Z3 Technology Z3-HE4K-01 User manual

User Instructions
4K Video Encoder and Decoder
Model Name: Z3-HE4K-01
The Power of ZEUSTM
DOC-USR-0056-09
Manual Version 2.33.2
Software Version 2.33.2
August 3, 2016
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2016 Z3 Technology, LLC. All rights reserved.
This document contains proprietary and confidential information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced,
disclosed, or disseminated to anyone without the prior written approval of an authorized representative of Z3.
Z3 Technology, LLC incorporates HDMI® technology. The terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
2
Revision History
Version
Date
Change Note
Author
0.00.01
07/25/2014
Original Document
KA
2.01.47
10/31/2014
Added Quick Start Section in Section 2.0. Added note on serial cable
and HDMI cable in Section 3.0. Updated features in Section 4.0 to
reflect current release. Added LEDs, note that serial port for debug
only, note that HDMI Out for future use, and broke out USB1/2 in
Section 5.0. Rewrote Section 6.0 to reflect current operation. Added
Section 8.0 on Changing Password. Added Section 9.0 on Summary of
Options Available. Added Appendix A on Troubleshooting. Updated
screenshots. Made document more robust.
RC
2.01.47
03/27/2015
Added Supported Resolutions, Latency, DHCP support sections. Added
Decode information in Section 7.0 and RTMP Streaming in Section 8.0
KA
2.01.47a
07/20/2015
Added SATA2 note
KA
2.01.47b
12/17/2015
Formatting updates. Added Section 9.4: Saving to File. Corrected
Video Bitrate range. Updated warranty information. Added notes
regarding version numbers pictured.
TT/TA
2.01.47c
02/10/2016
Added Simultaneous Streaming Encode Resolutions Supported,
Updated HW Warranty Link
TA
2.01.47d
02/19/2016
Added camera control information (Section 9.5), Corrected Max
Bitrate
TA
2.33.2
08/03/2016
Added registered ZEUS logo. Updated screenshots. Added Section 9.2
on setting a static IP address. Added multicast TTL question to
Appendix B. Added more information on items supported by optional
software upgrade.
TA

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL INFORMATION ................................................................................................. 6
Preface ................................................................................................................. 61.1
2.0 QUICK START GUIDE ..................................................................................................... 6
If You Have Received a System from Z3 with the Software Preloaded ........................................ 62.1
If You Already Have a System from Z3 and Need to Update the Firmware ................................... 62.2
3.0 PACKAGE CONTENTS..................................................................................................... 7
4.0 FEATURES ................................................................................................................. 8
Supported Single Stream Encode Resolutions..................................................................... 84.1
Supported Multi-Stream Encode Resolutions (Optional Upgrade).............................................. 84.2
Supported Decode Resolutions...................................................................................... 84.3
5.0 OPERATING CONTROLS .................................................................................................. 9
6.0 GETTING STARTED AND RUNNING THE ENCODER ...................................................................10
Prepare the 4K Source ..............................................................................................106.1
Connect and Power Up the Z3-HE4K-01 ..........................................................................106.2
Access the User Interface using ZFinder..........................................................................116.3
Streaming UDP .......................................................................................................126.4
Streaming RTP........................................................................................................156.5
Tuning for Latency...................................................................................................186.6
7.0 STREAMING RTMP .......................................................................................................19
Connect the Encoder ................................................................................................197.1
Configure for RTMP Streaming .....................................................................................197.2
Set Up the Wowza Server...........................................................................................207.3
Start the Encode .....................................................................................................207.4
View the Content on Wowza .......................................................................................207.5
8.0 RUNNING THE DECODER ...............................................................................................22
Connect the Z3-HE4K-01............................................................................................228.1
Set Decoder Mode ...................................................................................................238.2
Changing Back to Encoder Mode...................................................................................258.3
9.0 PERFORMING OTHER OPERATIONS WITH THE Z3-HE4K-01.........................................................26
Saving Current Settings .............................................................................................269.1
Using a Static IP Address............................................................................................289.2
Making a Firmware Update.........................................................................................309.3
Using the Password Feature ........................................................................................319.4
Saving to File .........................................................................................................339.5
Camera Control via the Z3-HE4K-01 (Optional Upgrade) ......................................................359.6
10.0 SUMMARY OF OPTIONS ................................................................................................38
The System Setup Tab .............................................................................................3810.1

