Yardistry AVERY User guide

1 [e-mail]
AVERY PAVILION
with ALUMINUM rOOF
Installaon and Operang Instrucons – YM11742
Yardistry – North America
Toll Free Customer Support: 1.888.509.4382
[e-mail]
www.yardistrystructures.com
For Spanish instrucons visit our website at:
(Para obtener instrucciones españoles, visite nuestro sio web en:)
hp://yardistrystructures.com/instrucon-manuals/
Revised 11-14-2016
HEIGHT:
10’6” or 3.2m
Height: 9’ 11” (3.02 m)
10’ 7”
12’
[3657.8]
[3225.8]
http://bit.ly/averyinstall

2 [e-mail]
Important Safety Notice!
Yardistry components are intended for privacy, decorative and ornamental use only.
Product is NOT INTENDED for the following:
• A safety barrier to prevent unsupervised access to pools, hot tubs, spas or ponds.
• As load bearing support for a building, structure, heavy objects or swings.
• Used in structures that trap wind, rain or snow that would create extra load on the
product.
Accumulated snow must be removed from roof.
DO NOT climb or walk on roof for any reason.
Permanent structures may require a building permit. As the purchaser and or installer of this
product you are advised to consult local planning, zoning and building inspection departments for
guidance on applicable building codes and/or zoning requirements.
Wood is NOT ame retardant and will burn. Grills, re pits and chimineas are a re hazard if
placed too close to a Yardistry structure. Consult user’s manual of the grill, re pit or chimnea for
safe distances from combustible materials.
Wear gloves to avoid injury from possible sharp edges of individual elements before assembly.
During installation, follow all safety warnings provided with your tools and use OHSA
approved safety glasses. Some structures may require two or more people to install safely.
Check for underground utilities before digging or driving stakes into the ground!
It is important during assembly to closely follow the instructions, complete the assembly
on a solid level surface and that you follow the instruction to square up, level and anchor the
structure, this will reduce the gap at wood connections during assembly.
General Information: Wood components are manufactured with Cedar (C. Lanceolata)
which is protected with factory applied water-based stain. Knots, small checks (cracks)
and weathering are naturally occurring and do not affect the strength of the product.
Annual application of a water-based water repellent sealant or stain is important and will
help reduce weathering and checks.
www.yardistrystructures.com
Questions?
Call toll free or write us at:
1 [phone]
[email protected]
Patents Pending
General Information

3 [e-mail]
Limited Warranty
Yardistry warrants that this product is free from defect in materials and workmanship
for a period of one year from the original date of purchase. In addition, all lumber is
warranted for 5 years against rot and decay. This warranty applies to the original owner
and registrant and is non-transferable.
Regular maintenance is required to assure the integrity of your product and is a requirement of
the warranty. This warranty does not cover any inspection cost.
This Limited Warranty does not cover:
• Labor for replacement of any defective item(s);
• Incidental or consequential damages;
• Cosmetic defects which do not affect performance or integrity;
• Vandalism; improper use or installation; acts of nature;
• Actsofnatureincludingbutnotlimitedtowind,storms,hail,oods,excessivewater 
 exposure;
• Minor twisting, warping, checking, or any other natural occurring properties of wood that
do not affect performance or integrity.
Yardistryproductshavebeendesignedforsafetyandquality.Anymodicationsmadetothe
original product could damage the structural integrity of the product leading to failure and
possibleinjury.Yardistrycannotassumeanyresponsibilityformodiedproducts.Furthermore,
modicationvoidsanyandallwarranties.
This product is warranted for RESIDENTIAL USE ONLY. Yardistry disclaims all other
representations and warranties of any kind, express or implied.
This Warranty gives you specic legal rights. You may have other rights as well which vary from state to state or province to
province. This warranty excludes all consequential damages, however, some states do not allow the limitation or exclusion of
consequential damages, and therefore this limitation may not apply to you.

