Cap Set (8Pk)
(Y70830-354)
1pc.
Contour
Washer
(Y05918-211)
1pc.
Base Plate
(Y01029-352)
8pc. -LT Panel -(Y01037-650)
1pc. - Roof Panel Set
(Y70837-649)
1pc.
Peak Cap
(Y01030-351)
8pc. -RT Panel-(Y01037-651)
16pc. Ridge Clip - (Y01037-653)
1pc. - Ridge Clip
Weather Seal (16Pk)
(Y70818-655)
8pc. Roof Edge - (Y01037-652)
8pc. Ridge Cap - (Y01037-654)

11 [email protected]
Hardware Identification ( )
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
264pc. Hex Roofing Screw
#8x 1"
(Y06730-510)
1pc. - Hex Driver (Y00400-004)
197pc. Wood Screw #8 x 1-1/2"
(Y06091-512)
48pc. Sheet Metal Screw
#8 x 3/4"
(Y06430-503)
62pc. Wood Screw #8 x 2 1/2" - (Y06091-522)
56pc. - 1/4" Lock Nut
(Y08318-203)
96pc. Wood Screw #7 x 3/4"
(Y06091-003)
160pc.
1/4-5/16 x 1-1/4" Large Washer
(Y05118-311)
32pc. 1/4 x 2-3/4 Hex Bolt - (Y07718-223)
32pc. Hex Bolt 5/16 x 2-1/4" - (Y07718-321)
142pc. Wood Screw #8 x 3" - (Y06091-530)
32pc. Lag Screw 1/4" x 1-15/16" No.12 Shank - (Y06218-219)
32pc. Pan Screw #12 x 1-1/2"
(Y06491-612)
8pc. 1/4 x 2" Hex Bolt - (Y07718-220)
16pc. Hex Bolt
1/4 x 5"
(Y07718-250)
98pc. Wood Screw #8 x 2" - (Y06091-520)
1pc. -1/8"Drill Bit
(Y00400-002)
58pc. Pan Screw #10 x 1-1/4"
(Y06491-711)
1pc. #2 x 2" Robertson Driver (Y00400-005)
32pc. 5/16 - T-Nut
(Y08518-300)
32pc. 5/16" Lock Washer
(Y05318-300)

12 [email protected]
PRODUCT NUMBER: YM12721
CARTON I.D. STAMP: __ __ __ __ __ 1 4 4 5 9 __ (Box 1)
CARTON I.D. STAMP: __ __ __ __ __ 1 4 4 5 9 __ (Box 2)
CARTON I.D. STAMP: __ __ __ __ __ 1 4 4 5 9 __ (Box 3)
STOP STOPSTOP STOP
1-888-509-4382
[email protected]
C. Read the assembly manual completely, paying special attention to ANSI
warnings; notes; and safety/maintenance information on pages 1 - 4.
• Follow the instructions in order.
• This structure is designed to be assembled and installed ideally by four
people, DO NOT attempt to install alone.
• Consider the slope of elevation where you plan to install the structure. Also, check
for gas, telephone, other utilities or sprinkler line locations prior to excavating any
holes.
D. Before you discard your cartons ll out the form below.
• The carton I.D. stamp is located on the end of each carton.
• Please retain this information for future reference. You will need this information if
you contact the Consumer Relations Department.
• Each step indicates which bolts and/or screws you will need for assembly, as well
as any at washers, lock washers, t-nuts or lock nuts.
A. This is the time for you to inventory all your hardware, wood and accessories,
referencing the parts identication sheets. This will assist you with your
assembly.
Step 1: Inventory Parts - Read This Before Starting Assembly
B. If there are any missing or damaged pieces or you need assistance with
assembly please contact the consumer relations department directly. Call us
before going back to the store.

