Yealink SIP-T4X User manual

Table of Contents
i

Table of Contents
iii
Table of Contents.................................................................. iii
Summary of Changes............................................................v
Changes for Release 71, Guide Version 71.181..............................................................v
Changes for Release 71, Guide Version 71.180..............................................................v
Changes for Release 71, Guide Version 71.171..............................................................v
Changes for Release 71, Guide Version 71.170..............................................................v
Changes for Release 71, Guide Version 71.150..............................................................v
Changes for Release 71, Guide Version 71.90 .............................................................. vi
Changes for Release 71, Guide Version 71.80 .............................................................. vi
Introduction ...........................................................................1
Getting Started .....................................................................3
Obtaining Configuration Information .............................................................................3
Obtaining Configuration Files ......................................................................................3
Obtaining Phone Information.......................................................................................3
Managing Configuration Files ........................................................................................4
Editing Common CFG File............................................................................................4
Editing MAC-Oriented CFG File ..................................................................................7
Encrypting Configuration Files ...................................................................................11
Customizing Resource Files ........................................................................................11
Customizing a Ringtone ..........................................................................................12
Customizing an LCD Language ..............................................................................12
Customizing an LCD Logo .......................................................................................15
Customizing a Wallpaper........................................................................................ 15
Customizing a Local Contact File............................................................................16
Customizing a Replace Rule File.............................................................................18
Customizing a Dial-now File....................................................................................19
Updating Firmware .................................................................................................20
Configuring a TFTP Server ...................................................21
Preparing a Root Directory ............................................................................................21
Configuring a TFTP Server.............................................................................................22

Yealink SIP-T4X IP Phones Auto Provisioning Guide
iv
Obtaining the Provisioning Server Address .........................23
Zero Touch......................................................................................................................23
Plug and Play (PnP) Server............................................................................................24
DHCP Options ................................................................................................................ 25
Phone Flash ....................................................................................................................26
Update Mode .....................................................................29
Power On........................................................................................................................29
Repeatedly.....................................................................................................................30
Weekly............................................................................................................................30
Auto Provision Now........................................................................................................31
Multi-mode Mixed .........................................................................................................32
SIP NOTIFY Message .....................................................................................................32
Downloading Configuration Files.........................................35
Troubleshooting ...................................................................37
Glossary..............................................................................39
Appendix ............................................................................41
Configuring an FTP Server.............................................................................................41
Preparing a Root Directory.........................................................................................41
Configuring an FTP Server..........................................................................................42
Configuring an HTTP Server ..........................................................................................44
Preparing a Root Directory.........................................................................................44
Configuring an HTTP Server .......................................................................................44
Configuring a DHCP Server...........................................................................................47
Customizing a Ringtone Using Cool Edit Pro ................................................................ 54
Customizing a Logo File Using PictureExDemo ............................................................ 55
Description of Configuration Parameters in CFG Files.................................................57

Summary of Changes
v
This section describes the changes to this guide for each release and guide version.
Major updates have occurred to the following section:
Customizing an LCD Language on page 12
Customizing a Local Contact File on page 16
Major updates have occurred to the following section:
Customizing an LCD Language on page 12
Description of Configuration Parameters in CFG Files on page 57
Major updates have occurred to the following section:
Customizing an LCD Language on page 12
Customizing an LCD Logo on page 15
Description of Configuration Parameters in CFG Files on page 57
Major updates have occurred to the following section:
Customizing an LCD Language on page 12
Description of Configuration Parameters in CFG Files on page 57
This version is updated to incorporate SIP-T41P as one of the SIP-T4X device models. The
following section is new for this version:
Customizing an LCD Logo on page 15
Customizing a Logo File Using PictureExDemo on page 55

Yealink SIP-T4X IP Phones Auto Provisioning Guide
vi
Major updates have occurred to the following section:
Description of Configuration Parameters in CFG Files on page 57
Major updates have occurred to the following section:
Description of Configuration Parameters in CFG Files on page 57
This version is updated to incorporate SIP-T42G as one of the SIP-T4X device models.
Major updates have occurred to the following sections:
Obtaining Configuration Files on page 3
Customizing Resource Files on page 11
Description of Configuration Parameters in CFG Files on page 57

