1.0 GENERAL DESCRIPTION
The ZCube-21 is a H.265/HEVC, H.264 and MJPEG video encoder designed for easy and portable use. It is
capable of accepting 4K video at 30 frames per second and producing IP streams that can be sent on a
standard Ethernet cable.
Figure 1 ZCube-21 Board Stack Dimensions
33 mm
61 mm
63 mm

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
8
2.0 FEATURES
▪HEVC/H.265 encode and stream up to 2160p at 30 fps
▪H.264 encode and stream up to 2160p at 30 fps
▪Encode modes of operation: HEVC/H.265, H.264 and MJPEG
▪Low bandwidth, low latency video encoding
▪Noise reduction filter improves video encoding quality
▪Simultaneously output two different resolutions from a single video source
▪Remote camera control via HTTP-based interface or pass VISCA camera control commands over IP
▪Inputs: HDMI, powered line audio
▪Outputs: HDMI
▪Supports HDMI cables with screw lock
▪Additional Interfaces include Gigabit Ethernet, USB 3.1, Micro SD Card, RS-232 Serial, and RS-485
▪Supports streaming in MPEG-2 TS (UDP), RTP, RTSP, RTMP*, SRT, RTMPS and TSRTP
▪Supports unicast and multicast streaming
▪Compatible with CDN’s including Wowza Streaming Engine™ *, YouTube Live* and Facebook Live*
▪Record a compressed .ts/.mp4 file to a USB storage device
▪Record a JPG snapshot while video streaming
▪ONVIFProfile S & T compliant
▪Compatible with the ZEUSDMD-4K decoder (also available from Z3 Technology)
▪HTTP-based configuration software for user-friendly configuration, control and update
▪RS-232 serial port for technical configuration and control
▪Supports Power over Ethernet (PoE) 802.3af when present
▪Weight: 222g
▪Operating Temp: -5 to 65 degrees C at 20-80% relative humidity (non-condensing)
▪Storage Temp: -10 to 85 degrees C at 20-80% relative humidity (non-condensing)
2.1 Supported Input Resolutions
▪3840x2160p at 30, 29.97, 25 and 24 fps
▪1920x1200 at 60 fps
▪1920x1080p at 60, 59.94, 50, 30, 29.97 and 25 fps
▪1280x720p at 60, 59.94, 50, 30, 29.97 and 25 fps
▪720x480p at 60, 59.94 or 50 fps
▪640x480p at 60, 59.94 or 50 fps
Other resolutions are available upon request.

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
9
The ZCube-21 supports simultaneous output of up to three streams encoded at different resolutions, frame
rates and bit rates. Supported stream resolutions are:
2160p (8MP), 1440p (4MP), 1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 800x600, 704x576,
640x480, 640x360, 420x380, 352x576, 352x288, 352x240, 320x240, and 320x180
The maximum performance for two channels is one 2160p30 plus one 720p30 stream.
3.0 PACKAGE CONTENTS
Figure 2 ZCube-21 Package Contents
ZCube-21
12V 1 Amp AC Adapter
Serial Cable
Null Modem Adapter
2x Screw Lock HDMI-HDMI Cable

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
10
4.0 OPERATING CONTROLS
1: HDMI In
2: Service: USB type-C connection used for factory operations and debug
3: HDMI Out
4: Gigabit Ethernet
5: USB 3.1
6: RS-232 Serial Port
1
: used as the system console, debug, or system control via serial port
The default is the system console at 115200, N81.
7: Audio In
8: 12V Power (optional)
9: Status/Power LED
10: Serial I/O terminals: provides access to the RS485/RS422* serial port and the RS232 serial port.
This can be used as RS485 or RS422*, as configured at the Term tab in the GUI.
•To use in RS422 mode connect the four RS422* wires A, B, X and Y as indicated.
•To use in RS485 mode connect the two RS485 wires A and B as indicated, and leave
terminals X and Y unconnected.
•Terminals RS232-TX and RS232-RX provide access to the RS232 port.
*RS422 is not currently supported.
1
For advanced debugging purposes only. Not needed by typical users.
Figure 3 ZCube-21 Interfaces
1
3
2
4
5
6
7
8
9
10

