Z3 Technology HE4K-DCK-10 User manual

User Instructions
Model Name: HE4K-DCK-10
DOC-USR-0123-01
Software Version 2.10f
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2017 Z3 Technology, LLC. All rights reserved.
Z3 Technology and ZEUS are registered trademarks of Z3 Technology, LLC.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
2
REVISION HISTORY
Version
Date
Change Note
Author
01
07/27/2016
Initial document
JC

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIPTION..............................................................................................7
2.0 FEATURES .............................................................................................................7
2.1 Supported Resolutions ........................................................................................... 8
3.0 PACKAGE CONTENTS.................................................................................................9
4.0 OPERATING CONTROLS ............................................................................................ 10
5.0 GETTING STARTED WITH THE HE4K-DCK-10.................................................................... 11
5.1 Access the User Interface Using ZFinder .....................................................................12
6.0 STREAMING CONTROL ............................................................................................. 14
6.1 Stream UDP.......................................................................................................14
6.2 Stream RTP .......................................................................................................17
6.3 Stream RTSP......................................................................................................19
6.4 Stream RTMP .....................................................................................................22
6.5 Tuning for Latency...............................................................................................30
6.6 Stream Multiple Resolutions ...................................................................................32
6.7 Record to USB ....................................................................................................33
6.8 Microphone Input ................................................................................................35
6.9 Composite Pass-Through........................................................................................35
6.10 Record Snapshot .................................................................................................37
7.0 CAMERA CONTROL ................................................................................................. 38
7.1 Zoom ..............................................................................................................38
7.2 Preview and Download Image..................................................................................38
7.3 Color Controls....................................................................................................39
7.4 Sony VISCA Camera Control ....................................................................................39
7.5 ONVIF Profile S .................................................................................................42
8.0 PERFORMING OTHER OPERATIONS WITH THE HE4K-DCK-10 ................................................. 43
8.1 Save Current Settings ...........................................................................................43
8.2Advanced Settings Mode........................................................................................44
8.3 Set a Static IP Address ..........................................................................................45
8.4 Upgrade Firmware...............................................................................................47
8.5 Setting a Password ..............................................................................................48
8.6 Factory Reset ....................................................................................................49
9.0 DECODE OPTIONS .................................................................................................. 50
9.1 PC Configuration for 4K HEVC/H.265 Decode ...............................................................50
9.2 ZEUS HE4K-01 Decode .........................................................................................53
10.0 SUMMARY OF OPTIONS ............................................................................................ 54

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
4
10.1 The System Setup Tab...........................................................................................54
10.2 The User Presets Tab ............................................................................................57
10.3 The Status Tab ...................................................................................................57
10.4 The Camera Tab .................................................................................................58
10.5 The Term Tab.....................................................................................................60
10.6 The CH1 Tab (Channel 1) .......................................................................................60
10.7 The CH2 & CH3 Tabs (Channels 2 & 3) .......................................................................65
10.8 Values Appearing at the Bottom of All Tabs..................................................................66
10.9 ZFinder............................................................................................................67
APPENDIX A: Finding the IP Address of Your Computer.............................................................. 68
APPENDIX B: Configuring the Wowza Server for RTMP .............................................................. 69
APPENDIX C: Example Camera Controller Application .............................................................. 71
APPENDIX D: Troubleshooting ........................................................................................... 75

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
5
LIST OF FIGURES
Figure 1: HE4K -DCK-10 Board Stack Dimensions ........................................................................ 7
Figure 2 HE4K-DCK-10 Package Contents ................................................................................ 9
Figure 3 HE4K-DCK-10 Interfaces.........................................................................................10
Figure 4 HE4K-DCK-10 Physical Block Diagram (Camera Not Included) .............................................11
Figure 5 HE4K-DCK-10 Connected to FCB-ER8300 (Camera Not Included) .........................................11
Figure 5 ZFinder with the HE4K-DCK-10 Selected .....................................................................12
Figure 6 HE4K-DCK-10 User Interface – System Setup Tab ............................................................13
Figure 7 CH1 Tab Configuration – UDP ...................................................................................15
Figure 8 VLC Open Network Stream Screen for UDP ..................................................................16
Figure 9 Example of Video Streaming to VLC (UDP) ...................................................................16
Figure 10 CH1 Tab Configuration – RTP ..................................................................................17
Figure 11 Example of Encoded Video Streaming to VLC (RTP) .......................................................18
Figure 12 CH1 Tab Configuration – RTSP.................................................................................19
Figure 13 Finding your Camera’s IP Address ............................................................................20
Figure 14 VLC Open Network Stream Screen for RTP .................................................................20
Figure 15 Example of Z3 Video Streaming to VLC (RTSP) .............................................................21
Figure 16 CH1 Tab Configuration – RTMP Streaming to Wowza Streaming Engine™ ...............................23
Figure 17 Navigating to the Wowza Test Player ........................................................................24
Figure 18 Viewing Streamed Content on Wowza Test Player .........................................................25
Figure 19 YouTube Live Dashboard – Encoder Setup ...................................................................26
Figure 20 CH1 Tab Configuration – RTMP Streaming to YouTube Live ...............................................27
Figure 21 Facebook “Create Post” dialog box...........................................................................28
Figure 22 Facebook Live Streaming Dialog ..............................................................................28
Figure 23 Facebook Live Stream Encoder Settings .....................................................................29
Figure 24 Enable TS Lowlat Mode ........................................................................................30
Figure 25 VLC Media Player Tools Menu ..................................................................................31
Figure 26 VLC Media Player Advanced Preferences.....................................................................31
Figure 27 Recommended Settings ........................................................................................32
Figure 28 Create Additional Output Channels ..........................................................................32
Figure 29 USB Connection .................................................................................................33
Figure 30 CH1 Tab Configuration – TSFILE..............................................................................34
Figure 31 Microphone Connection........................................................................................35
Figure 32 CH1 Tab Configuration – Microphone Audio Settings.......................................................35
Figure 33 Composite Connection .........................................................................................36
Figure 34 Set Composite Pass-Through Resolution.....................................................................36