Introduction
1
Yealink SIP-T4X IP phones are full-featured telephones that can be plugged directly into
an IP network and can be used easily without manual configuration.
This guide provides instructions on how to provision Yealink SIP-T4X IP phones with the
minimum settings required. Yealink SIP-T4X IP phones support FTP, TFTP, HTTP, and HTTPS
protocols for auto provisioning and are configured by default to use the TFTP protocol.
The purpose of this guide is to serve as a basic guidance for provisioning Yealink SIP-T4X
IP phones, including:
SIP-T46G
SIP-T42G
SIP-T41P
The auto provisioning process outlined in this guide applies to Yealink SIP-T4X IP phones
running firmware version 71 or later.

Yealink SIP-T4X IP Phones Auto Provisioning Guide
2

Getting Started
3
This section provides instructions on how to get ready for auto provisioning. The auto
provisioning process discussed in this guide uses the TFTP server as the provisioning
server.
To begin the auto provisioning process, the following steps are required:
Obtaining Configuration Information
Managing Configuration Files
Before beginning provisioning, you need to obtain configuration files. There are 2
configuration files both of which are CFG-formatted. We call these two files Common
CFG file and MAC-Oriented CFG file. The phone tries to download these CFG files from
the server during provisioning.
The MAC-Oriented CFG file is only effectual for the specific phone. It uses the 12-digit
MAC address of the phone as the file name. For example, if the MAC address of the
phone is 0015651130F9, the MAC-Oriented CFG file name must be 0015651130F9.cfg.
However, the Common CFG file is effectual for all the phones of the same model. It uses
a fixed name “y0000000000XX.cfg” as the file name, where "XX" equals to the hardware
version of the phone model.
The names of the Common CFG file for SIP-T4X IP phones are:
Phone Model
Common Configuration File
SIP-T46G
y000000000028.cfg
SIP-T42G
y000000000029.cfg
SIP-T41P
y000000000036.cfg
You can ask the distributor or Yealink FAE for configuration files. The IP phones can only
recognize configuration files using UTF-8 or ANSI encoding.
Before beginning provisioning, you also need the phone information. For example, MAC
address and the SIP account information of the phone.

Yealink SIP-T4X IP Phones Auto Provisioning Guide
4
MAC Address: The unique 12-digit serial number of the phone. You can obtain it from the
bar code on the back of the phone.
SIP Account Information: This may include SIP credentials such as user name, password
and address of the registration server. Ask your system administrator for SIP account
information.
Auto provisioning enables IP phones to update themselves automatically via
downloading Common CFG and MAC-Oriented CFG files. Before beginning
provisioning, you may need to edit and customize your configuration files. For more
information on configuration parameters in configuration files, refer to Description of
Configuration Parameters in CFG Files on page 57.
Common CFG file contains configuration parameters which apply to phones with the
same model, such as language, time and date.
The line beginning with “#” is considered to be a comment.
The file header “#!version:1.0.0.1” is not a comment and must be placed in the first line. It
cannot be edited or deleted.

Getting Started
5
The parameters commonly edited in the Common CFG file are described as follows
(take the SIP-T46G IP phone as an example):
####################################################
## Common CFG File ##
####################################################
#!version:1.0.0.1
##File header "#!version:1.0.0.1" cannot be edited or deleted, and must be placed in
the first line.
#Configure the transmission mode and the speed of the WAN port.
#0-Auto negotiate (default), 1-Full duplex 10Mbps, 2-Full duplex 100Mbps, 3-Half
duplex 10Mbps, 4-Half duplex 100Mbps, 5-Full duplex 1000Mbps (not applicable to
SIP-T41P);
network.internet_port.speed_duplex =
#Enable or disable Plug and Play feature; 0-Disabled, 1-Enabled (default)
auto_provision.pnp_enable =
#Configure the domain name of the PnP server.
auto_provision.pnp_domain_name =
#Configure the value (manufacturer of the device) of the PnP subscribe message.
auto_provision.pnp_event_vendor =
#Enable or disable the Power On mode for auto provisioning;
#0-Disabled, 1-Enabled (default);
auto_provision.mode =
#Enable or disable the IP phone to check the new configuration repeatedly.
auto_provision.repeat.enable =
#Configure the interval (in minutes) for the phone to check new configuration files. It
ranges from 1 to 43200, the default value is 1440.
auto_provision.repeat.minutes =
# Enable or disable the IP phone to check the new configuration weekly.
#0-Disabled (default), 1-Enabled;
auto_provision.weekly.enable =
#Configure the start time of the day for the phone to check new configuration files. The
default value is 00:00.
#If the desired start time of the day is seven forty-five a.m., the value format is 07:45.
auto_provision.weekly.begin_time =
#Configure the end time of the day for the phone to check new configuration files. The

