About This Guide
v
About This Guide
Thank you for choosing the SIP-T27P IP phone, exquisitely designed to provide business
telephony features, such as Call Hold, Call Transfer, Busy Lamp Field, Multicast Paging and
Conference over an IP network.
This guide provides everything you need to quickly use your new phone. First, verify with your
system administrator that the IP network is ready for phone configuration. Also be sure to read
the Packaging Contents in this guide before you set up and use the SIP-T27P IP phone.
See the Yealink Products Regulatory Notices guide for all regulatory and safety guidance.
In This Guide
Topics provided in this guide include:
Chapter 1 Overview
Chapter 2 Getting Started
Chapter 3 Customizing Your Phone
Chapter 4 Basic Call Features
Chapter 5 Advanced Phone Features
Summary of Changes
This section describes the changes to this guide for each release and guide version.
Changes for Release 81, Guide Version 81.90
Major updates have occurred to the following section:
Volume on page 38
Changes for Release 81, Guide Version 81.70
The following section is new:
Parking a Call/Retrieving a Parked Call to the Monitored User on page 144
Major updates have occurred to the following sections:
Entering Data and Editing Fields on page 23
Configuring an Access URL on page 55

User Guide for the SIP-T27P IP Phone
vi
DSS Keys on page 65
Ext Keys on page 77
Auto Answer on page 93
Do Not Disturb (DND) on page 102
Call Forward on page 107
Call Park/Retrieve on page 123
Configuring Visual and Audio Alert for BLF Pickup on page 138
Receiving RTP Stream on page 157
BLF Ring Type is moved to Configuring Visual and Audio Alert for BLF Pickup on page 138.
Changes for Release 81, Guide Version 81.20
None
Changes for Release 81, Guide Version 81.15
The contents in the following section are removed to Frequently Asked Questions on Yealink IP
Phones :
Troubleshooting
The following sections are new:
BLF ring type on page 139
Power Saving on page 27
Changes for Release 81, Guide Version 81.10
The following section is new:
Key Tone on page 42
Major updates have occurred to the following sections:
Basic Network Settings on page 20
Language on page 31
Phone Lock on page 35
Volume on page 38
DSS Keys on page 65
Dial Plan on page 79
Call Mute on page 99

About This Guide
vii
Do Not Disturb (DND) on page 102
Call Transfer on page 115
Call Park on page 123
Busy Lamp Field (BLF) on page 137
Intercom on page 150
Multicast Paging on page 154
Changes for Release 80, Guide Version 80.95
The following section is new:
Entering Data and Editing Fields on page 23
Major updates have occurred to the following sections:
Icon Instructions on page 3
Optional Accessories on page 15
Phone Installation on page 16
Changes for Release 80, Guide Version 80.80
Major updates have occurred to the following sections:
Backlight on page 30
Contrast on page 31
Ext Keys on page 77
Changes for Release 80, Guide Version 80.60
The following sections are new:
Shared Call Appearance (SCA) on page 163
Bridged Line Appearance (BLA) on page 178
Major updates have occurred to the following sections:
Icon Instructions on page 3
LED Instructions on page 5
Web User Interface on page 8
Call Forward on page 107

User Guide for the SIP-T27P IP Phone
viii

Table of Contents
ix
Table of Contents
About This Guide ........................................................................... v
In This Guide ..............................................................................................................................................................v
Summary of Changes .............................................................................................................................................v
Changes for Release 81, Guide Version 81.90..........................................................................................v
Changes for Release 81, Guide Version 81.70..........................................................................................v
Changes for Release 81, Guide Version 81.20.........................................................................................vi
Changes for Release 81, Guide Version 81.15.........................................................................................vi
Changes for Release 81, Guide Version 81.10.........................................................................................vi
Changes for Release 80, Guide Version 80.95........................................................................................vii
Changes for Release 80, Guide Version 80.80........................................................................................vii
Changes for Release 80, Guide Version 80.60........................................................................................vii
Table of Contents..........................................................................ix
Overview .........................................................................................1
Hardware Component Instructions ..................................................................................................................1
Icon Instructions.......................................................................................................................................................3
Feature Status Icons............................................................................................................................................3
Line Key Icons........................................................................................................................................................4
Other Icons.............................................................................................................................................................4
LED Instructions........................................................................................................................................................5
User Interfaces ..........................................................................................................................................................7
Phone User Interface..........................................................................................................................................8
Web User Interface..............................................................................................................................................8
Documentations.................................................................................................................................................... 11
Getting Started.............................................................................13
Packaging Contents ............................................................................................................................................. 13
Optional Accessories....................................................................................................................................... 15
Phone Installation ................................................................................................................................................. 16
Phone Initialization............................................................................................................................................... 18
Phone Status........................................................................................................................................................... 19
Basic Network Settings....................................................................................................................................... 20
Registration ............................................................................................................................................................. 22
Idle Screen ............................................................................................................................................................... 22
Entering Data and Editing Fields..................................................................................................................... 23