4 [e-mail]
Instructions for Proper Maintenance
Your Yardistry structure is designed and constructed of quality materials. As with all outdoor
products it will weather and wear. To maximize the enjoyment, safety and life of your structure
it is important that you, the owner, properly maintain it.
Symbols:
Throughout these instructions symbols are provided in the top, right-hand corner of the page.
If you dispose of your Yardistry structure: Please disassemble and dispose of your
unit so that it does not create any unreasonable hazards at the time it is discarded. Be
sure to follow your local waste ordinances.
HARDWARE:
• Check metal parts for rust. If found, sand and repaint using a non-lead paint complying
with 16 CFR 1303.
• Inspect and tighten all hardware after completion of assembly; after rst month of use; and
then annually. Do not over-tighten as to cause crushing and splintering of wood.
• Check for sharp edges or protruding screw threads, add washers if required.
WOOD PARTS:
• Applying a water repellent or stain (water-based) on a yearly basis is important
maintenance to maintain maximum life and performance of the product.
• Check all wood members for deterioration, structural damage and splintering. Sand down
splinters and replace deteriorated wood members. As with all wood, some checking and
small cracks in grain is normal
• Some gapping may occur at some wood connections.
• Tape Measure
• Carpenters Level
• Standard or Cordless Drill
• 7/16”, 1/2” & 9/16” Wrench
• 7/16”, 1/2” & 9/16” Socket
Assembly Guides
• 8’ Step Ladder
• Safety Glasses
• Adult Helper
• Safety Gloves
• Hard Hat
Tools Required:
• Use Help, where this is shown, 2, 3 or 4
people are required to safely complete
this step. To avoid injury or damage to the
assembly make sure to get some help.
• Use a measuring tape to assure proper
location
• Pre-drill a pilot hole before fastening
screw or lag to prevent splitting of wood.
• 6’ Step Ladder x 2
• Square
• Rachet
• Check that assembly is square before
tightening bolts

5 [e-mail]
Following are some helpful tips to make the assembly process smooth and efcient.
PRE-ASSEMBLIES:
(i.e. Post and Beam Assemblies, Roof Rafter Assembly, etc)
• Work on a raised, solid and at surface such as, a table or saw horse.
• Keep all connections ush where shown in the instructions.
• When assembling the beams keep parts at, straight and snug when
connecting.
METAL PARTS:
• Roong material may have sharp edges, wear safety gloves.
• Remove all plastic covering, on both sides of the metal panels, directly
before installing each piece.
• Place roong material on a non-abrasive surface before and after assembly
as it can bend, dent and scratch easily.
• The roong screws can easily crush the roof panels and roof edges when
using a power drill. We recommend hand tightening the roong screws so
they sit snug and tight to the roong material.
Assembly Tips

6 [e-mail]
Note: It is critically important you start with square, solid and level footings, concrete
pad or deck to attach your Pavilion.
We supply Post Mounts with this structure which gives you the exibility to permanently install your structure
to a pre-existing or new wood or concrete surface.
• The hardware to attach the Post Mount to the structure is included.
• The hardware to mount the structure permanently will need to be purchased separately at your local
hardware store.
If you are mounting to concrete footers see below for the correct locations and placement. Please double
check for possibility of any underground utilities such as gas, telephone, cable or sprinkler lines.
Following are some examples of how to mount the structure to wood or concrete surfaces.
Refer to your local building and city codes, ordinances, neighbourhood covenants, or height restrictions
regarding this type of structure for guidance on acceptable installation requirements.
Permanent Installation Examples
Concrete Footer
To
Required
Depth
Anchoring Hardware not included
Post Mount
post to post
plinth to plinth
"
3
9'- 4
"
32
13'-2 19
"
32
13'-219
"
1"
2
9'-4
10'-2 1
4
10'-6"
Post to Post
Plinth to Plinth
Post to Post
Post to Post Plinth to Plinth
9’ 3/4” 13’ 2-5/8”
10’ 6”
10’ 2-1/4”
9’ 4-1/2”

7 [e-mail]
Permanent Installation Examples cont.
Concrete Patio (min. 10’ 8” x 11’) with 6” clearance on all sides
Wood Deck (min. 10’ 8” x 11’) with 6” clearance on all sides
Anchoring Hardware not included
Anchoring Hardware not included
Anchoring Hardware (not included)
Post
Mount
Post Mounts have a 1/2” diameter
hole for anchoring hardware.