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
4
The User Presets Tab...............................................................................................3910.2
The Status Tab ......................................................................................................4010.3
The MPTS Tab .......................................................................................................4010.4
The Term Tab (Not Supported - Available by Optional Software Upgrade) .................................4110.5
The CH1 Tab (Encode Options) ...................................................................................4110.6
The CH1 Tab (Decode Options) ...................................................................................4410.7
The CH2 Tab (Not Supported - Available by Optional Software Upgrade) ..................................4510.8
Values Appearing at the Bottom of All Tabs ....................................................................4510.9
APPENDIX A: Configuring the Wowza Server for RTMP ................................................................47
APPENDIX B: Troubleshooting .............................................................................................49
LIST OF FIGURES
Figure 1 Package Contents ................................................................................................. 7
Figure 2 Front and Rear Panels of the Z3-HE4K-01 ..................................................................... 9
Figure 3 Encode Connections for Z3-HE4K-01 ..........................................................................10
Figure 4 Power On the Z3-HE4K-01 ......................................................................................11
Figure 5 ZFinder with Z3-HE4K-01 Selected ............................................................................11
Figure 6 System Setup Tab ................................................................................................12
Figure 7 Channel 1 Configuration Screen - UDP........................................................................13
Figure 8 VLC Open Network Screen for UDP............................................................................14
Figure 9 Example of Z3 Video Streaming to VLC (UDP) ...............................................................14
Figure 10 Channel 1 Configuration Screen - RTP.......................................................................15
Figure 11 VLC Open Network Stream Screen for RTP .................................................................16
Figure 12 Determine the Current IP Address of Your Z3-HE4K-01....................................................16
Figure 13 Example of Z3 Video Streaming to VLC (RTP) ..............................................................17
Figure 14 Tuning for Various Use Cases..................................................................................18
Figure 15 Channel 1 Configuration Screen - RTMP.....................................................................19
Figure 16 Getting to the Wowza Test Player............................................................................20
Figure 17 Viewing Z3-HE4K-01 Content on Wowza.....................................................................21
Figure 18 Decode Connections for Z3-HE4K-01.........................................................................22
Figure 19 System Setup Tab ...............................................................................................23
Figure 20 Changing a Preset ..............................................................................................23
Figure 21 Saving serial_menu Settings ..................................................................................24
Figure 22 The “Save complete” Window ................................................................................24
Figure 23 Decoder CH1 Tab ...............................................................................................25

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
5
Figure 24 The User Presets Tab ...........................................................................................26
Figure 25 Entering a User Preset Name .................................................................................26
Figure 26 Selecting a Newly Created Preset............................................................................27
Figure 27 Saving New Settings to a User Preset........................................................................27
Figure 28 Setting a Static IP Address within a User Preset ...........................................................28
Figure 29 User Interface Using New IP Address ........................................................................29
Figure 30 Updating the Device Firmware ...............................................................................30
Figure 31 Selecting “Set Password”......................................................................................31
Figure 32 Changing the Password ........................................................................................31
Figure 33 Password Entry Screen.........................................................................................32
Figure 34 Configuring the Encoder to Write to File....................................................................33
Figure 35 USB Connection for Camera Control .........................................................................35
Figure 36 Term Tab Settings for USB1 Camera Connection ...........................................................36
Figure 37 Com2TCP Configuration .......................................................................................36
Figure 38 Camera Controller Software Configuration .................................................................37
Figure 39 Wowza Performance Settings .................................................................................47
Figure 40 Wowza Security Settings.......................................................................................48