User Guide for the SIP-T27P IP Phone
x
Customizing Your Phone.............................................................27
General Settings .................................................................................................................................................... 27
Power Saving...................................................................................................................................................... 27
Backlight............................................................................................................................................................... 30
Contrast ................................................................................................................................................................ 31
Language.............................................................................................................................................................. 31
Time & Date........................................................................................................................................................ 32
Administrator Password................................................................................................................................. 34
Key As Send ........................................................................................................................................................ 35
Phone Lock.......................................................................................................................................................... 35
Audio Settings........................................................................................................................................................ 38
Volume.................................................................................................................................................................. 38
Ring Tones........................................................................................................................................................... 40
Key Tone............................................................................................................................................................... 42
Contact Management ......................................................................................................................................... 42
Directory............................................................................................................................................................... 42
Local Directory ................................................................................................................................................... 44
Blacklist ................................................................................................................................................................. 53
Remote Phone Book........................................................................................................................................ 55
Call History Management.................................................................................................................................. 57
Viewing History Records................................................................................................................................ 57
Placing a Call from History Records .......................................................................................................... 58
Adding a Contact to the Local Directory/Blacklist............................................................................... 58
Deleting History Records............................................................................................................................... 58
Disabling History Record............................................................................................................................... 60
Search Source List in Dialing ............................................................................................................................ 60
System Customizations....................................................................................................................................... 62
Logo Customization......................................................................................................................................... 62
Headset Use........................................................................................................................................................ 63
DSS Keys............................................................................................................................................................... 65
Account Management .................................................................................................................................... 77
Dial Plan................................................................................................................................................................ 79
Emergency Number......................................................................................................................................... 85
Live Dialpad......................................................................................................................................................... 86
Hotline................................................................................................................................................................... 86
Basic Call Features........................................................................89
Placing Calls ............................................................................................................................................................ 90
Answering Calls...................................................................................................................................................... 92
Auto Answer ....................................................................................................................................................... 93
Ending Calls............................................................................................................................................................. 94
Redialing Numbers............................................................................................................................................... 94

Table of Contents
xi
Recent Call In Dialing .......................................................................................................................................... 95
Auto Redial.............................................................................................................................................................. 96
Call Completion..................................................................................................................................................... 97
ReCall......................................................................................................................................................................... 98
Call Mute .................................................................................................................................................................. 99
Muting a Call ....................................................................................................................................................100
Muting While Dialing ....................................................................................................................................100
Call Hold/Resume ...............................................................................................................................................100
Do Not Disturb (DND).......................................................................................................................................102
Call Forward ..........................................................................................................................................................107
Static Forwarding............................................................................................................................................107
Dynamic Forwarding .....................................................................................................................................115
Call Transfer...........................................................................................................................................................115
Blind Transfer....................................................................................................................................................116
Semi-attended Transfer................................................................................................................................118
Attended Transfer...........................................................................................................................................119
Call Waiting ...........................................................................................................................................................120
Conference ............................................................................................................................................................121
Local Conference ............................................................................................................................................121
Network Conference......................................................................................................................................122
Call Park/Retrieve................................................................................................................................................123
FAC Mode ..........................................................................................................................................................125
Transfer Mode..................................................................................................................................................127
Call Pickup .............................................................................................................................................................129
Directed Call Pickup.......................................................................................................................................129
Group Call Pickup ...........................................................................................................................................131
Anonymous Call ..................................................................................................................................................133
Anonymous Call Rejection ..............................................................................................................................134
Advanced Phone Features.........................................................137
Busy Lamp Field (BLF)........................................................................................................................................137
Configuring the BLF Feature on the IP Phone.....................................................................................137
Using BLF Feature on the IP Phone .........................................................................................................142
BLF List ....................................................................................................................................................................144
Call Recording ......................................................................................................................................................146
Configuring a Record Key ...........................................................................................................................147
Configuring a URL Record Key..................................................................................................................148
Recording a Call ..............................................................................................................................................148
Hot Desking ..........................................................................................................................................................149
Intercom .................................................................................................................................................................150
Configuring the Intercom Feature on the IP Phone..........................................................................150
Using Intercom ................................................................................................................................................153
Multicast Paging..................................................................................................................................................154
Sending RTP Stream......................................................................................................................................154