13 [email protected]
use 2 Filler Inserts to set height and one to set the spacing
1a
A: Arrange 14 (1066) Spindles evenly accross two (1583) Filler Inserts (notches facing down) to set height. (F2.1)
B: On top of one end, place a (1583) Filler Insert. Place (1066) Spindles into slots to set spacing. (F2.2 and F2.3)
F2.1
use 2 Filler Inserts to set height and one to set the spacing
1a
Step 2: Rail Assemblies
Part 1
(1066) Spindle
(x 14)
(1066) Spindle
(x 14)
Flush
(1583) Filler Insert
to set spacing
(1583) Filler Insert
to set spacing
(1583) Filler Insert (x 2)
to set height
(1583) Filler Insert (x 2)
to set height
Wood Parts
7 x (1583) Filler Insert
98 x (1066) Spindle
F2.2
F2.3

14 [email protected]
1b 14X #8x3"
(1066) Spindle
(x 14)
1b 14X #8x3"
(1583) Filler Insert
to set spacing
#8 x 3” Wood
Screws (x 14)
(1583) Filler Insert (x 2)
to set height
C: Place (1582) Rail Bot against bottom of spindles, ush to the outside edges of the end spindles. Centre spindles
over holes in (1582) Rail Bot. Attach with one #8 x 3” Wood Screw per spindle. (F2.3 and F2.4)
D: Repeat Steps A - C six more times to create seven partial Rail Assemblies. Remove (1066) Filler Inserts when
complete.
Step 2: Rail Assemblies
Part 2
HardwareWood Parts
F2.4
7 x (1582) Rail Bot 98 x #8 x 3” Wood Screw
Note: Angle side
towards spindles
F2.3
Flush and
centred
(1582)
Rail Bot
(1066) Spindle
(x 14)

15 [email protected]
1c
14X #8x2"
1c
14X #8x2"
E: Place a (1583) Filler Insert at top of (1066) Spindles, ush to outside edges of end spindles and attach with one
#8 x 2” Wood Screw per spindle. (F2.5 and F2.6)
Step 2: Rail Assemblies
Part 3
Hardware
F2.5
F2.6
#8 x 2” Wood
Screws (x 14)
98 x #8 x 2” Wood Screw
Flush
(1583)
Filler
Insert
(1582) Rail Bot
(1066)
Spindle

16 [email protected]
alternate angles of the
same view, pick
one for the AI
F: On top of (1583) Filler Insert and ush to each end, place (1581) Rail Top. Attach (1583) Filler Insert to (1581)
Rail Top with three #8 x 1-1/2” Wood Screws as shown in F2.7, F2.8 and F2.9.
G: Repeat Steps E - F six more times to create seven Rail Assemblies.
Step 2: Rail Assemblies
Part 4
HardwareWood Parts
7 x (1581) Rail Top 21 x #8 x 1-1/2” Wood Screw
#8 x 1-1/2” Wood
Screws (x 3 per
assembly)
F2.8
F2.7
F2.9
(1583)
Filler
Insert
(1581) Rail Top
(1583)
Filler
Insert
Flush,
both ends
alternate angles of the
same view, pick
one for the AI
(1581)
Rail Top
alternate angles of the
same view, pick
one for the AI

17 [email protected]
STEP 3 - POST Assembly
STEP 3 - POST Assembly
STEP 3 - POST Assembly
STEP 3 - POST Assembly
STEP 3 - POST Assembly
STEP 3 - POST Assembly
A: Flush to the bottom of one (1059) Post Left and one (1061) Post Right place one Post Mount tight to the inside
of each post then attach with two #10 x 1-1/4” Pan Screws per Post Mount. (F3.1, F3.2, F3.3 and F3.4)
B: Flush to the bottom of each (1056) Post Main place one Post Mount tight to the inside of each post then attach
with two #10 x 1-1/4” Pan Screws per Post Mount. There will be six Post Main Assemblies. (F3.5 and F3.6)
Step 3: Post Assemblies
HardwareWood Parts
F3.3
6 x (1056) Post Main
1 x (1059) Post Left
1 x (1061) Post Right
Top
Bottom
F3.5
8 x Post Mount
F3.1
Post
Mount
F3.2
Post
Mount
#10 x 1-1/4”
Pan Screw
Flush
(1061)
Post Right
16 x #10 x 1-1/4” Pan Screw
Components
F3.4
F3.6
Bottom
(1059)
Post Left (1056)
Post Main
(1061)
Post Right
(1059)
Post Left
(1056)
Post Main
Flush
Flush
#10 x 1-1/4”
Pan Screw
Note: Holes
at top of posts