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
6
Figure 35 Camera Zoom Slider............................................................................................38
Figure 36 Camera Tab Preview Image ...................................................................................38
Figure 37 Color Controls...................................................................................................39
Figure 38 Com2TCP Configuration .......................................................................................40
Figure 39 Camera Controller Software Configuration .................................................................41
Figure 40 The User Presets Tab ...........................................................................................43
Figure 41 Entering a User Preset Name .................................................................................43
Figure 42 Saving a User Preset............................................................................................43
Figure 43 Accessing Advanced Settings ..................................................................................44
Figure 44 Default UDP Settings (Left) and Advanced UDP Settings (Right).........................................45
Figure 45 Saving Updated Network Settings ............................................................................46
Figure 46 Updating Device Firmware ....................................................................................47
Figure 47 Software Updater Screen......................................................................................47
Figure 48 Creating or Changing the Password ..........................................................................48
Figure 49 Password Entry Screen.........................................................................................48
Figure 50 Pinhole Reset.....................................................................................................49
Figure 52 LAV Filters Configuration ......................................................................................51
Figure 53 Disable Hardware Decoding in VLC ..........................................................................52
Figure 54 ZEUS HE4K-01 H.264 Decoder.................................................................................53
Figure 55 Using the Command Prompt to Determine Your PC’s IP Address.........................................68
Figure 56 Locating Your Computer’s IP Address ........................................................................68
Figure 57 Wowza Performance Settings .................................................................................69
Figure 58 Wowza Security Settings.......................................................................................70
Figure 59 Running the Example Application ............................................................................71

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
7
1.0 GENERAL DESCRIPTION
The HE4K-DCK-10 is a H.265/HEVC, H.264 and MJPEG video encoder designed to be a companion to the Sony
FCB-ER8300 block camera. It is capable of accepting HD video from the camera at 60 frames per second and
producing IP streams that can be sent on a standard Ethernet cable. The HE4K-DCK10 has one KEL connector
for Sony FCB-ER8300 or other compatible cameras.
Figure 1: HE4K -DCK-10 Board Stack Dimensions
2.0 FEATURES
▪Noise reduction algorithm for high frequency and high detail areas
▪HEVC/H.265 encode and stream up to 1080p at 60 fps
▪H.264 encode and stream up to 2160p at 60 fps
▪Encode modes of operation: HEVC/H.265, H.264 and MJPEG
▪Low bandwidth, low latency video encoding
▪Simultaneously output two different resolutions from a single video source
▪Remote camera control via HTTP-based interface or pass VISCA camera control commands over IP
▪Inputs: powered line audio
▪Outputs: composite
▪Additional Interfaces include Gigabit Ethernet, USB 2.0, Micro SD Card and RS-232 Serial
▪RS485, alarm input and output interfaces available internally
▪Supports streaming in MPEG-2 TS (UDP), RTP, RTSP, RTMP* and TSRTP
58 mm
58 mm