User Guide for the SIP-T27P IP Phone
xii
Receiving RTP Stream ...................................................................................................................................157
Using Multicast Paging.................................................................................................................................159
Music on Hold (MoH)........................................................................................................................................161
Automatic Call Distribution (ACD) ...............................................................................................................162
Shared Call Appearance (SCA).......................................................................................................................163
Configuring SCA Feature on the IP Phone ...........................................................................................164
Using SCA Feature on the IP Phone........................................................................................................171
Bridged Line Appearance (BLA).....................................................................................................................178
Configuring BLA Feature on the IP Phone............................................................................................178
Using BLA Feature on the IP Phone.........................................................................................................181
Messages................................................................................................................................................................183
Short Message Service (SMS).....................................................................................................................183
Voice Mail ..........................................................................................................................................................185
Message Waiting Indicator (MWI) ...........................................................................................................187
Appendix.....................................................................................191
Appendix A –Time Zones................................................................................................................................191
Appendix B –Menu Structure........................................................................................................................193
Index ...........................................................................................195

Overview
1
Overview
This chapter provides the overview of the SIP-T27P IP phone. Topics include:
Hardware Component Instructions
Icon Instructions
LED Instructions
User Interfaces
Documentations
If you require additional information or assistance with your new phone, contact your system
administrator.
Hardware Component Instructions
The main hardware components of the SIP-T27P IP phone are the LCD screen and the keypad.

User Guide for the SIP-T27P IP Phone
2
Hardware component instructions of the SIP-T27P IP phone are:
Item
Description
①
LCD Screen
Shows information about calls, messages, soft keys, time,
date and other relevant data:
• Default account
• Call information—caller ID, call duration
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file!")
• Time and date
②
Power Indicator LED
Indicates call status, message status and phone’s system
status.
• Receives an incoming call—Fast-flashing
• Receives a voice mail or text message—Slow-flashing
③
Line Keys
Use these keys to activate up to six accounts and assign
various features.
④
Soft Keys
Label automatically to identify their context-sensitive
features.
⑤
Scroll through the displayed information.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
⑥
HEADSET Key
Toggles and indicates the headset mode.
⑦
HOLD Key
Places a call on hold or resumes a held call.
⑧
TRAN Key
Transfers a call to another party.
⑨
Speakerphone Key
Toggles the hands-free (speakerphone) mode.
⑩
RD Key
Redials a previously dialed number.
⑪
MESSAGE Key
Indicates and accesses voice mails.
⑫
CONF Key
Conducts a conference call with multiple other parties.
⑬
MUTE Key
Mutes or un-mutes an active call.
⑭
Volume Key
Adjusts the volume of the handset, headset, speaker or
ringer.
⑮
Keypad
Provides the digits, letters and special characters in
context-sensitive applications.
⑯
Speaker
Provides hands-free (speakerphone) audio output.
⑰
Reversible Tab
Secures the handset in the handset cradle when the IP
phone is mounted vertically. For more information on how
to adjust the reversible tab, refer to Yealink Wall Mount
Quick Installation Guide for Yealink IP Phones .

Overview
3
Item
Description
⑱
Hookswitch
• Picking up the handset from the handset cradle, the
hookswitch bounces and the phone connects to the line.
• Laying the handset down on the handset cradle, the phone
disconnects from the line.
Icon Instructions
Feature Status Icons
Icons appearing on the top of the LCD screen are described in the following table:
Icons
Description
Network is unavailable
Hands-free (speakerphone) mode
Handset mode
Headset mode
Voice Mail
Text Message
Auto Answer
Do Not Disturb (DND)
Keep Mute
Ringer volume is 0
Phone Lock
Missed Calls
Call Forward

User Guide for the SIP-T27P IP Phone
4
Line Key Icons
Icons appearing on the line key label are described in the following tables:
Icon indicator (associated with line)
Icons
Description
The private line registers successfully
The shared/bridged line registers successfully
Registering
Register failed
DND is enabled on this line
Call forward is enabled on this line
Icon indicator (associated with ACD)
Icon
Description
The ACD state is available
and x
The ACD state is unavailable
The ACD state is Wrap up
Log out of the ACD system
Other Icons
Icons appearing when accessing features are described in the following tables:
Icon indicator (associated with call recording)
Icon
Description
Recording box is full
A call cannot be recorded

Overview
5
Icon
Description
Recording starts successfully
Recording cannot be started
Recording cannot be stopped
Icon indicator (associated with call history)
Icon
Description
Received Calls
Placed Calls
Missed Calls
Forwarded Calls
Icon indicator (associated with contact)
Icon
Description
The contact icon
LED Instructions
Power Indicator LED
LED Status
Description
Solid red
The phone is initializing.
Fast-flashing red (300ms)
The phone is ringing.
Slow-flashing red (1s)
The phone receives a text message or voice mail.
Off
The phone is powered off.
The phone is idle.
The phone is busy.
The call is placed on hold or is held.
The call is muted.