Yealink SIP-T4X IP Phones Auto Provisioning Guide
6
default time is 00:00.
#If the desired end time of the day is seven forty-five p.m., the value format is 19:45.
auto_provision.weekly.end_time =
#Configure the day of the week for the phone to check new configuration files. The
default value is 0123456.
#0-Sunday,1-Monday,2-Tuesday,3-Wednesday,4-Thursday,5-Friday,6-Saturday;
#If the desired week is Monday, Tuesday and Wednesday, the value format is 012.
auto_provision.weekly.mask =
#Configure the URL of the auto provisioning server.
auto_provision.server.url =
#Configure the user name and password for authentication.
auto_provision.server.username =
auto_provision.server.password =
#Enable or disable DHCP option mode; 0-Disabled, 1-Enabled (default);
auto_provision.dhcp_option.enable =
#Configure the value (manufacturer of the device) of DHCP option 60.
auto_provision.dhcp_option.option60_value =
#Configure the custom DHCP option value. It ranges from 128 to 254.
auto_provision.dhcp_option.list_user_options =
#Set the AES key used for decrypting the Common CFG file
auto_provision.aes_key_16.com =
#Set the AES key used for decrypting MAC-Oriented CFG file
auto_provision.aes_key_16.mac =
#Set the language used on the web user interface
#The valid values are: English, Chinese_S, Chinese_T, German, Turkish, Portuguese,
Spanish, Italian, and French. Chinese_S and Chinese_T are applicable to the SIP-T46G IP
phone only.
lang.wui =
#Set the language used on the LCD screen
#The valid values are: English (default), Chinese_S, Chinese_T, German, French, Turkish,
#Italian, Polish, Spanish and Portuguese. Chinese_S and Chinese_T are applicable to
the SIP-T46G IP phone only.
lang.gui = English
# Enable or disable the web server access for HTTPS; 0-Disabled, 1-Enabled (default);

Getting Started
7
#Require reboot
wui.https_enable =
# Enable or disable the web server access for HTTP; 0-Disabled, 1-Enabled (default);
#Require reboot
wui.http_enable =
#Set the HTTP port (80 by default)
#Require reboot
network.port.http =
#Set the HTTPS port (443 by default)
#Require reboot
network.port.https =
MAC-Oriented CFG file contains configuration parameters which are expected to be
updated per phone, such as the registration information.

Yealink SIP-T4X IP Phones Auto Provisioning Guide
8
The parameters commonly edited in the MAC-Oriented CFG file are described as
follows:
####################################################
## MAC-Oriented CFG File ##
####################################################
#!version:1.0.0.1
##The file header “#!version:1.0.0.1” is not a comment and must be placed in the first
line. It cannot be edited or deleted.
#Account 1 settings
#Enable or disable the account1, 0-Disabled (Default), 1-Enabled
account.1.enable =
#Configure the label displayed on the LCD screen for account1
account.1.label =
#Configure the display name of account 1
account.1.display_name =
#Configure the user name and password for register authentication
account.1.auth_name =
account.1.password =
#Configure the register user name
account.1.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.1.sip_server.1.address =
account.1.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.1.sip_server.2.address =
account.1.sip_server.2.port =
# Account 2 settings
#Enable or disable the account2, 0-Disabled (Default), 1-Enabled
account.2.enable =
#Configure the label displayed on the LCD screen for account 2
account.2.label =
#Configure the display name of account2
account.2.display_name =
#Configure the user name and password for register authentication
account.2.auth_name =
account.2.password =
#Configure the register user name