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
6
1.0 GENERAL INFORMATION
Preface1.1
The ZEUSZ3-HE4K-01 is a compact H.264 encoder and decoder that supports HD resolutions up to 2160p
at 30 frames per second (4K Ultra HD). Video from HDMI can be streamed via UDP or RTP or to be saved
to a .ts file through USB or SATA2. It is configurable through an easy-to-use HTTP-based user interface.
The Z3-HE4K-01 is the ideal solution for industrial video, video distribution, surveillance and remote
monitoring.
The Z3-HE4K-01 is also available with a multi-stream software upgrade capable of simultaneously
streaming one source in 4K and up to 1080p30. Please contact your Z3 sales account manager for more
information.
2.0 QUICK START GUIDE
If You Have Received a System from Z3 with the Software Preloaded2.1
To start working with the encoder, you can go straight to Section 6.0, “GETTING STARTED AND RUNNIG
THE ENCODER,”on page 10. This section describes how to quickly stream 4K through the Ethernet via
UDP or RTP. Adding password protection is described in Section 9.4, “Using the Password Feature,” on
page 31. Information on RTMP mode can be found in Section 7.0, “STREAMING RTMP,” on page 19. Details
on running the Decoder can be found in Section 8.0, “RUNNING THE DECODER,” on page 22. Finally, a
summary of each parameter that can be configured in the user interface is given in Section 10.0,
“SUMMARY OF OPTIONS,” on page 38.
If You Already Have a System from Z3 and Need to Update the Firmware2.2
You can update the firmware via the HTTP-based graphical user interface (GUI) by following the
instructions in Section 9.3, “Making a Firmware Update,” on page 30.
*Note: Actual version numbers for your Z3 product may differ from those pictured in this document.

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
7
3.0 PACKAGE CONTENTS
Z3-HE4K-01
12V Power Supply
HDMI Cable
Serial Cable
Gender Changer
*Note: The HDMI cable is an HDMI 1.4 cable. This is required for 4K support.
*Note: The serial cable and gender changer are included for advanced troubleshooting purposes only
and are not needed by the typical user.
Figure 1 Package Contents

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
8
4.0 FEATURES
Encode up to 3840 x 2160 at 30fps H.264 + AAC
29.97, 25, 24 and 23.98fps capture also supported
Output to MPEG-2 TS, RTP or RTMP stream through GigE Ethernet
Supports simultaneous encode of a single 4K source into two different resolutions
1
Supports camera control via USB connection, including VISCA protocol compatible cameras
Multicast or Unicast streaming
Optional output to TS file on USB or SATA2
2
Bitrate and frame rate changes without stopping/restarting encoder
HTTP-based configuration software for user-friendly configuration, control, and update
Operating temperature: 0 to 40 degrees C at 20-80% relative humidity
Storage temperature: -10 to 65 degrees C at 20-80% relative humidity
Measurements: 145 x 130 x 34 mm (5.71 x 5.12 x 1.34 in)
Weight: 608 g (1.34 lb)
Supported Single Stream Encode Resolutions4.1
HDMI: 2160p30, 2160p29.97, 2160p25, 1080p30, 1080i30, 1080i29.97, 1080i25, 720p60,
720p59.94, 720p50, 720p30, 720p29.97, 720p25, 576p50, 576i25, 480p60, 480i30, and
480i29.97
Supported Multi-Stream Encode Resolutions (Optional Upgrade)4.2
The Z3-HE4K-01 is also available with a software upgrade that supports simultaneous encode of a single
4K source into two different resolutions and bitrates. Supported simultaneous stream encode
resolutions:
HDMI: 2160p30 and 720p30
2160p29.97 and 720p29.97
2160p25 and 720p25
Supported Decode Resolutions4.3
HDMI: 2160p30, 2160p29.97, 2160p25, 1080p30, 1080i30, 1080i29.97, 1080i25, 720p60,
720p59.94, 720p50, 576p50 and 480p60
1
Software upgrade available. Contact Z3 for more information.
2
Only SATA2 drives are supported.

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
9
5.0 OPERATING CONTROLS
1: Power Switch
2: Status LED’s
3: RS-232 Serial Port
3
4: HDMI Input
4
5: HDMI Output
6: Gigabit Ethernet
3
For advanced troubleshooting purposes only. Not needed by typical
users. Please contact Z3 to activate serial functionality.
4
Supports Non-HDCP content only. For example, a Blu-
Ray player cannot be used as a video source.
7: 2x USB 2.0
Top: USB1
Bot: USB2
8: SATA2
9: 12V Power
FRONT PANEL
REAR PANEL
Figure 2 Front and Rear Panels of the Z3-HE4K-01