User Guide for the SIP-T27P IP Phone
6
Line key LED
LED Status
Description
Solid green
The line is seized.
The line is in conversation.
Fast-flashing green
The line receives an incoming call.
Slow-flashing green
The call is placed on hold.
Off
The line is inactive.
Line key LED (configured as a BLF key or BLF List key)
LED Status
Description
Solid green
The monitored user is idle.
Fast-flashing red (200ms)
The monitored user receives an incoming call.
Solid red
The monitored user is busy.
The monitored user’s conversation is placed on hold
(This LED status requires server support).
Slow-flashing red (1s)
The call is parked against the monitored user’s phone
number.
Off
The monitored user does not exist.
Line key LED (used as a page switch key)
LED Status
Description
Solid red
There is a parked call on the line key of the non-current
page.
Fast-flashing green
The line receives an incoming call on the non-current
page.
Fast-flashing red
The monitored user receives an incoming call on the
non-current page.
Off
Line keys on every page are idle.
Line key LED (associated with a shared line)
The local SCA phone indicates the phone is involved in an SCA call, while the monitoring SCA
phone indicates the phone is not involved in the SCA call.
LED Status
Description
Off
The shared line is idle.
Fast-flashing green
The shared line receives an incoming call.
Solid green (for local SCA
phone)
The shared line is in conversation.
The shared line is dialing.

Overview
7
LED Status
Description
Solid red (for monitoring SCA
phone)
The shared line is seized.
The shared line conversation is barged in by the other
shared line party.
Slow-flashing green (for local
SCA phone)
Slow-flashing red (for
monitoring SCA phone)
The shared line conversation is placed on public hold.
Slow-flashing green (for local
SCA phone)
Solid red (for monitoring SCA
phone)
The shared line conversation is placed on private hold.
For a multi-party call, all the shared line parties
participating in this call place the shared line
conversation on hold.
Line key LED (associated with a bridged line)
The local BLA phone indicates the phone is involved in a BLA call, while the monitoring BLA
phone indicates the phone is not involved in the BLA call.
LED Status
Description
Off
The bridged line is idle.
Fast-flashing green
The bridged line receives an incoming call.
Solid green (for local BLA
phone)
Solid red (for monitoring BLA
phone)
The bridged line is in conversation.
The bridged line is dialing.
The bridged line is seized.
Slow-flashing green (for local
BLA phone)
Slow-flashing red (for
monitoring BLA phone)
The bridged line conversation is placed on hold.
Note
User Interfaces
Two ways to customize configurations of your SIP-T27P IP phone:
The user interface on the IP phone.
The user interface in a web browser on your PC.
The hardware components keypad and LCD screen constitute the phone user interface, which
allows the user to execute all call operation tasks and basic configuration changes directly on
the phone. In addition, you can use the web user interface to access all configuration settings. In
many cases, it is possible to use either the phone user interface and/or the web user interface
The above introduces the default LED status. The statuses of the power indicator LED and BLF key
LED are configurable via web user interface. You can also customize the BLF key LED status and
BLF key behavior. For more information, contact your system administrator.

User Guide for the SIP-T27P IP Phone
8
interchangeably. However, in some cases, it is only possible to use one or the other interface to
operate the phone and change settings.
Phone User Interface
You can customize your phone by pressing the Menu soft key to access the phone user
interface. The Advanced Settings option is only accessible to the administrator, and the default
administrator password is “admin”(case-sensitive). For more information on customizing your
phone with the available options from the phone user interface, refer to Customizing Your
Phone on page 27.
Note
Web User Interface
In addition to the phone user interface, you can also customize your phone via web user
interface. In order to access the web user interface, you need to know the IP address of your
new phone. To obtain the IP address, press the OK key on the phone when the phone is idle.
Enter the IP address (e.g., http://192.168.0.10 or 192.168.0.10 for IPv4;
http://[2005:1:1:1:215:65ff:fe64:6e0a] or [2005:1:1:1:215:65ff:fe64:6e0a] for IPv6) in the address
bar of a web browser on your PC. The default administrator user name and password are both
“admin”(case-sensitive).
Note
The options you can use to customize the IP phone via phone user interface and/or via web user
interface are listed in the following table:
Options
Phone User Interface
Web User Interface
Status
√
√
--IPv4
--MAC
--Firmware
--Network
--Phone
--Accounts
Basic Phone Settings
√
--Power Saving
x
--Backlight
√
--Contrast
√
The access to the Advanced settings of the Account or Network via web user interface may be
blocked by the web browser (e.g., Chrome, Firebox) if you have installed “Adblock Plus plugin”.
For a better understanding of the menu structure, please refer to Appendix B –Menu Structure
on page 193.