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
8
▪Supports unicast and multicast streaming
▪Compatible with CDN’s including Wowza Streaming Engine™ *, YouTube Live* and Facebook Live*
▪Record a compressed .ts file to a USB storage device
▪Record a JPG snapshot while video streaming
▪Easily mounts to tripods or mounting brackets (enclosure is sold separately)
▪ONVIFprofile S compliant
▪Compatible with the ZEUSZ3-HE4K-01 decoder* (also available from Z3 Technology)
▪HTTP-based configuration software for user-friendly configuration, control and update
▪RS-232 serial port for technical configuration and control
▪Supports Power over Ethernet (PoE) when present
▪Operating Temp: -5 to 50 degrees C at 20-80% relative humidity (non-condensing)
▪Storage Temp: -10 to 60 degrees C at 20-80% relative humidity (non-condensing)
2.1 Supported Resolutions
Follow_input (2160p29.97)
Resize to 1080p29.97, 720p29.97 and 480p29.97
The HE4K-DCK-10 supports simultaneous output of up to three streams encoded at different resolutions,
frame rates and bitrates. Supported stream resolutions are:
2160p (8MP), 1440p (4MP), 1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 704x576,
640x480, 640x360, 420x380, 352x576, 352x288, 352x240, 320x240, and 320x180
In addition to scaling the resolution, the camera is also capable of scaling down the frame rate to save
bandwidth. Each channel can select from full frame rate, half frame rate or a quarter frame rate. For
example, it is possible to configure a primary stream of 3840x2160 at 30 fps simultaneously with a
secondary stream at 1280x720 at 7.5 fps.
The maximum performance for two channels is one 2160p30 plus one 720p30 stream.

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
9
3.0 PACKAGE CONTENTS
Figure 2 HE4K-DCK-10 Package Contents
*NOTE: additional cables may be required to connect your secondary camera. Contact Sales for more
information about available cables and compatible cameras.
HE4K PCB Assembly
KEL Ribbon Cable
12V 1 Amp AC Adapter-
Optional
Serial Cable-
Optional
Gender Changer-
Optional

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
10
4.0 OPERATING CONTROLS
1: RS-232 Serial Port
1
5: Status Light
2
2: USB 2.0 6: Composite Output
3: Microphone Input 7: 12V Power (optional)
4: GigE (PoE)
1
For advanced debugging purposes only. Not needed by typical users.
2
LED light will blink green when streaming.
Figure 3 HE4K-DCK-10 Interfaces

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
11
5.0 GETTING STARTED WITH THE HE4K-DCK-10
If you have received an HE4K-DCK-10 assembly, you will need to connect it to the Sony FCB-ER8300 4K
camera block. The Interface Front End PCB of the HE4K-DCK-10 assembly (see Figure 4) has a 30-pin KEL
connector that allows a flexible ribbon cable to be used to connect the encoder assembly to an identical
connector on the Sony FCB-ER8300.
The KEL cable is sold separately (ordering part number: CBL-0025-01).
WARNING: ONLY USE THE CORRECT KEL RIBBON CABLE PROVIDED BY Z3 TECHNOLOGY.
Using an incorrect cable can permanently damage the camera body.
Figure 4 HE4K-DCK-10 Physical Block Diagram (Camera Not Included)
Figure 5 HE4K-DCK-10 Connected to FCB-ER8300 (Camera Not Included)
Sony FCB ER-8300
(Not Included)
KEL Ribbon Cable
(Sold Separately)

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
12
5.1 Access the User Interface Using ZFinder
ZFinder is a PC utility that allows you to find any Z3 Technology product on your network. If you have
not yet downloaded this to your computer, you can find this program at Z3Cam-4K.Z3technology.com.
(1) Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder may be unable to discover
your camera.
Note: The HE4K-DCK-10 is set to DHCP by default. If no DHCP server is available on the network, a static IP
address of 192.168.0.120 and a netmask of 255.255.0.0 will be assigned. The IP address can be manually
entered as the URL in a browser window to access the user interface.
(2) Run the ZFinder PC utility on your PC. You may need to allow it past any firewalls or security
programs on your PC. The ZFinder window appears and completes a scan of the network. ZFinder
then lists all Z3 systems connected to the network. The HE4K-DCK-10 appears as the Z3Cam-4K.
(3) Click on the Z3Cam-4K entry in the window to select it. This will cause the Edit Device, Open
Device and Flash LEDs buttons to activate.
Figure 6 ZFinder with the HE4K-DCK-10 Selected
Note: Selecting Edit Device allows for manual changes to network settings. See Section 10.9, ZFinder, for more
information.
Note: If the device appears in red, there is a network error, and network settings will need to be modified in
order to access the user interface.
(4) Click on Open Device. An internet browser window is opened in your default web browser (for best
results, Firefox or Chrome are recommended) and the user interface appears with the System Setup
tab open.