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
10
6.0 GETTING STARTED AND RUNNING THE ENCODER
This section gives step-by-step instructions on using the Z3-HE4K-01 to stream 2160p video to VLC media
player running on your PC. In addition to the Z3-HE4K-01, a 4K video source with HDMI output and a PC are
required.
*Note: Actual version numbers for your ZEUS product may differ from those pictured in this document.
Prepare the 4K Source6.1
(1) Set the video source to output 3840x2160 at 30fps and connect an HDMI1.4 cable to it.
-29.97, 25, 24 and 23.98fps also supported.
-If you are using a VISCA or other camera control protocol compatible camera, see Section 9.6 for
information on camera control via the Z3-HE4K-01.
Connect and Power Up the Z3-HE4K-016.2
(2) Connect the HDMI1.4 cable from your video source to “HDMI In”on the back of the unit.
(3) Connect an Ethernet cable from “Ethernet” on the back of the unit to a switch, router or other DHCP
server on the same network as your Windows PC.
(4) Connect the 12V power supply and turn on the power switch. It will take 45-60 seconds to boot. The
red power LED will turn on immediately. After about five seconds, both status LED’s will blink on and
off. When the right LED remains on, the unit is ready to encode.
*Note: If the left LED is blinking, the encoder has auto-started and is currently encoding.
Figure 3 Encode Connections for Z3-HE4K-01
(1) Connect Video Source
to “HDMI In”
(2) Connect
Ethernet
(3) Connect
12V power

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
11
Access the User Interface using ZFinder6.3
ZFinder is a PC Utility that allows you to find any Z3 product on your network. If you have not
downloaded this to your computer, you can find it on the USB drive provided with your system.
(5) Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder will be unable to discover
your encoder, or it will appear in red and you will be unable to proceed further.
(6) Run the “ZFinder” PC Utility on your Windows PC. The ZFinder window appears. ZFinder completes a
scan of the network and lists the location of all Z3 systems connected to the network. In this case,
the Z3-HE4K-01 appears.
(7) Click on the Z3-HE4K-01 entry in the window. This will cause the “Edit Device”, “Open Device” and
“Flash LEDs” boxes to activate.
Figure 5 ZFinder with Z3-HE4K-01 Selected
*Note:Selecting “Edit Device” allows for manual changes to network settings. Selecting “Flash
LED’s” is helpful when multiple encoders are connected to the same network.
(1) Turn on
switch
Figure 4 Power On the Z3-HE4K-01
(2) Power LED
Lights up
(3) Status LED’s blink
for a few seconds
(4) Right LED turns green

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
12
(8) Click “Open Device”. An Internet browser window is opened (for best results, Firefox or Chrome are
recommended) and the HTTP-based graphical user interface (GUI) appears at the System Setup tab.
(9) Confirm that the Operation Mode in the lower right corner is “Encoder UltraHD.” If it is not, select
“Encoder UltraHD” from the dropdown menu.
(10) Click on the CH1 tab to bring up the channel 1 encoder settings.
Streaming UDP6.4
(11) On the “CH1” tab, change “Output Format” to “UDP.”
(12) Set the “Dest Address” to:
(a) the IP address of your PC that will be running the VLC media player (in the pictured
example, 192.168.0.6)
(b) or to a multicast address (An example multicast address would be “225.1.2.3”. If you are
on a shared network, check with your Network Administrator. See Appendix B if streaming
to multiple networks is desired.)
(13) Make note of the value of “Dest Port” (This will be “5004” by default).
(14) Verify whether or not your video source supports audio. If it does not support audio, set “Audio
Figure 6 System Setup Tab

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13
Enable” to “False” for the best performance.
(15) Click “start”.
(16) After your changes, the “CH1” tab should have the following settings:
Figure 7 Channel 1 Configuration Screen - UDP
(1) Change Output Format to “UDP”
(2) Change Dest Address
to IP address of PC or
multicast address
(3) Change Dest Port to
5004
(4) Set to “True” for
audio support

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
14
(17) Run VLC on your PC (Version used by Z3: 2.1.5)
(18) Select Media –Open Network Stream. In the box, type “udp://@192.168.0.6:5004”, where
“192.168.0.6” matches the values of the computer IP address or multicast address entered for “Dest
Address” previously, and 5004 is the value of “Dest Port” noted previously.
(19) Press “Play.”
(20) You will now see your 4K video streaming to VLC.
Figure 9 Example of Z3 Video Streaming to VLC (UDP)
Figure 8 VLC Open Network Screen for UDP

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
15
Streaming RTP6.5
(21) In the user interface, click the “stop” button to stop any previous encoding in progress.
(22) In the CH1 tab, change “Output Format” to “RTP.”
(23) Change “Dest Address” to the IP address of the PC running VLC or a multicast address (the pictured
example is 192.168.0.6).
(24) Click on the “start” button to begin encoding.
Figure 10 Channel 1 Configuration Screen - RTP
(1) Change Output Format to “RTP”
(2) Change Dest Address
to IP address of PC or
multicast address