8 [e-mail]
Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
4pc. (423) - 6 x 6 Post
152.4 X 152.4 X 2336.8mm (6 x 6 x 92")
Y70119-423
4pc. (330) - Gusset Right
38.1 x 190.5 x 1003.3mm (1-1/2 x 7-1/2 x 39-1/2")
Y70119-330
16pc. (422) - Plinth 6 x 6 Post
19.1 x 133.4 x 190.5mm (3/4 x 5-1/4 x 7-1/2")
Y50119-422
4pc. (404) - Beam End - Inside
38.1 x 139.7 x 460.4mm (1-1/2 x 5-1/2 x 18-1/8")
Y50119-404
4pc. (401) - Beam Front Back
38.1 x 139.7 x 1714.5mm (1-1/2 x 5-1/2 x 67-1/2")
Y50119-401
2pc. (402) - Beam Inside
38.1 x 139.7 x 2336.8mm (1-1/2 x 5-1/2 x 92")
Y50119-402
Y50119-403
38.1 x 139.7 x 1590.7mm (1-1/2 x 5-1/2 x 62-5/8")
4pc. (403) - Beam Side
12pc. (412) - Rafter
31.8 x 76.2 x 1866.9mm (1-1/4 x 3 x 73-1/2")
Y50119-412
4pc. (415) - Gable End
25.4 x 139.7 x 1946.3mm (1 x 5-1/2 x 76-5/8")
Y50119-415
Y50119-405
25.4 x 50.8 x 1574.8mm (1 x 2 x 62")
2pc. (405) - Cross Gusset Support
4pc. (331) - Gusset Left
38.1 x 190.5 x 1003.3mm (1-1/2 x 7-1/2 x 39-1/2")
Y70119-331
4pc. (414) - Gable Gusset
31.8 x 133.4 x 580.1mm (1-1/4 x 5-1/4 x 22-27/32")
Y50119-414
6pc. (419) - Strap Long
31.8 x 76.2 x 1905.6mm (1-1/4 x 3 x 75-1/32")
Y50119-419
6pc. (418) - Strap Short
31.8 x 76.2 x 1275.8mm (1-1/4 x 3 x 50-7/32")
Y50119-418
Y50119-420
25.4 x 81.8 x 1590.7mm (1 x 3-7/32 x 62-5/8")
4pc. (420) - Rafter Top
Y50119-413
25.4 x 81.8 x 590.6mm (1 x 3-7/32 x 23-1/4")
2pc. (413) - Rafter Brace
2pc. (409) - End Gable Centre Front
88.9 x 139.7 x 766.3mm (3-1/2 x 5-1/2 x 30-11/64")
Y70119-409
2pc. (406) - End Gable Centre Back
76.2 x 139.7 x 795.5mm (3 x 5-1/2 x 31-5/16")
Y70119-406
4pc. (416) - Tie
31.8 x 88.9 x 2333.6mm (1-1/4 x 3-1/2 x 91-7/8")
Y50119-416
4pc. (417) - Tie Brace
31.8 x 88.9 x 352.6mm (1-1/4 x 3-1/2 x 13-7/8")
Y50119-417

9 [e-mail]
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc. - Weather Seal -
Ridge Clip (6Pk)
(Y70818-120)
1pc. - Roof Panel (6 Pk)
(Y70828-111)
2pc.
Ridge Cap Short
(Y01028-116)
1pc.
Ridge Cap
(Y01028-117)
4pc.
Ridge Clip Short
(Y01028-115)
2pc.
Ridge Clip
(Y01028-114)
2pc.
Roof Edge Left
(Y01028-112)
2pc.
Roof Edge Right
(Y01028-113)
1pc. - Roof To Beam
Bracket Set (8Pk)
(Y70819-108)
1pc. - Tie Centre
Bracket Set (4Pk)
(Y70819-107)
1pc. - Post Mount
Bracket Set (8Pk)
(Y70819-109)
1pc. - Gazebo ID Plaque
(Y70800-104)
1pc. - Jamb Mount
Bracket Set (8Pk)
(Y70819-121)
1pc. - Tie Wrap
Bracket Set (8Pk)
(Y70819-106)
NOTE: Parts have been packed
inside (423) 6 x 6 Post. Check for parts inside the Posts.