Getting Started
9
account.2.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.2.sip_server.1.address =
account.2.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.2.sip_server.2.address =
account.2.sip_server.2.port =
# Account 3 settings
#Enable or disable the account3, 0-Disabled (Default), 1-Enabled
account.3.enable =
#Configure the label displayed on the LCD screen for account 3
account.3.label =
#Configure the display name of account3
account.3.display_name =
#Configure the user name and password for register authentication
account.3.auth_name =
account.3.password =
#Configure the register user name
account.3.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.3.sip_server.1.address =
account.3.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.3.sip_server.2.address =
account.3.sip_server.2.port =
#Account 4-6 is for the SIP-T46G IP phone only.
# Account 4 settings
#Enable or disable the account4, 0-Disabled (Default), 1-Enabled
account.4.enable =
#Configure the label displayed on the LCD screen for account 4
account.4.label =
#Configure the display name of account4
account.4.display_name =
#Configure the user name and password for register authentication
account.4.auth_name =
account.4.password =

Yealink SIP-T4X IP Phones Auto Provisioning Guide
10
#Configure the register user name
account.4.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.4.sip_server.1.address =
account.4.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.4.sip_server.2.address =
account.4.sip_server.2.port =
# Account 5 settings
#Enable or disable the account5, 0-Disabled (Default) 1-Enabled
account.5.enable =
# Configure the label displayed on the LCD screen for account 5
account.5.label =
#Configure the display name of account5
account.5.display_name =
#Configure the user name and password for register authentication
account.5.auth_name =
account.5.password =
#Configure the register user name
account.5.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.5.sip_server.1.address =
account.5.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.5.sip_server.2.address =
account.5.sip_server.2.port =
# Account 6 settings
#Enable or disable the account6, 0-Disabled (Default), 1-Enabled
account.6.enable =
#Configure the label displayed on the LCD screen for account 6
account.6.label =
#Configure the display name of account6
account.6.display_name =
#Configure the user name and password for register authentication
account.6.auth_name =
account.6.password =

Getting Started
11
#Configure the register user name
account.6.user_name =
#Configure the SIP server 1 address and port (5060 by default)
account.6.sip_server.1.address =
account.6.sip_server.1.port =
#Configure the SIP server 2 address and port (5060 by default)
account.6.sip_server.2.address =
account.6.sip_server.2.port =
#Configure the WAN port type; 0-DHCP (default), 1-PPPoE (for SIP-T46G only), 2-Static IP
Address
#Require reboot
network.internet_port.type =
#Configure the static IP address, submask, gateway address and DNS server address.
#Require reboot
network.internet_port.ip =
network.internet_port.mask =
network.internet_port.gateway =
network.primary_ dns=
network.secondary_dns =
To protect against unauthorized access and tampering of sensitive information (e.g.,
login passwords, registration information), you can encrypt configuration files using
Yealink Configuration Conversion Tool. AES keys must be 16 characters and the
supported characters contain: 0 ~ 9, A ~ Z, a ~ z. For more information on how to
encrypt configuration files, refer to Yealink Configuration Conversion Tool User Guide .
AES keys must be configured on the phone before the auto provisioning process. AES
keys are configurable via web user interface at the path: Settings->Auto
Provision->Common AES Key (and MAC-Oriented AES Key).
When configuring some particular features, you may need to upload resource files to IP
phones, such as personalized ringtone file, language package. Yealink provides some
resource file templates for the particular features. Ask the distributor or Yealink FAE for
resource file templates. The following provides information on how to customize
resource files and specify the access URL for the resource files.

