Yealink T48S Skype For Business Edition User manual

www.yealink.com
Applies to firmware version 66.9.0.42 or later.
®
T48S-Skype for Business Edition
Quick Start Guide (V9.42)

The following items are included in your package. If you find anything missing, contact your system
administrator.
(Optional) (Optional)
Stand
Handset Cord
Handset
Skype for Business Phone
Ethernet Cable
Wall Mount BracketPower Adapter
1
Quick Start Guide
Packaging Contents
Assembling the Phone
2. Connect the handset and optional headset, as shown below:
Note:The headset or wireless headset adapter EHS36 should be purchased separately.
The EXT port can also be used to connect the expansion module EXP40. For more information
on how to use the EHS36 and EXP40, refer to Yealink_EHS36_User_Guide and Yealink_EXP40-
Skype_for_Business_Edition_Quick_Start_Guide.
Note: We recommend that you use the accessories provided or approved by Yealink. The use of
unapproved third-party accessories may result in reduced performance.
Note :You can also mount the phone to a wall. For more information on how to attach the wall mount
bracket, refer to Yealink Wall Mount Quick Installation Guide.
(2m CAT5E FTP Cable)
T48S
The two wall mount slots are plugged up by
silica gels. You can pull out the silica gels
when mounting your IP phone to a wall.
1. Attach the stand, as shown below:
Desk Mount Method
45
Wireless Headset Adapter EHS36

2
Startup
After the Skype for Business phone is connected to the network and
supplied with power, it automatically begins the initialization process.
After startup, the sign-in screen appears on the touch screen.
Note:
Welcome
Initializing... Please wait
The Skype for Business phone should be used with Yealink original power adapter (5V/2A) only.
The use of the third-party power adapter may cause the damage to the phone. If you are
connecting a PC to your phone, we recommend that you use the Ethernet cable provided by
Yealink.
If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the
hub/switch is PoE-compliant.
A
AC Power Option
PC Connection
(Optional)
Power Adapter
(DC 5V)
B
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional) IEEE 802.3af compliant
PoE Hub/Switch
PC
PC
3. Connect optional USB devices:
Note:
The optional USB devices should be purchased separately.
For more information on how to use the BT40 and WF40, refer to Yealink Bluetooth USB Dongle
BT40 User Guide and Yealink Wi-Fi USB Dongle WF40 User Guide.
You can connect a Bluetooth USB dongle BT40, Wi-Fi USB dongle WF40, USB headset or USB flash drive
(to record calls) to the USB port.
4. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you
which one to use.

3
You can sign into or sign out of your Skype for Business account on the phone.
To sign into your Skype for Business account:
1. Tap Sign in, and then select a desired sign-in method.
2. Follow the onscreen prompts.
To sign out of your Skype for Business account:
1. Tap your avatar at the top-right corner of the touch screen.
2. Tap Sign Out.
If the Skype for Business server is configured to forcibly lock the phone, user can use phone lock feature
to lock the phone to prevent it from unauthorized use.
The Skype for Business phone will prompt the user to create a lock PIN at the initial sign-in.
To set a lock PIN:
1. Enter the lock PIN in the New PIN field.
2. Enter the lock PIN again in the Confirm PIN field.
3. Tap Save or press to accept the change.
After you create a lock PIN, you can use it to unlock your phone.
To unlock the phone:
1. Enter the lock PIN when the phone is locked.
2. Tap Unlock to unlock the phone.
Your presence information is a quick way for other people to see your availability status. You can change it
manually if you want to.
To update your presence status:
1. Tap your avatar at the top-right corner of the touch screen.
2. Tap the desired status.
You can tap Reset Status to change your status to Available.
The phone directory includes local directory and Skype for Business directory.
To add a local contact:
1. Tap Contacts->Local Directory.
2. Tap the desired group, and then tap to add a contact.
3. Enter a unique contact name in the Name field and other information in the corresponding fields.
4. Tap or press to accept the change.
To search for contacts:
1. Pick up the handset, press Speakerphone key or tap .
2. Enter a few continuous characters of the contact name or continuous numbers of the contact number to
search for the contact.
The phone automatically displays search results.
Phone Lock
Update Your Presence Status
Directory
Sign into or Sign Out of Your Skype for Business Account