10 [e-mail]
Hardware Identification ( )
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
64pc. 5/16" Flat Washer
(Y05118-203)
1pc. #2 x 2" Robertson Driver (9200014)
8pc. - 3/8" Lock Nut
(Y08318-803)
1pc. - 1/8" Drill Bit (Y00400-002)
48pc. Wood Screw #8 x 2 1/2" - (52043522)
40pc. 5/16 - T-Nut
(Y08518-300)
32pc. 1/4" Flat Washer
(Y05118-201)
40pc. 5/16" Lock Washer
(Y05318-300)
16pc.
3/8" Flat Washer
(Y05118-801)
4pc. Hex Bolt
3/8 x 9-1/2"
(Y07718-892)
8pc. Hex Bolt 5/16 x 3-3/4" - (Y07718-333)
8pc. Lag Screw 5/16 x 4-3/4" - (Y06218-343)
58pc. Pan Screw #8 x 1"
(52433510)
128pc. Hex Roofing Screw
#8x 1"
(Y06728-510)
26pc. Wood Screw
#7 x 3/4"
(Y06091-003)
152pc. Wood Screw #8 x 1-1/2"
(52043512)
1pc. - Hex Driver
(Y00400-004)
6pc. Hex Bolt 1/4 x 2-3/4" - (Y07718-223)
4pc. #8x3/4" - Sheet
Metal Screw
(Y06428-503)
4pc. Wood Screw #10 x 4" - (52043940)
2pc. Hex Bolt 1/4 x 4-3/4" - (Y07718-243)
16pc. 1/4" Flat Washer Large
(Y05118-211)
16pc. Hex Bolt 1/4 x 2" - (Y07718-220)
36pc. Wood Screw #8 x 2 1/4" - (52043521)
16pc. Lag Screw 5/16 x 3" - (Y06218-330)
4pc. Hex Bolt
3/8 x 8"
(Y07718-880)
24pc. - 1/4" Lock Nut
(Y08318-203)
20pc. Hex Bolt 5/16 x 1-1/2" - (Y07718-312)
4pc. Hex Bolt 5/16 x 4" - (Y07718-340)
8pc. Hex Bolt 5/16 x 2-1/4" - (Y07718-321)
56pc. Wood Screw #8 x 1-3/4"
(52043513)
8pc. Pan Screw #10 x 2-1/2" - (Y06491-722)
80pc. Pan Screw #10 x 1-1/4"
(52443911)

11 [e-mail]
PRODUCT NUMBER: YM11742
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 1)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 2)
CARTON I.D. STAMP: __ __ __ __ __ ___ (Box 3)
STOP STOPSTOP STOP
1-888-509-4382
[email protected]
C. Read the assembly manual completely, paying special attention to ANSI warnings;
notes; and safety/maintenance information on pages 1 - 4.
• Follow the instructions in order.
• This structure is designed to be assembled and installed ideally by four people,
DO NOT attempt to install alone.
• Consider the slope of elevation where you plan to install the structure. Also, check for
gas, telephone, other utilities or sprinkler line locations prior to excavating any holes.
D. Before you discard your cartons ll out the form below.
• The carton I.D. stamp is located on the end of each carton.
• Please retain this information for future reference. You will need this information if you
contact the Consumer Relations Department.
• Each step indicates which bolts and/or screws you will need for assembly, as well as
any at washers, lock washers, t-nuts or lock nuts.
A. This is the time for you to inventory all your hardware, wood and accessories,
referencing the parts identication sheets. This will assist you with your assembly.
Step 1: Inventory Parts - Read This Before Starting Assembly
B. If there are any missing or damaged pieces or you need assistance with
assembly please contact the consumer relations department directly. Call us
before going back to the store.