Yealink SIP-T4X IP Phones Auto Provisioning Guide
12
The IP phones have built-in system ringtones. You can change the ring type, or customize
a ringtone and upload it to the phone via auto provisioning.
The ringtone file must be PCMU audio format, mono channel, 8K sample rate and 16 bit
resolution.
The ringtone file format must be *.wav.
The ringtone file uploaded must be within 100KB.
####################################################
## Configure the access URL of the customized ringtone ##
####################################################
ringtone.url =
#Delete all the custom ringtones uploaded through auto provisioning
ringtone.delete = http://localhost/all
For example, enter “tftp://192.168.1.100/Ring9.wav” in the “ringtone.url =” field. During
the auto provisioning process, the phone connects to the provisioning server
“192.168.1.100”, and downloads the ringtone file “Ring9.wav”.
For more information on customizing a ringtone file, refer to Customizing a Ringtone
Using Cool Edit Pro on page 54.
You can modify the language translation for the phone user interface, and add a new
language to the phone. To modify or add a language, you need to edit the language
file, upload it to the provisioning server, and then specify the access URL in the
configuration file.
The following table lists available languages and the associated language files for the
phone user interface:
Available
Language
Associated Language Pack
for SIP-T42G/T41P
Associated Language Pack
for SIP-T46G
English
lang+English.txt
0.GUI.English.lang
Chinese_S
/
1.GUI.Chinese_S.lang
Chinese_T
/
2.GUI.Chinese_T.lang
German
lang-German.txt
3.GUI.German.lang
French
lang-French.txt
4.GUI.French.lang
Italian
lang-Italian.txt
5.GUI.Italian.lang
Polish
lang-Polish.txt
6.GUI.Polish.lang

Getting Started
13
Available
Language
Associated Language Pack
for SIP-T42G/T41P
Associated Language Pack
for SIP-T46G
Portuguese
lang-Portuguese.txt
7.GUI.Portuguese.lang
Spanish
lang-Spanish.txt
8.GUI.Spanish.lang
Turkish
lang-Turkish.txt
9.GUI.Turkish.lang
To update translation of a built-in language, you should modify translation items in the
language file, upload the file to the root directory of the provisioning server, and trigger
an auto provisioning process for update. The file name of the language file cannot be
changed.
To add a new translation language, you should add and edit a new language file
named as “X.GUI.Y.lang”for SIP-T46G IP phones or “lang-Y.txt”for SIP-T46G/T42G/T41P IP
phones (the file name of the English language pack is“lang+English.txt”), upload the file
to the directory of the provisioning server, and trigger an auto provisioning process for
update. “X”in the language file name is an integer which starts from 10. “Y”in the
language file name means the name of the new added language. For example, you
want to add a new translation language “Korean”for SIP-T46G IP phones. The file name
of the new added language file should be “10.GUI.Korean.lang”. After update, you will
find a new language selection named as “Korean”on the phone user interface:
Menu->Basic->Language.
The following figure shows a portion of a language file for SIP-T46G IP phones:
SIP-T46G IP phones also support to add a custom or modify an existing LCD language
with a txt formatted file. The txt formatted language file name must be “lang-Y.txt”,
where “Y”is the language name e.g., lang-German.txt). In addition, the txt formatted
English language file name must be “lang+English.txt”. You can also go to the file name
of language pack for SIP-T42G/T41P IP phones for reference.

Yealink SIP-T4X IP Phones Auto Provisioning Guide
14
You can also define the name of the new added language by editing the parameter
“Name=”in the language file for SIP-T46G IP phones. For example, edit the value of the
parameter “Name=”to be “en-us”in the “0.GUI.English.lang”language file. After
update, you will find the English language selection on the phone user interface is
“en-us”.
The following figure shows a portion of a txt formatted language file for SIP-T4X IP
phones:
####################################################
## Configure the access URL of the LCD language file ##
####################################################
gui_lang.url =
#Delete all custom languages through auto provision
gui_lang.delete = http://localhost/all
If you want to add a new language Russian to the phone, configure the parameter
“gui_lang.url =” in the configuration file, for example:
gui_lang.url = tftp://192.168.1.100/10.GUI.Russian.lang ## For SIP-T46G##
gui_lang.url = tftp://192.168.1.100/lang-Russian.txt ##For SIP-T42G/T41P##
During the auto provisioning process, the phone connects to the provisioning server
“192.168.1.100”, and downloads the language file. After update, you will find a new
language selection “Russian”on the phone user interface.
Available languages may vary between different firmware versions.
To update translation of an existing language, do not rename the file name of the
language file.