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
11
5.0 STREAMING CONTROL
This section gives step-by-step instructions on setting the ZCube-21 to output and stream video using each
of the output format options: UDP, RTP, RTSP and RTMP. In addition to the ZCube-21, a Windows PC with
the VLC media player
2
downloaded is required. Please see Section 8.0, Decode Options, for more
information on compatible decoders and PC configuration and requirements for H.265/HEVC decode at 4K
resolutions.
5.1 Stream UDP
5.1.1 UDP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Select the Video Codec you would like to use for your video encoding. In the pictured example
H265(HEVC) is selected.
(4) Under Output Setup, select UDP in the Output Format dropdown menu.
(5) Set Dest Address to:
a. the IP address of your PC that will be running the VLC media player. To determine the
correct IP address of your PC, see APPENDIX A: Finding the IP Address of Your Computer. In
the example pictured, 192.168.0.6 is used.
b. or a multicast address. An example multicast address would be 225.1.2.3. If you are on a
shared network, check with your Network Administrator.
(6) Make note of the value listed for Dest Port. This will be 8600 by default when your system is first
received.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
7.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
2
VLC is an open source media player from the VideoLAN organization that can be downloaded for free online.

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
12
Figure 4 CH1 Tab Configuration – UDP
(4) Change
to “UDP”
(1) If necessary, click “Stop”
(7) Click “Start”
(2) Verify is
“Follow input”
(3) Verify is
“H265(HEVC)”
(5) Set to PC
IP Address or
Multicast Address
(6) Note value

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
13
5.1.2 Run VLC to View UDP Stream
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 8.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open Network Stream.
(4) Under the Network tab, enter “udp://@Dest_Address:Dest_Port” for the network URL.
c. Dest_Address will be values of the IP address or multicast address entered in the Dest
Address field in the user interface CH1 tab. The IP address used in this example is
192.168.0.6.
d. Dest_Port will match the value found in the Dest Port field in the Encoder tab. The default
value is 8600.
e. In this example, the full network URL would be “udp://@192.168.0.6:8600”.
(5) Press Enter or click Play. You will see your camera’s video streaming to VLC.
Figure 6 Example of Video Streaming to VLC (UDP)
Figure 5 VLC Open Network Stream Screen for UDP

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
14
5.2 Stream RTP
5.2.1 RTP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen
of any tab.
(2) Verify Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution output
is desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
7.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 7 CH1 Tab Configuration – RTP
(4) Change
to “RTP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
15
5.2.2 Run VLC to View RTP Stream
An SDP file is needed to view an RTP stream from the ZCube-21 in the VLC media player. If you have not
yet downloaded these files to your computer, you can find them at Z3Cam-4K.Z3technology.com.
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 8.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open File.
(4) Find and select the SDP file corresponding to the video codec you selected previously.
a. H265(HEVC) video: use the SDP file entitled “z3-h265-he4k-dck.sdp”
b. H264(AVC) video: use the SDP file entitled “z3-h264-he4k-dck.sdp”
(5) Press Enter or click Open. You will see your camera’s video streaming to VLC.
Figure 8 Example of Encoded Video Streaming to VLC (RTP)

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
16
5.3 Stream RTSP
5.3.1 RTSP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) Return to the user interface, and if necessary, click on the Stop button in the Channel Controls
section of the user interface CH1 tab or the Stop All button in the lower right corner of the screen
of any tab.
(2) Verify Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution output
is desired, select this in the dropdown menu and resizing will occur.
(3) Select the codec you would like to use for your video encoding. In the pictured example,
H265(HEVC) is selected.
(4) Under Output Setup, select RTSP in the Output Format dropdown menu.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
7.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
Figure 9 CH1 Tab Configuration – RTSP
(4) Change
to “RTSP”
(1) If necessary, click “Stop”
(5) Click “Start”
(3) Note value
(2) Verify is
“Follow Input”