12 [e-mail]
Avery Inst 1 - Post Assembly
Avery Inst 1 - Post Assembly
Avery Inst 1 - Post Assembly
A: At the bottom of one (423) 6 x 6 Post insert two 5/16” T-Nuts as shown in g. 2.1.
B: At the bottom of the same (423) 6 x 6 Post place two Post Mounts tight to the bottom and inside faces as
shown in g. 2.1 and 2.2. Loosely attach with one 5/16 x 1-1/2” Hex Bolt (with 5/16” lock washer and 5/16” at
washer) per mount so they connect to the T-Nuts. From the bottom attach with two #8 x 2-1/2” Wood Screws per
mount and then from the inside with two #10 x 1-1/4” Pan Screws per mount. Tighten bolts.
C: Place one (422) Plinth ush to the bottom and tight to the Post Mounts on each side of the (423) 6 x 6 Post
and attach with four #8 x 1-1/2” Wood Screws per plinth. Rounded edges on top. (g. 2.3 and 2.4)
D: Repeat Steps A - C three more times to make four Post Assemblies.
Step 2: Post Assemblies
HardwareWood Parts
Fig. 2.1
(422) Plinth
4 x (423) 6 x 6 Post 152.4 x 152.4 x 2336.8 mm (6 x 6 x 92”)
16 x (422) Plinth 19.1 x 133.4 x 190.5 mm (3/4 x 5-1/4 x 7-1/2”)
Top
Bottom
#8 x 2-1/2” Wood Screws
(x 2 per Post Mount, from
bottom)
#8 x 1-1/2”
Wood Screws
(x 4 per Plinth)
(423) 6 x 6 Post
Post
Mount
Fig. 2.2
16 x #10 x 1-1/4” Pan Screw
16 x #8 x 2-1/2” Wood Screw
64 x #8 x 1-1/2” Wood Screw
8 x 5/16” T-Nut
8 x 5/16 x 1-1/2” Hex Bolt
(with 5/16” lock washer, 5/16” at washer)
8 x Post Mount
Avery Inst 1 - Post Assembly
Fig. 2.4
Post
Mount
(423) 6 x 6 Post
5/16” T-Nut
(x 2 per
Post)
(423) 6 x 6
Post
Rounded
Edge on Top
Fig. 2.3
Post
Mount
#10 x 1-1/4” Pan Screws
(x 2 per Post Mount, from
inside)
5/16” Flat
Washer
5/16” Lock
Washer
5/16 x 1-1/2”
Hex Bolt
5/16” T-Nut
(x 2 per
Post)
(423) 6 x 6
Post
http://bit.ly/avery2-4

13 [e-mail]
Avery Inst 2 - Beam Assembly - Front/Back
Step 3: Beam Assembly - Front/Back
HardwareWood Parts
A: Fit together two (401) Beam Front Back so the notched out ends are tight together then place one (409) End
Gable Centre Front on one side and one (406) End Gable Centre Back and one (405) Cross Gusset Support on
the other side. Loosely attach with two 5/16 x 4” Hex Bolts (with 5/16” lock washer, 5/16” at washer and 5/16”
t-nut) from the front of the assembly. Note: Bolt holes to the bottom of each (401) Beam Front Back. (g. 3.1)
B: Square then attach the tops of (406) End Gable Centre Back and (409) End Gable Centre Front with two #8 x
2-1/4” Wood Screws. Tighten bolts from Step A. (g. 3.1)
C: Attach (405) Cross Gusset Support to each (401) Beam Front Back with four #8 x 2-1/4” Wood Screws. (g.
3.1)
D: Attach (406) End Gable Centre Back to (409) End Gabel Centre Front with two #8 x 1-1/2” Wood Screws and
to (401) Beam Front Back with two #8 x 2-1/2” Wood Screws. (g. 3.1)
E: Repeat Steps A - D one more time to make a second Beam Assembly - Front/Back.
Fig. 3.1
4 x 5/16 x 4” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
4 x #8 x 1-1/2” Wood Screw
12 x #8 x 2-1/4” Wood Screw
4 x #8 x 2-1/2” Wood Screw
5/16” Flat
Washer
5/16 x 4”
Hex Bolt
5/16”
T-nut
Tight
(405) Cross
Gusset Support
(409) End Gable
Centre Front
(401) Beam
Front Back
Front
4 x (401) Beam Front Back 38.1 x 139.7 x 1714.5 mm (1-1/2 x 5-1/2 x 67-1/2”)
2 x (405) Cross Gusset Support 25.4 x 50.8 x 1574.8 mm (1 x 2 x 62”)
2 x (406) End Gable Centre Back 76.2 x 139.7 x 795.3 mm (3 x 5-1/2 x 31-5/16”)
2 x (409) End Gable Centre Front 88.9 x 139.7 x 766.3 mm (3-1/2 x 5-1/2 x 30-11/64”)
(406) End Gable
Centre Back
(401) Beam
Front Back
5/16” Lock
Washer
#8 x 2-1/2”
Wood Screw
#8 x 1-1/2”
Wood Screw
#8 x 2-1/4”
Wood Screw
#8 x 2-1/4”
Wood Screw
x 4
Notice holes
on bottom of
both boards