4
Basic Call Features
To add a Skype for Business contact:
1. Tap the desired contact from the search results.
2. Tap Add to SFB.
3. Tap the desired group.
To add a contact to the Favorites group：
When you add contacts to the Favorites group, those favorites display on the Favorites screen too. By
default, local favorites are displayed before the Skype for Business favorites. Local favorites are indicated by
the icon . Skype for Business favorites are indicated by the presence status icon.
To view a contact’s information:
1. Tap Contacts.
2. Tap the desired group.
3. Tap the desired contact to view the detailed information.
To call contacts from the directory:
1. Tap Contacts.
2. Tap the desired group.
3. Tap the desired contact to view the detailed information.
4. Tap .
To place a call:
1. Do one of the following:
- Pick up the handset.
- Press .
- Press .
2. Enter the number and then tap .
To answer a call:
1. Do one of the following:
- Pick up the handset. The call is answered in handset mode.
- Press . The call is answered in hands-free (speakerphone) mode.
- Press . The call is answered in headset mode.
To end a call:
1. Do one of the following:
- If you are using the handset, hang up the handset or tap .
- If you are using the speakerphone, press or tap .
- If you are using the headset, tap .
To redial a call:
1. Press when the phone is idle to dial out the last dialed number.
To mute or un-mute a call:
1. Press to mute the microphone or press it again to un-mute the microphone during a call.

5
To place a call on hold:
1. Press or tap during an active call.
To resume the held call, do one of the following:
- If there is only one call on hold, press or tap .
- If there is more than one call on hold, tap the call you want to resume, and then press or tap .
Initiate a Conference Call
You can initiate a Skype for Business conference call by meet now or calling a group of Skype for Business
contacts.
To initiate a conference call:
1. Tap Menu->Meet Now-> .
2. Select a contact and tap .
3. Tap to add additional contacts.
To initiate a conference call with a Skype for Business group:
1. Tap Contacts.
2. Tap the desired Skype for Business group.
3. Tap to dial all Skype for Business contacts in the group.
Call Forward
You can enable the call forward feature to forward all incoming calls to the desired destination.
To enable call forward:
1. Tap Menu->Setting->Features->Call Forward.
2. Tap the On radio box of the Call Forward field.
3. Tap the desired type.
4. Tap or press to accept the change.
You can also forward an incoming call when your phone is ringing.
To forward an incoming call to a contact when your phone is ringing:
1. Tap .
2. Select a contact and tap .
To forward an incoming call to voicemail when your phone is ringing:
1. Tap .
Call Transfer
You can transfer a call in the following ways:
To perform a blind transfer during a call:
1. Press or tap during an active call. The call is placed on hold.
2. Select a contact.
3. Press or tap to complete the transfer.
Then the call is connected to the number to which you are transferring.
To perform a consultative transfer:
1. Tap during an active call. The call is placed on hold.
2. Select a contact and tap .
3. After the party answers the call, press or tap to complete the transfer.

Better Together over Ethernet (BToE) enables you to place, hold, and answer calls on your phone and
Skype for Business client on your computer. You can download the Yealink BToE Connector application
from the Yealink Website and install the application on your computer.
Before you can begin using BToE, you must pair your phone with your computer.
To activate BToE:
1. Do one of the following:
- Connect an Ethernet cable from your computer to the PC port on your phone.
- Enter the phone IP address into the BToE application manually and click OK.
If you are not signed into Skype for Business on your phone, a dialog box is displayed on your
computer asking for your Skype for Business login credentials.
2. If the dialog box does not display on your computer, tap Sign in on your phone and select Sign in via
PC.
3. Enter your login credentials in the dialog box.
The same user account is signed into your phone and your Skype for Business client, so that the BToE is
activated.
To place BToE calls, do one of the following:
- Hover your cursor over the avatar of the contact, and then click in the Skype for Business client.
- Select a contact or enter the phone number, and then tap .
To answer BToE calls, do one of the following:
- Click in the Skype for Business client.
- Tap on your phone.
To hold BToE calls, do one of the following:
- Click , and then click in the Skype for Business client.
- Tap or press on your phone.
To resume a call, do one of the following:
- Click , and then click in the Skype for Business client.
- Tap or press on your phone.
To change the audio device during a call in the Skype for Business client:
1. Click , and then click to change the audio device.
6
Using Better Together over Ethernet (BToE)