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
13
(5) By default, the system will have automatically started encoding. Click on the CH1 tab for channel
one configuration settings. If the encoder status message in the bottom right corner of the screen
shows RUNNING, you will need to click the stop or Stop All button in order to change any settings.
Figure 7 HE4K-DCK-10 User Interface – System Setup Tab

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
14
6.0 STREAMING CONTROL
This section gives step-by-step instructions on setting the HE4K-DCK-10 to output and stream video using
each of the output format options: UDP, RTP, RTSP and RTMP. In addition to the HE4K-DCK-10, a Windows
PC with the VLC media player
3
downloaded is required. Please see Section 8.4, Decoder Options, for more
information on compatible decoders and PC configuration and requirements for H.265/HEVC decode at 4K
resolutions.
6.1 Stream UDP
6.1.1 UDP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Select the Video Codec you would like to use for your video encoding. In the pictured example
H265(HEVC) is selected.
(4) Under Output Setup, select UDP in the Output Format dropdown menu.
(5) Set Dest Address to:
a. the IP address of your PC that will be running the VLC media player. To determine the
correct IP address of your PC, see APPENDIX A: Finding the IP Address of Your Computer. In
the example pictured, 192.168.0.6 is used.
b. or a multicast address. An example multicast address would be 225.1.2.3. If you are on a
shared network, check with your Network Administrator.
(6) Make note of the value listed for Dest Port. This will be 8600 by default when your system is first
received.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
3
VLC is an open source media player from the VideoLAN organization that can be downloaded for free online.

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
15
Figure 8 CH1 Tab Configuration – UDP
(4) Change
to “UDP”
(1) If necessary, click “Stop”
(7) Click “Start”
(2) Verify is
“Follow input”
(3) Verify is
“H265(HEVC)”
(5) Set to PC
IP Address or
Multicast Address
(6) Note value

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
16
6.1.2 Run VLC to View UDP Stream
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 9.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open Network Stream.
(4) Under the Network tab, enter “udp://@Dest_Address:Dest_Port” for the network URL.
c. Dest_Address will be values of the IP address or multicast address entered in the Dest
Address field in the user interface CH1 tab. The IP address used in this example is
192.168.0.6.
d. Dest_Port will match the value found in the Dest Port field in the Encoder tab. The default
value is 8600.
e. In this example, the full network URL would be “udp://@192.168.0.6:8600”.
(5) Press Enter or click Play. You will see your camera’s video streaming to VLC.
Figure 10 Example of Video Streaming to VLC (UDP)
Figure 9 VLC Open Network Stream Screen for UDP

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
17
6.2 Stream RTP
6.2.1 RTP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen
of any tab.
(2) Verify Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution output
is desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 11 CH1 Tab Configuration – RTP
(4) Change
to “RTP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
18
6.2.2 Run VLC to View RTP Stream
An SDP file is needed to view an RTP stream from the HE4K-DCK-10 in the VLC media player. If you have
not yet downloaded these files to your computer, you can find them at Z3Cam-4K.Z3technology.com.
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 9.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open File.
(4) Find and select the SDP file corresponding to the video codec you selected previously.
a. H265(HEVC) video: use the SDP file entitled “z3-h265-he4k-dck.sdp”
b. H264(AVC) video: use the SDP file entitled “z3-h264-he4k-dck.sdp”
(5) Press Enter or click Open. You will see your camera’s video streaming to VLC.
Figure 12 Example of Encoded Video Streaming to VLC (RTP)

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
19
6.3 Stream RTSP
6.3.1 RTSP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen
of any tab.
(2) Verify Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution output
is desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTSP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 13 CH1 Tab Configuration – RTSP
(4) Change
to “RTSP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

HE4K-DCK-10 User Instructions
DOC-USR-0123-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
20
6.3.2 Run VLC to View RTSP Stream
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 9.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(6) Open the VLC media player on your PC.
(7) Select the Media menu.
(8) Select Open Network Stream.
(9) Enter “rtsp:// IP_Address/z3-#{m}.mp4” for the network URL.
a. IP_Address will be the IP address of your HE4K-DCK-10. If your camera is set to DHCP (This is
the default setting when it is first received.), you can find this in ZFinder or the web
browser with your user interface open. If you have set your encoder to a static IP address,
this should match the Local IP Address field in the System Setup tab. In the example
pictured, the encoder was assigned 192.168.0.120 at start up.
b. z3-#
corresponds to the number of the channel tab of the user interface. For example if the CH1
tab is used, “z3-1” is entered.
a. {m} is added if a multicast address is being used. (For example, rtsp://IP_Address/z3-
1m.mp4) If you are using a unicast address, as we are in the example pictured, omit the
letter m after z3-1 in the address.
b. In this example, the full network URL would be “rtsp://192.168.0.120/z3-1.mp4”.
(10) Press Enter or click Play. You will see your camera’s video streaming to VLC.
Figure 15 VLC Open Network Stream Screen for RTP
Figure 14 Finding your Camera’s IP Address
Current IP Address of
your HE4K-DCK-10