14 [e-mail]
Avery Inst 3 - Beam Assembly - Side
HardwareWood Parts
A: Fit two (403) Beam Sides together so the middle pilot holes are at the bottom for both. Connect using two
5/16 x 1-1/2” Hex Bolts (with 5/16” lock washer, 5/16” at washer and 5/16” t-nut) as shown in g. 4.1.
B: Connect one (404) Beam End - Inside to each end of one (402) Beam Inside using two 5/16 x 1-1/2” Hex
Bolts (with 5/16” lock washer, 5/16” at washer and 5/16” t-nut) per end as shown in g. 4.2.
C: Repeat Steps A and B one more time to make two Beam Side Assemblies and two Beam Inside Assemblies.
4 x (403) Beam Side 38.1 x 139.7 x 1590.7 mm (1-1/2 x 5-1/2 x 62-5/8”)
2 x (402) Beam Inside 38.1 x 139.7 x 2336.8 mm (1-1/2 x 5-1/2 x 92”)
4 x (404) Beam End - Inside 38.1 x 139.7 x 460.4 mm (1-1/2 x 5-1/2 x 18-1/8”)
Fig. 4.1
12 x 5/16 x 1-1/2” Hex Bolt
(5/16” lock washer, 5/16” at washer, 5/16” t-nut)
Fig. 4.2
5/16” Flat
Washer
5/16 x 1-1/2”
Hex Bolt
5/16”
T-nut
Tight
(402)
Beam
Inside
(403) Beam Side
Step 4: Beam Assembly - Side
Part 1
(403) Beam
Side
5/16 x 1-1/2”
Hex Bolt
5/16 x 1-1/2”
Hex Bolt
5/16” Lock
Washer
(404) Beam
End - Inside
(404) Beam
End - Inside

15 [e-mail]
Avery Inst 3 - Beam Assembly - Side
Hardware
24 x #8 x 2-1/2” Wood Screw
Fig. 4.3
Beam Inside
Assembly
Flush
Step 4: Beam Assembly - Side
Part 2
D: Place one Beam Side Assembly and one Beam Inside Assembly so the ends are ush. Match the bolt holes
in each (404) Beam End - Inside with the bolt holes in each (403) Beam Side. Attach assemblies with 12 #8 x
2-1/2” Wood Screws. (g. 4.3)
E: Repeat Step D one more times to make a second Beam Assembly - Side.
Flush
Beam Side
Assembly
#8 x 2-1/2” Wood
Screws (x 12 per
assembly)
Match
bolt
holes
(403)
Beam
Side
(404) Beam
End - Inside
(404) Beam
End - Inside
Match
bolt
holes
Hint: Use bolts at
both ends to line up
bolt holes. Remove
bolts once step is
complete

16 [e-mail]
Avery Inst 4 - Frame Assembly
A: Move your Post Assemblies to the nal location. Make sure the ground is at and level before continuing
assembly.
B: With one person at each Post stand two complete Post Assemblies. A third person places one Beam
Assembly - Side against the outside of each Post, ush to the tops and outside corners. Notice bolt hole
orientation on the assemblies. A fourth person attaches Beam to Post with one 3/8 x 9-1/2” Hex Bolt (with two
3/8” at washers and one 3/8” lock nut) per Post. The distance from the outside of one Post to the outside of the
second Post should be 10’ 2-1/4”. (g. 5.1, 5.2 and 5.3)
C: Place one Beam Assembly - Front/Back against two Post Assemblies so the (405) Cross Gusset Support faces
the inside and is ush to the top and outside corner of Beam Assembly - Side, then attach with one 3/8 x 8” Hex
Bolt (with two 3/8” at washers and one 3/8” lock nut) per Post, The distance from the outside of one Post to the
outside of the second Post should be 10’ 6”. (g. 5.1 and 5.2) See g. 5.3 for accurate positioning of Posts.
Avery Inst 4 - Frame Assembly
Step 5: Frame Assembly and Anchoring
Part 1
Fig. 5.1
Fig. 5.2
Hardware
4 x 3/8 x 9-1/2” Hex Bolt (3/8” at washer x 2, 3/8” lock nut)
4 x 3/8 x 8” Hex Bolt (3/8” at washer x 2, 3/8” lock nut)
Note hole
orientation (on
bottom)
Fig. 5.3
3/8” Lock
Nut
3/8” Flat
Washer
3/8” Flat
Washer
3/8 x 8”
Hex Bolt
3/8 x 9-1/2”
Hex Bolt
Beam
Assembly -
Side
Post Assembly
Post
Assembly
(405) Cross
Gusset Support
Post
Assembly
Plinth
Beam Assembly
- Front/Back
Beam
Assembly -
Side
Beam Assembly -
Front/Back
Beam Assembly
- Side
post to post
plinth to plinth
"
3
9'- 4
"
32
13'-2 19
"
32
13'-219
"
1"
2
9'-4
10'-2 1
4
10'-6"
9’ 3/4”
Plinth to Plinth
Plinth to Plinth
13’ 2-5/8”
Post to Post
10’ 2-1/4”
Post to Post
9’ 4-1/2”
10’ 6”
Post to Post
D: Repeat Steps B and C for remaining
Beam Assemblies. See g. 5.3 for
accurate positioning of Posts.
Flush
x 3
http://bit.ly/avery5-6