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
16
(25) Open VLC. Select “Media –Open Network Stream”
(26) In the “Open Media” box, type “rtsp://192.168.81.68/{name}.mp4”, where “192.168.81.68” is the
IP address of the Z3-HE4K-01, and {name} is “z3-1” for unicast streaming, and “z3-1m” for multicast
streaming.
In the pictured example, the IP address of the Z3-HE4K-01 is a static IP address value of
192.168.81.68 and unicast streaming is being done. The user would type in
“rtsp://192.168.81.68/z3-1.mp4”:
You can find the IP address of your encoder as the URL in your open web browser or by using ZFinder.
Figure 11 VLC Open Network Stream Screen for RTP
Figure 12 Determine the Current IP Address of Your Z3-HE4K-01
HE4K-01 Current
IP address
HE4K-01 Current
IP address

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
17
(27) Click “Play.”
(28) You will then see RTP video streaming on VLC.
*Note: VLC Version 2.1.5 or higher is needed for RTSP support.
Figure 13 Example of Z3 Video Streaming to VLC (RTP)

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
18
Tuning for Latency6.6
For latency, the key parameter to work with is Maximum Delay.
Maximum Delay defines the number of milliseconds of buffering the encoder has to work with. The
higher this value, the more buffers it has to work with and the more time it has to “smooth things out”
for challenging content. However, a higher value also causes latency to increase accordingly. To
minimize latency, this value should be set to the lowest possible value. The lowest value Z3
recommends is 100.
Figure 14 shows the suggested values for Maximum Delay for three common use cases:
Maximum Delay
Case 1: Highest Quality, Highest Latency
3000
Case 2: Good Quality, Standard Latency
2000
Case 3: Normal Quality, Lowest Latency
100
Figure 14 Tuning for Various Use Cases
RTP offers lower latency than UDP, so for the lowest latency you should use RTP.
If you are streaming to VLC, you can reduce latency on the decode side by adjusting the network caching
value. By default, this is set to 1000ms. You can lower this to as low as 200ms. To do this, go to the
following:
VLC →Tools →Preferences →Show Settings (ALL) →Input / Codecs →Network caching (ms)

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
19
7.0 STREAMING RTMP
This section shows how to use the Z3-HE4K-01 to stream over RTMP to a server. Z3 has used the Wowza
Streaming EngineTM as an example server for RTMP streaming.
*Note: VLC does not support RTMP. The test player within Wowza Streaming EngineTM is recommended.
Connect the Encoder7.1
(1) Follow steps (1) –(10) in Section 6.0 to connect the Z3-HE4K-01 for encode and bring up the encoder
user interface.
Configure for RTMP Streaming7.2
(2) Click on the “CH1” tab.
(3) Set “Output Format”to “RTMP” using the dropdown menu.
(4) For “Dest Address”, type “192.168.0.2:1935/live/4k”, where:
a. “192.168.0.2” is the IP address of the PC with the Wowza server
b. “1935” is the PC port
c. “live” matches the application selected within Wowza
d. “4k” represents the name of your stream and will also need to match the information
provided to Wowza in Section 7.5.
(5) After you’re finished, your settings should look like the following:
Figure 15 Channel 1 Configuration Screen - RTMP

DOC-USR-0056-09
___________________________________________________________________________________________
Z3 Technology, LLC ♦100 N 8th ST, STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
20
Set Up the Wowza Server7.3
(6) Install the Wowza server on a PC on your network (for details on configuring Wowza, please see
Appendix A).
Start the Encode7.4
(7) Click “start” on the CH1 tab.
View the Content on Wowza7.5
(8) Go to a PC that is on the same network as the Wowza server and open a web browser (in this
example, FireFox is used). Type in the URL of the Wowza server with the port 8088 (in this example,
“192.168.0.2:8088”). This will bring up the Wowza home page. Log in with your valid user name and
password.
(9) At the top you will see four options: Home, Server, Applications, and Help. Click on “Applications”
and select “live”. Then click on “Test Players” in the top right hand corner.
Figure 16 Getting to the Wowza Test Player
(1) Use IP address of Wowza server + “:8088”
(2) Select “Applications”
(3) Select “live”
(4) Select “Test Players”