18 [email protected]
STEP 4 - POST/RAIL Assembly
LAYOUT FOR 1 RIGHT POST ASSEMBLY
LAYOUT FOR 2 MAIN POST ASSEMBLIES
LAYOUT FOR 1 Left POST ASSEMBLY
A: Place two Post Main (1056) on each side of one Rail Assembly and attach using (2)
#8 x 2-1/2” Wood Screws. (First Image) -Repeat for 2nd assembly.
B: Place One Post Main 1056) on the right side of the Rail Assembly and one Post Right
(1061) on the left side and attach using (2) #8 x 2-1/2” Wood Screws. (Second Image) C: Place
One Post Main 1056) on the left side of the Rail Assembly and one Post Left(1059) on the right side
and attach using (2) #8 x 2-1/2” Wood Screws. (Third Image)
4
4
4
F4.5
(1056)
Post Main
(1066) Spindle
Step 4: Attach Rail Assemblies to Posts
Part 1
Hardware
A: Place one (1056) Post Main on each side of one Rail Assembly. Rail Assembly should sit tight to top of post
insert. See F4.1 and F4.2 for correct positioning of posts. At an angle attach (1581) Rail Top to posts with two #8 x
2-1/2” Wood Screws. (F4.1, F4.2, F4.3 and F4.4)
B: For each (1066) Spindle which is next to a post, at an angle, pre-drill with a 1/8” drill bit then attach (1066)
Spindles to posts, on an angle, with two #8 x 3” Wood Screws per post. (F4.5 and F4.6)
C: Repeat Steps A and B for a second Rail and Post Assembly using two (1056) Post Mains.
F4.1
4 x #8 x 2-1/2” Wood Screw
8 x #8 x 3” Wood Screw
Rail Assembly
#8 x 2-1/2”
Wood Screw
F4.2
Notice screw
attached at an
angle
(1056)
Post Main
F4.3
(1056) Post Main
(1581)
Rail Top
(1056)
Post Main
Notice Posts
face the same
direction
Pre-drill and
attach screws at
an angle
(1056)
Post Main
A
#8 x 3”
Wood Screw
F4.6
4
Post
Insert
Tight
F4.4
(1066)
Spindle

19 [email protected]
4
F4.11
(1056)
Post Main
(1066) Spindle
4.2 4.3
4.2 4.3
4
Step 4: Attach Rail Assemblies to Posts
Part 2
Hardware
F4.7
2 x #8 x 2-1/2” Wood Screw
4 x #8 x 3” Wood Screw
Rail Assembly
#8 x 2-1/2”
Wood Screw
F4.8
Notice screw
attached at an
angle
(1056)
Post Main
F4.9
(1581)
Rail Top
(1059)
Post Left
Pre-drill and
attach screws at
an angle
(1056)
Post Main
A
#8 x 3”
Wood Screw
F4.12
4
Post
Insert
Tight
F4.10
(1066)
Spindle
(1059)
Post Left
(at side)
(1059)
Post Left
Notice groove
side faces Rail
Assembly, at side
faces away
D: Place one (1056) Post Main on one side of one Rail Assembly and (1059) Post Left on the other side. Rail
Assembly should sit tight to top of post insert. See F4.7 and F4.8 for correct positioning of posts. At an angle,
attach (1581) Rail Top to posts with two #8 x 2-1/2” Wood Screws. (F4.7, F4.8, F4.9 and F4.10)
E: For each (1066) Spindle which is next to a post, at an angle, pre-drill with a 1/8” drill bit then attach (1066)
Spindles to posts, on an angle, with two #8 x 3” Wood Screws per post. (F4.11 and F4.12)

20 [email protected]
4.2 4.3
4.2 4.3
4
F4.17
(1056)
Post Main
(1066) Spindle
4
Step 4: Attach Rail Assemblies to Posts
Part 3
Hardware
F4.13
2 x #8 x 2-1/2” Wood Screw
4 x #8 x 3” Wood Screw
Rail Assembly
#8 x 2-1/2”
Wood Screw
F4.14
Notice screw
attached at an
angle
(1061)
Post Right
F4.15
(1581)
Rail Top
(1056)
Post Main
Pre-drill and
attach screws at
an angle
(1056)
Post Main
A
F4.18
4
Post
Insert
Tight
F4.16
(1066)
Spindle
(1061)
Post Right
(at side)
(1061)
Post Right
Notice groove
side faces Rail
Assembly, at side
faces away
F: Repeat Steps D and E using one (1056) Post Main with one (1061) Post Right. See F4.13 and F4.14 for correct
positioning of Posts.(F4.13, F4.14, F4.15, F4.16, F4.17 and F4.18)
#8 x 3”
Wood Screw