17 [e-mail]
Avery Inst 4 - Frame Assembly
E: Make sure each corner is square and level then attach Beam Assemblies to Post Assemblies with two 5/16
x 4-3/4” Lag Screws (with 5/16” at washer) per corner. (g. 5.4)
F: Depending on what you are placing the Pavilion on will determine how you anchor it to that surface. Please
refer to pages 6 and 7 for installation examples.
Any hardware or extra materials for
mounting will have to be purchased in advance.
Hardware
8 x 5/16 x 4-3/4” Lag Screw (5/16” at washer)
5/16” Flat
Washer
5/16 x 4-3/4”
Lag Screw
5/16 x 4-3/4”
Lag Screw
Fig. 5.4
Post Assembly
Step 5: Frame Assembly and Anchoring
Part 2
5/16” Flat
Washer
Beam Assembly
- Front/Back
Beam Assembly
- Side

18 [e-mail]
Avery Inst 5 - Attach Gussets
Avery Inst 5 - Attach Gussets
Note: The bevelled ends on each gusset
should always face away from the wood it
is attaching to.
A: Make sure the assembly is still square
and level then facing one Beam Assembly
- Side place one (330) Gusset Right on the
right hand side so the top ts tight to the
Beam Assembly - Side and the bottom ts
tight to the Post Assembly. Attach gusset to
Beam Assembly - Side with two 5/16 x 3-3/4”
Hex Bolts (with 5/16” lock washer, 5/16” at
washer and 5/16” t-nut) and to Post Assembly
with two 5/16 x 3” Lag Screws (with 5/16” at
washer). Repeat for the left hand side with
one (331) Gusset Left. (g. 6.1 and 6.2)
B: Repeat Step A for Beam Assembly -
Front/Back using two 5/16 x 2-1/4” Hex Bolts
(with 5/16” lock washer, 5/16” at washer
and 5/16” t-nut) to attach gussets to Beam
Assembly - Front/Back. (g. 6.1 and 6.2)
C: Repeat Steps A and B so all 8 gussets are
attached. (g. 6.1 and 6.2)
Step 6: Attach Gussets
Fig. 6.1
Tight
4 x (330) Gusset Right 38.1 x 190.5 x 1003.3 mm (1-1/2 x 7-1/2 x 39-1/2”)
4 x (331) Gusset Left 38.1 x 190.5 x 1003.3 mm (1-1/2 x 7-1/2 x 39-1/2”)
HardwareWood Parts
16 x 5/16 x 3” Lag Screw (5/16” at washer)
8 x 5/16 x 3-3/4” Hex Bolt (5/16” lock washer, 5/16” at washer, 5/16” t-nut)
8 x 5/16 x 2-1/4” Hex Bolt (5/16” lock washer, 5/16” at washer, 5/16” t-nut)
Fig. 6.2
(331)
Gusset
Left
Post
Assembly
(330)
Gusset
Right
(331)
Gusset
Left
5/16” Flat
Washer
5/16 x 3”
Lag Screw
5/16”
T-nut
5/16” Lock
Washer
5/16” Flat
Washer
5/16 x 2-1/4”
Hex Bolt
5/16 x 3-3/4”
Hex Bolt
(330) Gusset
Right
(331)
Gusset
Left
(330)
Gusset
Right
(331) Gusset
Left
(330)
Gusset
Right
(330)
Gusset
Right
(331) Gusset
Left
Beam
Assembly -
Front/Back
Beam
Assembly -
Side
Beam
Assembly -
Side
Beam
Assembly -
Side
Beam
Assembly -
Front/Back
Beam
Assembly -
Front/Back
5/16 x 3”
Lag Screw