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
17
5.3.2 Run VLC to View RTSP Stream
Note: Verify your PC is set up to handle decode of H.265 content at 4K resolutions. See Section 8.1, “PC
Configuration for 4K HEVC/H.265 Decode”, for more information.
(1) Open the VLC media player on your PC.
(2) Select the Media menu.
(3) Select Open Network Stream.
(4) Enter “rtsp:// IP_Address/z3-#.sdp” for the network URL.
a. IP_Address will be the IP address of your ZCube-21. If your camera is set to DHCP (This is
the default setting when it is first received.), you can find this in ZFinder or the web
browser with your user interface open. If you have set your encoder to a static IP address,
this should match the Local IP Address field in the System Setup tab. In the example
pictured, the encoder was assigned 192.168.0.120 at start up.
b. z3-# corresponds to the number of the channel tab of the user interface. For example, if
the CH1 tab is used, “z3-1” is entered.
c. In this example, the full network URL would be “rtsp://192.168.0.120/z3-1.sdp”.
Figure 10 Finding your Encoder’s IP Address
Current IP Address of
your ZCube-21

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
18
Figure 11 Force multicast RTP via RTSP
Note: some versions of VLC do not require the Force Multicast settings in VLC. In this example
“rtsp://192.168.0.120/z3-1m.mp4” would apply.
(5) When streaming RTSP via multicast the output address must end in .mp4 instead of .sdp. Also, {m}
is added if a multicast address is being used. (For example, rtsp://IP_Address/z3-1m.mp4).
a. If using a multi switch/router network, please note that a failure can be caused by the TTL
needing to be longer, resulting in the packets being discarded before reaching the
Figure 12 VLC Open Network Stream Screen for RTP

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
19
destination. This can be fixed by increasing the TTL by adding /NN after the multicast
address within our Web Interface. (NN is a two-digit number).
Ex: 239.0.12.33/10 equals a TTL of 10 hops the max value that can be defined as 255.
(6) Press Enter or click Play. You will see your camera’s video streaming to VLC.
Note: RTSP is only supported with VLC version 2.1.5 or later. When encoding via RTSP, any time the encoding
session is stopped and restarted, you will need to reopen VLC in order to view the stream.
Figure 13 Example of Z3 Video Streaming to VLC (RTSP)

ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
20
5.4 Stream RTMP
When in H.264 mode, the ZCube-21 supports RTMP streaming accepted by a variety of CDN’s (Content
Delivery Networks) and social media platforms for wide content distribution and live streaming.
5.4.1 RTMP Camera Streaming to the Wowza Streaming Engine™
Z3 Technology is a member of the Wowza Media Systems™ Technology Alliance partner program, and the
Wowza Streaming Engine™ is used here as an example.
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Set the Video Codec to H264(AVC) for RTMP streaming. Newer versions of the Wowza Streaming
Engine support HEVC to use HEVC check the Use H.265 for RTMP checkbox.
(4) Under Output Setup, select RTMP in the Output Format dropdown menu. In the case that an
encrypted stream is required select RTMPS. Encryption requires a certificate to be set up on the
Wowza Streaming Engine. See Wowza documentation for details.
(5) Set Dest Address to “IP_Address: port#/application/Stream_Name”.
a. IP_Address will be the IP address of the PC with the Wowza server. In this example,
192.168.0.6 is used.
b. port# will be the port number of the PC with the Wowza server. In this example, 1935 is
used.
c. application will need to match the application selected in Wowza. In this example the live
application is used.
d. Stream_Name will need to match the stream information you provide to the Wowza server.
In this example, hevc4k is used.
e. In this example, the full destination address would be “192.168.0.6:1935/live/hevc4k”.
(6) If necessary, set Authentication to Enable and enter your valid Wowza log in credentials.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
7.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