19 [e-mail]
Avery Inst 6A - Frame Roof Panel
Avery Inst 6A - Frame Roof Panel
A: Lay out 6 (412) Rafters on a hard at surface as shown in g. 7.1. You will need lots of room for this step.
B: Place 1 (419) Strap Long on the bottom of four (412) Rafters, ush to the outside edge of the rst and centred
on the last. Be sure the wider gap on (419) Strap Long is on the rst (412) Rafter. Follow by placing one (418)
Strap Short then another (419) Strap Long in the same manner. Make sure the assembly is square, pre-drill
the rst (419) Strap Long with a 1/8” drill bit as shown below, then attach both (419) Strap Longs with eight #8 x
1-1/2” Wood Screws per board and to (418) Strap Short with six #8 x 1-1/2” Wood Screws. The screws on the
fourth (412) Rafter are inserted at an angle. (g. 7.1, 7.2 and 7.3)
C: Place one (420) Rafter Top on the angled ends of the (412) Rafters so the outside edges are ush then attach
to three (412) Rafters with six #8 x 2-1/4” Wood Screws. (g. 7.1 and 7.4)
Step 7: Frame Roof Panel
Part 1
Fig. 7.1
Fig. 7.2
HardwareWood Parts
12 x (412) Rafter 31.8 x 76.2 x 1866.9 mm (1-1/4 x 3 x 73-1/2”)
2 x (418) Strap Short 31.8 x 76.2 x1275.8 mm (1-1/4 x 3 x 50-7/32”)
4 x (419) Strap Long 31.8 x 76.2 x 1905.6 mm (1-1/4 x 3 x 75-1/32”)
2 x (420) Rafter Top 25.4 x 81.8 x 1590.7 mm (1 x 3-7/32 x 62-5/8”)
44 x #8 x 1-1/2” Wood Screw
12 x #8 x 2-1/4” Wood Screw
(418) Strap
Short
(419) Strap Long
(pre-drill pilot holes
for this board only) (420)
Rafter Top
(412) Rafter
Flush
Notice
screws at
an angle
Flush
(419) Strap
Long
(412)
Rafter
(412) Rafter
Fig. 7.3
Fig. 7.4
(418) Strap
Short
(419) Strap
Long
Notice large
notch gap on
outside ends Notice small notch
gap on inside ends
where straps meet
Notice large
notch gap on
outside ends
#8 x 1-1/2” Wood
Screws (x 22)
#8 x 2-1/4”
Wood Screws
(x 6)
Side View
Bottom
http://bit.ly/avery7-9

20 [e-mail]
Hardware
Wood Parts
Fig. 7.5
Side View
D: Tight to each (419) Strap Long place one (418) Strap Short and tight to the rst (418) Strap Short place one
(419) Strap Long. Make sure the wider gap on each strap is on the outside. Make sure the assembly is square,
pre-drill the rst (418) Strap Short with a 1/8” drill bit, as shown below, then attach both (418) Strap Shorts with
six #8 x 1-1/2” Wood Screws per board and (419) Strap Long with eight #8 x 1-1/2” Wood Screws. The screws
where the straps meet are inserted at an angle. (g. 7.3 and 7.5)
E: Tight to (420) Rafter Top attach a second (420) Rafter Top with six #8 x 2-1/4” Wood Screws. (g. 7.4 and
7.5)
Step 7: Frame Roof Panel
Part 2
Notice
screws at
an angle
Fig. 7.3
(418) Strap
Short
(419) Strap
Long
Notice large
notch gap on
outside ends Notice small notch
gap on inside ends
where straps meet
Notice large
notch gap on
outside ends
Avery Inst 6A - Frame Roof Panel
(420)
Rafter Top
Flush
(412)
Rafter
Fig. 7.4
#8 x 2-1/4”
Wood Screws
(x 6)
(418) Strap Short
(pre-drill pilot holes
for this board only)
(419) Strap
Long
(412) Rafter
#8 x 1-1/2”
Wood Screws
(x 20)
(418) Strap Short
4 x (418) Strap Short 31.8 x 76.2 x1275.8 mm (1-1/4 x 3 x 50-7/32”)
2 x (419) Strap Long 31.8 x 76.2 x 1905.6 mm (1-1/4 x 3 x 75-1/32”)
2 x (420) Rafter Top 25.4 x 81.8 x 1590.7 mm (1 x 3-7/32 x 62-5/8”)
40 x #8 x 1-1/2” Wood Screw
12 x #8 x 2-1/4” Wood Screw
Bottom
